2021 MAZDA MODEL 6 engine

Engine Compartment Overview
Windshield washer fluid reservoir
Engine oil-filler cap
Engine oil dipstick BatteryFuse block
Cooling system cap
Engine coolant reservoir
Windshield washer fluid reservoir
Engine oil-filler cap
Brake fluid reservoir
Engine oil dipstick Battery
Fuse block
Cooling system cap
Engine coolant reservoir
SKYACTIV-G 2.5
SKYACTIV-G 2.5T Brake fluid reservoir
Maintenance and Care
Owner Maintenance
6-20
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Windshield washer fluid reservoir
Engine oil-filler cap
Engine oil dipstick Battery
Fuse block
Cooling system cap
Engine coolant reservoir
SKYACTIV-D 2.2
Brake fluid reservoir
Maintenance and Care
Owner Maintenance
6-21
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Engine Oil
NOTE
Changing the engine oil should be
performed by an Authorized Mazda
Dealer.
Refer to Introduction (page 6-2) for
owner's responsibility in protecting your
investment.
▼Recommended Oil
U.S.A., Canada
SKYACTIV-G 2.5
Use SAE 0W-20 engine oil.
Mazda Genuine Oil is used in your Mazda
vehicle. Mazda Genuine 0W-20 Oil is
required to achieve optimum fuel
economy.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Oil.

(ILSAC)
Only use SAE 0W-20 oil “Certified For
Gasoline Engines” by the American
Petroleum Institute (API).
Oil with this trademark symbol conforms
to the current engine and emission system
protection standards and fuel economy
requirements of the International
Lubricant Standardization and Approval
Committee (ILSAC), c
omprised of U.S.
and Japanese automobile manufacturers.

80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
Maintenance and Care
Owner Maintenance
6-22
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

SKYACTIV-G 2.5T
Use SAE 5W-30 engine oil.
Mazda Genuine Oil is used in your Mazda
vehicle. Mazda Genuine 5W-30 Oil is
required to achieve optimum fuel
economy.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Oil.

(ILSAC)
Only use SAE 5W-30 oil “Certified For
Gasoline Engines” by the American
Petroleum Institute (API).
Oil with this tradem ark symbol conforms
to the current engine and emission system
protection standards and fuel economy
requirements of the International
Lubricant Standardization and Approval
Committee (ILSAC), comprised of U.S.
and Japanese automobile manufacturers.

80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
SKYACTIV-D 2.2
Mazda Genuine Oil is used in your Mazda
vehicle and is the recommended SAE
0W-30 lubricant. Mazda Genuine
SKYACTIV-D SAE 0W-30 Diesel Engine
Oil is required to achieve optimum fuel
economy and durability for the Diesel
Particulate Filter. If Mazda Genuine
SKYACTIV-D SAE 0W-30 Diesel Engine
Oil is not available, an alternative oil
specified below may be used for oil level
maintenance and oil changes however, it is
strongly recommended to replace the
alternative oil with Mazda Genuine
SKYACTIV-D SAE 0W-30 Diesel Engine
Oil at the next oil change to maintain
optimum performance.

Maintenance and Care
Owner Maintenance
6-23
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

Recommended oil: Mazda Genuine
SKYACTIV-D SAE 0W-30 Diesel
Engine Oil
Alternative oil: ACEA C3 and SAE
0W-30 or 5W-30

For maintenance service, Mazda
recommends Mazda Genuine Part.

80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
CAUTION
SKYACTIV-D 2.2 uses
specified oil. Please
confirm the specification in owner's
manual. If engine oil other than the
specified oil is used, the Diesel Particulate
Filter effective period of use will be
shortened or the Diesel Particulate Filter
may be damaged.
NOTE
Whenever the engine oil is replaced, the
vehicles engine control unit needs to be
reset as soon as possible. Otherwise, the
engine oil warning light or the wrench
indicator light may display at the wrong
timing.
Refer to the Information section in the
Mazda Connect Owner's Manual for the
details.
Except U.S.A., Canada
Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution th is type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine
friction.

For maintenance service, Mazda
recommends Mazda Genuine Parts.

(ILSAC)
(Mexico)
80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
Maintenance and Care
Owner Maintenance
6-24
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

SKYACTIV-G 2.5
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 5W-20
engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.

SKYACTIV-G 2.5T
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 0W-30
or SAE 10W-30 engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.
▼Inspecting Engine Oil Level
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal operating temperature.
3. Turn it off and wait at least 5 minutes for the oil to return to the oil pan.
4. Pull out the dipstick, wipe it clean, and reinsert it fully.
SKYACTIV-G 2.5 and
SKYACTIV-G 2.5T

MAX
OK
MIN
SKYACTIV-D 2.2

MIN OK
MAX
X Mark
Maintenance and Care
Owner Maintenance
6-25
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

NOTE
(SKYACTIV-D 2.2)
When inspecting the engine oil level,
pull out the dipstick straight without
twisting. In addition, when inserting
the dipstick, always insert it without
twisting so that the “X” mark faces the
front of the vehicle.
5. Pull it out again and examine the level. The level is normal if it is between the
MIN and MAX marks.
If it is near or below MIN, add enough
oil to bring the level to MAX.
CAUTION
Do not overfill the engine oil. This may
cause engine damage.
6. Make sure the O-ring on the dipstick is positioned properly before reinserting
the dipstick.
7. Reinsert the dipstick fully.
NOTE
(SKYACTIV-D 2.2)
Inspect the engine oil level
periodically. When inspecting the
engine oil, if the engine oil level is
exceeds the “X” mark on the dipstick,
replace the engine oil. This should be
done by an Authorized Mazda Dealer.
When replacing the engine oil, inspect
the oil level using the oil dipstick and
refill so that the engine oil level is
within the range between MIN and
MAX as shown in the figure.
X Mark
MAX
MIN
Engine Coolant
▼ Inspecting Coolant Level
WA R N I N G
Do not use a match or live flame in the
engine compartment. DO NOT ADD
COOLANT WHEN THE ENGINE IS HOT:
A hot engine is dangerous. If the engine has
been running, parts of the engine
compartment can become very hot. You
could be burned. Carefully inspect the
engine coolant in the coolant reservoir, but
do not open it.
Pull over to a safe location, then switch
the ignition off and make sure the fan is
not running before attempting to work
near the cooling fan:
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if the
engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.
Do not remove either cooling
system cap when the engine and radiator
are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot out
under pressure and cause serious injury.
Maintenance and Care
Owner Maintenance
6-26
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

NOTE
Changing the coolant should be done by
an Authorized Mazda Dealer.
Inspect the antifreeze protection and
coolant level in the coolant reservoir at
least once a year―at the beginning of the
winter season―and before traveling where
temperatures may drop below freezing.

Inspect the condition and connections of
all cooling system and heater hoses.
Replace any that are swollen or
deteriorated.

The coolant should be at full in the
radiator and between the F and L marks on
the coolant reservoir when the engine is
cool.
SKYACTIV-G 2.5

SKYACTIV-G 2.5T

SKYACTIV-D 2.2

If it is at or near L, add enough coolant to
the coolant reservoir to provide freezing
and corrosion protection and to bring the
level to F.
Securely tighten the coolant reservoir tank
cap after adding coolant.
Maintenance and Care
Owner Maintenance
6-27
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27
