2023 MAZDA CX3 high beam

Interior Equipment (View A)
▼Interior Equipment (View
A-type A)
ƒ
High Beam Control System (HBC) switch.......................................... page 4-101
„ Lighting control................................................................................. page 4-53
… Turn and lane-change signals............................................................. page 4-58
† Audio remote control switches........................................................... page 5-23
‡ INFO switch...................................................................................... page 4-20
ˆ Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) switches........................................................................... page 4-132
‰ TJA switches....................................................................................page 4-144
Š Cruise control switches................................................................... page 4-208
‹ Wiper and washer lever..................................................................... page 4-59
Pictorial Index
Interior Overview
1-2The equipment and installation position varies by vehicle
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

High Beam Control System
(HBC)
*.............................. 4-100
Lane Departure Warning System
(LDWS)
*............................ 4-102
Blind Spot Monitoring (BSM)
*......
........................................ 4-105 Traffic Sign Recognition System
(TSR)
*................................4-110
Distance & Speed Alert (DSA)
*.....
........................................ 4-116
Driver Attention Alert (DAA)
*.......
........................................ 4-117
Driver Monitoring (DM)
*.... 4-119
Front Cross Traffic Alert
(FCTA)
*............................. 4-121
Rear Cross Traffic Alert (RCTA)
*....
........................................ 4-124
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
*......... 4-128
Tra ffi c Jam Assist (TJA)
*....... 4-138
Lane-keep Assist System (LAS)
*.....
........................................ 4-152
Smart Brake Support (SBS)
*..........
........................................ 4-156
360° View Monitor
*........... 4-164
Forward Sensing Camera
(FSC)
*............................... 4-197
Front Radar Sensor
*........... 4-201
Front Side Radar Sensor
*.... 4-203
Rear Side Radar Sensor
*..... 4-204
Rear/Rear Corner Ultrasonic
Sensor
*..............................4-206
Front Camera/Side Cameras/
Rear Camera
*.................... 4-206
Driver Monitoring Camera
*..........
........................................ 4-207
Cruise Control......................4-208 Cruise Control
*.................. 4-208
Tire Pressure Monitoring System
(TPMS)................................ 4-212 Tire Pressure Monitoring System
(TPMS)..............................4-212
Rear View Monitor................4-216 Rear View Monitor
*........... 4-216
Parking Sensor System........... 4-231 Parking Sensor System
*....... 4-231
4-2*Some models.
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

SignalWarning Refer to
*AWD Warning Indication/Warning Light*17-27
Air Bag/Front Seat Belt Pretensioner System Warning Indication/
Warning Light*17-28
Tire Pressure Monitoring System (TPMS) Warning Indication/Warning
Light*1
Flashing
7-28
Tu r n s o n 7-32
(Red) KEY Warning Indication/Warning Light
*17-29
(Amber)
*High Beam Control System (HBC) Warning Indication/Warning
Light*17-30
*i-ACTIVSENSE Warning Indication/Warning Light*17-30
Exterior Light Warning Indication/Warning Light*17-30
Low Fuel Warning Indication/Warning Light 7-30
Check Fuel Cap Warning Indication/Warning Light*17-31
Engine Oil Level Warning Indication/Warning Light*17-31
Seat Belt Warning Indication/Warning Light (Front seat) 7-31
(Red)Seat Belt Warning Light (Rear seat)
7-32
*Low Washer Fluid Level Warning Indication/Warning Light7-32
Door-Ajar Warning Indication
7-32
When Driving
Instrument Cluster and Display
4-30*Some models.
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

SignalIndicator Refer to
Lights-On Indicator Light 4-53
Headlight High-Beam Indicator LightHeadlight
High-Low Beam
4-56
Flashing the Headlights 4-56
Turn Signal/Hazard Warning Indicator Lights Tu r n a n d
Lane-Change
Signals4-58
Hazard Warn- ing Flasher 4-66
Electric Parking Brake (EPB) Indication/Indicator Light*1*27-26
AUTOHOLD Active Indicator Light*14-80
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) indicator Light 4-136
*Tra ffi c
Jam Assist (TJA) indicator Light 4-151
TCS/DSC Indication/Indicator Light*1
Tra c t i o n C o n -
trol System (TCS)4-85
Dynamic Sta- bility Control
(DSC)4-87
Tu r n s o n 7-28
TCS OFF Indicator Light (FWD) *14-86
Off-Road Traction Assist Indicator Light (AWD) *14-88
When Driving
Instrument Cluster and Display
4-32*Some models.
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

SignalIndicator Refer to
*Select Mode Indicator Light 4-91
(White)
*i-ACTIVSENSE Status Symbol (Warning/Risk Avoidance Support Sys-
tem) 4-97
(Green)
(Amber)
*i-ACTIVSENSE OFF Symbol (Warning/Risk Avoidance Support Sys-
tem) 4-97
(Green)
*High Beam Control System (HBC) Indicator Light
4-101
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) Standby Indication 4-132
*Traffic Jam Assist (TJA) Standby Indication
4-144
(Green)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) Set Indication 4-132
*Traffic Jam Assist (TJA) Set Indication
4-144
*Smart Brake Support (SBS) OFF Indicator Light*14-163
(White)
*Cruise Standby Indication4-208
(Green)
*Cruise Set Indication4-208
*1 The light turns on when the ignition is switched on for an operation check, and
turns off a few seconds later or when the en gine is started. If the light does not
turn on or remains turned on, have the vehicle inspected at an Authorized
Mazda Dealer.
When Driving
Instrument Cluster and Display
*Some models.4-33
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

▼Headlight High-Low Beam
The headlights switch between high
and low beams by moving the lever
forward or backward.

1. High beam
2. Low beam

When the headlight high-beams are
on, the headlight high-beam indicator
light is turned on.

▼Flashing the Headlights
When the ignition is switched ON, and
regardless of the headlight position,
the headlights switch to high beams
while the lever is being pulled.

1. OFF
2. Headlight flashing

The headlight high-beam indicator
light in the instrument cluster
illuminates simultaneously. The lever
will return to the normal position when
released.

▼ Coming Home Light
The coming home light turns on the
headlights (low beams) when the lever
is operated.
To turn on the lights
When the lever is pulled with the
ignition switched to ACC or OFF, the
low beam headlights turn on.
The headlights turn off after a certain
period of time has elapsed after all of
the doors are closed.
NOTE
The time until the headlights turn
off
after all of the doors are closed can
be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
If no operations are done for 3
minutes after the lever is pulled, the
headlights turn off.
The headlights turn off if the lever is
pulled again while the headlights are
illuminated.
When Driving
Switches and Controls
4-56
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

i-ACTIVSENSE*
▼i-ACTIVSENSE
i-ACTIVSENSE is a collective term
covering a series of advanced safety
and driver support systems which
make use of cameras and sensors. The
systems consist of active safety and
pre-crash safety systems.
These systems are designed to assist
the driver in safer driving by reducing
the load on the driver and helping to
avert collisions or reduce their severity.
However, because each system has its
limitations, always drive carefully and
do not rely solely on the systems.
▼Active Safety Technology
Active Safety Technology supports safer
driving by helping the driver to
recognize potential hazards and avert
accidents.
Driver awareness support systems
Nighttime visibility
Adaptive Front Lighting System
(AFS).................................. page 4-99
High Beam Control System
(HBC).............................. page 4-100
Left/right side and rear side detection
Lane Departure Warning System
(LDWS)............................ page 4-102
Blind Spot Monitoring (BSM)...............
........................................ page 4-105
Road sign recognition
Traffic Sign Recognition System
(TSR)................................ page 4-110
Inter-vehicle distance recognition
Distance & Speed Alert (DSA) .............
........................................ page 4-116
Front obstruction detection when
approaching a crosswalk
Front Cross Traffic Alert (FCTA) ............
........................................ page 4-121
Rear obstruction detection when
leaving a parking space
Rear Cross Traffic Alert (RCTA) .............
........................................ page 4-124
Full-surround recognition
360°View Monitor............ page 4-164
Driver fatigue detection
Driver Attention Alert (DAA) ...............
........................................ page 4-117
Driver Monitoring (DM).... page 4-119
Driver support systems
Inter-vehicle distance
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function).......................... page 4-128
Lane departure
Lane-keep Assist System (LAS) .............
........................................ page 4-152
Inter-vehicle distance and lane
keeping
Tra ffi c
Jam Assist (TJA)........ page 4-138
▼Pre-Crash Safety Technology
Pre-crash safety technology is designed
to assist the driver in averting collisions
or reducing their severity in situations
where they cannot be avoided.
Collision damage reduction
Smart Brake Support (SBS) ..................
........................................ page 4-156
When Driving
i-ACTIVSENSE
*Some models.4-95
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

▼Camera and Sensors
Forward Sensing Camera (FSC)
The Forward Sensing Camera (FSC)
detects lane indications and recognizes
headlights, taillights and city lights
during nighttime driving. In addition, it
also detects the vehicle ahead,
pedestrians, or obstructions. The
following systems use the Forward
Sensing Camera (FSC).
High Beam Control system (HBC)Lane Departure Warning System
(LDWS)
Traffic Sign Recognition System (TSR)Distance & Speed Alert (DSA)Driver Attention Alert (DAA)Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
Lane-keep Assist System (LAS)Tra ffi c Ja m A s s i s t ( TJ A )Smart Brake Support (SBS) forward
drive detection
The Forward Sensing Camera (FSC) is
installed at the top of the windshield
near the rearview mirror.
Refer to Forward Sensing Camera
(FSC) on page 4-197.
Front radar sensor
The front radar sensor detects radio
waves reflected off a vehicle ahead
sent from the radar sensor. The
following systems use the front radar
sensor.
Distance & Speed Alert (DSA)Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
Traffic Jam Assist (TJA)Smart Brake Support (SBS) forward
drive detection
The front radar sensor is mounted
behind the radiator grille.
Refer to Front Radar Sensor on page
4-201.
Front side radar sensor
The front side radar sensors detects
radio waves reflected
off a vehicle
ahead sent from the radar sensor. The
following systems use the front side
radar sensor.
Front Cross Traffic Alert (FCTA)
The front side radar sensors are
installed inside the front bumper, one
on the left side and one on the right
side.
Refer to Front Side Radar Sensor on
page 4-203.
When Driving
i-ACTIVSENSE
4-96
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56
