2021 Lexus LC500C display

1
LC500_QG_OM11518U_(U)
Air Conditioning System*
Control panel .................................................................................................................................. 75
Main control screen............................................................................................................ .......... 76
Option control screen .......................................................................................................... ....... 77
Side display................................................................................................................... ....................78
Using automatic mode ........................................................................................................... .....78
Audio System
*
Audio control screen ........................................................................................................... ........ 67
Selecting an audio source ...................................................................................................... .... 67
Steering switch operation ...................................................................................................... ....68
Radio ...................................................................................................................................................70
CD......................................................................................................................................................... 71
DVD .................................................................................................................................................... 72
iPod ...................................................................................................................................................... 73
Automatic High Beam............................................................................................................ 37
Automatic Transmission ........................................................................................................2 4
Brake Hold ..................................................................................................................... .............31
BSM (Blind Spot Monitor) ................................................................................................... 50
Door Locks ..................................................................................................................... ...........96
Driving Mode Select Switch ............................................................................................... 48
Driving Position Memory ....................................................................................................... 1 9
Dynamic Radar Cruise Control with Full-Speed Range .............................................42
Engine (Ignition) Switch ....................................................................................................... ...21
Floor Mat Installation ......................................................................................................... .....13
Contents
The Quick Guide is not intended as a substitute for yourOWNER’S MANUAL. We strongly encourage you to review
the OWNER’S MANUAL and supplementary manuals so you
will have a better understanding of your vehicle’s capabilities
and limitations.

2
LC500_QG_OM11518U_(U)
Front Seats.................................................................................................................................. 18
Fuel Consumption Information ........................................................................................... 59
Garage Door Opener ........................................................................................................... 87
Hands-free System For Cellular Phone
*
Registering/connecting Bluetooth® device ..................................................................... 63
Contacts transfer .............................................................................................................. ............ 64
Registering the contacts in the favorites list.. ..................................................................... 65
Calling by favorites list ...................................................................................................... .......... 65
Calling the message sender ..................................................................................................... 65
Receiving a call ............................................................................................................... ............... 66
Steering switches .............................................................................................................. ............ 66
Headlights..................................................................................................................... ............. 36
Head-up Display ......................................................................................................................34
Intuitive Parking Assist ....................................................................................................... ... 47
Keys ........................................................................................................................... ................... 14
Lexus Climate Concierge .................................................................................................... 74
Lexus Enform Remote ...........................................................................................................9 3
Lexus Enform Safety Connect ............................................................................................. 91
Lexus Enform Service Connect .......................................................................................... 94
Lexus Safety System +.......................................................................................................... ..40
LKA (Lane-Keeping Assist)................................................................................................... 41
Multi-information Display.....................................................................................................3 2
Navigation System
*
Registering home ............................................................................................................... ............. 61
Destination search - Search by address ................................................................................ 61
Destination search - Search points of intere st by name ............................................... 62
Destination search - Search points of intere st by category ........................................ 62
Destination search - Search points of interest by phone number ............................ 62
Voice Command System ........................................................................................................... 79
*: These features may be operated by Voice Command (See P.79)

5
LC500_QG_OM11518U_(U)
■Instrument panel
Engine switch .............................................................................................................. P.21
Starting the engine/changing the mode.............................................................. P.21, 22
Emergency stop of the engine ........................................................................................P.23
When the engine will not start ......................................................................................P.102
Warning messages
*
Shift lever .................................................................................................................... P.24
Changing the shift position...............................................................................................P.24
Precautions against towing
*
Meters*
Reading the meters/adjusting the instrument panel lights*
Warning lights/indicator lights .......................................................................................P.97
When the warning lights come on
*
Multi-information display ...................................................................................... P.32
Display.......................................................................................................................................P.32
When the warning messages are displayed
*
Pictorial Index
A
B
C
D

7
LC500_QG_OM11518U_(U)
■Switches
Driving mode select switch ................................................................................... P.48
VSC OFF
*1/snow mode switch ........................................................................... P.26
Odometer/trip meter/trip meter reset button
*1
Instrument panel light control switches*1
Fuel filler door opener switch*1
HUD (Head-up display) switch*2....................................................................... P.34
Trunk opener switch ............................................................................................... P.101
*1: Refer to the “OWNER’S MANUAL”.
*2: If equipped
A
B
C
D
E
F
G

19
LC500_QG_OM11518U_(U)
1Turn the engine switch to ON.
2Check that the shift position is in P.
3Adjust the driver’s seat, steering wheel, outside rear view mirrors and head-up display
to the desired positions.
4While pressing the “SET” button, or
within 3 seconds after the “SET” button
is pressed, press button “1”, “2” or “3”
until the buzzer sounds.
If the selected button has already been
preset, the previously recorded posi-
tion will be overwritten.
1Turn the engine switch to ON.
2Check that the shift position is in P.
3Press one of the buttons for the driving
position you want to recall until the
buzzer sounds.
Driving Position Memory
This feature automatically adjusts the positions of the driver’s seat, steering wheel, outside
rear view mirrors and head-up display (if equipped) to suit your preferences.
Recording a driving position into memory
Recalling a driving position

22
LC500_QG_OM11518U_(U)
1Stop the vehicle completely.
2If the parking brake is in manual mode, set the parking brake. (P.29)
3Shift the shift position to P.
4Press the engine switch.
5Check that “ACCESSORY” or “IGNITION ON” is not shown on the meter.
Modes can be changed by pressing the engine switch with the brake pedal released. (The
mode changes each time the switch is pressed.)
1OFF
The emergency flashers can be used.
2ACC
Some electrical components such as
the audio system can be used.
“ACCESSORY” will be displayed on
the meter.
3ON
All electrical components can be used.
“IGNITION ON” will be displayed on
the meter.
Stopping the engine
Changing engine switch modes

24
LC500_QG_OM11518U_(U)
Shift lever
Operate the shift lever gently and
securely in the direction of the arrow
on the shift position indicator.
To shift to N, slide the shift lever in the
direction of the arrow and hold it.
Release the shift lever after each shift-
ing operation to allow it to return to its
regular position ( ).
Shifting to M is only possible when the
shift position is in D.
When shifting from P to N, D or R,
from N, D, M or R to P, from D or M to
R, or from R to D, ensure that the brake
pedal is being depressed and the vehi-
cle is stationary.
Shift position indicator
Meter display:
The current shift position is highlighted.
When any shift position other than D or M is selected, the arrow toward M and M posi-
tion indicator are displayed in gray.
Shift lever display:
The current shift position is illuminated.
When selecting the shift position, make sure that the shift position has been changed to
the desired position by checking the shift po sition indicator provided on the instrument
cluster.
P position switch
 P.25
Automatic Transmission
Shifting the shift lever
A
B
C

26
LC500_QG_OM11518U_(U)
■Driving mode
P.48
■Snow mode
Snow mode can be sele cted to suit the con-
ditions when driving on slippery road sur-
faces, such as on snow.
Turn the switch backward.
The snow mode indicator comes on.
Turn the switch backward again to
return to normal mode.
When the “-” paddle shif t switch is operated, the shift rang e switches to a range that enables
engine braking force that is suit able to driving conditions. When the “+” paddle shift switch is
operated, the shift range switches to a range that is one range higher than the current range.
1Upshifting
2Downshifting
The selected shift range, from D1 to D10,
will be displaye d in the meter.
A lower shift range will provide greater engine braking forces than a higher shift range.
Selecting the driving mode
Selecting shift ranges in the D position
Meter displayFunction
D2 - D10
A gear in the range between D1 and the selected shift range is
automatically chosen depending on vehicle speed and driving conditions
D1Setting the shift range at D1
