258SERVICING AND MAINTENANCE
NOTE:TPMS sensor must be replaced after driving the
vehicle on a flat tire condition.
It is not recommended driving a vehicle loaded at
full capacity or to tow a trailer while a tire is in the
Run Flat mode.
See the Tire Pressure Monitoring System section
for more information Úpage 168.
Tire Spinning
When stuck in mud, sand, snow, or ice conditions,
do not spin your vehicle's wheels above 30 mph
(48 km/h) or for longer than 30 seconds
continuously without stopping.
Refer to “Freeing A Stuck Vehicle” for further
information Úpage 218.
Tread Wear Indicators
Tread wear indicators are in the original equipment
tires to help you in determining when your tires
should be replaced.

Tire Tread

These indicators are molded into the bottom of the
tread grooves. They will appear as bands when the
tread depth becomes 1/16 of an inch (1.6 mm).
When the tread is worn to the tread wear
indicators, the tire should be replaced.
Life Of Tire
The service life of a tire is dependent upon varying
factors including, but not limited to:
Driving style.
Tire pressure - Improper cold tire inflation pres -
sures can cause uneven wear patterns to
develop across the tire tread. These abnormal
wear patterns will reduce tread life, resulting in
the need for earlier tire replacement.
Distance driven.
Performance tires, tires with a speed rating of V
or higher, and Summer tires typically have a
reduced tread life. Rotation of these tires per
the vehicle scheduled maintenance is highly
recommended.
NOTE:Wheel Valve Stem must be replaced as well when
installing new tires due to wear and tear in existing
tires.
WARNING!
Fast spinning tires can be dangerous. Forces
generated by excessive wheel speeds may
cause tire damage or failure. A tire could
explode and injure someone. Do not spin your
vehicle's wheels faster than 30 mph (48 km/h)
for more than 30 seconds continuously when
you are stuck, and do not let anyone near a
spinning wheel, no matter what the speed.
1 — Tread Wear IndicatorsWARNING!

Tires and the spare tire should be replaced after six
years, regardless of the remaining tread. Failure to
follow this warning can result in sudden tire failure.
You could lose control and have a collision resulting
in serious injury or death.

23_VF_OM_EN_USC_t.book Page 258

284 Brake/Transmission Interlock
......................... 81Bulb Replacement......................................... 244Bulbs, Light.......................................... 191, 244
C
Camera, Rear...................................... 119, 120Capacities, Fluid............................................ 273Caps, Filler Fuel........................................................... 122Oil (Engine)................................................ 225Radiator (Coolant Pressure)...................... 234Car Washes................................................... 266Carbon Monoxide Warning............................ 192Cargo Area Cover............................................. 51Cargo Compartment........................................ 51Cargo Light...................................................... 36Cellular Phone............................................... 151Certification Label......................................... 123Change Engine Oil — If Equipped
S
.............. 57Change Oil Indicator........................................ 57Changing A Flat Tire....................................... 196Chart, Tire Sizing............................................ 250Check Engine Light (Malfunction
Indicator Light)................................................ 74Checking Your Vehicle For Safety.................. 189Checks, Safety............................................... 189Child Restraint............................................... 185
Child RestraintsBooster Seats........................................... 187Child Seat Installation.............................. 189Infant And Child Restraints....................... 186Older Children And Child Restraints......... 187Clean Air Gasoline......................................... 271CleaningWheels..................................................... 262Climate Control................................................ 40Manual........................................................ 40Rear............................................................. 43Cold Weather Operation.................................. 76Compact Spare Tire...................................... 260Contract, Service.......................................... 277Cooling Pressure Cap (Radiator Cap)............ 234Cooling System............................................. 233Adding Coolant (Antifreeze)...................... 233Coolant Level................................... 233, 234Cooling Capacity....................................... 273Disposal Of Used Coolant......................... 234Drain, Flush, And Refill............................. 233Inspection................................................. 234Points To Remember................................ 234Pressure Cap............................................ 234Radiator Cap............................................ 234Selection Of Coolant (Antifreeze)..... 233, 273Corrosion Protection..................................... 265Cruise Control (Speed Control)................. 87, 88
Cruise Light......................................................72Customer Assistance.................................... 275Customer Programmable Features............... 134Cybersecurity................................................ 133
D
Dealer Service............................................... 227Defroster, Windshield................................... 190Diagnostic System, Onboard............................74Dimmer Control Switch....................................37Dimmer SwitchHeadlight.....................................................34DipsticksAutomatic Transmission........................... 236Oil (Engine)............................................... 226Disable Vehicle Towing................................. 219DisposalAntifreeze (Engine Coolant)...................... 234Door Ajar..........................................................66Door Ajar Light.................................................66Door Locks.......................................................21Automatic....................................................23Doors...............................................................21Driver’s Seat Back Tilt......................................23DrivingThrough Flowing, Rising, Or Shallow Standing Water
.................................................... 131Drowsy Driver Detection................................ 157

23_VF_OM_EN_USC_t.book Page 284

287
Lights
............................................................. 191Air Bag.......................................65, 178, 190Brake Assist Warning................................ 155Brake Warning............................................ 66Bulb Replacement..................................... 244Collision Warning................................. 70, 72Cruise.......................................................... 72Daytime Running......................................... 33Dimmer Switch, Headlight.................... 33, 34Electronic Stability Program(ESP) Indicator.................................. 67, 69, 155Exterior............................................... 33, 191Fuel Cutoff Failure....................................... 72Hazard Warning Flasher............................ 193Headlights................................................... 33High Beam.................................................. 34Illuminated Entry......................................... 38Instrument Cluster...................................... 67Interior........................................................ 36Malfunction Indicator (Check Engine)......... 69Park...................................................... 34, 73Passing........................................................ 34Rear Cargo Door Open Warning Light.......... 68Seat Belt Reminder..................................... 68Security Alarm............................................. 68Service...................................................... 244Tire Pressure Monitoring (TPMS)............... 168Tow Haul..................................................... 72
TowingHookBreakdown............................... 71Traction Control........................................ 155Turn Signals.......................................33, 191Warning Instrument Cluster Descriptions.... 67Loading Vehicle................................... 123, 124Capacities................................................. 124Tires......................................................... 253LocksAutomatic Door..................................... 21, 23Low Tire Pressure System............................. 168Lubrication, Body.......................................... 231Lug Nuts/Bolts.............................................. 269
M
Maintenance Free Battery............................ 227Maintenance Schedule................................. 221Malfunction Indicator Light (Check Engine)..... 69ManualService..................................................... 279Methanol...................................................... 271Mirrors............................................................. 30Electric Remote........................................... 32Exterior Folding............................................ 31Heated......................................................... 33Outside........................................................ 31Rearview.............................................30, 193Modifications/AlterationsVehicle........................................................... 8Monitor, Tire Pressure System...................... 168Mopar Parts.................................................. 278
MP3 Control.....................................................45Multi-Function Control Lever............................33
N
New Vehicle Break-In Period............................78
O
Occupant Restraints..................................... 170Octane Rating, Gasoline (Fuel)...................... 270Oil Change Indicator.........................................57Reset...........................................................57Oil Filter, Change........................................... 228Oil Filter, Selection........................................ 228Oil Pressure Light.............................................68Oil, Engine............................................ 228, 273Capacity.................................................... 273Checking................................................... 226Dipstick..................................................... 226Disposal.................................................... 228Filter......................................................... 228Filter Disposal........................................... 228Identification Logo.................................... 228Materials Added To................................... 228Pressure Warning Light................................68Recommendation............................ 228, 273Synthetic................................................... 228Viscosity.................................................... 273Onboard Diagnostic System.............................74Operating Precautions.....................................74
11

23_VF_OM_EN_USC_t.book Page 287

289
Sentry Key (Immobilizer)
.................................. 16Service Assistance......................................... 275Service Contract............................................ 277Service Manuals............................................ 279Settings Personal.................................................... 134Shift Lever Override....................................... 217Shoulder Belts............................................... 172Side Distance Warning.................................. 110Signals, Turn.................................................. 191Snow Chains (Tire Chains)............................. 263Snow Tires..................................................... 260Spare Tires.......................................... 260, 261Speed Limiter, Active....................................... 86Starting............................................................ 76Automatic Transmission.............................. 76Button......................................................... 16Cold Weather.............................................. 76Engine Fails To Start................................... 77Steering........................................................... 23Column Lock............................................... 23Power.......................................................... 85Storage, Vehicle...................................... 43, 265Storing Your Vehicle...................................... 265Supplemental Restraint System – Air Bag..... 179Surround View Camera.................................. 120Sway Control, Trailer...................................... 157Symbol Glossary................................................ 9Synthetic Engine Oil....................................... 228
T
Telescoping Steering Column.......................... 23Tip Start........................................................... 76Tire And Loading Information Placard........... 253Tire Markings................................................ 249Tire Safety Information................................. 249Tire Service
Kit................... 203, 209, 210, 211, 212, 213
Tire Service Kit — If Equipped
S
................ 203Tires...................................191, 256, 260, 264Aging (Life Of Tires).................................. 258Air Pressure.............................................. 256Chains...................................................... 263Changing.................................................. 196Compact Spare......................................... 260General Information........................ 256, 260High Speed............................................... 257Inflation Pressure..................................... 256Jacking..................................................... 196Life Of Tires.............................................. 258Load Capacity........................................... 253Pressure Monitoring System (TPMS)..70, 168Quality Grading......................................... 264Radial....................................................... 257Replacement............................................ 259Rotation.................................................... 264Safety.............................................. 249, 256
Sizes......................................................... 250Snow Tires................................................ 260Spare Tires...................................... 260, 261Spinning................................................... 258Trailer Towing........................................... 128Tread Wear Indicators.............................. 258Wheel Nut Torque..................................... 269To Open Hood..................................................50Tongue Weight/Trailer Weight...................... 127Towing.................................................. 124, 219Disabled Vehicle....................................... 219Guide........................................................ 126Recreational............................................. 130Weight...................................................... 126Towing Behind A Motorhome........................ 130Traction......................................................... 131Traction Control............................................ 156Traffic Sign Assist.............................................98Trailer Sway Control (TSC)............................. 157Trailer Towing................................................ 124Hitches..................................................... 126Minimum Requirements........................... 127Tips........................................................... 130Trailer And Tongue Weight........................ 127Wiring....................................................... 129Trailer Towing Guide..................................... 126Trailer Weight................................................ 12611

23_VF_OM_EN_USC_t.book Page 289
