Important manual information
EJU30193
To the owner/operator
Thank you for choosing a Yamaha watercraft.
This owner’s/operator’s manual contains in-
formation you will need for proper operation,
maintenance, and care. If you have any ques-
tions about the operation or maintenance of
your watercraft, please consult a Yamaha
dealer.
This manual is not a course on boating safety
or seamanship. If this is your first watercraft,
or if you are changing to a type of watercraft
you are not familiar with, for your own com-
fort and safety, please ensure that you obtain
proper training or practice before operating
the watercraft by yourself. In addition, a
Yamaha dealer or boating organization will be pleased to recommend local sea schools, or
competent instructors.
In this manual, information of particular im-
portance is distinguished in the following
ways:
This is the safety alert symbol. It is used
to alert you to potential personal injury haz-
ards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
EWJ00072
A WARNING indicates a hazardous situa-
tion which, if not avoided, could result in
death or serious injury.
ECJ00092
A NOTICE indicates special precautions
that must be taken to avoid damage to the
watercraft or other property.
TIP:
A TIP provides key information to make pro-
cedures easier or clearer.
EJU45451
Engine data recording
This model’s ECM stores certain engine data
to assist in the diagnosis of malfunctions and
for research, statistical analysis and develop-
ment purposes.
Although the sensors and recorded data will
vary by model, the main data points are:
Engine status and engine performance
data
This data will be uploaded only when a spe-
cial Yamaha diagnostic tool is attached to the
engine, such as when maintenance checks or
service procedures are performed. Engine
data uploaded will be handled appropriately
according to the following Privacy Policy.
Privacy Policy
Yamaha will not disclose this data to a third party except in the following cases. In addi-
tion, Yamaha may provide engine data to a
contractor in order to outsource services re-
lated to the handling of the engine data. Even
in this case, Yamaha will require the contrac-
tor to properly handle the engine data we
provided and Yamaha will appropriately
manage the data.
With the consent of the boat owner
Where obligated by law
For use by Yamaha in litigation
For general Yamaha-conducted research
purposes when the data is not related to an
individual engine or owner
https://www.yamaha-motor.eu/eu/
privacy/privacy-policy.aspx
UF3X72E0.book Page 2 Friday, May 29, 2020 10:09 AM

Table of contents
General and important labels ........... 1Identification numbers .................... 1
Primary Identification (PRI-ID)
number............................................ 1
Craft Identification Number (CIN) ....... 2
Engine serial number.......................... 2
Manufactured date label .................... 2
Model information ........................... 3
Builder’s plate .................................... 3
Important labels .............................. 4
Warning labels.................................... 5
Other labels ........................................ 8
Safety information ........................... 10 Limitations on who may operate the watercraft ............................. 10
Cruising limitations ........................ 11
Operation requirements ................ 12
Recommended equipment ........... 14
Hazard information........................ 15
Watercraft characteristics ............. 15
Wakeboarding and water-skiing ... 17
Safe boating rules ......................... 18
Enjoy your watercraft responsibly ................................. 19
Description....................................... 20 Watercraft glossary ....................... 20
Location of main components ...... 21
Control function operation ............. 25 Watercraft control functions ......... 25
Yamaha Security System ................. 25
Engine stop switch .......................... 26
Engine shut-off switch .................... 26
Start switch ..................................... 26
Throttle lever .................................... 27
RiDE lever ........................................ 27
Steering system ............................... 27
Adjustable tilt steering system ......... 28
Cooling water pilot outlets ............... 29
Water separator................................ 29
Watercraft operation ...................... 30Watercraft operation functions ..... 30
Shift system ..................................... 30
Electric trim system .......................... 32
Watercraft operation modes ......... 34
Reverse assist .................................. 34
T.D.E. (thrust directional
enhancer) ...................................... 34
No-wake mode ................................. 35
Drive control mode ........................... 36
Cruise assist ..................................... 38
Instrument operation ...................... 40 Multifunction information center ... 40
Operation buttons ............................ 41
Touch screen.................................... 41
Status area ....................................... 42
Home screen ................................... 42
Information screen .......................... 43
Drive control mode screen .............. 44
Setting menu screen ....................... 44
Engine lock screen .......................... 46
Warning function .............................. 46
Equipment operation ...................... 49Equipment..................................... 49
Seats ................................................ 49
Handgrip........................................... 50
Reboarding grip................................ 50
Reboarding step ............................... 50
Bow eye............................................ 51
Stern eyes ........................................ 51
Cleat ................................................. 51
Pull-up cleats (FX CRUISER SVHO /
FX LIMITED SVHO) ....................... 52
Storage compartments .................... 52
Fire extinguisher holder and cover ... 56
Optional part mounting bracket ....... 56
Operation and handling
requirements ................................... 57 Fuel requirements ......................... 57
Fuel................................................... 57
UF3X72E0.book Page 1 Friday, May 29, 2020 10:09 AM

General and important labels
1
EJU36452
Identification numbers
Record the Primary Identification (PRI-ID)
number, Craft Identification Number (CIN),
and engine serial number in the spaces pro-
vided for assistance when ordering spare
parts from a Yamaha dealer. Also record and
keep these ID numbers in a separate place in
case your watercraft is stolen.
EJU42521Primary Identification (PRI-ID) number
The PRI-ID number is stamped on a plate at-
tached inside the engine compartment. (See
page 49 for seat removal and installation pro-
cedures and page 55 for information on the
removable watertight storage compartment.)MODEL:
FC1800-W (FX SVHO)
FC1800A-W (FX CRUISER SVHO)
FC1800B-W (FX LIMITED SVHO)
1
Primary Identification (PRI-ID) number loca-
tion
1
MODELYAMAHA MOTOR CO.,LTD.
ASSEMBLED IN U.S.A. WITH FOREIGN AND DOMESTIC COMPONENTS.
ASSEMBLÉ EN U.S. AVEC DES COMPOSANTS ÉTRANGERS ET
DOMESTIQUES. PRI-I.D.
UF3X72E0.book Page 1 Friday, May 29, 2020 10:09 AM

Pre-operation checks
70
than 15 seconds without supplying water,
otherwise the engine could overheat.
Check the start switch, the engine stop
switch, and the engine shut-off switch for
proper operation. (See pages 26 to 26 for in-
formation on operating each switch.)
To check the operation of the switches:
(1) If the lock mode is selected for theYamaha Security System setting, selectthe unlock mode. (See page 25 for
Yamaha Security System setting proce- dures.)
(2) Push the start switch to make sure that the engine starts.
(3) As soon as the engine starts running, push the engine stop switch to make
sure that the engine stops immediately.
(4) Restart the engine, and then pull the en- gine shut-off cord (lanyard) to remove
the clip from the engine shut-off switch
to make sure that the engine stops im-
mediately.
EJU45370Electric trim system check
Turn on the multifunction information center,
and then operate the “TRIM/T.D.E.” switch-
es. Check that the jet thrust nozzle moves up and down properly and
that the trim setting
indicator and displayed setting level change
according to the operation of the switches.
(See page 40 for information on turning on
the multifunction information center without
starting the engine and page 32 for informa-
tion on the electric trim system.)
EJU40102Storage compartment checks
Make sure that the storage compartments
are not damaged and that water has not col-
lected in the compartments. (See page 52 for
information on the storage compartments.)
EJU41082Fire extinguisher holder, cover, and band
checks
Make sure that the fire extinguisher holder,
cover, and band are not damaged and that
the cover is securely held in place using the
band. (See page 56 for information on the fire
extinguisher holder, cover, and band.)
1 Clip
2 Engine shut-off switch
3 Start switch
4 Engine stop switch
5 Engine shut-off cord (lanyard)
12 3
5
4
0
UF3X72E0.book Page 70 Friday, May 29, 2020 10:09 AM

Trouble recovery
97
EJU34562
Troubleshooting
If you have any trouble with your watercraft, use the troubleshooting chart to check for the
possible cause.
If you cannot find the cause, consult a Yamaha dealer.
EJU45280Troubleshooting chart
Confirm the possible cause and remedy, and then refer to the applicable page.
TROUBLEPOSSIBLE CAUSE REMEDYPAGE
Engine does not
start (Starter motor
does not turn over) Ya m a h a S e -
curity System
Lock mode selected Select unlock mode
25
Engine shut-
off switch Clip not in place Install clip
26
Fuse Burned out Replace fuse and
check wiring 102
Battery Run down Recharge87
Poor terminal con-
nections Tighten as required
87
Terminal corroded Clean or replace 87
Starter motor Faulty Have serviced by
Yamaha dealer —
Engine does not
start (Starter motor
turns over) Throttle lever Squeezed
Release26
Faulty Have serviced by
Yamaha dealer —
RiDE lever Squeezed Release26
Faulty Have serviced by
Yamaha dealer —
Fuel Fuel tank empty Refill as soon as pos-
sible 57
Stale or contaminat-
ed Have serviced by
Yamaha dealer
—
Fuel tank Water or dirt present Have serviced by Yamaha dealer—
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Fuel injec-
tion system Fuel pump faulty Have serviced by
Yamaha dealer —
UF3X72E0.book Page 97 Friday, May 29, 2020 10:09 AM

Trouble recovery
99
Watercraft slow or
loses powerWatercraft
operation
modeDrive control mode
activated
Deactivate or adjust
drive control mode 36
Cavitation Jet intake clogged Clean 100 Impeller damaged or
worn Have serviced by
Yamaha dealer
100
Engine over-
heat warning Engine speed reduc-
tion control activated Clean jet intake and
cool engine
47
Oil pressure
warning Engine speed reduc-
tion control activated Add oil
48
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Incorrect heat range Have serviced by Yamaha dealer —
Gap incorrect Have serviced by Yamaha dealer —
Electrical wir-
ing Loose connection Have serviced by
Yamaha dealer —
Fuel Stale or contaminat- ed Have serviced by
Yamaha dealer
—
Incorrect octane
number Use correct fuel
57
Air filter Clogged Have serviced by Yamaha dealer—
Oil buildup Have serviced by Yamaha dealer —
Throttle lever Faulty Have serviced by Yamaha dealer—
TROUBLE POSSIBLE CAUSE REMEDY PAGE
UF3X72E0.book Page 99 Friday, May 29, 2020 10:09 AM

Index
107
Learning to operate your watercraft ........ 74
Leaving the watercraft ............................. 76
Limitations on who may operate the watercraft.............................................. 10
Long-term storage ................................... 89
Lubrication ............................................... 89
M
Main components, location of ................. 21
Maintenance ............................................ 91
Manufactured date label ............................ 2
Model information ...................................... 3
Multifunction information center .............. 40
Multifunction information center check ... 72
N
No-wake mode ........................................ 35
O
Operating in weeded areas ...................... 84
Operating the watercraft .......................... 76
Operating the watercraft in reverse or neutral ................................................... 79
Operating your watercraft ........................ 74
Operation buttons .................................... 41
Operation requirements ........................... 12
Optional part mounting bracket ............... 56
P
Periodic maintenance chart ..................... 93
Post-launch checks ................................. 72
Post-operation care ................................. 86
Pre-launch checks ................................... 66
Pre-operation check points ..................... 66
Pre-operation checklist ............................ 64
Primary Identification (PRI-ID) number ...... 1
Pull-up cleats (FX CRUISER SVHO / FX LIMITED SVHO) ............................... 52
R
Raising the reverse gate ........................ 101
Reboarding grip ....................................... 50
Reboarding step ...................................... 50
Recommended equipment ...................... 14
Removable watertight storage compartment ........................................ 55
Reverse assist .......................................... 34
RiDE lever................................................. 27
RiDE lever checks .................................... 69
Riding position ......................................... 75 Rustproofing ............................................ 90
S
Safe boating rules .................................... 18
Safety equipment check .......................... 71
Seats ........................................................ 49
Setting menu screen ................................ 44
Shift system ............................................. 30
Shift system check ................................... 72
Start switch .............................................. 26
Starting off ............................................... 82
Starting off from a trailer .......................... 83
Starting the engine on water .................... 75
Status area ............................................... 42
Steering system ....................................... 27
Steering system checks ........................... 68
Stern drain plug checks ........................... 71
Stern eyes ................................................ 51
Stern storage compartment ..................... 54
Stopping the engine ................................. 76
Stopping the watercraft ........................... 78
Storage compartment checks.................. 70
Storage compartments ............................ 52
Submerged watercraft ........................... 104
Switch checks .......................................... 69
T
T.D.E. (thrust directional enhancer) .......... 34
Throttle lever ............................................ 27
Throttle lever checks ................................ 69
Touch screen ........................................... 41
Towing the watercraft ............................ 104
Transporting on a trailer ........................... 62
Troubleshooting ....................................... 97
Troubleshooting chart .............................. 97
Turning the watercraft .............................. 77
W
Wakeboarding and water-skiing .............. 17
Warning function ...................................... 46
Water separator ....................................... 29
Water separator check ............................. 67
Watercraft characteristics ........................ 15
Watercraft control functions..................... 25
Watercraft operation functions ................ 30
Watercraft operation modes .................... 34
Y
Yamaha Security System ......................... 25
UF3X72E0.book Page 107 Friday, May 29, 2020 10:09 AM
