Warning and Indicator Lights
140■
ABS Warning Light
The ABS warning light illuminates
together with the brake system warning
light if the EBD system malfunctions. For
further details of the EBD system malfunc-tion warning, refe
r to "Brake System
Warning Light" P140.
NOTEIf the warning light behavior is as
described in the following conditions,
the ABS may be considered normal.
 The warning light illuminates right
after the engine is started but turns off
immediately, remaining off.
 The warning light remains illumi-
nated after the engine has been
started, but it turns off while driving.
 The warning light illuminates during
driving, but it turns off immediately and
remains off.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warn ing light may illumi-
nate. This is due to the low battery voltage
and does not indicate a malfunction.
When the battery becomes fully charged,
the light will turn off.
■
Brake System
Warning Light
This light has the following functions.
▼
Parking brake warning
The light illuminates with the parking
brake applied while the ignition switch is in the “ACC” or “ON” position. It turns off
when the parking brake is fully released.
▼Brake fluid level warning
This light illuminates when the brake fluid
level has dropped to near the “MIN” level
of the brake fluid reservoir with the ignition
switch in the “ON” position and with the
parking brake fully released.
CAUTION
 If any of the following conditions
occur, we recommend that you
have the ABS repaired at the first
available opportunity by your
SUBARU dealer.
- The warning light does not
illuminate when the ignition
switch is turned to the “ON”
position.- The warning light illuminates when the ignition switch is
turned to the “ON” position,
but it does no t turn off even
after starting the vehicle.- The warning light illuminates during driving.
When the warning light is on (and
brake system warning light is off),
the ABS function shuts down;
however, the conventional brake
system continues to operate
normally.
WARNING
 Driving with the brake system
warning light on is dangerous.
This indicates your brake system
may not be working properly. If
the light remains illuminated,
have the brakes inspected by a
SUBARU dealer immediately.If at all in doubt about whether the
brakes are operating properly, do
not drive the vehicle. Have your
vehicle towed to the nearest
SUBARU dealer for repair.
B5=B8.ERRN 140 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Winter Driving
293
Driving Tips8
– CONTINUED –
8-8. Winter Driving■
Operation during Cold
Weather
Carry some emergency equipment, such
as a window scraper, a bag of sand,
flares, a small shovel and jumper cables.
Check the battery and cables. Cold
temperatures reduce battery capacity.
The battery must be in good condition to
provide enough power for cold winter
starts.
It normally takes longer to start the engine
in very cold weather conditions. Use an
engine oil of a proper grade and viscosity
for cold weather. Using heavy summer oil
will make it harder to start the engine.
Keep the door locks from freezing by
squirting them with deicer or glycerin.
Forcing a frozen door open may damage
or separate the rubber weather strips
around the door. If the door is frozen, use
hot water to melt the ice, and afterwards
thoroughly wipe the water away.
Use a windshield washer fluid that
contains an antifr eeze solution. Do not
use engine antifreeze or other substitutes
because they may damage the paint of
the vehicle.
If you fill the windshield washer tank with
a fluid with a different concentration from
If all four tires are not the same in
items (a) to (h), serious mechani-
cal damage could be caused to
the drivetrain of the car, and
affect the followings.- Ride- Handling- Braking- Speedometer/Odometer cali-
bration- Clearance between the bodyand the tires
It also may be dangerous and
lead to loss of vehicle control,
and it can lead to an accident.
 In a rollover crash, an unbelted
person is significantly more likely
to die than a person wearing a
seat belt. The driver and all your
passengers should fasten their
seatbelts before st arting to drive
in order to minimize the chance of
serious injury or death. Do not make sharp turns or quick
maneuvers unless absolutely
unavoidable. Such actions are
dangerous as you may lose
control, possibly resulting in a
rollover which could cause death
or serious injury.
Whenever strong crosswinds are
present, slow do wn sufficiently to
maintain control of your vehicle. Never to drive through pools and
puddles, or roads flooded with
water. Water entering the engine
air intake or the exhaust pipe or
water splashing onto electrical
parts may damage your vehicle
and may cause it to stall. In this
case, contact your SUBARU
dealer immediat ely. Regardless
of its depth, it can wash away the
ground from under your tires,
resulting in possible loss of trac-
tion and even vehicle rollover.
CAUTION
After driving on gravel roads or
rough roads, check the undercar-
riage of the vehicle body for any
damage, deformation, or paint
removal. If you notice any irregulari-
ties, contact a SUBARU dealer for
an inspection as soon as possible.
B5=B8.ERRN 23 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

In Case of Emergency9
In Case of Emergency
9-1. If You Park Your Vehicle in an Emergency.......302
9-2. Maintenance Tools..............................................302
Models with Flat Tire Repair Kit ..................................303
Models with Spare Tire ................................................303
9-3. Flat Tires ..............................................................303
Changing a Flat Tire .....................................................303
Sealing a Flat Tire (Models with the Flat Tire Repair Kit) ...........................................................306
Tire Pressure Monitoring System (TPMS) (If Equipped) ...............................................................315
TPMS Screen (If Equipped)..........................................316
9-4. Jump Starting ......................................................316
Battery Precautions......................................................316
How to Jump Start ........................................................317
9-5. Engine Overheating ............................................319
If Steam Is Coming from the Engine Compartment ..............................................................319 If No Steam Is Coming from the Engine
Compartment ............................................................. 319
9-6. Towing .................................................................320
Towing Hook and Tie-Down Hooks/Holes ................. 320
Using a Flat-Bed Truck................................................ 324
Towing with All Wheels on the Ground ..................... 324
9-7. Access Key Fob – If Access Key Fob Does
Not Operate Properly ...... ..................................325
Locking and Unlocking ............................................... 326
Switching Power Status .............................................. 326
Starting Engine ............................................................ 326
9-8. Malfunctions of the Center Information
Display ...............................................................327
9-9. If Your Vehicle Is Invo lved in an Accident ........328
To Restart the Engine When Involved in an
Accident ..................................................................... 328
B5=B8.ERRN 301 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Jump Starting
316■
TPMS Screen (If Equipped)
This screen displays each tire pressure.
Refer to "Combination Meter Display
(Color TFT)" P151.
9-4. Jump Starting■
Battery Precautions
When your vehicle does not start due to a
run down (discharged) battery, the vehicle
may be jump started by connecting your
battery to another battery (called the
booster battery) with jumper cables.
702781
WARNING
 Battery fluid is SULFURIC ACID.
Do not let it come in contact with
the eyes, skin, clothing or the
vehicle.
If battery fluid gets on you, thor-
oughly flush the exposed area
with water immedi ately. Get med-
ical help if the fluid has entered
your eyes.If battery fluid is accidentally
swallowed, imme diately drink a
large amount of milk or water,
and obtain immediate medical
help.Keep everyone including chil-
dren away from the battery.
 The gas generated by a battery
explodes if a flame or spark is
brought near it. Do not smoke or
light a match while jump starting.Never attempt jump starting if the
discharged battery is frozen. It
could cause the battery to burst
or explode.
Whenever working on or around a
battery, always wear suitable eye
protectors, and remove metal
objects such as rings, bands or
other metal jewelry.Be sure the jumper cables and
clamps on them do not have
loose or missing insulation.Do not jump start unless cables in
suitable condition are available.A running engine can be
dangerous. Keep your fingers,
hands, clothing, hair and tools
away from the cooling fan, belts
and any other moving engine
parts. Removing rings, watches
and ties is advisable.Jump starting is dangerous if it is
done incorrectly. If you are
unsure about the proper proce-
dure for jump starting, consult a
competent mechanic.
B5=B8.ERRN 316 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Jump Starting
317
In Case of Emergency9
– CONTINUED –
■
How to Jump Start
1. Make sure the booster battery is 12
volts and the negative terminal is
grounded.
2. If the booster battery is in another
vehicle, do not let the two vehicles touch.
3. Turn off all unnecessary lights and
accessories.
4. Connect the jumper cables exactly in
the sequence illustrated.
B5=B8.ERRN 31 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Jump Starting
318
B
A
(2)
(4)
(3)
(1)
901200
A) Booster battery
B) Strut mounting nut
1) Connect one jumper cable to the posi-tive (+) terminal on the discharged
battery.
2) Connect the other end of the jumper cable to the positive (+) terminal of the
booster battery.
3) Connect one end of the other cable to the negative ( −) terminal of the booster
battery.
4) Connect the other end of the cable to the strut mounting nut.Make sure that the cables are not near
any moving parts and that the cable
clamps are not in contact with any other
metal.
5. Start the engine of the vehicle with the
booster battery and run it at moderate
speed. Then start the engine of the
vehicle that has the discharged battery.
6. When finished, carefully disconnect
the cables in exactly the reverse order.
B5=B8.ERRN 31 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Index
410AAbbreviation .............................................................................P4
ABS (Anti-lock Brake System) .............................................P245
Warning light....................................................................P140
Access key Warning indicator.................................................. P143, P144
Access key fob
Warning light....................................................................P144
Accessories ..........................................................................P373
Accessory power outlet ........................................................P215
Active sound control .............................................................P242
Air cleaner element ..............................................................P350
Air conditioner
Automatic climate control ......... .......................................P200
Manual climate control system .... ....................................P201
Air filtration system ....... ........................................................P205
Airflow mode selection . ........................................................P201
Alarm system .... ...................................................................P114
All season tires .....................................................................P358
Alloy wheel .......... ......................................................... ........P366
Cleaning .................................................................... ......P333
Antenna Roof antenna ...................................................................P210
Anti-lock Brake System (ABS) ...... .......................................P245
Arming the system ....... ........................................................P114
Ashtray .................................................................................P217
AT OIL TEMP warning light..................................................P138 Audio
Antenna system ........... .......................................... ......... P210
Set .................................................................................. P210
Audio system-linked display ........ ........................................ P156
Auto dimmer cancel function ............................................... P131
Auto on/off headlights.......................................................... P174 Sensor ............................................................................ P176
Auto-dimming mirror/compass ....... ..................................... P186
Automatic Transmission .................................................................. P236
Automatic climate control operation .................................... P200
Automatic headlight beam leveler . ................................ ...... P182
Warning light ................................................................... P150
Automatic Locking Retractor/Emergency Locking Retractor (ALR/ELR).......................................................................... P40
Automatic transmission Oil temperature warning light (AT OIL TEMP) ................ P138
Average vehicle speed .................................................. ...... P153
BBattery
Drainage prevention function .......................................... P113
Jump starting .................................................................. P316
Replacement (access key fob) ....................................... P376
Replacement (keyless access wi th push-button start system)
....................................................................................... P376
Vehicle battery ................................................................ P370
Blind Spot Detection (BSD) ................................................. P269
Booster seat .......................................................................... P54
B5=B8.ERRN 410 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Index
415
Index14
Turn signal ...................................................................... P149
Vehicle Stability Control (VSC) OFF ............................... P143
Vehicle Stability Control (VSC) operation ............. P142, P143
Inside mirror ........................................................................ P186
Interior lights ........................................................................ P212
Internal trunk lid release handle .. ........................................ P121
JJack and jack handle ... ................................................... ..... P302
Jack-up point ....................................................................... P303
Jump starting ....................................................................... P316KKey ........................................................................................ P94
Replacement ................................................................... P108
Keyless access with push-button start system ...................... P94
Disabling keyless access functions................................. P103
Locking and unlocking doors ............................................ P98
Opening trunk ................................................................... P98
Warning chimes and warning i ndicator ................. P106, P143
When access key fob does not operate properly ............ P325LLane Change Assist (LCA) .................................................. P269
Leather seat materials ................ ......................................... P335
LED headlight warning light ........ ............................... P150, P373
LED headlights .................................................................... P373
Light Backup ............................................................................ P373 Control switch.................................................................. P174
Daytime running ...........
................................................... P180
Map ................................................................................. P212
Trunk ............................................................................... P374
Turn signal ................ ....................................... ............... P182
Loading your vehicle ............................................................ P297
Low fuel warning light .......................................................... P141
Low tire pressure warning light ............................................ P138
Lower anchors and tethers for ch ildren (LATCH) .................. P55
Lower and top tether anchorages .......................................... P55
MMaintenance Precautions ..................................................................... P339
Schedule ............. ........................................................ .... P339
Seatbelt ............................................................................. P43
Tips ................................................................................. P341
Tools ............................................................................... P302
Malfunction indicator light (check engine warning light) ...... P136
Manual Climate control ................................................................ P201
mode (automatic transmission) ... .................................... P239
Seat ................................................................................... P33
Transmission ................................................................... P233
Transmission oil ....................................................P353, P383
Map light .............................................................................. P212
Meters and gauges .............................................................. P127
Mirror defogger .................................................................... P185
Mirrors.................................................................................. P186
B5=B8.ERRN 415 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分
