EBU35255Fuse replacementThe main fuse, the fuel injection system fuse,
the EPS fuse, and the fuse box are located
under panel A. (See page 9-10.)If a fuse is blown, replace it as follows.1. Turn the key to “ ” (off) and turn off the electrical circuit in question.1. Main fuse
2. EPS fuse
3. Fuse box
4. Fuel injection system fuse
5. Fuel injection system spare fuse
12
3
4
5
1. Headlight fuse çHEADé
2. Signaling system fuse çSIGNALé
3. Four-wheel-drive motor fuse çDIFFé
4. Ignition fuse çIGNITIONé
5. Backup fuse çBACK UPé (for clock)
6. Radiator fan motor fuse çFANé
7. Spare fuse
8. Accessory fuse çACCé
9. Sub radiator fan motor fuse çFAN_2é
10.Auxiliary DC jack fuse çTERMINALé
1 234
5
6
7
8
9
10
