2023 MAZDA MODEL CX-50 display

▼Low Fuel Warning Indication/
Warning Light
The warning indication/warning light
displays/turns on wh
en the ignition is
switched ON and the remaining fuel is
about 9 L (2.3 US gal, 1.9 Imp gal) or
the remaining distance to empty is 50
km (31 miles) or shorter. The warning
light flashes when the vehicle
continues to be driven with the
warning indication/warning light
displayed/turned on and the
remaining fuel in the tank is near
empty.
NOTE
The light illumination timing may vary
because fuel inside the fuel tank moves
around according to the driving
conditions and the vehicle posture.
Action to be taken
Add fuel. If the light is flashing, refuel
as soon as possible.
▼ Check Fuel Cap Warning
Indication/Warning Light
If the check fuel cap warning light
illuminates while driving, the fuel-filler
cap may not be installed properly.
Action to be taken
Stop the engine and reinstall the
fuel-filler cap.
Refer to Refueling on page 3-30.
▼
Engine Oil Level Warning
Indication/Warning Light
This warning light indicates that the
engine oil level is around the MIN
mark (page 6-18).
CAUTION
Do not continue to drive the vehicle
with the engine oil level warning
indication/warning light displayed/
turned on. If the vehicle continues to
be driven with an
insufficient amount
of engine oil, it could cause damage to
the engine.
Action to be taken
Add 1 L (0.26 US gal, 0.22 Imp gal) of
engine oil (page 6-16).
▼ Seat Belt Warning Indication/
Warning Light (Front seat)
The seat belt warning light turns on if
the driver or front passenger's seat is
occupied and the seat belt is not
fastened with the ignition switched
ON.
If the driver or front passenger's seat
belt is unfastened (only when the front
passenger's seat is occupied) and if the
vehicle is driven at about 20 km/h (12
mph) or faster, or about 10 km/h (6
mph) or faster for a continuous 30
seconds, with the seat belt unfastened,
the warning light flashes for a certain
period. After a short time, the warning
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-28
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

▼Tire Pressure Monitoring System
(TPMS) Warning Indication/
Warning Light (Turns on)
If a tire pressure decreases below the
specified air pressure, the TPMS
warning light turns on.
At the same time, a message and the
tire pressure of each tire are displayed
on the multi-information display
alternately. In addition, the tire (s) with
low air pressure is displayed in yellow.
WARNING
Do not drive the vehicle at high
speeds if the TPMS warning light turns
on or flashes:
Driving the vehicle at high speeds
while the TPMS warning light is turned
on or
flashing is dangerous because
the brake performance and the
steering wheel operability will be
reduced. If the vehicle is driven at high
speeds or the brakes are suddenly
applied, it could lead to an accident.
Gradually apply the brakes to lower the
vehicle's speed.
Do not ignore the TPMS warning light
when it is turned on or flashing:
Continuing to driv e the vehicle while
ignoring the illumi nation/flashing of
the TPMS warning light is dangerous
because a tire may burst which could
lead to an accident. Take appropriate
measures as soon as possible.
NOTE
While the TPMS is learning the tire
positions, such as immediately after a
tire position has been changed, the tire
pressure at the tire position prior to it
being changed is displayed until the
system completes the learning. For this
reason, the tire pressures displayed for
the tire positions may be different from
the actual tire pressures at the tire
positions.
Action to be taken
Adjust the tire pressures to the
appropriate pressures.
Refer to Tire Inflation Pressure on page
6-31.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-30
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

CAUTION
Adjust the tire pressures while the
tires are cool. Because the air
pressure in the tires fluctuates
depending on the temperature,
before adjusting the tire pressures,
let the vehicle sit for an hour or drive
it only within a 1.6 km (1 mile)
distance. If the tire pressures are
adjusted while the tires are warm,
the tire pressures may decrease
below the
specified air pressure after
cooling down which could turn on
the warning light. In addition,
because the air pressure in the tires
decreases when the ambient
temperature is low, if the ambient
temperature increases, an
illuminated TPMS warning light may
turn off. Under any circumstances,
always adjust the tire pressures while
the tires are cool.
 After adjusting the tire pressures, the
TPMS warning light turns off. If the
TPMS warning light does not turn
off,
drive the vehicle at a speed of about
25 km (16 mph) or faster for 3
minutes or longer and make sure the
warning light turns off.
If the TPMS warning light remains on
even after adjusting the tire pressures,
one of the tires may have a puncture.
▼ KEY Indicator Light (Green)
(Flashing)
“Low Key Fob Battery. Replace
Battery” is displayed/When the light
is flashing
When the key battery is low, the
indication is displayed when the
ignition is switched OFF.
Action to be taken
Replace the key battery.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-31
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Message Indicated on Multi-information Display
▼Message Indicated on Multi-information Display
If there is a notification from the vehicle, a message is displayed on the
multi-information display. Check the information and take the necessary action.

1. Multi-information display

If the warning light turns on/flashes simultaneously or a symbol is indicated on the
display, check the information rega
rding the warning light or symbol.
Refer to If a Warning Light Turn s On or Flashes on page 7-20.
Display*1*2*3Content Action to be taken
Depress Brake Pedal.
Brake Hold Disabled This message is indicated when there
is a problem with the brake related
system while the vehicle is being held
in a stop position by the AUTOHOLD
function. Depress the brake pedal. Cancel the
AUTOHOLD function and have your
vehicle inspected at an Authorized
Mazda Dealer.
Steep Slope. Continue
Pressing Brake Pedal to
Hold Stopped Position This message indicates the possibility
of the vehicle not being held in the
stopped position by the AUTOHOLD
function, such as on steep slopes.
Depress and hold your foot on the
brake pedal.
Depress Brake Pedal and
Operate Switch to Re-
lease Elec. Parking Brake This message is indicated when the
Electric Parking Brake (EPB) switch is
operated without depressing the
brake pedal.
Operate the Electric Parking Brake
(EPB) switch while depressing the
brake pedal.
Depress Brake Pedal and
Operate Switch to Re-
lease This message is indicated when the
cancel operation is done without de-
pressing the brake pedal while the
vehicle is being held in the stopped
position by the AUTOHOLD function. Cancel the AUTOHOLD function stop
hold control while depressing the
brake pedal.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-32
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Display*1*2*3ContentAction to be taken
Mazda Radar Cruise
Control Canceled. Drive
Safely This message is indicated when the
Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function), and the Traffic Jam
Assist (TJA) have been canceled other
than by the driver.
Have your vehicle inspected by an
Authorized Mazda Dealer.
Distance & Speed Alert
Operation Canceled
Drive Safely This message is indicated when the
Distance & Speed Alert (DSA) have
been canceled other than by the driv-
er.
Have your vehicle inspected by an
Authorized Mazda Dealer.
Cruise Control Opera-
tion Canceled. Drive
Safely This message is indicated when the
Cruise Control have been canceled
other than by the driver.
Have your vehicle inspected by an
Authorized Mazda Dealer.
Emergency Braking Acti-
vated. Depress Brake
Pedal to Hold Stop This message is indicated after the
Smart Brake Support (SBS) brakes op-
erate and when the Smart Brake Sup-
port (SBS) is canceled.
Depress the brake pedal.
Touch Key Fob to Push
Button Start Switch This message is indicated when the
key battery is weak (battery dead or
damaged key). Touch the key against push button
start to start the engine.
Refer to Engine Start Function When
Key Battery is Dead on page 4-7.
Depress Brake Pedal to
Start Vehicle This message is indicated when the
push button start is pressed without
depressing the brake pedal. When starting the engine, press the
push button start with the brake ped-
al depressed.
Check Gear Selector
Lever Position This message is indicated when the
selector lever is shifted to the P or R
position while driving.
Check the selector lever position.
Close Door and Fasten
Seat Belt This message is indicated when AU-
TOHOLD is about to operate and a
door is opened or a seat belt is unfas-
tened. When the AUTOHOLD is turned on,
close the doors and fasten seat belts.
Wiper Blades Must Be
on Windshield Before
Operating This message is indicated when the
ignition is switched ON with the wip-
er arms at the service positions.
Return the wiper arms to the initial
positions.
Windshield Wiper Range
of Motion Reduced. Re-
move Obstruction(s) This message is indicated when there
is snow or dirt accumulation on the
windshield and the wiper operation
range is narrowed.
Remove foreign matter from the
windshield.
Ve h i c l e N o t S w i t c h e d
Off This message is indicated when the
driver’s door is opened without
switching the ignition OFF.
Switch the ignition OFF before leaving
the vehicle.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-33
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Display*1*2*3ContentAction to be taken
Gear Selector Lever Not
in Park Displays when the push button start
is pressed while the selector lever is
in a position other than P, and the ig-
nition is switched to ACC. Shift the selector lever to the P posi-
tion and then switch the ignition OFF.
Excessive Transmission
Te m p e ra t u r e . D r i v e
Slowly This message is indicated when the
internal temperature of the automatic
transmission is high.
Drive slowly to reduce load on the
automatic transmission.
Excessive Transmission
Temp. Stop Vehicle in a
Safe Location This message is indicated when the
automatic transmission
fluid temper-
ature is abnormally high. Park the vehicle in a safe place imme-
diately and contact an Authorized
Mazda Dealer.
Battery Saving Mode.
Drive Vehicle to Charge
Battery This message is indicated when the
power consumption exceeds a cer-
tain amount such as by repeatedly
opening/closing the doors or the lift-
gate when the ignition is switched
OFF.
Some of the functions are restricted
to reduce power consumption. There is no need to contact an Au-
thorized Mazda Dealer. Drive the ve-
hicle for 5 minutes or longer to
charge the battery. The warning mes-
sage will clear just after starting the
engine.
Trailer Connected. Safe-
ty and Driver Support
Systems Partially Disa-
bled This message is indicated when the
trailer hitch is connected.
Some systems of i-ACTIVSENSE are
disabled. Drive the vehicle while pay-
ing attention to safety.
Trailer Connected. Rear
Safety and Driver Sup-
port Systems Disabled This message is indicated when the
trailer hitch is connected while some
systems of i-ACTIVSENSE are turned
off. Some systems of i-ACTIVSENSE are
disabled. Drive the vehicle while pay-
ing attention to safety.
Mi-Drive Unavailable
Due to System Malfunc-
tion This message is indicated when the
Mi-Drive switch is operated while
there is a problem with the Mazda in-
telligent Drive Select (Mi-Drive) relat-
ed system.
Have your vehicle inspected by an
Authorized Mazda Dealer.
SPORT Mode Unavaila-
ble Due to Speed/
Cruise Control Use This message is indicated when
SPORT mode is selected while Mazda
Radar Cruise Control with Stop & Go
function (MRCC with Stop & Go
function), and Traffic Jam Assist (TJA)
are operating. When Mazda Radar Cruise Control
with Stop & Go function (MRCC with
Stop & Go function), and Traffic Jam
Assist (TJA) are operating, the vehicle
cannot be driven in SPORT mode.
Mi-Drive Canceled Due
to System Malfunction This message is indicated when there
is a problem with the related system
during Mi-Drive operation. Have your vehicle inspected by an
Authorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-34
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Display*1*2*3ContentAction to be taken
SPORT Mode Canceled
Due to Speed/Cruise
Control Use This message is indicated when Maz-
da Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function), and Traffic Jam Assist (TJA)
are turned on while the vehicle is be-
ing driven in SPORT mode. When Mazda Radar Cruise Control
with Stop & Go function (MRCC with
Stop & Go function), and Traffic Jam
Assist (TJA) are operating, the vehicle
cannot be driven in SPORT mode.
Mi-Drive Selection Tem-
porarily Unavailable This message is indicated when the
Mi-Drive switch operation is not ac-
cepted during ABS operation. Operate the Mi-Drive switch during
steady driving.
Mi-Drive Canceled This message is indicated when
Mi-Drive is stopped by an operation
other than by the driver. If this message is indicated even
though the Mi-Drive switch is operat-
ed again, have your vehicle inspected
by an Authorized Mazda Dealer.
TOWING Mode Can
Now Be Selected. This message is indicated when the
Mazda genuine trailer hitch is con-
nected.
Select TOWING mode if necessary.
*1 A pop-up is displayed when a warning occurs.*2 One screen displays four rows. If the entire message cannot be displayed on the screen, it switches to
another screen.
*3 The displayed content may differ from the actual vehicle.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-35
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

▼Electric Parking Brake (EPB)
War n in g Be ep
The warning buzzer is activated under
the following conditions:
The vehicle is driven with the parking
brake applied.
The Electric Parking Brake (EPB)
switch is pulled while the vehicle is
driven.
You attempt to start driving the
vehicle while the conditions for
releasing the Electric Parking Brake
(EPB) automatically have not been
met.
▼AUTOHOLD Warning Beep
Warning light flashes/message is
displayed and beep sound is activated
simultaneously for about 5 seconds
when using AUTOHOLD function or
when AUTOHOLD switch is operated.
Because a problem with AUTOHOLD
function has occurred, AUTOHOLD
function does not operate even if
AUTOHOLD switch is operated.

If the warning light flashes/message is
displayed and the beep sound is
activated simultaneously, have your
vehicle inspected at an Authorized
Mazda Dealer.
▼
Vehicle Problem Warning Beep
If any of the following problems occur,
a warning beep is activated. Check the
information regarding the warning
indication in the instrument cluster or
on the center display.
Automatic transmission problemIncrease in automatic transmission
internal temperature
Brake
fluid amount decreaseEngine oil level sensor problemElectric Parking Brake (EPB) problemEngine hydraulic pressure decreaseEngine coolant temperature increaseEngine system problem
▼Blind Spot Monitoring (BSM)
System Warning Beep*
The Blind Spot Monitoring (BSM)
warning beep operates when the turn
signal lever is operated to the side
where the Blind Spot Monitoring
(BSM) warning light is illuminated.
▼Rear Cross
Tra ffi c Alert (RCTA)
Warning Beep*
The Rear Cross Traffic Alert (RCTA)
warning beep is activated if there is a
possibility of collision with a vehicle
approaching from the rear on the left
and right sides of the vehicle.
▼ Lane/Road Departure Warning
Beep*
The warning beep is activated when
the system determines that the vehicle
may depart from the lane or the road.
Check whether the vehicle has not
deviated from the driving lane/road.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-39
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18
