2021 NISSAN MAXIMA engine coolant

110,000 miles/(176,000 km)/
132 months
Perform at number of miles, kilometers or
months, whichever comes first.
Standard maintenance:
Not Applicable. Proceed to next interval
Severe maintenance:
Inspections:
• Brake pads & rotors
• Exhaust system
• Front drive shaf t boots
• Steering gear & linkage
• Axle & suspension parts
• Horn, lights, signals, wipers, rear hatch/hood lif t supports
• All fluids inspected (engine, wiper, brake, power steering, coolant)
• Hose inspections
• Engine air filter
• Suspension components (shocks, sub- frame, tie rods)
• Battery terminals and cables, battery test
• Tire pressure, treadwear and depth
Essential:
• Replace engine oil & filter
• Replace brake fluid
112,500 miles/(180,000 km)/
90 months
Perform at number of miles, kilometers or
months, whichever comes first.
Standard maintenance:
Inspections:
• Horn, lights, signals, wipers, rear hatch/ hood lif t supports
• All fluids inspected (engine, wiper, brake, power steering, coolant)
• Hose inspections
• Engine air filter
• Suspension components (shocks, sub- frame, tie rods)
• Battery terminals and cables, battery test
• Tire pressure, treadwear and depth
Essential:
• Replace engine oil & filter
• Replace intelligent key battery
• Tire rotation
Severe maintenance:
Not Applicable. Proceed to next interval
115,000 miles/(184,000 km)/
138 months
Perform at number of miles, kilometers or
months, whichever comes first.
Standard maintenance:
Not Applicable. Proceed to next interval
Severe maintenance:
Inspections:
• Brake pads & rotors
• Exhaust system
• Front drive shaf t boots
• Steering gear & linkage
• Axle & suspension parts
• Horn, lights, signals, wipers, rear hatch/ hood lif t supports
• All fluids inspected (engine, wiper, brake, power steering, coolant)
• Hose inspections
• Engine air filter
• Suspension components (shocks, sub- frame, tie rods)
• Battery terminals and cables, battery test
• Tire pressure, treadwear and depth
Essential:
• Replace engine oil & filter
Maintenance and schedules9-23

120,000 miles/(192,000 km)/
96 months
Perform at number of miles, kilometers or
months, whichever comes first.
Standard maintenance:
Inspections:
• Brake lines and cables
• Brake pads and rotors
• CVT transmission fluid
• Engine drive belts*
• Fuel tank vapor vent system*
• Fuel lines/connections*
• Exhaust system
• Front drive shaf t boots
• Steering gear and linkage
• Axle and suspension parts
• Horn, lights, signals, wipers, rear hatch/hood lif t supports
• All fluids inspected (engine, wiper, brake, power steering, coolant)
• Hose inspections
• Suspension components (shocks, sub- frame, tie rods)
• Battery terminals and cables, battery test
• Tire pressure, treadwear and depth Essential:
• Replace engine air filter (1)
• Replace brake fluid
• Replace engine oil & filter
• Replace in-cabin microfilter
• Tire rotation
Severe maintenance:
Not Applicable. Proceed to next interval
(1) If operating mainly in dusty conditions,
more frequent maintenance may be
required.
* Maintenance items and intervals with “*”
are recommended by NISSAN for reliable
vehicle operation. The owner need not per-
form such maintenance in order to main-
tain the emission warranty or manufac-
turer recall liability. Other maintenance
items and intervals are required.
9-24Maintenance and schedules

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure
described in the “Do-it-yourself ” section to determine the proper refill capacity.
Fluid typeCapacity (approximate)
Recommended Fluids/Lubricants
Metric
Measure US
Measure Imperial
Measure
Fuel 68 L 18 gal 15 gal • For additional information, see “Fuel recommendation” (P. 10-3).
Engine oil*1
Drain and refill
*1: For additional information, see
“Engine oil” (P. 8-6). With oil filter
change 4.8 L 5-1/8 qt 4-1/4 qt • Genuine “NISSAN Motor Oil 0W-20 SN” (or equivalent) is recom-
mended.
• If the above motor oil (or engine oil) is not available, a synthetic
0W-20 GF-5 SN motor oil (or engine oil) may be used. Damage
caused by the use of motor oil (or engine oil) other than as rec-
ommended is not covered under NISSAN’s New Vehicle Limited
Warranty. For additional information, see “Engine oil and oil filter
recommendation” (P. 10-6).
Without oil
filter change 4.5 L 4-3/4 qt 4 qt
Engine coolant
with reservoir 9.2 L 2-3/8 gal 2 gal• Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue)
or equivalent
Continuously Variable Transmission (CVT) fluid — — — • Genuine NISSAN CVT Fluid NS-3
• NISSAN recommends using Genuine NISSAN CVT Fluid NS-3 (or
equivalent) ONLY in NISSAN CVTs. Do not mix with other fluids.
Using fluids that are not equivalent to Genuine NISSAN CVT Fluid
NS-3 may damage the CVT. Damage caused by the use of fluids
other than as recommended is not covered under NISSAN's
New Vehicle Limited Warranty outlined in your Warranty Infor-
mation Booklet.
Power Steering Fluid (PSF) — — — • Genuine NISSAN E-PSF or equivalent.
• Use of a power steering fluid other than Genuine NISSAN E-PSF
may prevent the power steering system from operating prop-
erly.
Brake fluid reservoir 0.49 L 1/2 qt 3/8 qt • Genuine NISSAN Super Heavy Duty Brake Fluid*2 or equivalent
DOT 3
*2: Available in mainland U.S.A through a NISSAN dealer.
Multi-purpose grease — — — • NLGI No. 2 (Lithium Soap base)
RECOMMENDED FLUIDS/
LUBRICANTS AND CAPACITIES
10-2Technical and consumer information

Continuously Variable Transmission
(CVT).......................5-16Continuously Variable Transmission (CVT)
fluid......................8-10Driving with Continuously Variable
Transmission (CVT)............5-16Control panel and vehicle information
display interaction..............2-32ControlsHeater and air conditioner controls. .4-29CoolantCapacities and recommended
fuel/lubricants
...............10-2Changing engine coolant.........8-5Checking engine coolant level......8-5Engine coolant temperature gauge. . .2-6Corrosion protection..............7-9Cruise control................ .5-54Cup holders................. .2-64
D
Daytime Running Light System......2-50Defroster switch
Rear window and outside mirror
defroster switch
..............2-45Dimensions and weights..........10-9Dimmer switch for instrument panel. . .2-50DisplayInformation display............2-17Door locks................... .3-4Drive belt....................8-15Drive Mode Selector..............5-21
Drive Sport Mode Selector..........5-21Driving
Cold weather driving...........5-120Driving with Continuously Variable
Transmission (CVT)............5-16Precautions when starting and
driving.................... .5-4Driving the vehicle...............5-16Dynamic driver assistance switch.....2-56
E
E-call (SOS) Button..............2-59Economy - fuel................5-110Emergency engine shutoff.......5-13,6-2Emission control information label. . . .10-11Emission control system warranty. . . .10-20Engine
Before starting the engine........5-14Capacities and recommended
fuel/lubricants...............10-2Changing engine coolant.........8-5Changing engine oil............8-6Changing engine oil filter.........8-6Checking engine coolant level......8-5Checking engine oil level.........8-6Engine compartment check
locations.................. .8-3Engine coolant temperature gauge. . .2-6Engine cooling system...........8-4Engine oil...................8-6Engine oil and oil filter
recommendation..........10-2, 10-6
Engine oil pressure warning light. . . .2-10Engine oil viscosity.............10-6Engine serial number...........10-11Engine specifications...........10-8Starting the engine............5-14Engine coolant temperature gauge. . . .2-6Event Data recorders............10-22Exhaust gas (Carbon monoxide)......5-4Explanation of maintenance items.....9-2Explanation of scheduled maintenance
items...................... .9-5Extended storage switch..........2-60Eyeglass case.................2-63
F
F.M.V.S.S. certification label.........10-11Flashers (See hazard warning flasher
switch)......................6-2Flat tire.................. .6-3, 6-4Floor mat positioning aid...........7-8Fluid
Brake fluid..................8-11Capacities and recommended
fuel/lubricants...............10-2Continuously Variable Transmission
(CVT) fluid..................8-10Engine coolant................8-4Engine oil.................. .8-6Power steering fluid............8-11Windshield-washer fluid.........8-12Fog light switch................2-51Folding rear seat................1-5
11-2

Front air bag system
(See supplemental restraint system). . .1-51Front and rear sonar system.......5-116Front power seat adjustment........1-3Front seats....................1-2Front-door pocket...............2-61FuelCapacities and recommended
fuel/lubricants
...............10-2Fuel economy...............5-110Fuel gauge................. .2-6Fuel octane rating.............10-5Fuel recommendation.......10-2, 10-3Fuel-filler cap................3-23Fuel-filler lid.................3-23Loose fuel cap warning..........2-27Fuel efficient driving tips..........5-109Fuel gauge................... .2-6Fuel-filler door.................3-22Fuses.......................8-19Fusible links..................8-20
G
Garage door opener, HomeLink® Universal
Transceiver.........2-73,2-74,2-76,2-77Gas cap.....................3-23Gauge
Engine coolant temperature gauge. . .2-6Fuel gauge................. .2-6Odometer.................. .2-5Speedometer................2-4Tachometer.................2-5
Trip odometer................2-5General maintenance.............9-2Glove box................... .2-62Glove box lock.................2-62
H
Hazard warning flasher switch........6-2Head restraints.................1-7Headlight and turn signal switch.....2-45Headlight control switch..........2-45Headlights...................8-23Heated rear seats...............2-55Heated seat switches............2-54Heated seats..............2-52, 2-54Heated steering wheel............2-56Heater
Heater and air conditioner (automatic)
(if so equipped)
...............4-28Heater and air conditioner controls. .4-29Heater operation.............4-30Heater and air conditioner
(automatic)...................4-28HomeLink® Universal
Transceiver.........2-73,2-74,2-76,2-77Hood.......................3-20Horn...................... .2-52
I
Ignition Switch
Push-button ignition switch.......5-10Immobilizer system..........2-41, 5-14
Important vehicle information label. . .10-11In-cabin microfilter..............8-17Increasing fuel economy..........5-110IndicatorNISSAN Intelligent Key® battery discharge
indicator
...................5-13Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)
................... .2-8Inside automatic anti-glare mirror.....3-27Instrument brightness control.......2-50Instrument panel.............0-6, 2-2Instrument panel dimmer switch.....2-50Integrated Dynamics-control Module. .5-115Intelligent Around View Monitor......4-10Intelligent Cruise Control (ICC).......5-56Intelligent Drive Alertness (I-DA)......5-106Intelligent Engine Brake (I-EB).......5-115Intelligent Forward Collision Warning
(I-FCW)..................... .5-95Intelligent Key system
Key operating range............3-8Key operation................3-9Mechanical key................3-3Remote keyless entry operation. . . .3-13Troubleshooting guide..........3-16Warning signals...............3-16Intelligent Lane Intervention (I-LI).....5-30Intelligent Trace Control (I-TC).......5-115Interior light...................2-71Interior trunk lid release...........3-21ISOFIX child restraints.............1-24
11-3

SeatMemory seat.............3-30, 3-32Seat adjustmentFront power seat adjustment.......1-3Seat beltChild safety.................1-20Infants and small children.....1-20,1-21Injured person................1-14Larger children...............1-21Precautions on seat belt usage.....1-11Pregnant women..............1-14Seat belt extenders............1-19Seat belt maintenance..........1-19Seat belts................1-11,7-8Shoulder belt height adjustment. . . .1-18Three-point type with retractor.....1-15Seat belt extenders..............1-19Seat belt warning light.........1-14,2-10Seatback pockets...............2-61SeatsAdjustment..................1-2Armrests....................1-7Front seats..................1-2Heated seats............2-52, 2-54Rear seat.................. .1-5Security indicator light............2-10Security system (NISSAN Vehicle Immobilizer
System), engine start.........2-41, 5-14Security systems
Vehicle security system.........2-39Self-adjusting brakes.............8-18Service manual order form........10-22Servicing air conditioner...........4-32
Shif tingContinuously Variable Transmission
(CVT)
.....................5-17Shoulder belt height adjustment......1-18Spark plug replacement...........8-16Spark plugs...................8-16Specifications................ .10-8Speedometer................. .2-4Spotlights (See map light)..........2-72SRS warning label...............1-64Stability control................5-113Standard maintenance............9-8Starting
Before starting the engine........5-14Jump starting.............6-9, 8-15Precautions when starting and
driving.................... .5-4Push starting................6-11Starting the engine............5-14Starting the engine..............5-14Steering
Heated steering wheel..........2-56Power steering fluid............8-11Power steering system.........5-112Steering wheel.................3-24Stop light....................8-24Storage.................... .2-61Storage tray..................2-62Sun visors....................3-26Sunglasses case...............2-63Sunglasses holder..............2-63Sunroof..................2-68, 7-7Supplemental air bag warning
light................... .1-64, 2-10
Supplemental front impact air bag
system..................... .1-51Supplemental restraint system
Information and warning labels.....1-64Precautions on supplemental restraint
system................... .1-43Supplemental restraint system
(Supplemental air bag system).......1-43Switch
Autolight switch..............2-46Automatic power window switch. . .2-67Fog light switch...............2-51Hazard warning flasher switch......6-2Headlight and turn signal switch. . . .2-45Headlight control switch.........2-45Instrument brightness control.....2-50Power door lock switch..........3-6Rear window and outside mirror defroster
switch................... .2-45Turn signal switch.............2-51
T
Tachometer...................2-5Temperature gauge
Engine coolant temperature gauge. . .2-6Thef t (NISSAN Vehicle Immobilizer System),
engine start...............2-41, 5-14Three-way catalyst...............5-4TireFlat tire................. .6-3, 6-4Spare tire................6-5, 8-37Tire and Loading Information label. .10-12
11-6
