2023 INFINITI Q50 jump start

6 In case of emergency
Hazard warning flasher switch ..................................... 6-2
Roadside assistance program ....................................... 6-2
Emergency engine shut off ............................................ 6-3
Flat tire ........................................................................\
........ 6-3Tire Pressure Monitoring System (TPMS) ........... 6-3
Run-flat tires (if so equipped) .................................. 6-4 Jump starting .................................................................... 6-5
Push starting ...................................................................... 6-7
If your vehicle overheats ................................................. 6-7
Towing your vehicle ........................................................ 6-8
Towing recommended by INFINITI ..................... 6-9
Vehicle recovery (freeing a stuck vehicle) ........ 6-10

ing up the vehicle and replacing tires” (P.8-
38).To start your engine with a booster battery,
the instructions and precautions below must
be followed.
WARNING
.
If done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could also
damage your vehicle.
. Explosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
. Do not allow battery fluid to come
into contact with eyes, skin, clothing
or painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
. Keep the battery out of the reach of
children.
. The booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.
. Whenever working on or near a
battery, always wear suitable eye
protectors (for example, goggles or industrial safety spectacles) and re-
move rings, metal bands, or any other
jewelry. Do not lean over the battery
when jump starting.
. Do not attempt to jump start a
frozen battery. It could explode and
cause serious injury.
. Your vehicle has an automatic engine
cooling fan. It could come on at any
time. Keep hands and other objects
away from it.
In case of emergency6-5
JUMP STARTING

6-6In case of emergency
JVE0282X
WARNING
Always follow the instructions below.
Failure to do so could result in damage to
the charging system and cause personal
injury.1. If the booster battery is in another
vehicle
, position the two vehiclesandto bring the batteries into close
proximity to each other.
CAUTION
. Do not allow the two vehicles to
touch.
2. Apply parking brake. Move the shift lever to the P (Park) position. Switch off all
unnecessary electrical systems (light,
heater, air conditioner, etc.).
3. Remove vent caps on the battery (if so equipped). Cover the battery with a
firmly wrung out moist cloth
to reduce
explosion hazard.
4. Connect jumper cables in the sequence as illustrated (
???).
CAUTION
.Always connect positive (+) to posi-
tive (+) and negative (−) to body
ground (as illustrated) − not to the
battery.
. Make sure the jumper cables do not
touch moving parts in the engine
compartment and that clamps do
not contact any other metal.
5. Start the engine of the booster vehicle
and let it run for a few minutes.

6. Keep the engine speed of the boostervehicleat about 2,000 rpm, and start
the engine of the vehicle being jump
started
.
CAUTION
Do not keep the starter motor engaged
for more than 10 seconds. If the engine
does not start right away, push the
ignition switch to the OFF position and
wait 10 seconds before trying again.
7. After starting your engine, carefully disconnect the negative cable and then
the positive cable (
???).
8. Replace the vent caps (if so equipped). Be sure to dispose of the cloth used to
cover the vent holes as it may be
contaminated with corrosive acid.
9. Put the battery cover and the engine cover back to the original location. Do not attempt to start the engine by
pushing.
CAUTION
.
Automatic Transmission (AT) models
cannot be push-started or tow-
started. Attempting to do so may
cause transmission damage.
. Three-way catalyst equipped models
should not be started by pushing
since the three-way catalyst may be
damaged.
. Never try to start the vehicle by
towing it; when the engine starts,
the forward surge could cause the
vehicle to collide with the tow vehi-
cle.
CAUTION
.Do not continue to drive if your
vehicle overheats. Doing so could
cause engine damage or a vehicle fire.
. To avoid the danger of being scalded,
never remove the radiator cap while
the engine is still hot. When the
radiator cap is removed, pressurized
hot water will spurt out, possibly
causing serious injury.
. Do not open the hood if steam is
coming out.
If your vehicle is overheating (indicated by an
extremely high temperature gauge reading),
or if you feel a lack of engine power, detect
abnormal noise, etc., take the following
steps:
1. Move the vehicle safely off the road, apply the parking brake and move the
shift lever to the P (Park) position.
Do not stop the engine.
2. Turn off the climate control. Open all the windows, move the heater or air condi-
tioner temperature control to maximum
hot and fan control to high speed.
3. If engine overheating is caused by climb- ing a long hill on a hot day, run the engine
In case of emergency6-7
PUSH STARTING IF YOUR VEHICLE OVERHEATS

8 Do-it-yourself
Maintenance precautions ............................................... 8-2
Engine compartment check locations ......................... 8-3VR30DDTT engine ..................................................... 8-3
Engine cooling system ..................................................... 8-3 Checking engine coolant level ................................ 8-4
Changing engine coolant .......................................... 8-5
Intercooler cooling system ............................................. 8-5 Checking intercooler coolant level ......................... 8-6
Changing intercooler coolant .................................. 8-6
Engine oil ........................................................................\
..... 8-7
Checking engine oil level ........................................... 8-7
Changing engine oil and filter .................................. 8-7
Automatic Transmission Fluid (ATF) .......................... 8-9
Brake fluid ........................................................................\
8-10
Window washer fluid ................................................... 8-10
Battery ........................................................................\
....... 8-11
Checking battery fluid level .................................... 8-12
Jump starting ............................................................. 8-13
Variable voltage control system ................................. 8-13
Drive belts ........................................................................\
. 8-13
Spark plugs ....................................................................... 8-14 Replacing spark plugs .............................................. 8-14 Air cleaner ........................................................................\
8-15
Windshield wiper blades .............................................. 8-15
Cleaning ..................................................................... 8-15
Replacing ................................................................... 8-16
Brakes ........................................................................\
........ 8-16 Self-adjusting brakes ............................................. 8-16
Brake pad wear warning ....................................... 8-16
Fuses ........................................................................\
.......... 8-17 Engine compartment .............................................. 8-17
Passenger compartment ....................................... 8-18
Intelligent Key battery replacement ......................... 8-19
Lights ........................................................................\
......... 8-22 Headlights ................................................................. 8-22
Exterior and interior lights .................................... 8-23
Wheels and tires ............................................................. 8-26 Tire pressure ............................................................. 8-26
Tire labeling ............................................................. 8-30
Types of tires ........................................................... 8-32
Tire chains ................................................................ 8-34
Changing wheels and tires ................................... 8-35
Jacking up the vehicle and replacing tires ...... 8-38

JUMP STARTING
If jump starting is necessary, see “Jump
starting” (P.6-5). If the engine does not start
by jump starting, the battery may have to be
replaced. It is recommended you visit an
INFINITI retailer for this service.CAUTION
.Do not ground accessories directly to
the battery terminal. Doing so will
bypass the variable voltage control
system and the vehicle battery may
not charge completely.
. Use electrical accessories with the
engine running to avoid discharging
the vehicle battery.
The variable voltage control system mea-
sures the amount of electrical discharge
from the battery and controls voltage gen-
erated by the generator.
JVM0655X
1. Water pump
2. Alternator
3. Drive belt auto-tensioner
4. Crankshaft pulley
5. Air conditioner compressor
WARNING
Be sure the ignition switch is in the OFF
or LOCK position before servicing drive
belts. The engine could rotate unexpect-
edly.
1. Visually inspect each belt for signs of unusual wear, cuts, fraying or looseness.
Do-it-yourself8-13
VARIABLE VOLTAGE CONTROL SYSTEMDRIVE BELTS

11-4
Indicators for operation (vehicle
information display) ............................................ 2-21
INFINITI Drive Mode Selector ......................... 5-21
INFINITI InTouch Owner’s Manual .................. 4-2
INFINITI Vehicle Immobilizer System ............ 2-31Engine start ..................................................... 2-31
Inside mirror .......................................................... 3-29
Inspection/maintenance (I/M) test ............. 10-23
Instrument brightness control ......................... 2-42
Instrument panel ..................................................... 2-5
Intelligent All-Wheel Drive (AWD) ............... 5-123
Intelligent Cruise Control (ICC) ....................... 5-75
Intelligent Cruise Control (ICC) system
ON indicator ......................................................... 2-23
Intelligent Key .......................................................... 3-2
Intelligent Key system ........................................... 3-6
Battery replacement ..................................... 8-19
Key operating range ....................................... 3-8
Key operation ................................................... 3-9
Warning signals .............................................. 3-13
Intercooler cooling system .................................. 8-5
Interior light control switch .............................. 2-59
Interior light replacement .................................. 8-23
Interior lights ......................................................... 2-58
Interior trunk lid release .................................... 3-24
ISOFIX child restraint ......................................... 1-24
J
Jump starting ........................................................... 6-5
K
Keyless entry (See remote keyless
entry system) ........................................................ 3-15
Keys ........................................................................\
.... 3-2 For Intelligent Key system ............................ 3-6
L
LabelsAir bag warning labels ................................. 1-60
Air conditioner specification label ......... 10-13
Emission control information label ........ 10-12
Engine serial number ................................. 10-12
F.M.V.S.S./C.M.V.S.S.
certification label ........................................ 10-12
Tire and Loading
information label ............................. 8-28, 10-13
Vehicle identification number (VIN) ....... 10-11
Lane Departure Warning (LDW)/Lane
Departure Prevention (LDP) ............................ 5-33
LATCH system ..................................................... 1-24
License plate Installing front license plate .................... 10-15
Light
Air bag warning light .................................... 1-60
Bulb replacement ........................................... 8-22
Fog light switch ............................................. 2-43
Headlight switch ............................................ 2-36
Interior light control switch ........................ 2-59
Interior lights ................................................... 2-58
Map lights ........................................................ 2-58 Personal lights ................................................ 2-58
Replacement ................................................... 8-22
Trunk light ...................................................... 2-60
Vanity mirror lights ...................................... 2-60
Lights Exterior and interior light replacement .... 8-23
Loading information (See vehicle
loading information) ......................................... 10-17
Lock Automatic door locks ..................................... 3-5
Door locks .......................................................... 3-4
Power door lock ............................................... 3-4
Trunk lid ........................................................... 3-22
Locking with mechanical key ............................. 3-4
Log-in function .................................................... 3-15
Loose Fuel Cap warning ....................... 2-22, 3-27
Low fuel warning light ....................................... 2-14
Low outside temperature warning ................. 2-23
Low tire pressure warning light ...................... 2-14
Low tire pressure warning system (See Tire
Pressure Monitoring System
(TPMS)) ............................................... 5-5, 6-3, 8-26
M
Maintenance Battery .............................................................. 8-11
General maintenance ...................................... 9-2
Indicators for maintenance (vehicle
information display) ...................................... 2-25
Inside the vehicle ............................................. 9-3
Maintenance precautions .............................. 8-2

11-6
Readiness for inspection/maintenance
(I/M) test (US only) .......................................... 10-23
Rear door lockChild safety rear door lock ........................... 3-6
Rear seats ................................................................. 1-5
Rear window and outside mirror
defroster switch ................................................... 2-35
RearView Monitor ................................................. 4-3
Recorders Event data .................................................... 10-24
Registering your vehicle in
another country ................................................. 10-11
Remote engine start ........................................... 3-19
Remote keyless entry system .......................... 3-15
Reporting safety defects ................................ 10-22
Request switch (See Intelligent
Key system) .............................................................. 3-9
Roadside assistance program ............................. 6-2
Rollover ..................................................................... 5-9
Roof Moonroof ......................................................... 2-56
Run-flat tires .......................................................... 6-4
S
Safety Child seat belts ............................................... 1-20
Reporting safety defects .......................... 10-22
Seat adjustment Front power seat adjustment ....................... 1-3
Front seats ......................................................... 1-3 Seat belt(s)
Child safety ..................................................... 1-20
Infants ............................................................... 1-20
Injured persons ............................................... 1-15
Larger children ............................................... 1-21
Pre-crash seat belts with comfort
function ............................................................ 1-15
Precautions on seat belt usage ................. 1-12
Pregnant women ........................................... 1-15
Seat belt cleaning ............................................. 7-7
Seat belt extenders ....................................... 1-19
Seat belt maintenance ................................. 1-19
Seat belt warning light
and chime ............................................. 1-14, 2-12
Seat belts ......................................................... 1-12
Seat belts with pretensioners .................... 1-59
Shoulder belt height adjustment ............... 1-18
Small children .................................................. 1-21
Three-point type ............................................ 1-16
Seat(s) Driver-side memory ...................................... 3-33
Heated seats .................................................. 2-44
Seats .................................................................... 1-2
Security system Vehicle security system ............................... 2-30
Security system (INFINITI Vehicle
Immobilizer System) Engine start ..................................................... 2-31
Servicing air conditioner .................................... 4-43
Shift lever Shift lock release ........................................... 5-19 Shift lock release, Transmission ...................... 5-19
Shifting
Automatic transmission ............................... 5-16
Shoulder belt height adjustment ..................... 1-18
SNOW mode ......................................................... 5-22
Sonar system Camera aiding sonar function
(models with Around View
®Monitor) ..... 4-26
Front and rear sonar system .................... 5-135
Sonar system settings ...................................... 5-136
Spare tire ............................................................... 10-9
Spark plugs ............................................................ 8-14
Speedometer ............................................................ 2-7
SPORT mode ........................................................ 5-22
SPORT+ mode ...................................................... 5-22
Standard maintenance ......................................... 9-8
STANDARD mode ............................................... 5-22
Starting Before starting the engine .......................... 5-14
Jump starting .................................................. 8-13
Precautions when starting and driving ..... 5-4
Push starting ...................................................... 6-7
Starting the engine ....................................... 5-15
Status light, Front passenger air bag ............ 1-50
Steering
Direct Adaptive Steering ........................... 5-126
Heated steering wheel ................................. 2-46
Power steering system .............................. 5-126
Tilt/telescopic steering ................................ 3-27
Storage ................................................................... 2-49
Storage box ........................................................... 2-52
