2021 MAZDA MODEL CX-3 display

SignalWarning Action to be taken
(Amber)
Smart Brake Support/
Smart City Brake Sup ‐
port (SBS/SCBS)
Warning Light
*
The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc ‐
tion in the system. (Vehicles with type B audio)
Verify the reason why the warning light is
illuminated on the center display (page
7-26).
If the reason why th
e warning light is illu ‐
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em ‐
blem.
For any other reasons, have the vehicle in ‐
spected at an Authorized Mazda Dealer.
(Vehicles without type B audio)
If the reason why th e warning light is illu ‐
minated is due to a dirty windshield, clean
the windshield. For any other reasons,
have the vehicle inspected at an Author ‐
ized Mazda Dealer.

Tire Pressure Monitoring System Warning Light (Turns on)
*
Take the appropriate action and verify that the warning light turns off.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-36*Some models.
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Message Indicated on Display*
If a message is displayed in the center display (Type B audio), take appropriate action (in a
calm manner) according to the displayed message.

(Display example)
▼ Stop Vehicle in Safe Place Immediately
If the following messages are displayed in
the center display (Type B audio), a vehicle
system may be malfunctioning. Stop the vehicl e in a safe place and contact an Authorized
Mazda Dealer.
Display Indicated Condition
Displays if the engine coolant temperature has increased excessively.
Displays if the charging system has a malfunction.
▼Verify Display Content
Displays in the following cases:
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-40*Some models.
CX-3_8JL1-EA-20G_Edition1_old
2020-5-22 15:31:00

DisplayIndicated Condition/Action to be taken
The following message is displayed when the temperature around the
center display is high.
Lowering the temperature in the cabin or the temperature around the
center display by avoiding direct sunlight is recommended.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-41
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

flashes and the buzzer operates at the same
time.
Refer to Stop Vehicle in Safe Place
Immediately on page 7-26.
▼Blind Spot Monitoring (BSM)
Warning Beep*
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Moni
toring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Personalization Features on page
9-9.
Reversing
The Blind Spot Monitoring (BSM)
warning sound is activated if there is a
possibility of collision with a vehicle
approaching from behind and from the
rear on the left and right sides of the
vehicle.
▼ Lane Departure Warning Sound*
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
The volume of the LDWS warning sound
can be changed.
Refer to Personalization Features on
page 9-9.
The type of the LDWS warning sound
can be changed.
Refer to Personalization Features on
page 9-9.
▼Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) System
War ni ng s
*
The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system
warnings notify the
driver of system malfunctions and
cautions on use when required.
Check based on the beep sound.
Warning beep What to check
The beep sounds 1 time
while the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func ‐
tion) is operating The Mazda Radar Cruise
Control with Stop & Go
function (MRCC with
Stop & Go function) sys
‐
tem has been canceled.
The beep continues to
sound while the vehicle
is being driven. The distance between
your vehicle and the ve‐
hicle ahead is too close.
Verify the safety of the
surrounding area and re
‐
duce vehicle speed.
When the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func ‐
tion) is operating, the
beep sounds and the
Mazda Radar Cruise
Control with Stop & Go
function (MRCC with
Stop & Go function)
warning light (amber) in
the instrument cluster
turns on. A malfunction in the
system may be indicated.
Have your vehicle in‐
spected at an Authorized
Mazda Dealer.
▼
Excessive Speed Warning*
If the vehicle speed exceeds the speed
limit sign displayed on the active driving
display, the warning sound is activated and
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-45
CX-3_8JL1-EA-20G_Edition1_old
2020-5-22 15:31:00

the area around the speed limit sign
displayed on the active driving display
flashes 3 times in amber, and if the vehicle
speed continues to exceed the displayed
speed limit sign, the indication stops
flashing and remains on.
▼Collision warning*
If there is a possibility of a collision with a
vehicle ahead, a warning sound is
activated intermittently
at the same time as
the warning light flas hes and the warning
indication is displayed in the active
driving display (With active driving
display).
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-46*Some models.
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

If the Active Driving
Display Does Not Operate
If the active driving display does not
operate, switch the ignition off and then
restart the engine. If the active driving
display does not operate even with the
engine restarted, have the vehicle
inspected at an Aut horized Mazda Dealer.
If Trouble Arises
Active Driving Display Does Not Operate
7-48
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Personalization Features
The following personalization features can be set or changed by an Authorized Mazda Deal‐
er. Consult an Authorized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer depend ‐
ing on the feature.
Personalization features and settings which can be changed differ depending on the market
and specification.
Settings Change Method
Settings can be changed by operating the center display screen.
A: Refer to Settings on page 5-123.
B: Refer to Fuel Economy Monitor on page 4-69.
C: Refer to Active driving display on page 4-18.
Settings can be changed by operating the vehicle switches.
D: Refer to Stopping The Smart City Brake Support (SCBS) System Operation on page
4-122.
E: Refer to Auto Lock/Unlock Function on page 3-16.
F: Refer to Transmitter on page 3-5.
G: Refer to Locking, Unlocking with Request Switch (With the advanced keyless function)
on page 3-13.
Settings can be changed by an Authorized Mazda Dealer.
Item FeatureFactory Set
‐
ting Available Settings Settings
Change
Method
Safety
Smart City Brake Support
(SCBS) (page 4-120) The system can be changed so
that Smart City Brake Support
(SCBS) does not operate.
*1On
On/Off A D ―
Advanced Smart City
Brake Support (Advanced
SCBS) (page 4-116)
Smart Brake Support (SBS)
(page 4-123) The system can be changed so
that Smart City Brake Support
(Advanced SCBS)/Smart Brake
Support (SBS) does not oper
‐
ate.
*1
On On/Off A ―
The distance at which the colli ‐
sion warning activates can be
changed. Med. Near/Med./Far A
―
The volume of the collision
warning can be changed. High High/Low/Off A
―
Specifications
Personalization Features
9-9
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

ItemFeatureFactory Set‐
ting Available Settings Settings
Change
Method
Lane Departure Warning
System (LDWS) (page
4-82) The warning timing in which
the Lane Departure Warning
System (LDWS) determines
that the vehicle may be deviat
‐
ing from its lane can be
changed. At At/Before A
―The sensitivity of the warning
for the Lane Departure Warning
System (LDWS) can be
changed. Low
High/Low A ―
Warning beep sound*2Beep Beep/Rumbl. A ―
Warning beep volumeRumbl. High High/Mid/Low A
―Beep HighHigh/Low A―
Blind Spot Monitoring
(BSM) (page 4-87) The system can be changed so
that Blind Spot Monitoring
(BSM) does not operate.*1On
On/Off A ―
Warning beep volume*3High High/
Low/ Off A
―
Traffic Sign Recognition
System (TSR)*4 (page
4-93) The Traffic Sign Recognition
System (TSR) can be set to in
‐
operable.
*1On On/Off A ―
The warning pattern of the ex ‐
cessive speed warning can be
changed. OffOff/
Vi s ua l /
Audio & Visual A
―
The activation timing for the
excessive speed warning can be
changed. 0 0/ 5/ 10 A
―
Distance Recognition Sup ‐
port System (DRSS) (page
4-99) The system can be changed so
that Distance Recognition Sup‐
port System (DRSS) does not
operate.*1
On
On/Off A ―
The distance at which the vehi‐
cle ahead and your vehicle indi ‐
cated in the display flashes in
white can be changed. Near Far/Med./Near A
―
Ve h i c l e
Specifications
Personalization Features
9-10
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00
