2021 NISSAN GT-R warning light

OPENING AND CLOSING THE
TRUNKWhen opening the trunk, first unlock it
then lift up the trunk lid so that it is fully
open.
When closing the trunk, lower the trunk
lid and press it until it is securely locked in
place. The strap
(except for carbon
trunk lid models) or the handle
(for
carbon trunk lid models) can be used
when the trunk lid is dirty.
NOTICE
. Open and close the trunk without
grasping the rear spoiler. Grasp-
ing the rear spoiler to open or
close the trunk may damage the
spoiler.
. Do not leave the key inside the
trunk.
NOTE:
. To prevent the Intelligent Key from
being accidentally locked in the
trunk, lockout protection is
equipped with the Intelligent Key
system. When the trunk lid is closed
with the Intelligent Key inside the
trunk, the outside buzzer will sound and the trunk will open.
. The trunk of this vehicle is slightly
more difficult to close than an or-
dinary vehicle (particularly when the
vehicle is new). This is because the
trunk rigidity has been increased to
handle the high load on the rear
spoiler during vehicle operation.
This does not indicate that there is
a malfunction. Check that the trunk
is securely locked.
EMERGENCY TRUNK LID RELEASE
WARNING
Closely supervise children when they
are around cars to prevent them
from playing and becoming locked
in the trunk where they could be
seriously injured. Keep the car
locked, with the trunk lid securely
latched, when not in use, and pre-
vent children’s access to Intelligent
Keys.
The emergency trunk lid release mechan-

WARNING
Do not attempt to top off the fuel
tank after the fuel pump nozzle
shuts off automatically. Continued
refueling may cause fuel overflow,
resulting in fuel spray and possibly a
fire. The fuel tank is full at the first
automatic shutoff.
To maximize vehicle performance, the
fuel tank is located as low as possible to
lower the vehicle center of gravity. The
tank is also divided into two parts. This
fuel tank design causes higher pressures
inside the tank than other vehicles so fuel
spillage is possible by trying to top off the
fuel tank after automatic shutoff.
The fuel tank pressure is higher when the
vehicle is hot, especially if the tank is more
than half full. If the cap is opened when
the vehicle is hot, it may cause fuel spray
and there may be a hissing noise. Open
the cap slowly, releasing the pressure
from the tank gradually. Also, if the
vehicle is refueled when the vehicle is
hot, the fuel pump may automatically
shut off before the tank is full. This does
not indicate that there is a malfunction. Refuel slowly or refuel after the vehicle
has cooled.
GASOLINE SMELLThe fuel temperature is higher when the
vehicle is hot. This may cause a gasoline
smell from the vehicle. This does not
indicate that there is a malfunction. The
smell will go away when the fuel tem-
perature has cooled.OUTSIDE TEMPERATURE DISPLAY
INDICATES HIGHER TEMPERATUREHeat from the engine compartment, ra-
diator and intercoolers can affect the
outside temperature display. The outside
temperature display may indicate a high-
er than actual temperature while driving
or stopped. This is normal.IDLE SPEED IS NOT STEADYThe idle speed may not be steady when
the engine compartment is extremely
hot. This is normal. The engine speed will
be steady when the engine cools down.
In this case, the Malfunction Indicator
Light (MIL) may come on. After a few
driving trips, the MIL should turn off. If the
light remains on after a few driving trips, it
is recommended you have the vehicle
inspected by a GT-R certified NISSAN
dealer.
GT-R Overview
GTR-25
GT-R SPECIFIC VEHICLE CHARACTERISTICS

0 Illustrated table of contentsSeats, seat belts and Supplemental Restraint
System (SRS).................................................................................... 0-2
Front ................................................................................................ 0-2
Rear .................................................................................................. 0-3
Exterior front ................................................................................... 0-4
Exterior rear ..................................................................................... 0-6 Passenger compartment ...................................................... 0-7
Cockpit ................................................................................................ 0-8
Instrument panel ........................................................................ 0-9
Meters and gauges ................................................................ 0-10
Engine compartment ........................................................... 0-11
Warning and indicator lights .......................................... 0-12

NOTICE
.When the temperature of the
engine coolant and transmission
oil is high or low, the function
cannot be used. The temperature
range in which the R mode start
function can be used:
— Engine coolant: 140°F - 212°F
(60°C - 100°C)
— Transmission oil: 140°F - 266°F (60°C - 130°C)
. If the R mode start function is
used 4 times consecutively, the
function may be disabled and
cannot be turned on to protect
the vehicle system. While the function is disabled, the warning
light illuminates. When the warn-
ing light illuminates, perform cool
down driving. (
“Cool down”
page GTR-14) When the warning
light turns off, the function can be
used again.
. The performance of start may
vary depending on the amount
of wheel spin ,or increase and
decrease of the engine output in
response to the outside tempera-
ture. (This vehicle was set up
according to the road surface
conditions of the straight sec-
tions of the Sendai Highland Ra-
ceway course in Japan at 59°F
(15°C).)
. For safety reasons, VDC control
may activate automatically when
driving on a slippery road surface,
such as a wet road, in order to
apply the brakes or limit the
engine output.
. Frequent use of the R mode start
function increases the load on
the powertrain related parts such
as the clutch and transmission
compared to normal driving. In
particular, the clutch will wear out
Starting and driving
5-33
R MODE START FUNCTION

Do not use the cruise control when
driving under the following condi-
tions. Doing so could cause a loss of
vehicle control and result in an acci-
dent.
.When it is not possible to keep
the vehicle at a set speed.
. In heavy traffic or in traffic that
varies in speed.
. On winding or hilly roads.
. On slippery roads (rain, snow, ice,
etc.).
. In very windy areas.
NOTE:
. When the SAVE mode is selected
with the transmission setup switch,
the acceleration and deceleration
can be controlled smoothly. When
the SAVE mode is selected, the
maximum setting speed is lower
than the one in the normal mode. When the vehicle approaches a gen-
tle uphill, there may be a slight delay
as the vehicle returns to the preset
speed. However, the vehicle will
gradually accelerate and return to
the preset speed.
PRECAUTIONS ON CRUISE CON-
TROL.
If the cruise control system malfunc-
tions, it will cancel automatically. The
SET indicator will blink and the cruise
control system warning will appear to
warn the driver. (
“Cruise control
system warning” page 2-43)
. If the engine coolant temperature
becomes excessively high, the cruise
control system will be canceled auto-
matically.
. If the SET indicator blinks, turn the
cruise control main switch off and it is
recommended you contact a GT-R
Starting and driving
5-35
CRUISE CONTROL

is started.
If any malfunction occurs in the AWD
system while the engine is running, the
warning light will come on.
The warning light may blink rapidly
(about twice per second) while trying to
free a stuck vehicle due to high AWD
clutch temperature. The driving mode
may change to two-wheel drive. If the
warning light blinks rapidly during opera-
tion, stop the vehicle with the engine
idling in a safe place immediately. Then if
the light goes off after a while, you can
continue driving.
A large difference between the diameters
of front and rear wheels will make the
warning light blink slowly (about once per
two seconds). Pull off the road in a safe
area, and idle the engine. Check that all
tire sizes are the same, tire pressure is
correct and tires are not worn and winter
tires are not installed on the front or rear
wheels only.
If the warning light is blinking after the
above operation, it is recommended you
have your vehicle checked by a GT-R
certified NISSAN dealer as soon as possi-
ble.
If non-genuine GT-R tires are used, the
warning light may illuminate. (

WARNING
Do not attempt to top off the fuel
tank after the fuel pump nozzle
shuts off automatically. Continued
refueling may cause fuel overflow,
resulting in fuel spray and possibly a
fire. The fuel tank is full at the first
automatic shutoff.
To maximize vehicle performance, the
fuel tank is located as low as possible to
lower the vehicle center of gravity. The
tank is also divided into two parts. This
fuel tank design causes higher pressures
inside the tank than other vehicles so fuel
spillage is possible by trying to top off the
fuel tank after automatic shutoff.
The fuel tank pressure is higher when the
vehicle is hot, especially if the tank is more
than half full. If the cap is opened when
the vehicle is hot, it may cause fuel spray
and there may be a hissing noise. Open
the cap slowly, releasing the pressure
from the tank gradually. Also, if the
vehicle is refueled when the vehicle is
hot, the fuel pump may automatically
shut off before the tank is full. This does
not indicate that there is a malfunction. Refuel slowly or refuel after the vehicle
has cooled.
GASOLINE SMELLThe fuel temperature is higher when the
vehicle is hot. This may cause a gasoline
smell from the vehicle. This does not
indicate that there is a malfunction. The
smell will go away when the fuel tem-
perature has cooled.OUTSIDE TEMPERATURE DISPLAY
INDICATES HIGHER TEMPERATUREHeat from the engine compartment, ra-
diator and intercoolers can affect the
outside temperature display. The outside
temperature display may indicate a high-
er than actual temperature while driving
or stopped. This is normal.IDLE SPEED IS NOT STEADYThe idle speed may not be steady when
the engine compartment is extremely
hot. This is normal. The engine speed will
be steady when the engine cools down.
In this case, the Malfunction Indicator
Light (MIL) may come on. After a few
driving trips, the MIL should turn off. If the
light remains on after a few driving trips, it
is recommended you have the vehicle
inspected by a GT-R certified NISSAN
dealer.
GT-R Overview
GTR-25
GT-R SPECIFIC VEHICLE CHARACTERISTICS

or the brake
warning light comes on, add Genuine
NISSAN Brake Fluid R35 Special II fluid (or
equivalent) up to the MAX line
. If fluid
must be added frequently, the system
should be checked. It is recommended
you contact a GT-R certified NISSAN deal-
er.
