2022 TOYOTA 4RUNNER navigation system

2974-5. Using the driving support systems
4
Driving
4RUNNER (U)
Multi-information display
Turning the RCTA function on/off.
Outside rear view mirror indica-
tors
When a vehicle approaching from
the right or left at the rear of the
vehicle is detected, both outside
rear view mirror indicators will
flash.
Navigation system screen
If a vehicle approaching from the
right or left at the rear of the vehicle
is detected, the RCTA icon (P.
299) for the detected side will be
displayed.
RCTA buzzer
If a vehicle approaching from the right or left at the rear of the vehicle is
detected, a buzzer will sound.
The RCTA function can be enabl ed/disabled on screen of the
multi-information display. ( P. 9 7 )
When the RCTA function is disabled, the “RCTA OFF” indicator wi ll come
on. Each time the engine switch is turned to the “LOCK” position (vehicles
without smart entry & start system) or off (vehicles with smart entry & start
system) then changed to the “ON” position (vehicles without sma rt entry &
start system) or IGNITION ON mode (vehicles with smart entry & start sys-
tem), the RCTA function will be enabled automatically.
RCTA (Rear Cross Traffic Alert)
: If equipped
The RCTA function uses the BSM radar sensors installed on the
inner side of the rear bumper. This function is intended to ass ist
the driver in checking areas that are not easily visible when
backing up.
System components
1
2
3
Turning the RCTA function on/off
4

2994-5. Using the driving support systems
4
Driving
4RUNNER (U)■
Operation of the RCTA function
The RCTA function uses radar
sensors to detect vehicles
approaching from the right or left at the rear of the vehicle a nd
alerts the driver of the presence of such vehicles by flashing the
outside rear view mirror indi cators and sounding a buzzer.
Approaching vehicles
Detection areas of approaching vehicles
■RCTA icon display
When a vehicle approaching
from the right or left at the rear
of the vehicle is detected, the
following will be displayed on
the navigation system screen.
Example: Vehicles are
approaching from both sides of
the vehicle.
RCTA function
1
2

5588-2. Customization
4RUNNER (U)
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.
Settings that can be changed usi ng the meter control switches
Settings that can be changed usin g the navigation system or the
multimedia system
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available, – =Not available
■
Door lock (P. 110, 130, 520)
Customizable features
1
2
3
FunctionDefault settingCustomized
setting
Unlocking using a key Driver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one step
––O
Automatic door lock
Shift position
linked door
locking opera-
tionOff
–OOSpeed linked door locking operation
Automatic door unlock
Shift position
linked door
unlocking oper- ationOff
–OODriver’s door
linked door
unlocking oper- ation
123

585
Index
4RUNNER (U)What to do if...
(Troubleshooting) .................... 586
Alphabetical index ..................... 591
For details of equipment relat ed to the audio/navigation
system, refer to the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”.

591
4RUNNER (U)
Alphabetical index
Alphabetical index
A/C .................................... 352, 359Air conditioning filter ............. 453
ABS (Anti-lock Brake System)...... 333
Function ................................ 333
Warning light ......................... 487
Active head restraints ............. 136
Active traction control ............ 313
Air conditioning filter .............. 453
Air conditioning
system ............................ 352, 359 Air conditioning filter ............. 453
Airbags ....................................... 37
Airbag operating conditions .... 44
Airbag precautions for your child ......................... 39
Airbag warning light .............. 487
Correct driving posture ........... 30
Curtain shield airbag operating conditions ............. 44
Curtain shield airbag precautions ........................... 41
Front passenger occupant classification syst em............. 48
General airbag precautions .... 39
Locations of airbags................ 37
Modification and disposal of airbags.............................. 43
Side airbag operating
conditions ............................. 44
Side airbag precautions .......... 39
Side and curtain shield airbags operating conditions ............. 44
Side and curtain shield airbags precautions .............. 39
SRS airbags............................ 37 Alarm .......................................... 80
Alarm ...................................... 80
Warning buzzer .................... 486
Anchor brackets ........................ 59
Antennas (smart key system) ............... 119
Anti-lock Brake System (ABS) ...................................... 333
Function ................................ 333
Warning light......................... 487
Armrest..................................... 395
Assist grip ................................ 395
Audio system
*
AUTO LSD system................... 315
Automatic air conditioning
system.................................... 359
Automatic High Beam ............. 228
Automatic light control
system.................................... 223
Automatic running boards ..... 127
Automatic transmission ......... 216
If the shift lever cannot be shifted from P .... 219
S mode ................................. 217
AUX port
*
Auxiliary boxes ........................ 376
A
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

598Alphabetical index
4RUNNER (U)
Multi Terrain ABS .................... 333
Multi-information display .......... 92Driving information .................. 95
Dynamic radar cruise control................................. 268
Language .............................. 567
LDA (Lane Departure Alert)........ 260
Outside temperature ............. 100
PCS (Pre-Collision System)........ 250
Settings ................................... 98
Warning messages ............... 497
Multi-terrain Select .................. 326
Navigation system
*
Noise from under vehicle............ 8
Odometer.................................... 90
Off-road precaution s ............... 346
Oil Engine oil .............................. 423
Opener Back door.............................. 131
Hood ..................................... 420
Outer foot lights....................... 369
Outside rear view mirrors ....... 159
Adjusting and folding ............ 159
Outside rear view mirror defoggers ......... 354, 361
Outside temperature display .................................... 100
Overhead console ................... 376
Overheating, Engine................ 527 Parking brake........................... 222
Operation .............................. 222
Parking brake engaged warning buzzer ................... 486
PCS (Pre-Collision System).......... 250 Warning light......................... 212
Parking lights........................... 223 Light switch ........................... 223
Replacing light bulbs ............ 465
Wattage ................................ 541
Pen holder ................................ 377
Personal lights......................... 370
Power back window ................ 165 Jam protection function ........ 167
Operation .............................. 165
Power outlets ................... 386, 390
Power steering Fluid ...................................... 429
Warning light......................... 488
Power windows ....................... 161 Door lock linked
window operation ............... 163
Jam protection function ........ 162
Operation .............................. 161
Window lock switch .............. 161
N
O
P

599Alphabetical index
4RUNNER (U)
Radiator .................................... 427
Rear differential lock system .................................... 317
Rear seats
Adjustment ............................ 138
Folding down ........ 140, 142, 144
Rear step bumper .................... 131
Rear turn signal lights............. 221
Replacing light bulbs............. 469
Turn signal lever ................... 221
Wattage ................................ 541
Rear view mirror Inside rear view mirror .......... 157
Outside rear view mirrors...... 159
Rear view monitor system
*
Rear window ............................ 165
Rear window defoggers ....................... 354, 361
Rear window wiper .................. 237
Refueling .................................. 240
Capacity ................................ 534
Fuel types ............................. 534
Opening the fuel tank cap ..... 242
Replacing Fuses .................................... 459
Key battery............................ 455
Light bulbs ............................ 462
Tires ...................................... 502
Reporting safety defects
for U.S. owners ...................... 572
Resetting the message indicating maintenance
is required .............................. 412
Roof luggage carrier ............... 184 Safety Connect .......................... 72
Seat belt reminder light .......... 489
Seat belts ................................... 32
Adjusting the seat belt ............ 32
Automatic Locking
Retractor (ALR) .................... 33
Child restra int system
installation ............................ 64
Cleaning and maintaining the seat belt........................ 409
Emergency Locking Retractor (ELR) .................... 33
How to wear your seat belt ..... 32
How your child should wear
the seat belt.......................... 33
Pregnant women, proper
seat belt use ......................... 34
Reminder light and buzzer.... 489
Seat belt extender .................. 33
Seat belt pretensioners........... 33
SRS warning light ................. 487
Seat heaters ............................. 367
Seat position memory ............. 148
Seat ventilators........................ 367
Seating capacity ...................... 189
RS
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

601Alphabetical index
4RUNNER (U)
SwitchesAutomatic High Beam
switch ................................. 228
Cruise control switch............. 268
Door lock switches ................ 113
Driving position memory switches.............................. 148
Emergency flashers switch ... 474
Engine switch................ 207, 210
Fog light switch ..................... 232
Garage door opener
switches.............................. 396
Ignition switch ............... 207, 210
LDA (Lane Departure Alert) switch ................................. 260
Light switches ....................... 223
Moon roof switches ............... 169
Outside rear view mirror switches.............................. 159
Power back window
switch ................................. 165
Power door lock switch ......... 113
Power window switches ........ 161
Rear window and outside rear view mirror defoggers
switch ......................... 354, 361
Rear window wiper and
washer switch ..................... 237
Seat heater switches ............ 367
Seat ventilator switches ........ 367
“SOS” button ........................... 72
Telephone switches
*
VSC OFF switch ................... 335
Window lock switch............... 161
Windshield wipers and washer switch .............. 234 Tachometer ................................ 90
Tail lights.................................. 223
Light switch ........................... 223
Telephone switches
*
Theft deterrent system
Alarm ...................................... 80
Engine immobilizer system ..... 78
Tire inflation pressure............. 448 Maintenance data ................. 540
Warning light......................... 490
Tire information ....................... 545 Glossary ............................... 551
Size....................................... 547
Tire identification number ..... 546
Uniform Tire Quality Grading .............................. 549
Tire pressure warning system.................................... 437 Function ................................ 437
Installing tire pressure warning
valves and transmitters ...... 438
Registering ID codes ............ 439
Warning light......................... 490
T
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
