2021 MAZDA MODEL 6 check engine

SignalWarning Page
Low Fuel Warning Indication/Warning Light 7-35
Check Fuel Cap Warning Indication/Warning Light*17-35
Engine Oil Level Warning Light*17-35
Seat Belt Warning Light (Front seat) 7-35
(Red)Seat Belt Warning Light (Rear seat) 7-35
Low Washer Fluid Level Warning Indication
7-35
Door-Ajar Warning Indication7-35
Trunk lid-Ajar Warning Indication 7-35
Door-Ajar Warning Light7-35
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
When Driving
Instrument Cluster and Display
4-28
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

SignalIndicator Page
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Ind ica‐
tor Light*1
Advanced Smart City Brake Sup‐ port (Advanced
SCBS)4-177
Smart City
Brake Support [Reverse]
(SCBS R) 4-185
Smart Brake
Support (SBS) System4-187
(White)
*Cruise Main Indication 4-228
(Green)
*Cruise Set Indication4-228
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
When Driving
Instrument Cluster and Display
*Some models.4-31
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

SignalWarning Page
Power Steering Malfunction Indication 7-25
Master Warning Indication 7-28
Electric Parking Brake (EPB) Warning Indication/Warning Light*17-28
Check Engine Light*17-28
*Selective Catalytic Reduction (SCR) system Warning Indication/W arning
Light*17-28
Automatic Transaxle War ning Indication 7-28
*AWD Warning Indication 7-28
Air Bag/Front Seat Belt Pretensioner System Warning Light*17-28
Tire Pressure Monitoring System Warning Light*1
Flashing
7-28
Turns on 7-35
(Amber/White) KEY Warning Indication Amber
7-28
White 7-35
(Amber)
*High Beam Control System (HBC) Warning Indication/Warning Light*17-28
Blind Spot Monitoring (BSM) Warning Indication 7-28
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) War ning Indication 7-28
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Warning Indication 7-28
LED Headlight Warning Light*17-28
(Amber)
*Smart Brake Support/Smart City B
rake Support (SBS/SCBS) Warning In‐
dication 7-35
Low Fuel Warning Indication
7-35
When Driving
Instrument Cluster and Display
*Some models.4-45
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

SignalWarning Page
Check Fuel Cap Warning Indication/Warning Light*17-35
Engine Oil Level Warning Light*17-35
Seat Belt Warning Light (Front seat) 7-35
(Red)Seat Belt Warning Light (Rear seat) 7-35
*Low Washer Fluid Level Warning Indication
7-35
Door-Ajar Warning Indication
7-35
Trunk lid-Ajar Warning Indication 7-35
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
▼Indication/Indicator Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-68
*Front Passenger Air Bag Deactivation Indicator Light*12-68
Security Indicator Light*13-41
Wrench Indication
4-50
(Blue)Low Engine Coolant Temperature Indicator Light 4-50
When Driving
Instrument Cluster and Display
4-46*Some models.
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

*1 The light turns on when the ignition is switched on for an operation check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
When Driving
Instrument Cluster and Display
4-49
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

SignalWarning Page
Electric Parking Brake (EPB) Warning Light*17-28
(Red)Brake Pedal Operation Demand Warning Light
*1
Flashing
4-105
Buzzer & Flash‐ ing
7-28
Check Engine Light*17-28
Automatic Transaxle Warning Light*17-28
Air Bag/Front Seat Belt Pretensioner System Warning Light*17-28
Tire Pressure Monitoring System Warning Light*1
Flashing
7-28
Turns on 7-35
(Red) KEY Warning Light
*1
Turns on
7-28
Flashing 7-35
LED Headlight Warning Light*17-28
(Amber) Smart City Brake Support (SCBS) Warning Light
*17-35
Low Fuel Warning Light
7-35
Check Fuel Cap Warning Light*17-35
Engine Oil Level Warning Light*17-35
Seat Belt Warning Light (Front seat) 7-35
(Red)Seat Belt Warning Light (Rear seat) 7-35
Low Washer Fluid Level Warning Light
7-35
Door-Ajar Warning Light7-35
When Driving
Instrument Cluster and Display
4-60
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If t he light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is appl ied.
▼Indication/Indicator Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-68
*Front Passenger Air Bag Deactivation Indicator Light*12-68
(Green)KEY Indicator Light 4-5
Security Indicator Light*13-41
Wrench Indication/Indicator Light*14-63
Shift Position Indication
4-69
Lights-On Indication/Indicator Light 4-78
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-82
Flashing the Headlights 4-82
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-84
Hazard Warning Flasher4-91
(Green) Brake Pedal Operation demand Indicator Light 4-101
AUTOHOLD Active Indicator Light*14-107
When Driving
Instrument Cluster and Display
*Some models.4-61
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

Shift-Lock System
The shift-lock system prevents shifting out
of P unless the brake pedal is depressed.

To shift from P:
1. Depress and hold the brake pedal.
2. Start the engine.
3. Press and hold the lock-release button.
4. Move the selector lever.
NOTE
When the ignition is switched to ACC or
the ignition is switched off, the selector
lever cannot be shifted from P position.
The ignition cannot be switched to OFF
if the selector lever is not in P position.
▼ Shift-Lock Override
If the selector lever will not move from P
using the proper shift procedure, continue
to hold down the brake pedal.
1. Remove the shift-lock override cover
using a cloth-wrapped flat head
screwdriver.
2. Insert a screwdriver and push it down.
Cover
Lock-release button
3. Press and hold the lock-release button.
4. Move the selector lever.
Take the vehicle to an Authorized Mazda
Dealer to have the system checked.
Transaxle Ranges
The shift position indication in the
instrument cluster illuminates.
Refer to Indication/Indicator Lights on
page 4-29, 4-46, 4-61.
The selector lever must be in P or N
position to operate the starter.
P (Park)
P locks the transaxle and prevents the
front wheels from rotating.
WA R N I N G
Always set the selector lever to P position
and set the parking brake:
Only setting the selector lever to the P
position without using the parking brake to
hold the vehicle is dangerous. If P fails to
hold, the vehicle could move and cause an
accident.
CAUTION
 Shifting into P, N or R while the vehicle is
moving can damage your transaxle.
 Shifting into a driving gear or reverse
when the engine is running faster than
idle can damage the transaxle.
R (Reverse)
In position R, the vehicle moves only
backward. You must be at a complete stop
before shifting to or from R, except under
rare circumstances as explained in
Rocking the Vehicle (page 3-46).
When Driving
Automatic Transaxle
4-68
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27
