2021 Lexus LC500C window

6
LC500_QG_OM11518U_(U)
Parking brake switch ............................................................................................... P.29
Applying/releasing..............................................................................................................P.29
Precautions against winter season
*
Warning buzzer/message*
Turn signal lever ........................................................................................................ P.28
Headlight switch ....................................................................................................... P.36
Headlights/parking lights/tail lights/license plate lights/ daytime
running lights ..........................................................................................................................P.36
Automatic High Beam ....................................................................................................... P.37
Windshield wiper and washer switch ................................................................. P.39
Usage ........................................................................................................................................P.39
Adding washer fluid
*
Warning messages*
Emergency flasher switch*
Hood lock release lever*
Tilt and telescopic steering control switch*
Adjustment*
Driving position memory ................................................................................................... P.19
Air conditioning system .......................................................................................... P.75
Usage .......................................................................................................................... .............. P.76
Rear window defogger ...................................................................................................... P.75
Audio system.............................................................................................................. P.67
Trunk opener main switch
*
*
: Refer to the “OWNER’S MANUAL”.
E
F
G
H
I
J
K
L
M

8
LC500_QG_OM11518U_(U)
Driving position memory switches ....................................................................... P.19
Outside rear view mirror switches
*
Window lock switch*
Power window switches*
Door lock switches ................................................................................................... P.96
*: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E

10
LC500_QG_OM11518U_(U)
Audio control switches ........................................................................................... P.67
Remote Touch ........................................................................................................... P.55
Roof switch ................................................................................................................. P.54
All window control switch
*
P position switch........................................................................................................ P.25
Brake hold switch ...................................................................................................... P.31
*: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F

15
LC500_QG_OM11518U_(U)
Locks the doors
Unlocks the doors
Opens the windows (press and hold)
*
Opens the trunk
Sounds the alarm
*: This setting must be customized at yourLexus dealer.
Wireless remote control
A
B
C
D
E

54
LC500_QG_OM11518U_(U)
1Open the palm rest.
2Operate the switch.
1Open
2Close
The side windows and rear quarter win-
dows operate linked to opening or closing
the soft top roof.
Opening/closing status of the soft top roof
will be displayed on the multi-information
display.
When the operation of the soft top roof has completed, the bar will turn to gray and the
buzzer will sound.
To close the side windows and rear quarte r windows, press the power window switch.
Opening or closing the soft top roof

75
LC500_QG_OM11518U_(U)
Automatic mode switch
Off switch
Left-hand side temperature control switch
Fan speed control switch
Outside/recirculated air mode switch
Right-hand side temperature control switch
Windshield defogger switch
Rear window and outside rear view mirror defoggers switch
■Adjusting the temperature
Operate the temperature control switch upwards to increase the temperature and down-
wards to decrease the temperature.
If the “A/C” indicator is turned off, the system will blow ambient temperature air or heated
air.
■Setting the fan speed
Operate the fan speed control switch upwards to increase the fan speed and downwards
to decrease the fan speed.
Press the off switch to turn the fan off.
■Changing the air flow mode
P.76
Air Conditioning System
Press the “MENU” button on the Remote Touch, then select “Climate” to display the air
conditioning control screen.
Control panel
A
B
C
D
E
F
G
H

What to do if...
101
LC500_QG_OM11518U_(U)
1Push in the depression on the front edge of the driver’s door handle.
2Insert the mechanical key while pulling
on the driver’s door handle.
3Turn the key in order to perform the fol-
lowing operations.
Locks both side doors
Closes the windows (turn and hold)
*
Unlocks the door
Turning the key rearward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other door.
Opens the windows (turn and hold)
*
*
: These settings must be customized at your Lexus dealer.
Unlock the doors, and press the trunk
opener switch.
If the electronic key does not operate properly
Locking and unlocking the door
A
B
C
D
Opening the trunk
