3655-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically .)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the windshiel d
is defogged.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain -
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of tim e.
Other functions

3705-1. Using the air conditioning system and defogger
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid weathe r.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
Do not touch the rear view mirror surfaces when the outside rea r view mirror
defoggers are on.
NOTICE
■ To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
hybrid system is stopped.
■ When repairing/replacing parts of the air conditioning system
Have repair/replacement performed by your Toyota dealer.
When a part of the air conditioning system, such as the evapora tor, is to be
replaced, it must be replaced with a new one.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

4005-4. Other interior features
■Before programming the HomeLink®
●During programming, it is possible that garage doors, gates, or
other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices t o
prevent injury or other potential harm.
● It is recommended that a new battery be placed in the remote
control transmitter for mo re accurate programming.
● Garage door opener motors manufactured after 1995 may be
equipped with rolling code pro tection. If this is the case, you may
need a stepladder or other sturdy, safe device to reach the
“Learn” or “Smart” button on the garage door opener motor.
■Programming the HomeLink®
Steps through must be perfo rmed within 60 seconds, other-
wise the indicator light will st op flashing and programming wil l not
be able to be completed.
Press and release the HomeLink
® button you want to program
and check that the HomeLink® indicator light flashes orange.
Point the remote control
transmitter for the device at
the rear view mirror, 1 to 3 in.
(25 to 75 mm) from the
HomeLink
® buttons.
Keep the HomeLink® indicator
light in view while programming.
Program a device.
13
1
2
3

5548-2. Customization
■Lights (P. 2 2 2 )
■Intuitive parking assist* ( P. 313)
*: If equipped
■
BSM (Blind Spot Monitor) ( P. 2 9 7 )
■RCTA (Rear Cross Traffic Alert) ( P. 297)
FunctionDefault settingCustomized setting
Daytime running light
systemOnOffOO
Welcome lightingOnOff—O
Windshield wiper linked
headlight illuminationOnOff—O
12
FunctionDefault settingCustomized setting
Detection distance of the
front center sensorFarNear—O
Detection distance of the
rear center sensorFarNear—O
12
FunctionDefault settingCustomized setting
Outside rear view mirror
indicator brightnessBrightDim—O
Alert sensitivity for pres-
ence of approaching
vehicle
Intermediate
Early
—OLate
Only when vehicle
detected in blind spot
12
FunctionDefault settingCustomized setting
Buzzer volume21 to 3—O
12

569Alphabetical index
Daytime running light system .................................... 223
Defogger Outside rear view mirrors...... 365
Rear window ......................... 365
Windshield ............................ 365
Dimensions .............................. 524
Dinghy towing .......................... 199
Display Dynamic radar cruise control
with full-speed range .......... 281
LTA (Lane Tracing Assist) .... 270
Multi-information display ....... 102
Warning messages ............... 488
Do-it-yourself maintenance .... 421
Door courtesy lights Location ................................ 374
Wattage ................................ 531
Door lock
Doors .................................... 142
Smart key system ................. 142
Wireless remote control ........ 142
Doors ........................................ 142 Automatic door locking and unlocking systems ....... 145
Door lock............................... 144
Outside rear view mirrors...... 174
Rear door child-protector ...... 145
Side doors............................. 142
Side windows ........................ 177 Drive-Start Control .................. 187
Sudden start restraint control ................................ 187
Driver’s seat belt reminder light ........................ 481
Driver’s seat position memory .................................. 163
Driving Break-in tips.......................... 188
Correct posture ....................... 26
Driving mode select switches ............................. 342
Hybrid vehicle driving tips ..... 351
Procedures ........................... 186
Winter drive tips .................... 354
Driving information ................. 106
Driving position memory ........ 163
Memory recall function ......... 166
Power easy access system .......... ...................... 163
DSC (Drive-Start Control) ....... 187 Sudden start restraint
control ................................ 187
Dynamic radar cruise control with full-speed range ............ 281
D
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

572Alphabetical index
Fuel consumption............ 106, 134
Fuel filler door.......................... 234If the fuel filler door
cannot be opened............... 238
Refueling............................... 234
Fuses ........................................ 464
Garage door opener ................ 399
Gauges ....................................... 98
Glove box ................................. 378
Grocery bag hooks .................. 383
Head restraints ........................ 168
Head-up display ....................... 123
Headlights ................................ 222 Automatic High Beam ........... 226
Light switch ........................... 222
Replacing light bulbs............. 467
Windshield wiper linked headlight illumination .......... 224
Heated steering wheel............. 371
Heaters Automatic air
conditioning system ............ 360
Outside rear view mirrors...... 365
Seat heaters ......................... 371
High mounted stoplight Replacing .............................. 467
High voltage components......... 79
Hill-start assist control............ 344
Hood ......................................... 423 Hooks
Coat hooks ........................... 398
Grocery bag hooks ............... 383
Retaining hooks (floor mat) .... 24
Horn .......................................... 171
HUD (Head-up display) ........... 123
Hybrid battery (traction battery) ..................... 79
Hybrid battery (traction battery) air
intake vent ....................... 80, 456
Hybrid system............................ 75 Acoustic Vehicle Alerting
System ................................. 76
Emergency shut off system .... 80
Energy monitor/ consumption screen ........... 130
EV drive mode ...................... 206
High voltage components ....... 79
Hybrid System Indicator ....... 100
Hybrid system precautions ..... 79
Hybrid vehicle driving tips ..... 351
If the hybrid system will not start ........................ 505
Overheating .......................... 517
Power (ignition) switch.......... 200
Starting the hybrid system .... 200
Hybrid System Indicator ......... 100
Hybrid transmission................ 209
If the shift lever cannot be shifted from P .... 213
Paddle shift switches ............ 212
S mode ................................. 211
G
H

573Alphabetical index
I/M test ...................................... 420
ICS (Intelligent Clearance Sonar) ..................................... 321 Warning light ......................... 481
Warning messages ............... 332
Identification Engine................................... 525
Vehicle .................................. 525
Ignition switch (power switch) ....................... 200
Illuminated entry system ........ 376
Immobilizer system ................... 86
Indicators ................................... 95
Initialization Intelligent Clearance Sonar .................................. 332
Items to initialize ................... 557
Tire pressure warning system ... ............... 438
Inside rear view mirror ............ 172
Instrument panel light control ...................................... 99
Intelligent Clearance Sonar (ICS)............................. 321 Warning light ......................... 481
Warning messages ............... 332
Interior lights............................ 374 Switch ................................... 375
Intuitive parking assist............ 313 Jack
Positioning the jack............... 424
Vehicle-equipped jack .......... 494
Jack handle .............................. 494
Jam protection function
Moon roof ............................. 182
Power window ...................... 177
Keyless entry Smart key system ......... 142, 148
Wireless remote control ........................ 142, 149
Keys .......................................... 138 Battery-saving function ......... 154
Electronic key ....................... 138
Engine switch ....................... 200
If the electronic key does not operate properly ........... 507
If you lose your keys ..... 139, 141
Key number plate ................. 138
Keyless entry ........................ 138
Mechanical key ..................... 139
Power switch ........................ 200
Replacing the battery............ 461
Warning buzzer .................... 153
Wireless remote control ........ 138
Knee airbags .............................. 34
IJ
K

574Alphabetical index
Lane Tracing Assist (LTA) ...... 261
Language (multi- information display) .............. 118
LATCH anchors ......................... 59
Lever
Auxiliary catch lever .............. 423
Hood lock release lever ........ 423
Internal trunk release lever ... 150
Shift lever .............................. 209
Tilt and telescopic steering lock release lever ............... 170
Turn signal lever ................... 215
Wiper lever............................ 230
License plate lights Light switch ........................... 222
Replacing light bulbs............. 467
Light bulbs Replacing .............................. 467
Lights
Automatic High Beam ........... 226
Cornering lights..................... 223
Daytime running light system ......... ....................... 223
Door courtesy lights .............. 374
Headlight switch.................... 222
Illuminated entry system ....... 376
Interior lights ......................... 375
Interior lights list .................... 374
Personal lights ...................... 375
Replacing light bulbs............. 467
Trunk light ............................. 149
Turn signal lever ................... 215
Vanity lights .......................... 384
Wattage ................................ 531
Welcome lighting .................. 225
Load capacity........................... 197
Lock steering column ............. 203
LTA (Lane Tracing Assist) ...... 261 Maintenance
Do-it-yourself maintenance... 421
General maintenance ........... 416
Maintenance data ................. 524
Maintenance requirements ...................... 414
Resetting the message
indicating maintenance
is required .......................... 415
Malfunction indicator lamp..... 479
Master warning light ............... 481
Memory recall function ........... 166
Meter
Head-up display.................... 123
Indicators ................................ 95
Instrument panel light control .................................. 99
Meters..................................... 98
Multi-information display ....... 102
Settings................................. 111
Warning lights ......................... 93
Warning messages ............... 488
Mirrors Inside rear view mirror .......... 172
Outside rear view mirror defoggers ........................... 365
Outside rear view mirrors ..... 174
Vanity mirrors ....................... 384
Moon roof ................................. 181 Door lock linked moon roof operation ............................ 182
Jam protection function ........ 182
Operation .............................. 181
LM
