SERVICING AND MAINTENANCE357
F38 ––Not Populated
F39 ––Not Populated
F40 –5 Amp TanBattery Sensor #1
F41 –20 Amp YellowCADM MAP*
F42 ––Not Populated
F43 –10 Amp RedEngine Control Module (ECM)
F44 ––Not Populated
F45 –15 Amp BlueFront Axle Disconnect
F46 ––Not Populated
F47 ––Not Populated
F48 –10 Amp RedCVPAM
F49 ––Not Populated
F50 ––Not Populated
F51 –20 Amp YellowFuel Pump
F52 ––Not Populated
F53 ––Not Populated
F54 –20 Amp YellowHeadlamp LT
F55 –15 Amp BlueBPCM *
F56 ––Not Populated
F57 ––Not Populated
Cavity Cartridge Fuse Micro FuseDescription
* If Equipped
8

23_WL_OM_EN_USC_t.book Page 357

362SERVICING AND MAINTENANCE
F10 40 Amp Green –HVAC Blower Motor
F11 ––Spare
F12 –20 Amp YellowAssy Cigar Lighter
F13 –10 Amp RedAssy Mirror Inside Rearview / Digital
TV (DTV) */ Sunroof Single - Dual
Pane / Port UC1 Dual USB RR /
Interior Monitoring Camera
F14 ––Spare
F15A ––Spare
F15B ––Spare
F16 –10 Amp RedMOD ORC
F17 ––Spare
F18 ––Spare
F19 ––Spare
F20 –10 Amp RedOverhead Console Assy (OHC) W/
Sunshade / Intrusion Module /
Intrusion Sensor / Siren / Head Up
Display (HUD) / Digital TV (DTV) *
F21 30 Amp Pink –Trailer Tow Electric Brake -
Aftermarket
F22 ––Spare
F23 ––Spare
Cavity Cartridge Fuse Micro FuseDescription

* If Equipped

23_WL_OM_EN_USC_t.book Page 362

SERVICING AND MAINTENANCE363
F24 ––Spare
F25 ––Spare
F26 ––Spare
F27 ––Spare
F28 ––Spare
F29 ––Spare
F30 ––Spare
F31 ––Spare
F32 –15 Amp BlueMOD ICS Switch Bank / SW Bank
Upper / SW EPB / Aux Switch Bank
Module (ASBM)
F33 –15 Amp BlueTransfer case SW / Humidity Rain
Light Sensor (HRLS) / Suspension
SW*
F34 ––Spare
F35 –10 Amp RedIRCAM Heater
F36 ––Spare
F37 ––Spare
F38 ––Spare
F39 ––Spare
F40 ––Spare
Cavity Cartridge Fuse Micro FuseDescription

* If Equipped
8

23_WL_OM_EN_USC_t.book Page 363

372SERVICING AND MAINTENANCE
F67 –30 Amp GreenMOD Audio Amplifier #1B
F68 ––Spare
F69 –20 Amp YellowL2+ Central ADAS Decision Module
(CADM) MID*
F70 –10 Amp RedVideo Routing Module (VRM) / Port
Power - USB IP (USB Ch Only)
F71 ––Spare
F72 ––Spare
F73 ––Spare
F74 –5 Amp Tan
L2+ Intelligent Battery Sensor (IBS) - 2*

F75 ––Spare
F76 ––Spare
F77 ––Spare
F78 50 Amp Red –MOD IAir Suspension
F79 ––Spare
Cavity Cartridge Fuse Micro FuseDescription
* If Equipped

23_WL_OM_EN_USC_t.book Page 372

SERVICING AND MAINTENANCE383
Inflation pressures specified on the placard are
always “cold tire inflation pressure”. Cold tire
inflation pressure is defined as the tire pressure
after the vehicle has not been driven for at least
three hours, or driven less than 1 mile (1.6 km)
after sitting for a minimum of three hours. The cold
tire inflation pressure must not exceed the
maximum inflation pressure molded into the tire
sidewall.
Check tire pressures more often if subject to a
wide range of outdoor temperatures, as tire
pressures vary with temperature changes.
Tire pressures change by approximately 1 psi
(7 kPa) per 12°F (7°C) of air temperature change.
Keep this in mind when checking tire pressure
inside a garage, especially in the Winter.
Example: If garage temperature = 68°F (20°C)
and the outside temperature = 32°F (0°C) then
the cold tire inflation pressure should be increased
by 3 psi (21 kPa), which equals 1 psi (7 kPa) for
every 12°F (7°C) for this outside temperature
condition. Tire pressure may increase from 2 to 6 psi (13 to
40 kPa) during operation. DO NOT reduce this
normal pressure buildup or your tire pressure will
be too low.
Tire Pressures For High Speed Operation
The manufacturer advocates driving at safe
speeds and within posted speed limits. Where
speed limits or conditions are such that the vehicle
can be driven at high speeds, maintaining correct
tire inflation pressure is very important. Increased
tire pressure and reduced vehicle loading may be
required for high-speed vehicle operation. Refer to
an authorized tire dealer or original equipment
vehicle dealer for recommended safe operating
speeds, loading and cold tire inflation pressures.
Radial Ply Tires
Tire Repair
If your tire becomes damaged, it may be repaired if
it meets the following criteria:
The tire has not been driven on when flat.
The damage is only on the tread section of your
tire (sidewall damage is not repairable).
The puncture is no greater than ¼ of an inch
(6 mm).
Consult an authorized tire dealer for tire repairs
and additional information.
Damaged Run Flat tires, or Run Flat tires that have
experienced a loss of pressure should be replaced
immediately with another Run Flat tire of identical
size and service description (Load Index and
Speed Symbol). Replace the tire pressure sensor
as well as it is not designed to be reused.
CAUTION!
After inspecting or adjusting the tire pressure,
always reinstall the valve stem cap. This will
prevent moisture and dirt from entering the
valve stem, which could damage the valve stem.
WARNING!
High speed driving with your vehicle under
maximum load is dangerous. The added strain
on your tires could cause them to fail. You could
have a serious collision. Do not drive a vehicle
loaded to the maximum capacity at continuous
speeds above 75 mph (120 km/h).
WARNING!
Combining radial ply tires with other types of
tires on your vehicle will cause your vehicle to
handle poorly. The instability could cause a
collision. Always use radial ply tires in sets of
four. Never combine them with other types of
tires.
8

23_WL_OM_EN_USC_t.book Page 383

384SERVICING AND MAINTENANCE
Run Flat Tires — If Equipped
Run Flat tires allow you the capability to drive
50 miles (80 km) at 50 mph (80 km/h) after a
rapid loss of inflation pressure. This rapid loss of
inflation is referred to as the Run Flat mode. A Run
Flat mode occurs when the tire inflation pressure is
of/or below 14 psi (96 kPa). Once a Run Flat tire
reaches the Run Flat mode it has limited driving
capabilities and needs to be replaced immediately.
A Run Flat tire is not repairable. When a Run Flat
tire is changed after being driven in a Run Flat
mode 14 psi (96 kPa) condition, please replace the
TPMS sensor as it is not designed to be reused.
NOTE:TPMS sensor must be replaced after driving the
vehicle on a flat tire condition.
It is not recommended driving a vehicle loaded at
full capacity or to tow a trailer while a tire is in the
Run Flat mode.
See the Tire Pressure Monitoring System section
for more information Úpage 264.
Tire Spinning
When stuck in mud, sand, snow, or ice conditions,
do not spin your vehicle's wheels above 30 mph
(48 km/h) or for longer than 30 seconds
continuously without stopping.
For further information Ú page 325.
Tread Wear Indicators
Tread wear indicators are in the original equipment
tires to help you in determining when your tires
should be replaced.

Tire Tread
These indicators are molded into the bottom of the
tread grooves. They will appear as bands when the
tread depth becomes 1/16 of an inch (1.6 mm).
When the tread is worn to the tread wear
indicators, the tire should be replaced.
For further information Ú
page 385.
Life Of Tire
The service life of a tire is dependent upon varying
factors including, but not limited to:
Driving style
Tire pressure - Improper cold tire inflation pres -
sures can cause uneven wear patterns to
develop across the tire tread. These abnormal
wear patterns will reduce tread life, resulting in
the need for earlier tire replacement.
Distance driven
Performance tires, tires with a speed rating of V
or higher, and Summer tires typically have a
reduced tread life. Rotation of these tires per
the vehicle scheduled maintenance is highly
recommended.
WARNING!
Fast spinning tires can be dangerous. Forces
generated by excessive wheel speeds may
cause tire damage or failure. A tire could
explode and injure someone. Do not spin your
vehicle's wheels faster than 30 mph (48 km/h)
for more than 30 seconds continuously when
you are stuck, and do not let anyone near a
spinning wheel, no matter what the speed.
1 — Tread Wear Indicators
WARNING!

Tires and the spare tire should be replaced after
six years, regardless of the remaining tread.
Failure to follow this warning can result in sudden
tire failure. You could lose control and have a
collision resulting in serious injury or death.

23_WL_OM_EN_USC_t.book Page 384
