Driving Your Vehicle
6-54
Winter Precautions
Use high quality ethylene glycol coolant
Your vehicle is delivered with high
quality ethylene glycol coolant in the
cooling system. It is the only type of
coolant that should be used because it
helps prevent corrosion in the cooling
system, lubricates the water pump and
prevents freezing. Be sure to replace or
replenish your coolant in accordance
with the maintenance schedule in
chapter 9. Before winter, have your
coolant tested to assure that its freezing
point is sufficient for the temperatures
anticipated during the winter.
Check battery and cables
Winter temperatures affect battery
performance. Inspect the battery and
cables, as specified in chapter 9. The
battery charging level can be checked by
an authorized retailer of Genesis Branded
products or in a service station.
Change to “winter weight” oil if
necessary
In some regions during winter, it is
recommended to use the “winter
weight” oil with lower viscosity. In
addition, replace the engine oil and filter
if it is close to the next maintenance
interval. Fresh engine oil ensures
optimum engine operation during the
winter months. For further information,
refer to chapter 2. When you are not sure
about a type of winter weight oil, consult
an authorized retailer of Genesis Branded
products.Check spark plugs and ignition system
Inspect the spark plugs, as specified in
chapter 9. If necessary, replace them.
Also check all ignition wirings and
components for any cracks, wear-out,
and damage.
To prevent locks from freezing
To prevent the locks from being frozen,
spray approved de-icing fluid or glycerin
into key holes. When a lock opening is
already covered with ice, spray approved
de-icing fluid over the ice to remove it.
When an internal part of a lock freezes,
try to thaw it with a heated key. Carefully
use the heated key to avoid an injury.
Use approved window washer anti-
freeze solution in system
To prevent the window washer from
being frozen, add authorized window
washer anti-freeze solution, as specified
on the window washer container.
Window washer anti-freeze solution is
available from an authorized retailer of
Genesis Branded products, and most
vehicle accessory outlets. Do not use
engine coolant or other types of anti-
freeze solution, to prevent any damage
to the vehicle paint.
Maintenance
9-8
Normal Maintenance Schedule
MAINTENANCE
INTERVALS
MAINTENANCE
ITEMNumber of months or driving distance, whichever comes first
Months 12 24 36 48 60 72 84 96 108 120 132 144 156 168 180
Miles×1,000 6 12 18 24 30 36 42 48 54 60 66 72 78 84 90
Km×1,000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Engine oil and engine oil filter R R R R R R R R R R R R R R R
Fuel additives
*1
Add every 7,500 miles (1,390 km)
Rotate tires Rotate every 6,000 miles (10,000 km)
Cabin air filter (for evaporator and blower unit) Replace every 16,000 miles (24,000 km)
Air cleaner filterIRIRIRI
Spark plugs Replace every 42,000 miles (70,000 km)
Drive belts
*2
At first, inspect at 60,000 miles (100,000 km) or 72 months,
after that, inspect every 12,000 miles (20,000 km) or 24 months
Valve clearance
*3
Inspect every 60,000 miles (100,000 km) or 72 months
Vacuum hose I I I I I I I I I I I I I I I
I : Inspect and if necessary, adjust, correct, clean or replace.
R : Replace or change. *1 :
If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your
authorized retailer of Genesis Branded products along with information on how to use them. Do not mix other additives.
*2 :
The drive belt should be replaced when cracks occur or tension is reduced.
*3 :
Inspect for excessive valve noise and/or engine vibration and adjust if necessary. Have an authorized retailer of Genesis
Branded products perform the operation.
Maintenance
9-12
Maintenance Under Severe Usage Conditions
The following items must be serviced more frequently on cars normally used under
severe driving conditions. Refer to the chart below for the appropriate maintenance
intervals.
R : Replace or change.
I : Inspect and if necessary, adjust, correct, clean or replace.
Maintenance itemMaintenance
operationMaintenance intervalsDriving
condition
Engine oil and filter REvery 3,000 miles
(5,000 km) or 6 monthsA, B, C, D,
E, F, G, H, I,
J, K, L
Air cleaner filter IInspect more frequently
depending on the
conditionC, E
Spark plugs RReplace more
frequently depending
on the condition A, B, F, G,
H, I, K
Automatic transmission fluid REvery 60,000 miles
(100,000 km)A,C,E,F,G,
H,I,K
Front brake disc/pads, calipers IInspect more frequently
depending on the
conditionC, D, E, G,
H , J, K
Rear brake disc/pads IInspect more frequently
depending on the
conditionC, D, E, G,
H , J, K
Parking brake IInspect more frequently
depending on the
conditionC, D, G, H
Steering gear box, linkage & boots/
Lower arm ball joint, upper arm ball
jointIInspect more frequently
depending on the
conditionC, D, E,
F, G
Drive shafts and boots IEvery 3,000 miles
(5,000 km) or 6 monthsC, D, E, F,
G, H, I, J
Differential oil (front) (AWD) IEvery 72,000 miles
(120,000 km)C, E, G, H,
I, J
Differential oil (rear)Without LSD REvery 72,000 miles
(120,000 km)C, E, G, H,
I, J
With LSD REvery 36,000 miles
(60,000 km)C, E, G, H,
I, J
Cabin air filter
(for evaporator and blower unit)RInspect more frequently
depending on the
conditionC, E, G
Propeller shaft IEvery 3,000 miles
(5,000 km) or 6 monthsC, E
