However, the brake pads can be sepa-
rately replaced only when a GT-R certified
technician judges that the brake disc
rotors are reusable, based on a measured
weight and a check for scratches and
cracks.EXHAUST MUFFLER AND TRUNK
CARPETThe GT-R exhaust system is designed to
provide the maximum vehicle perfor-
mance and to protect the vehicle from
high exhaust gas temperatures.
If non-genuine GT-R exhaust system
parts are used it is possible that the
muffler or other exhaust system parts will
deform and cause damage to the under-
body. Non-genuine GT-R exhaust system
parts can also affect vehicle performance
and possibly lead to turbocharger, engine
or power train related parts including
transmission, damage.
Also, do not remove the trunk carpet from
the vehicle for any reason. The carpet
insulates the vehicle interior from the
heat of the muffler and from the noise
of the transmission.
TITANIUM MUFFLER AND TRUNK
CARPET (if so equipped)
NOTICE
Never allow polishes with com-
pounds, because there is a possibi-
lity that the titanium muffler finisher
coloring will be changed.
GT-R Overview
GTR-7

Cool downThe information and specifications in
this section apply only when engaging
in performance driving.
Cool down the vehicle to help extend the
life of the vehicle if coolant temperatures
are extremely high. Drive the vehicle at 37
to 50 MPH (60 to 80 km/h), in 5th or 6th
gear for 2 to 3 miles (3 to 5 km) and then
stop the engine.Refueling precautions
WARNING
Do not attempt to top off the fuel
tank after the fuel pump nozzle
shuts off automatically. Continued
refueling may cause fuel overflow,
resulting in fuel spray and possibly a
fire. The fuel tank is full at the first
automatic shutoff.
To maximize vehicle performance, the
fuel tank is located as low as possible to
lower the vehicle center of gravity. The
tank is also divided into two parts. This
fuel tank design causes higher pressures
inside the tank than other vehicles so fuel
spillage is possible by trying to top off the fuel tank after automatic shutoff.
The fuel tank pressure is higher when the
vehicle is hot, especially if the tank is more
than half full. If the cap is opened when
the vehicle is hot, it may cause fuel spray
and there may be a hissing noise. Open
the cap slowly, releasing the pressure
from the tank gradually. Also, if the
vehicle is refueled when the vehicle is
hot, the fuel pump may automatically
shut off before the tank is full. This does
not indicate that there is a malfunction.
Refuel slowly or refuel after the vehicle
has cooled.
INSPECTION AND ADJUSTMENTS
BEFORE DRIVINGThe information and specifications in
this section apply only when engaging
in performance driving.Fluids.
Check the engine, transmission, differ-
ential and under vehicle surfaces for
oil and coolant leaks.
. Check the fluid levels and adjust as
necessary using the specified fluid as
described under the conditions listed
in this section.(
“Recommended
fluids and maintenance interval” page GTR-20) If you do not drive under the
conditions listed, refer to the “9. Main-
tenance and schedules” section of this
manual.

to be 0.39 in (10
mm) (1/8 gal (0.5 liters))
below the H
mark on the engine oil dipstick. (
range is 1.18 in (30 mm).) Before
checking the oil level, run the engine
until it reaches operating temperature
and wait at least 5 minutes after
turning off the engine. Make sure the
oil level always remains above the L
mark.
When the vehicle is delivered, the
engine oil is set to

Check the coolant level in the pressurized
coolant reservoir. Adjust the level so that
the fluid is between the MAX and MIN
markings. For the coolant, use genuine
NISSAN Long Life coolant or equivalent.
(On delivery of new vehicle, the reservoir
is filled to the MIN level. Be sure to
replenish approximately 3/8 US quart
(0.3 to 0.4 liter) of coolant.)
NOTICE
Do not overfill the coolant. This may
increase the pressure in the cooling
system and cause coolant leaks.
To maximize vehicle performance, the
coolant mixture ratio should be a combi-
nation of 30% coolant antifreeze and 70%
demineralized or distilled water for max-
imum cooling system performance re-
gardless of ambient temperatures.
If ambient temperatures are anticipated
below 5°F (−15°C), make sure a proper
mixture ratio of 50% antifreeze and 50%
demineralized or distilled water mix is
used.Engine and powertrainThe information and specifications in
this section apply only when engaging in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks.
. Inspect the areas surrounding of the
catalytic converter for heat deteriora-
tion.
. Always perform the transmission
setting. After that, adjust the clutch
clearance so that the clearance is less
than the clearance used for daily
driving. Your GT-R certified NISSAN
dealer has the necessary information
and equipment to set the clutch
clearance to the correct specification.
The clearance used for daily driving
increases clutch heat generated dur-
ing Performance Driving. This leads to
an increase in temperature of the
transmission oil. In addition, a more
direct shifting feel can be obtained by
reducing the clutch clearance for
Performance Driving. The clutch clear-
ance should be reset to the daily
driving specification after Perfor-
mance Driving. It is recommended
you see a GT-R certified NISSAN dealer
for information.
NOTICE
Failure to have the clutch properly
adjusted before performance driving
may cause the transmission oil tem-
perature to increase which may
cause transmission damage.
. Inspect and confirm the clearance
between the exhaust finisher and rear
bumper is more than 0.24 in (6 mm)
(up/down) and more than 0.20 in (5
mm) (left/right).
. Inspect the dust boot of the drive
shaft universal joint for cracks or
damage.Suspension and wheel alignmentThe information and specifications in
this section apply only when engaging
in performance driving.
.Check the steering and suspension
system and other links for loose and/
or damaged parts.
. Measure and adjust the wheel align-
ment. (
“Wheel alignment” page
GTR-10) It is recommended you con-
tact a GT-R certified NISSAN dealer to
adjust the wheel alignment to the
recommended setting for high perfor-

in this section for 48 hours after tires
are installed on the wheels. The tire
may slip on the wheel if the vehicle is
driven in these conditions before 48
hours have passed. If the tire slips on
the wheel, the wheel/tire assembly
will be out of balance and will require
rebalancing.
BrakesThe information and specifications in
this section apply only when engaging
in performance driving.
.Check for the heat deterioration of the
brakes and parts around the brakes.
. It is recommended that you remove
air from the brake system after any of
the following:
— When engaging in high perfor-
mance driving for the first time
after purchasing a new vehicle.
— After replacing the brake fluid.
— When engaging in high perfor- mance driving for a sustained per-
iod of time. It is recommended that
bleeding the brake be performed
when the brake calipers are hot
(about 212°F (100°C)). Brake pad break-in procedure:
NISSAN recommends that a special brake
pad break-in procedure be performed
before engaging in performance driving.
It is recommended you contact a GT-R
certified NISSAN dealer for details.
INSPECTION AND ADJUSTMENTS
AFTER DRIVINGThe information and specifications in
this section apply only when engaging
in performance driving.
NOTICE
At the completion of performance
driving, all fluid and other adjust-
ments should be returned to the
normal fluid specifications as shown
in the “8. Do-it-yourself” section of
this manual.FluidsThe information and specifications in
this section apply only when engaging
in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks. .
Check the fluid levels and adjust as
necessary using the specified fluid as
described under the conditions listed
in this section. (
“Recommended
fluids and maintenance interval” page
GTR-20) If you do not drive under the
conditions listed, refer to the “9. Main-
tenance and schedules” section of this
manual.
. When changing fluids, be sure to use
the specified fluids as described in this
Owner’s manual. (“Capacities and
recommended fluids/lubricants” page
10-2)
GT-R Overview
GTR-19

to
position before the vehicle stops, you may not be able
to shift gear or it may take longer to shift gear. Make sure to depress the brake pedal and check that the vehicle has
stopped before shifting.
Multiple-disc wet
clutch
.
When stopping the vehicle with the shift lever in the
orposition. Move the shift lever after turning off the system check
display. Also, it is normal to hear clicking noises during the transmission systems check.
Changing modes
.
The higher shift speeds in the
position may result in shift shock and jerkiness when starting or shifting.
.
The quickest shifting in the R mode with the transmission in the
position is available when the engine speed is high.
However, the transmission may shift more slowly when the engine speed is low.
Mechanical Limited Slip
Differential (LSD) If the vehicle accelerates from a stop with the steering wheel turned half a turn in cold temperatures, the inner wheel tire
may slip and some noise or vibration may be heard. This phenomenon occurs because the viscosity of the differential oil
becomes thicker and the Limited Slip Differential (LSD) operates with increasing load. When the steering wheel is returned
to the straight ahead position or the differential oil warms up, the noise and vibration decrease.

is started.
If any malfunction occurs in the AWD
system while the engine is running, the
warning light will come on.
The warning light may blink rapidly
(about twice per second) while trying to
free a stuck vehicle due to high AWD
clutch temperature. The driving mode
may change to two-wheel drive. If the
warning light blinks rapidly during opera-
tion, stop the vehicle with the engine
idling in a safe place immediately. Then if
the light goes off after a while, you can
continue driving.
A large difference between the diameters
of front and rear wheels will make the
warning light blink slowly (about once per
two seconds). Pull off the road in a safe
area, and idle the engine. Check that all
tire sizes are the same, tire pressure is
correct and tires are not worn and winter
tires are not installed on the front or rear
wheels only.
If the warning light is blinking after the
above operation, it is recommended you
have your vehicle checked by a GT-R
certified NISSAN dealer as soon as possi-
ble.
If non-genuine GT-R tires are used, the
warning light may illuminate. (

, open the
reservoir cap (pressure type)and add
coolant up to between the MAX
and
MIN
level. If the reservoir is empty, open
the radiator filler cap
and check the
coolant level in the radiator when the
engine is cold. If there is insufficient
coolant in the radiator, fill the radiator
with coolant up to the filler opening and
also add it to the reservoir up to between
the MAX
and MIN
level. This vehicle contains Genuine NISSAN
Long Life Antifreeze/Coolant (blue). The
life expectancy of the factory-fill coolant
is 24,000 miles (38,400 km) or 2 years.
Mixing any other type of coolant or the
use of non-distilled water will reduce the
life expectancy of the factory-fill coolant.
Refer to the “9. Maintenance and sche-
dules” section of this manual for more
details.
If the cooling system frequently re-
quires coolant, it is recommended you
have it checked by a GT-R certified
NISSAN dealer.
Check that the level of coolant is between
MAX and MIN on the pressurized radiator
reservoir. If the level is below the mid-
point, the amount of coolant circulating
may be insufficient for maximum vehicle
performance, possibly causing engine
overheating or other trouble.
For the coolant level and mixture ratio
when engaging in performance driving,
see
“Coolant level and mixture ratio”
page GTR-15.
Except for NISMO models:
If it is difficult to determine the midpoint
between MAX and MIN, remove the cool-
ant reservoir cap and look inside through
the opening to check that the coolant
level is above the divider
between the
top half and bottom half of the pressur- ized coolant reservoir.
NOTICE
.
The coolant reservoir is equipped
with a pressure type cap, and the
radiator is equipped with a non-
pressure type cap. Do not switch
the radiator filler cap and the
coolant reservoir cap. Doing so
will cause substandard cooling
performance and overheating.
. If you have added only water as
the coolant in an emergency,
change it to a coolant mixture
ratio specified as soon as possi-
ble.CHANGING ENGINE COOLANTIf major cooling system repairs are re-
quired, it is recommended you contact a
GT-R certified NISSAN dealer. The service
procedures can be found in the appro-
priate NISSAN Service Manual.
Improper servicing can result in re-
duced heater performance and engine
overheating.
