2022 NISSAN GT-R stop start

of the following items:
.Gear clearances
. Ultralight flywheel
. Dry sump lubrication
These noises do not indicate that there is
a malfunction.
or
position to the
or
or
position while the vehicle is mov-
ing forward and
or
toposition before the vehicle stops,
you may not be able to shift gear
or it may take longer to shift gear.
Make sure to depress the brake
pedal and check that the vehicle
has stopped before shifting.
CAUTION
. Because the vehicle includes a
dual clutch transmission that
automatically controls the clutch
and shifting operation of the
manual transmission, whenever
the shift lever is in a position
other than
or
, the vehicle will
begin to move slowly, in the same
way as when the clutch in a
manual transmission vehicle is
partially engaged. Keep the brake
pedal firmly depressed when the vehicle is stopped. In some cir-
cumstances the vehicle may not
start moving on its own, however
this does not indicate that there
is a malfunction.
NOTICE
.
To avoid possible damage to your
vehicle; when stopping the vehi-
cle on an uphill grade, do not hold
the vehicle in place by depressing
the accelerator pedal. Doing so
may cause the clutch to overheat
and result in transmission da-
mage. Use the brakes to prevent
the vehicle from moving.
. The GT-R dual clutch transmis-
sion is provided with a dry sump
lubrication system that improves
efficiency and ensures reliability
under high g-force conditions.
When oil viscosity is high at low
temperatures, it takes longer for
all components to be sufficiently
lubricated. Thus, when the trans-
mission temperature is low (ap-
proximately 104°F (40°C), do not
accelerate rapidly or run the en-
gine faster than 4,000 rpm.

position to the
,
,or
to any other
position.
The shift lever cannot be moved out of
the
position and into any other position
with the ignition switch other in the LOCK,
OFF or ACC position.
When accelerating from a stopKeep the foot brake pedal depressed and
push the shift lever button to shift into a
driving gear as following:
Starting and driving
5-21

.To drive forward, move the shift lever
to the
position.
Starting on level ground or an uphill:
1. Check the shift lever position indicator on the meter to confirm that the
driving gear is selected.
2. Release the parking brake.
3. Release the foot brake pedal gradu- ally, then slowly depress the accelera-
tor pedal to start the vehicle in
motion.
(“R mode start function” page 5-33)
NOTE:
. To prevent the clutch from over-
heating when the parking brake is
applied, engine output is limited
when the accelerator pedal is de-
pressed. In particular, the vehicle
may not start smoothly when the
accelerator pedal is depressed with
the parking brake applied on an
uphill grade. To enable smooth
starting, release the parking brake
before moving the vehicle.
. The hill start assist system operates
when the vehicle is accelerating
from a stop on an uphill. (
“Hill
Start Assist System” page 5-39)
When driving the vehicle
WARNING
Do not move the shift lever to theposition while driving. Doing so may
result in an accident due to loss of
engine braking. It may also damage
the transmission.
Normal driving:
Drive with the shift lever in the
position.
The appropriate gear will be automati-
cally shifted according to the position of
the accelerator pedal, the driving speed
and driving conditions.
Passing:
.
position. This automatically shifts the
transmission into a lower gear and
maintains this position depending on
the gradient of the hill.
. The system may down shift according
to the accelerator pedal position and
the vehicle speed.
. If the transmission is frequently chan-
ging gears while driving, switch to theposition and select the appropriate
gear for the driving conditions.
Driving on a downhill:
.position and 4th or 3rd gear will
provide gentle engine braking.
When driving on a steep downhill, select-
ing the
position and 2nd or 1st gear will
provide powerful engine braking.

When parking the vehicle
position
and stop the engine. If the engine is
running and the shift lever is not in
the
position, the vehicle may start
moving due to partial engagement
of the clutch or to the effects of
gravity on a slope, or the vehicle may
suddenly accelerate due to acciden-
tal operation of the accelerator ped-
al, possibly causing an accident.
For models without NCCB (NISSAN Car-
bon Ceramic Brake) package:
WARNING
Follow the instructions below when
parking the vehicle to help prevent
the brake rotor and brake pads from
rusting together. Failure to follow
the instructions could cause the
rotor and pads to rust together. If
the rotor and pads rust together,
there may be a popping noise and
some vibration when the vehicle is
driven, a wheel may not roll correctly, or the brake pads could be damaged.
If the pads are damaged, this may
reduce the effectiveness of the brake
system which could cause a collision,
serious personal injury or death.
The GT-R uses brake pad materials that
have high metallic content. The brake pad
material helps maintain braking perfor-
mance in a wide range of weather and
driving conditions.
For the first 3,000 miles (5,000 km) of the
vehicle’s service life, and for the first 3,000
miles (5,000km) after a brake replace-
ment, the brake pad to brake rotor
clearance is very small. When parking,
apply the parking brake and move the
shift lever to the
position is selected.
5. Push the ignition switch to stop the engine.
For models with NCCB (NISSAN Carbon
Ceramic Brake) package:
(“NCCB (NISSAN Carbon Ceramic
Brake)” page 8-20)

NOTICE
When the vehicle is stopped on a hill,
do not hold the vehicle in place by
depressing the accelerator pedal.
Doing so may cause the clutch to
overheat and result in transmission
damage. Use the brakes to prevent
the vehicle from moving.
The hill start assist system automatically
keeps the brakes applied to help prevent
the vehicle from rolling backwards in the
time it takes the driver to release the
brake pedal and apply the accelerator
when the vehicle is stopped on a hill.
Hill start assist will operate automatically
under the following conditions:
. The shift lever is moved to a forward
or reverse position.
. The vehicle is stopped completely on a
hill by applying the brake.
The maximum holding time is 2 seconds.
After 2 seconds the vehicle will begin to
roll back and hill start assist will stop operating completely.
Hill start assist will not operate when the
shift lever is moved to the
or
position
or on a flat and level road.
NOTE:
This system does not function when the
Vehicle Dynamic Control VDC) system
warning appears on the vehicle infor-
mation display located in the tach-
ometer. (
“Vehicle Dynamic Control
(VDC) system warning” page 2-40)Starting and driving
5-39
HILL START ASSIST SYSTEM

is started.
If any malfunction occurs in the AWD
system while the engine is running, the
warning light will come on.
The warning light may blink rapidly
(about twice per second) while trying to
free a stuck vehicle due to high AWD
clutch temperature. The driving mode
may change to two-wheel drive. If the
warning light blinks rapidly during opera-
tion, stop the vehicle with the engine
idling in a safe place immediately. Then if
the light goes off after a while, you can
continue driving.
A large difference between the diameters
of front and rear wheels will make the
warning light blink slowly (about once per
two seconds). Pull off the road in a safe
area, and idle the engine. Check that all
tire sizes are the same, tire pressure is
correct and tires are not worn and winter
tires are not installed on the front or rear
wheels only.
If the warning light is blinking after the
above operation, it is recommended you
have your vehicle checked by a GT-R
certified NISSAN dealer as soon as possi-
ble.
If non-genuine GT-R tires are used, the
warning light may illuminate. (

wheels will lose even more trac-
tion.
. Allow more stopping distance
under these conditions. Braking
should be started sooner than on
dry pavement.
. Allow greater following distances
on slippery roads.
. Watch for slippery spots (glare
ice). These may appear on an
otherwise clear road in shaded
areas. If a patch of ice is seen
ahead, brake before reaching it.
Try not to brake while on the ice,
and avoid any sudden steering
maneuvers.
. Do not use the cruise control on
slippery roads.
. Snow can trap dangerous ex-
haust gases under your vehicle.
Keep snow clear of the exhaust
pipe and from around your vehi-
cle.
NOTE:
When driving on snow, select the SAVE
mode with the setup switch. By select-
ing the SAVE mode, the engine output is
controlled appropriately for snow or slippery road surfaces. This enables
the vehicle to start or accelerate
smoothly.
ENGINE BLOCK HEATER (if so
equipped)Engine block heaters are used to assist
with cold temperature starting.
The engine block heater should be used
when the outside temperature is 20°F
(−7°C) or lower.To use the engine block heater1. Turn the engine off.
2. Plug the engine block heater cord into
a grounded 3-wire, 3-pronged exten-
sion cord.
3. Plug the extension cord into a Ground Fault Interrupt (GFI) protected,
grounded 110-volt AC (VAC) outlet.
4. The engine block heater must be plugged in for at least 2 - 4 hours,
depending on outside temperatures,
to properly warm the engine coolant.
Use an appropriate timer to turn the
engine block heater on.
5. Before starting the engine, unplug and properly store the cord to keep it
away from moving parts.

.
NOTE:
Do not keep the starter motor en-
gaged for more than 10 seconds. If
the engine does not start right away,
push the ignition switch to the OFF
position and wait 10 seconds before
trying again.
7. After starting your engine, carefully disconnect the negative cable and
then the positive cable (
?
?“Removing the cowl top cover”
page 8-5) Do not attempt to start the engine by
pushing.
NOTICE
Your NISSAN cannot be push-started
or tow-started. Attempting to do so
may cause transmission damage.
WARNING
.
Do not continue to drive if your
vehicle overheats. Doing so could
cause engine damage or a vehicle
fire.
. To avoid the danger of being
scalded, never remove the radia-
tor filler cap and the coolant
reservoir cap while the engine is
still hot. When the cap is removed,
pressurized hot water will spurt
out, possibly causing serious in-
jury.
. Do not open the hood if steam is
coming out.
If your vehicle is overheating (indicated by
an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect unusual noise, etc., take the
following steps:
1. Move the vehicle safely off the road, apply the parking brake and move the
shift lever to the
position.
Do not stop the engine.
2. Turn off the air conditioner. Open all the windows, move the temperature
control to maximum hot and fan
PUSH STARTING IF YOUR VEHICLE OVERHEATS
