2021 NISSAN GT-R key

until the lock
releases and push up on the trunk lid.
The release lever is made of a material
that glows in the dark after a brief
exposure to ambient light.
The handle is located on the back of the
trunk lid as illustrated.
2. Insert the mechanical key into the
emergency trunk lid opener and turn
it clockwise until it stops.
NOTE:
Because the trunk rigidity has been
increased to handle the high load on
the rear spoiler during vehicle opera-
tion, more force is required to operate
the mechanical key (particularly when
the vehicle is new). Be sure to turn the
key clockwise until it stops.Pre-driving checks and adjustments
3-23

2. Press the rear side of the fuel-fillerdoor to release the door lock, and
open the door.
3. Turn the cap
slowly counterclock-
wise to remove it.
During refueling, place the cap on the
inside of the door
.
CLOSING THE FUEL-FILLER DOOR1. Turn the cap clockwise until a single click sound is heard.
2. Close the door. Lock the fuel-filler door by using one of the following
operations.
. Push the door handle request switch
with the Intelligent Key carried with
you.
. Push the LOCK button on the Intelli-Pre-driving checks and adjustments
3-25

HOW TO TURN ON AND OFF PRE-
DICTIVE COURSE LINESIf the RearView Monitor is in operation
and the rear view is displayed, turn on
and off the predictive course line setting
according to the following procedure.
1. Touch the touch screen display.
2. Touch the “Predictive Course Lines”key to turn the feature on or off.
If the RearView Monitor is not in opera-
tion, change the setting according to the
following procedure.
1. Touch the “Settings” key on theLaunch Bar
on the touch screen
display.
2. Touch the “Camera” key.
3. Touch the “Predictive Course Lines” key. The indicator illuminates when
the item is turned on.
SONAR INDICATORThe sonar indicator will appear in the
RearView Monitor display. (
“Sonar
system” page 5-48)
REARVIEW MONITOR SYSTEM LIM-
ITATIONS
WARNING
Listed below are the system limita-
tions for RearView Monitor. Failure to
operate the vehicle in accordance
with these system limitations could
result in serious injury or death.
. The system cannot completely
eliminate blind spots and may
not show every object.
. Underneath the bumper and the
corner areas of the bumper can-
not be viewed on the RearView
Monitor because of its monitoring
range limitation. The system will
not show small objects below the
bumper, and may not show ob-
jects close to the bumper or on
the ground.
. Objects viewed in the RearView
Monitor differ from actual dis-
tance because a wide-angle lens
Display screen, heater, air conditioner and audio systems
4-7

position.NOTE:
.
If the steering lock release malfunc-
tion indicator appears on the vehicle
information display when the igni-
tion switch is pressed, press the
ignition switch again while gently
turning the steering wheel left and
right. (
“Steering lock release
malfunction indicator” page 2-47)
. If the shiftwarning appears on the
vehicle information display when
the ignition switch is pushed, the
shift lever is in any position except
the
position. Move the shift lever
to the
position. (
“Shift “P”
warning” page 2-46)
. If the Intelligent Key battery dis-
charge indicator appears on the
vehicle information display, the In-
telligent Key battery is discharged
and the ignition switch will not
operate. Insert the Intelligent Key
into the key port to operate the
ignition switch. (
“Intelligent Key
battery discharge indicator” page 2-
48)
. When all of the following conditions
are met for 60 minutes, the battery
saver system will cut off the power
supply to prevent battery discharge.
—The ignition switch is in the ACC
Starting and driving
5-11

position, and
— All doors are closed, and
— The shift lever is in the
of
the Intelligent Key port blinks and the
indicator appears on the vehicle informa-
tion display. (
“Intelligent Key insertion
indicator” page 2-47)
In this case, inserting the Intelligent Key
into the port allows you to start the
engine. Make sure that the mechanical
key side faces backward as illustrated.
Insert the Intelligent Key in the port until it
is latched and secured.
To remove the Intelligent Key from the port, push the ignition switch to the OFF
position and pull the Intelligent Key out of
the port.
NOTICE
Never place anything except the
Intelligent Key in the Intelligent Key
port. Doing so may cause damage to
the equipment.

position.
. Be sure the ignition switch is in
the OFF or LOCK position when
performing any parts replace-
ment or repairs.
. If you must work with the engine
running, keep your hands, cloth-
ing, hair and tools away from
moving fans, belts and any other
moving parts.
. It is advisable to secure or re-
move any loose clothing and
remove any jewelry, such as
rings, watches, etc. before work-
ing on your vehicle.
. Always wear eye protection whenever you work on your ve-
hicle.
. If you must run the engine in an
enclosed space such as a garage,
be sure there is proper ventilation
for exhaust gases to escape.
. Never get under the vehicle while
it is supported only by a jack. If it
is necessary to work under the
vehicle, support it with safety
stands.
. Keep smoking materials, flame
and sparks away from fuel tank
and the battery.
. Your vehicle is equipped with an
automatic engine cooling fan. It
may come on at any time without
warning, even if the ignition key is
in the OFF position and the en-
gine is not running. To avoid
injury, always disconnect the ne-
gative battery cable before work-
ing near the fan.
. The fuel filter or fuel lines should
be serviced by a GT-R certified
NISSAN dealer because the fuel
lines are under high pressure
even when the engine is off.
CAUTION
.Do not work under the hood while
the engine is hot. Turn the engine
off and wait until it cools down.
. Avoid direct contact with used
engine oil and coolant. Impro-
perly disposed engine oil, coolant,
and/or other vehicle fluids can
damage the environment. Always
conform to local regulations for
disposal of vehicle fluid.
NOTICE
.Never connect or disconnect the
battery or any transistorized
component while the ignition
switch is in the ON position.
. Never leave the engine or trans-
mission related component har-
nesses disconnected while the
ignition switch is in the ON posi-
tion.
This “8. Do-it-yourself” section gives in-
structions regarding only those items
which are relatively easy for an owner to
perform.
Do-it-yourself
8-3
MAINTENANCE PRECAUTIONS

found on
each side of the extended storage
fuse switch.
5. Pull the extended storage fuse switch straight out from the fuse box
.
wrapped with a cloth into the slitand twist it to separate the case into
the upper and lower parts.
NOTICE
Because there is the risk of scratch-
ing the key, wrap a cloth or similar
item around the screwdriver when
separating the parts. If the screwdri-
ver is inserted too far into the key, it
may damage the internal circuit
board.
Do-it-yourself
8-25
INTELLIGENT KEY BATTERY REPLACEMENT

in a safe
place. To purchase a lock key, con-
tact a GT-R certified NISSAN dealer
with your original codeon the key
code card.
. When you ask for a service at a GT-R
certified NISSAN dealer, make sure
to keep the lock key in the vehicle.
Otherwise, tires cannot be removed
and any service requiring the re-
moval of the wheels cannot be
performed.
Do-it-yourself
8-47
