Table of contents
Lubricating the swingarm pivots ...7-33
Checking the front fork..................7-34
Checking the steering ...................7-34
Checking the wheel bearings ........7-35
Battery ...........................................7-35
Replacing the fuses .......................7-36
Vehicle lights .................................7-38
Replacing the license plate light
bulb ............................................7-38
Supporting the motorcycle............7-39
Troubleshooting ............................7-39
Troubleshooting chart ...................7-41
Motorcycle care an d stora ge ..........8-1
Matte color caution .........................8-1
Care .................................................8-1
Storage ............................................8-3
Specifications ....................................9-1
Consumer information ...................10-1
Identification numbers ...................10-1
Diagnostic connector ....................10-2
Vehicle data recording ..................10-2
In dex ................................................11-1
UBN6EBE0.book Page 2 Tuesday, October 19, 2021 8:35 AM

Periodic maintenance an d a djustment
7-38
7
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
EAU80380
Vehicle li ghtsExcept for the license plate light bulb,
this model’s lights are all LED.
If an LED light does not come on,
check the fuses and then have a
Yamaha dealer check the vehicle. If the
license plate light does not come on,
check and replace the bulb. (See page
7-38.)NOTICE
ECA16581
Do not affix any type of tinted film or
stickers to the head lig ht lens.
EAU24314
Replacin g the license plate
lig ht bul b1. Remove the license plate light unit
by removing the screws.
2. Remove the license plate light bulb socket (together with the
bulb) by pulling it out.
1. Headlight
2. Auxiliary light21
21
1. License plate light unit
2. Screw
1
2
UBN6EBE0.book Page 38 Tuesday, October 19, 2021 8:35 AM

Periodic maintenance an d a djustment
7-39
7 3. Remove the burnt-out bulb by
pulling it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with the bulb) by pushing it in.
6. Install the license plate light unit by installing the screws.
EAU67131
Supportin g the motorcycleSince this model is not equipped with a
centerstand, use maintenance stands
when removing the front or rear wheel
or when performing other maintenance
that requires the motorcycle to stand
up right.
Check that the motorcycle is in a stable
and level position before starting any
maintenance.
EAU25872
Trou bleshootin gAlthough Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur
during operation. Any problem in the
fuel, compression, or ignition systems,
for example, can cause poor starting
and loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look
like Yamaha parts, but they are often
inferior, have a shorter service life and
can lead to expensive repair bills.
WARNING
EWA15142
When checkin g the fuel system, do
not smoke, an d make sure there are
no open flames or sparks in the ar-
ea, inclu din g pilot li ghts from water
1. License plate light bulb socket
2. License plate light bulb
1
2
1. Maintenance stand (exampleF
1
UBN6EBE0.book Page 39 Tuesday, October 19, 2021 8:35 AM

11-1
11
Index
AABS....................................................... 4-18
ABS warning light ................................... 4-7
Air filter element.................................... 7-20
Auxiliary DC connector ......................... 4-29BBattery .................................................. 7-35
Brake and clutch levers, checking
and lubricating ................................... 7-32
Brake and shift pedals, checking and lubricating........................................... 7-32
Brake fluid, changing............................ 7-28
Brake fluid level, checking.................... 7-27
Brake lever............................................ 4-17
Brake lever free play, checking ............ 7-25
Brake light switches ............................. 7-26
Brake pedal .......................................... 4-17CCables, checking and lubricating ......... 7-31
Canister ................................................ 7-14
Care ........................................................ 8-1
Catalytic converter ............................... 4-22
Clutch lever........................................... 4-16
Clutch lever free play, adjusting ........... 7-24
Coolant ................................................. 7-19
Coolant temperature warning light ......... 4-6
Cowlings and panels, removing and installing ............................................... 7-9DData recording, vehicle......................... 10-2
Diagnostic connector ........................... 10-2
Dimmer switch........................................ 4-4
D-mode (drive mode).............................. 3-1
Drive chain, cleaning and lubricating ... 7-30 Drive chain slack .................................. 7-29
Drive mode switch ................................. 4-5
EEngine break-in ...................................... 6-3
Engine idling speed, checking ............. 7-20
Engine oil and oil filter cartridge........... 7-15
Engine overheating .............................. 7-42
Engine serial number ........................... 10-1
Engine trouble warning light .................. 4-6
EXUP system ....................................... 4-28FFront and rear brake pads, checking ... 7-26
Front fork, adjusting ............................. 4-24
Front fork, checking ............................. 7-34
Fuel ...................................................... 4-19
Fuel level warning light........................... 4-6
Fuel tank cap........................................ 4-19
Fuel tank overflow hose ....................... 4-21
Fuses, replacing ................................... 7-36HHandlebar switches ............................... 4-3
Hazard switch ........................................ 4-4
High beam indicator light ....................... 4-5
Horn switch ............................................ 4-4IIdentification numbers ......................... 10-1
Ignition circuit cut-off system .............. 4-30
Immobilizer system ................................ 4-1
Immobilizer system indicator light ......... 4-7
Indicator lights and warning lights ......... 4-5LLicense plate light bulb, replacing ....... 7-38MMain switch/steering lock ...................... 4-2Maintenance and lubrication, periodic ... 7-5
Maintenance, emission control
system .................................................. 7-3
Matte color, caution................................ 8-1
Model label ........................................... 10-1
Multi-function meter unit ........................ 4-8
NNeutral indicator light ............................. 4-5OOil level warning light .............................. 4-5PParking.................................................... 6-4
Part locations.......................................... 2-1
Pass switch............................................. 4-4QQuick shifter............................................ 3-4RRear view mirrors .................................. 4-23SSafety information................................... 1-1
Seats ..................................................... 4-22
Shifting.................................................... 6-2
Shift light ................................................. 4-7
Shift pedal............................................. 4-17
Shock absorber assembly, adjusting ... 4-26
Sidestand.............................................. 4-29
Sidestand, checking and lubricating .... 7-33
Spark plugs, checking .......................... 7-13
Special features ...................................... 3-1
Specifications ......................................... 9-1
Starting the engine ................................. 6-1
Steering, checking ................................ 7-34
Stop/Run/Start switch ............................ 4-4
Storage ................................................... 8-3
