2021 LEXUS RC350 fuse

3157-2. Steps to take in an emergency
7
When trouble arises
The engine starting system may be
malfunctioning due to an electrical
problem such as electronic key battery
depletion or a blown fuse. However, an
interim measure is available to start the
engine. (P.315)
One of the following may be the cause
of the problem:
 One or both of the battery terminals
may be disconnected. ( P.263)
 The battery may be discharged.
( P.319)
 There may be a malfunction in the
steering lock system.
Contact your Lexus dealer if the problem
cannot be repaired, or if repair procedures
are unknown.
When the engine does not start, the
following steps can be used as an
interim measure to start the engine if
the engine switch is functioning nor-
mally:
1 Set the parking brake.
2 Shift the shift lever to P.
3 Turn the engine switch to ACCES-
SORY mode. 4
Press and hold the engine switch
for about 15 seconds while
depressing the brake pedal firmly.
Even if the engine can be started using
the above steps, the system may be
malfunctioning. Have the vehicle
inspected by your Lexus dealer.
The starter motor does not turn
over
The starter motor does not turn
over, the interior lights and head-
lights do not turn on, or the horn
does not sound.
Emergency start function

388Alphabetical Index
If the engine will not start .........................314
If your vehicle has to be stopped in an
emergency ................................................286
Ignition switch (engine switch) ............. 127
Overheating................................................. 322
Tachometer ..................................................... 66
Engine coolant Capacity ......................................................... 332
Checking .......................................................260
Preparing and checking before winter.........................................................................205
Engine coolant temperature gauge ....... 66
Engine immobilizer system ........................ 56
Engine oil Capacity .........................................................330
Checking .......................................................258
Preparing and checking before winter.........................................................................205
Warning light ............................................... 296
Engine oil maintenance data .................. 260
Engine oil pressure gauge ...........................74
Engine oil temperature gauge ...................74
Engine switch .................................................. 127 Auto power off function .......................... 130
Changing the engine switch modes.. 129
If your vehicle has to be stopped in an
emergency ................................................286
EPS (Electric Power Steering) ................201 Warning light ............................................... 297
Event data recorder (EDR) ............................6
F
First-aid kit storage belt ............................ 229
Flat tire Tire pressure warning system .............268
Vehicles with a spare tire ...................... 307
Floor mats ...........................................................22
Fluid Automatic transmission .......................... 333
Brake.................................................... 262, 334
Washer ........................................................... 264
Footwell light ................................................. 225 Front passenger occupant classification
system .............................................................. 36
Front position lights Wattage ......................................................... 338
Front seats Adjustment ....................................................... 99
Cleaning .........................................................245
Correct driving posture ............................ 23
Driving position memory ........................ 102
Head restraints............................................. 105
Memory recall function............................ 104
Power easy access system .................... 102
Seat heaters .................................................. 223
Seat position memory .............................. 102
Seat ventilators ............................................ 223
Front side marker light Light switch .....................................................142
Front turn signal lights Replacing light bulbs ................................282
Turn signal lever .......................................... 136
Wattage ......................................................... 338
Fuel Capacity ........................................................ 330
Fuel gauge ........................................................ 66
Fuel pump shut off system..................... 294
Information ....................................................339
Refueling.......................................................... 155
Type ................................................................. 330
Warning light ...............................................299
Fuel consumption Average fuel economy .............................. 73
Current fuel consumption ........................ 73
Fuel filler door If the fuel filler do or cannot be opened
........................................................................... 316
Refueling.......................................................... 155
Fuel gauge ......................................................... 66
Fuel pump shut off system........................ 294
Fuses ................................................................. 278
G
Garage door opener ................................. 232

392Alphabetical Index
Power easy access system ........................102
Power outlet .................................................. 230
Power steering (Electric power steering
system)............................................................201 Warning light ............................................... 297
Power windows Door lock linked window operation... 113
Jam protection function..............................112
Operation..........................................................112
Window lock switch ................................... 113
Pre-Collision System (PCS) Function ............................................................ 162
PCS OFF switch ..........................................164
Warning light ...............................................298
Warning message.....................................303
R
Radar cruise control (dynamic radar cruise control with full-speed range)............... 176
Radiator ........................................................... 262
RCTA Function ............................................................. 191
Rear Cross Traffic Alert (RCTA) ............ 191
Rear seats .......................................................... 101 Head restraints ............................................ 105
Seat heaters .................................................. 223
Seat ventilators............................................ 223
Rear side marker lights Light switch ..................................................... 142
Rear turn signal lights Turn signal lever ...........................................136
Wattage..........................................................338
Rear view mirror Inside rear view mirror............................. 109
Outside rear view mirrors ....................... 110
Rear window defogger ...............................219
Refueling Capacity .........................................................330
Fuel types.......................................................330
If the fuel filler door cannot be opened...........................................................................316
Opening the fuel tank cap ..................... 155 Remote Touch ................................................210
Replacing
Electronic key battery .............................. 277
Fuses................................................................. 278
Light bulbs ...................................................... 281
Tires ..................................................................307
Resetting the message indicating mainte- nance is required ...................................... 248
Rev indicator .................................................... 69
Rev peak............................................................. 69
S
Seat belt reminder light............................. 299
Seat belts............................................................ 24 Automatic Locking Retractor................. 26
Child restraint system installation ..40, 41
Cleaning and maintaining the seat belt..........................................................................245
Emergency Locking Retractor .............. 26
How to wear your seat belt ..................... 25
How your child should wear the seat belt ............................................................................. 25
Pregnant women, proper seat belt use ............................................................................. 24
Reminder light and buzzer ...................299
Seat belt extender......................................... 25
Seat belt pretensioners .............................. 27
SRS warning light.......................................296
Seat heaters ................................................... 223
Seat position memory..................................102
Seat ventilators ............................................. 223
Seating capacity.............................................125
Seats Adjustment ....................................................... 99
Cleaning .........................................................245
Driving position memory ........................ 102
Head restraints............................................. 105
Power easy access system .................... 102
Properly sitting in the seat ........................ 23
Seat heaters .................................................. 223
Seat position memory .............................. 102
Seat ventilators ............................................ 223
