2022 TOYOTA CAMRY maintenance

4566-3. Do-it-yourself maintenance
CAMRY_U
WARNING
The engine compartment contains many mechanisms and fluids that may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury, observe the following precautions.
■ When working on the engine compartment
● Keep hands, clothing and tools away from the moving fan and engine
drive belt.
● Be careful not to touch the engine, radiator, exhaust manifold, etc. right
after driving as they may be hot. Oil and other fluids may also be hot.
● Do not leave anything that may burn easily, such as paper and r ags, in the
engine compartment.
● Do not smoke, cause sparks or expose an open flame to fuel or t he bat-
tery. Fuel and battery fumes are flammable.
● Be extremely cautious when working on the battery. It contains poisonous
and corrosive sulfuric acid.
■ When working near the electric cooling fan or radiator grille
Vehicles without a smart key system:
Be sure the engine switch is off. With the engine switch in the “ON” position,
the electric cooling fan may automatically start to run if the air conditioning
is on and/or the coolant temperature is high. ( P. 467)
Vehicles with a smart key system:
Be sure the engine switch is off. With the engine switch in IGNITION ON
mode, the electric cooling fan may automatically start to run if the air condi-
tioning is on and/or the coolant temperature is high. ( P. 467)
■ Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc.
from getting in your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air.

4576-3. Do-it-yourself maintenance
CAMRY_U
6
Maintenance and care
Pull the hood lock release lever.
The hood will pop up slightly.
Pull up the auxiliary catch lever
and lift the hood.
Hold the hood open by inserting
the support rod into the slot.
■Open hood warning buzzer
If the vehicle reaches a speed of 3 mph (5 km/h), the master warning light
flashes and a buzzer sounds to indicate that the hood is not fu lly closed.
Hood
Release the lock from the inside of the vehicle to open the hoo d.
1
2
3

4586-3. Do-it-yourself maintenance
CAMRY_U
WARNING
■Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehic le is in motion
and cause an accident, which may result in death or serious inj u r y.
■ After installing the sup port rod into the slot
Make sure the rod supports the hood securely preventing it from falling
down onto your head or body.
NOTICE
■ When closing the hood
Be sure to return the support rod to its clip before closing the hood. Closing
the hood with the support rod not clipped could cause the hood to bend.

4596-3. Do-it-yourself maintenance
CAMRY_U
6
Maintenance and care
◆Front
◆Rear
2WD models
AWD models
Positioning a floor jack
When using a floor jack, follow the instructions in the manual
provided with the jack and perform the operation safely.
When raising your vehicle with a floor jack, position the jack cor-
rectly. Improper placement may damage your vehicle or cause
injury.

4606-3. Do-it-yourself maintenance
CAMRY_U
2.5 L 4-cylinder (A25A-FKS) engine
Engine compartment
Fuse boxes (if equipped)( P. 499)
Engine oil filler cap ( P. 464)
Engine oil level dipstick ( P. 462)
Brake fluid reservoir ( P. 468) Battery
( P. 469)
Radiator ( P. 467)
Electric cooling fan
Condenser ( P. 467)
Engine coolant reservoir ( P. 466)
Washer fluid tank ( P. 472)1
2
3
4
5
6
7
8
9
10

4616-3. Do-it-yourself maintenance
CAMRY_U
6
Maintenance and care
3.5 L V6 (2GR-FKS) engine
Fuse boxes (if equipped)( P. 499)
Engine oil filler cap ( P. 464)
Engine oil level dipstick ( P. 462)
Brake fluid reservoir ( P. 468)
Battery ( P. 469) Radiator (
P. 467)
Electric cooling fan
Condenser ( P. 467)
Engine coolant reservoir ( P. 466)
Washer fluid tank ( P. 472)1
2
3
4
5
6
7
8
9
10

4626-3. Do-it-yourself maintenance
CAMRY_U
With the engine at operating temperature and turned off, check the oil
level on the dipstick.
■Checking the engine oil
Park the vehicle on level ground. After warming up the engine
and turning it off, wait more than 5 minutes for the oil to dra in
back into the bottom of the engine.
Holding a rag under the end, pull the dipstick out.
Wipe the dipstick clean.
Reinsert the dipstick fully.
Engine oil
1
2
2.5 L 4-cylinder (A25A-FKS)
engine3.5 L V6 (2GR-FKS) engine
3
4

4636-3. Do-it-yourself maintenance
CAMRY_U
6
Maintenance and care
Holding a rag under the end, pull the dipstick out and check the
oil level.
Low
Normal
Excessive
The shape of the dipstick may differ depending on the type of v ehicle
or engine.
Wipe the dipstick and reinsert it fully.
5
Flat dipstickTwist dipstick
1
2
3
6
