2021 TOYOTA C-HR tow

2744-5. Using the driving support systems
C-HR_OM_USA_OM10684U
After the vehicle ahead of you
starts off, push the lever up.
Your vehicle will also resume
follow-up cruising if the accelera-
tor pedal is depressed after the
vehicle ahead of you starts off.
Pulling the lever toward you
cancels the speed control.
The speed control is also canceled
when the brake pedal is
depressed.
(When the vehicle has been
stopped by system control,
depressing the brake pedal does
not cancel the setting.)
Pushing the lever up resumes the cruise control and returns veh icle
speed to the set speed.
Resuming follow-up cruising when the vehicle has been stopped
by system control (vehicle-to- vehicle distance control mode)
Canceling and resuming the speed control

2834-5. Using the driving support systems
4
Driving
C-HR_OM_USA_OM10684U
BSM (Blind Spot Monitor)
The Blind Spot Monitor is a system that uses rear side radar sensors
installed on the inner side of the rear bumper on the left and right side
to assist the driver in confir ming safety when changing lanes.
Outside rear view mirror indicators
When a vehicle is detected in a blind spot of the outside rear view mirrors
or approaching rapidly from behind into a blind spot, the outsi de rear view
mirror indicator on the detected side will illuminate. If the t urn signal lever
is operated toward the detected side, the outside rear view mir ror indicator
flashes.
BSM OFF indicator
Illuminates when the Blind Spot Monitor is disabled.
: If equipped
Summary of the Blind Spot Monitor

2994-5. Using the driving support systems
4
Driving
C-HR_OM_USA_OM10684U●
Instances of the RCTA function unnecessarily detecting a vehicl e and/or
object may increase in the following situations:
• When a vehicle passes by the side of your vehicle
• When the distance between your vehicle and metal objects, such as a
guardrail, wall, sign, or parked vehicle, which may reflect electrical waves
toward the rear of the vehicle, is short
• When the parking space faces a
street and vehicles are being driven
on the street

3285-3. Using the storage features
C-HR_OM_USA_OM10684U
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
FrontRear
WARNING
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottl es in the bot-
tle holders, or glass or paper cups containing liquid. The cont ents may spill
and glass cups may break.

3315-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Lift the deck mat tab and pull it
toward you to remove it.
Auxiliary boxes
Side auxiliary boxes

3325-3. Using the storage features
C-HR_OM_USA_OM10684U
Hard type
Unhook the cords and return
the luggage cover to horizontal
position.
Ty p e A
Pull it toward you and then lift
the luggage cover to remove
it.
Installation position
Confirm that the cover has
been securely installed to the
original position when install-
ing.
Removal position
Ty p e B
Lift the luggage cover and
pull it toward you to remove
it.
Confirm that the cover has been
securely installed to the original
position when installing.
Luggage cover
1
2
2

3335-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Soft type
■Removing the luggage cover
Unhook the cords.
Unhook the hook to the hook
brackets.
■Stowing the luggage cover
Hold the luggage cover with
both hands. Point your
thumbs in opposite direc-
tions.
1
2
1

3345-3. Using the storage features
C-HR_OM_USA_OM10684U
Bend one side of the cover
towards you.
Twist the other side in the
opposite direction, as shown
in the illustration.
Make a small circle, then fold
it inward.
Make sure the three circles
are side by side.2
3
4
5
