Description
24
Engine compartment
1
6
7
8
5
2 43
1
Air filter case
2 Spark plug/Ignition coil
3 Seat storage compartment (page 59)
4 Battery (page 72)
5 Fuel tank
6 Water separator (page 29)
7 Flushing hose connector (page 92)
8 Oil tank filler cap/Dipstick (page 64)
UF4N70E0.book Page 24 Tuesday, October 6, 2020 5:13 PM

Care and storage
96
Steering cable (jet thrust nozzle end)
VX / VX DELUXE / VX CRUISER / VX
LIMITED: Shift rod (reverse gate end) and ball joint
TIP:
Disconnect the shift rod from the ball joint be-
fore lubricating.
EJU46360Rustproofing
Rustproofing the hull, deck, and engine
Spray metallic parts of the hull, deck, and en-
gine with a rust inhibitor.
Rustproofing the internal engine compo-
nents
Rustproof the internal engine components
with a rust inhibitor.
To rustproof the internal engine components:
(1) Remove the seats. (See page 54 for seat removal and installation procedures.)
(2) Remove the plastic tie that is fastening the fuel hose to the holder on the star-
board side of the air filter case. (3) Release the hooks on the port side of the
air filter case, and remove the air filter
case cover.
(4) Spray a rust inhibitor into the intake opening for 3 seconds. WARNING! Do
not spray flammable rust inhibitor
products on engine surfaces while the
engine is hot. The sprayed substance
or propellants could catch fire.
[EWJ00262]
(5) Place the air filter case cover in its origi- nal position, and then fit the hooks onto
the cover.
TIP:
Make sure that the air filter case cover is se-
curely installed.
1Hook
2 Air filter case cover
3 Fuel hose
4 Plastic tie
5 Holder
1 Intake opening
2
1 3
4
5
1
UF4N70E0.book Page 96 Tuesday, October 6, 2020 5:13 PM

Maintenance
99
EJU43102Periodic maintenance chart
The periodic maintenance chart gives general guidelines for periodic maintenance. Have a
Yamaha dealer perform the checks in the following chart. However, maintenance may need to be performed more frequently depending on your operating conditions. If you have any
questions, consult a Yamaha dealer.
This “ √” mark indicates items to be checked and serviced by a Yamaha dealer.
Item OperationInitial Thereafter every
Page
10 hours 50 hours
or 12
months *1 100
hours or 12
months *1 200
hours or 24
months *1
Fuel line Check fuel hoses and
clamps
√
—
Fuel filler cap/Wa-
ter separator Check O-rings for cracks
and deformation
√
—
Fuel tank Check installation and
straps
√
—
Water inlet strainer Check for clogs and dam-
age
√
—
Cooling water hos-
es Check for damage and
leakage, and check
clamps
√
—
Engine oil Replace √√ 101
Oil filter Replace √101
Intermediate hous-
ing Lubricate
√—
Spark plugs Check √√ —
Battery Check state of charge,
terminals and bands
√
—
Battery leads Check terminals √—
Steering master Check operation and for
looseness
√√
—
Steering cable Check exterior and con-
nections, and lubricate
√
—
Shift rod and re-
verse gate (VX /
VX DELUXE /
VX CRUISER / VX
LIMITED) Check exterior and con-
nections, and lubricate
√
—
Air filter element Check for damage and
dirt
√
—
Air intake hoses Check for damage, and
check clamps
√
—
Throttle body Lubricate throttle valve √—
UF4N70E0.book Page 99 Tuesday, October 6, 2020 5:13 PM

Specifications
103
Recommended engine oil grade API:API SG, SH, SJ, SL
Fuel tank total capacity: 70 L (18.5 US gal, 15.4 Imp.gal)
Engine oil quantity with oil filter replacement:
3.4 L (3.59 US qt, 2.99 Imp.qt)
Engine oil quantity without oil filter replacement: 3.2 L (3.38 US qt, 2.82 Imp.qt)
Engine oil total quantity: 3.7 L (3.91 US qt, 3.26 Imp.qt)
UF4N70E0.book Page 103 Tuesday, October 6, 2020 5:13 PM

Trouble recovery
106
Watercraft slow or
loses powerWatercraft op-
eration mode
(VX DELUXE /
VX CRUISER /
VX LIMITED)Drive control mode
activatedDeactivate or adjust
drive control mode
36
Cavitation Jet intake clogged Clean 107
Impeller damaged or
worn Have serviced by
Yamaha dealer
107
Engine over-
heat warning Engine speed reduc-
tion control activated Clean jet intake and
cool engine
43, 50
Oil pressure
warning Engine speed reduc-
tion control activated Add oil
42, 51
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Incorrect heat range Have serviced by Yamaha dealer —
Gap incorrect Have serviced by Yamaha dealer —
Electrical wir-
ing Loose connection Have serviced by
Yamaha dealer —
Fuel Stale or contaminat-
ed Have serviced by
Yamaha dealer
—
Air filter Clogged Have serviced by
Yamaha dealer —
Oil buildup Have serviced by
Yamaha dealer —
Throttle lever Faulty Have serviced by
Yamaha dealer —
Audio system does
not activate
(equipped models) Fuse Burned out
Have serviced by
Yamaha dealer —
TROUBLE
POSSIBLE CAUSE REMEDYPAGE
UF4N70E0.book Page 106 Tuesday, October 6, 2020 5:13 PM
