Interior Equipment (View D)
ƒSeat belts..................................................... .......................................................... page 2-35
„ SRS air bag............................................................................................................page 2- 69
… Rear door sunshade............................................................................................... page 5-77
† Bottle holder.................................................. ........................................................ page 5-71
‡ Sunvisor....................................................... ..........................................................page 5-57
ˆ Vanity mirror......................................................................................................... page 5-5 7
‰ Overhead lights..................................................................................................... page 5-58
Š Moonroof switch................................................................................................... page 3-40
‹ Rearview mirror................................................ .................................................... page 3-34
ΠAccessory socket............................................... .................................................... page 5-62
Cup holders........................................................................................................... page 5-6 9
Ž Front seat................................................................................................................. pag e 2-5
Center console....................................................................................................... page 5-72
External input terminal........................................ ........................................ page 5-14, 5-34
‘ Seat warmer switches........................................... ................................................. page 2-31
’ Second-row seat................................................ .................................................... page 2-15
“ USB power outlet.................................................................................................. page 5-63
” Third-row seat....................................................................................................... page 2-26
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

(Switch)*
Press the switch to fold the seatback forward and release the seat slide lock. Then slide the
seat forward.
Refer to Third-row Seat Access on page 2-16.
Make sure the seat is locked in place by attempting to push it forward and backward.
▼Armrest
The armrest in the center of the
second-row seatback can be used (no
occupant in the center seat) or placed
upright.

WA R N I N G
Never put your hands and fingers around
the moving parts of the seat and armrest:
Putting your hands and fingers around the
moving parts of the seat and armrest is
dangerous as they could get injured.
CAUTION

When storing the armrest, make sure
that any cables connected to the USB
power outlets in the armrest box are
stored away in the armrest box.
If the cables are not stored away in the
armrest box, the cables and connection
devices may become damaged when
storing the armrest.
 Be careful not to apply excessive force to
the armrest such as by sitting on it.
Otherwise, it could be deformed or
damaged.
▼ Third-row Seat Access
Occupants can get into and out of the
third-row seats eas
ily by sliding the
second-row seats forward.
WA R N I N G
Make sure there is nobody in the
second-row seat area before operating a
lever or pressing a switch:
Not checking the second-row seat area for
persons before foldin g a seatback with a
lever or switch is dangerous. The
second-row seat area is difficult to see from
the rear of the vehicle. Operating a lever or
pressing a switch without checking could
cause injury to a person when a seatback
suddenly flips forward.
Essential Safety Equipment
Seats
2-16*Some models.
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

5Interior Features
Use of various features for ride comfort, including air-conditioning
system and audio system.
Climate Control System.................... 5-2 Operating Tips.............................. 5-2
Vent Operation (Front)................. 5-3
Front Air Conditione r................... 5-5
Vent Operation (Rear)...................5-9
Rear Air Conditioner. ................. 5-11
Mazda Connect [Mazda Connect
(Type A)]...........................................5-14 What is Mazda Connect ?........... 5-14
Mazda Connect Basic
Operations...................................5-17
Mazda Connect [Mazda Connect
(Type B)]........................................... 5-34 What is Mazda Connect ?........... 5-34
Mazda Connect Basic
Operations...................................5-38
Connected Service (If
applicable).................................. 5-55
Interior Equipment......................... 5-57 Sunvisors.................................... 5-57
Interior Lights............................. 5-58
Accessory Sockets...................... 5-62
USB Power Outlet
*.................... 5-63
Wireless Charger (Qi)
*............... 5-66
Cup Holder................................. 5-69
Bottle Holder.............................. 5-71
Storage Compartments............... 5-71
Sunshade (Rear Door Window)
*.......
.................................................... 5-77
*Some models.5-1
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

What is Mazda Connect ?
▼What is Mazda Connect ?
For vehicles with the following display type, refer to the foll
owing page because your
vehicle is equipped with Mazda Connect (Type B).
Refer to What is Mazda Connect ? 5-34.
This manual only indicates a part of the information for Mazda Connect. For details, check
the Web owner's manual at the Mazda site for each country and r egion.

1. Radio
2. Bluetooth
® Audio/Hands-Free Call/SMS (Short Message Service)/E-mail
3. USB Audio
4. AUX
5. USB port
*1/Auxiliary jack*1/SD card slot*2
Interior Features
Mazda Connect [Mazda Connect (Type A)]
5-14
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

6. SD card (Navigation system)*
*
1 The location of the USB slot/auxiliary jack differs depending on the specifications.
*2 The SD card slot is for the navigation system only. For vehicles with the navigation
system, the SD card (Mazda genuine) with stored map data is ins erted into the SD card
slot and used.

Icon Function
Applications
Information such as average fuel economy, maintenance, and warn ings can be verified. In
addition, SiriusXM
®*, Apple CarPlay™*, and Android™* can be selected.
Depending on the grade and specification, the screen display ma y differ.
Entertainment
Operates audio such as the radio. The audio source most recentl y used is displayed. An
audio source which cannot be used at that time is skipped and t he previous audio source is
displayed.
To change the audio source, select the
icon displayed at the bottom of the screen.
Communication
Bluetooth® related functions are available.
Navigation
Navigation screen is displayed (v ehicles with navigation system).
If the SD card for the navigation system is not inserted, the compass indicating the direc‐
tion in which the vehicle is moving is displayed.
The compass may not indicate th e correct bearing when the vehicle is stopped or traveling
at a slow speed.
Settings
Overall setting menu (Such a s display, sound, Bluetooth® and Language).
Depending on the grade and specification, the screen display ma y differ.
Interior Features
Mazda Connect [Mazda Connect (Type A)]
*Some models.5-15
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Radio stations can be called up in the order they were stored with each press of the switch
(
, ).

USB Audio/Bluetooth® Audio
Press the seek switch (
) to skip forward to the beginning of the next track.
Press the seek switch (
) within a few seconds after playback begins to track down to t he
beginning of the previous track.
Press the seek switch (
) after a few seconds have elapsed to start playback from the
beginning of the current track.
Press and hold the seek switch (
, ) to continuously switch the tracks up or down.
Pandora
®/Aha™/Stitcher™ Radio
Press the seek switch (
) to skip forward to the beginning of the next track.
Press and hold the seek switch (
) to evaluate the playback of the current song as “Like”.
Press and hold the seek switch (
) to evaluate the playb ack of the current song as
“Dislike”.
Pick up/hang up the Phone, or Ac tivate Voice Control Using the Switch
Talk button
Activates the voice recognition. In addition, it skips the voice guidance.
Pick-up button
Answers incoming calls. In additi on, after selecting a contact or dialing a number, it places
the call when the button is pressed.
Hang-up button
Ends the call or refuses an incoming call. In addition, it ends the voice recognition
operation.
Interior Features
Mazda Connect [Mazda Connect (Type A)]
5-22
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Returning to previous operation
To return to the previous operation, say, “Go Back” while in voice recognition mode.
Cancel
To put the Bluetooth
® Hands-Free system in standby mode, say, “Cancel” while in voic e
recognition mode.
To prevent a deterioration in the voice recognition rate and vo ice quality, the following
points should be observed:
The voice recognition cannot be performed while voice guidance or the beep sound is
operating. Wait until the voice g uidance or the beep sound is finished before saying a
command.
Phone related commands are available only when a phone is conne cted via Bluetooth®.
Make sure a phone is connected via Bluetooth
® before you operate phone related voice
commands.
Music play commands, such as Play Artist and Play Album can be used only in USB
audio mode.
Do not speak too slowly or loudly (no loud voice).
Speak clearly, without pausing between words or numbers.
Dialects or different wording ot her than hands-free prompts can not be recognized by
voice recognition. Speak in the wording specified by the voice commands.
It is not necessary to face the microphone or be close to it. Speak the voice commands
while maintaining a safe driving position.
Close the windows and/or the mo onroof to reduce loud noises from outside the vehicle, or
turn down the airflow of the cli mate control system while Bluet ooth
® Hands-Free is being
used.
Make sure the vents are not directing air up towards the microp hone.

Interior Features
Mazda Connect [Mazda Connect (Type A)]
5-24
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Vo i c e C o m m a n d L i s t
Voice command
When the talk button is pressed and the following command is spoken, the audio or
navigation can be operated. The commands in the () can be omitt ed. The specified name and
number are put into the {}.
Standard command
Voice command Function
Help Usable commands can be verified.
Tutorial Basic voice commands and methods of use can be verified .
(Navigate/Take me/Drive) Home Set the destination to Home.
Communication (phone) related command
Voice command Function
Call {name in phonebook} (mobile/
home/work/other)
Example: “Call John Mobile” Calls to the contact in the downloaded phonebook.
Redial Calls to the last contact you called.
Callback Calls to the last contact who called you.
Entertainment (audio) related command
Voice command FunctionCorresponding audio
source
(Go to/Play) Bluetooth (Audio) Switches the audio source to Bluetooth
® audio.
Can also switch to each audio source by similarly us‐
ing commands such as FM, AM, or USB. All
Play Artist {Artist name} Plays the selected artist. USB
Navigation related command*
For the navigation screen voice c ommands, refer to the separate navigation system manual.
NOTE
Some commands cannot be used depending on the vehicle specifications.
Some commands cannot be used depending on the device connection conditions and the
use conditions.
The commands indicated in this manual are some examples of usable voice commands.
Some commands cannot be used depending on the vehicle specifications.
Interior Features
Mazda Connect [Mazda Connect (Type A)]
*Some models.5-25
