1193-4. Adjusting the steering wheel and mirrors
3
Before driving
1To select a mirror to adjust, press
the switch.
The indicator comes on.
Left
Right
Pressing the same switch again will put the
switch in neutral.
2To adjust the mirror, press the
switch.
Up
Right
Down
Left
■Mirror angle can be adjusted when
The engine switch is in ACC or ON.
■Defogging the mirrors
The outside rear view mirrors can be
cleared using the mirror defoggers. Turn on
the rear window defogger to turn on the
outside rear view mirror defoggers.
(  P.233)
■Auto anti-glare function
When the anti-glare inside rear view mirror
is set to automatic mode, the outside rear
view mirrors will activate in conjunction
with the anti-glare insi de rear view mirror to
reduce reflec ted light. (P.118)
■Automatic adjustment of the mirror
angle
A desired mirror face angle can be entered
to memory and recalled automatically by
the driving position memory. ( P.112)
Outside rear view mirrors
The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.
WARNING
■Important points while driving
Observe the following precautions while
driving.
Failure to do so may result in loss of con-
trol of the vehicle and cause an accident,
resulting in death or serious injury.
●Do not adjust the mirrors while driving.
●Do not drive with the mirrors folded.
●Both the driver and passenger side
mirrors must be extended and prop-
erly adjusted before driving.
Adjustment procedure
A
BWARNING
■When the outside rear view mirror
defoggers are operating
Do not touch the outside rear view mir-
ror surfaces, as they can become very
hot and burn you.
A
B
C
D

1203-4. Adjusting the steering wheel and mirrors
■Using the switch
Press the switch to fold the mirrors.
Press it again to extend them to the original
position.
■Setting automatic mode
Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.
The indicator will come on.
Pressing the switch on ce more will return
to manual mode.
■When disconnecting and reconnecting
battery terminals
The automatic folding/extending mirror
function will return to off as default. To turn
the function on, press the switch again to
select on.
■Using automatic mode in cold weather
When automatic mode is used in cold
weather, the door mirror could freeze up
and automatic stowing and return may not
be possible. In this case, remove any ice and
snow from the door mirror, then either
operate the mirror using manual mode or
move the mirror by hand.
■Customization
The automatic mirror folding and extending
operation can be changed.
(Customizable features: P.367)
When either “L” or “R” of the mirror
select switch is selected, the outside
rear view mirrors will automatically
angle downwards when the vehicle is
reversing in order to give a better view
of the ground.
To disable this function, select neither
“L” nor “R”.
■Adjusting the mirror angle when
the vehicle is reversing
With the shift position in R, adjust the
mirror angle at a desired position.
The adjusted angle will be memorized
and the mirror will automatically tilt to
the memorized angle whenever the
shift position is shifted to R from next
time.
The memorized downward tilt position of
the mirror is linked to the normal position
Folding and extending the mir-
rors
A
WARNING
■When a mirror is moving
To avoid personal injury and mirror mal-
function, be careful not to get your hand
caught by the moving mirror.
Linked mirror function when
reversing

1213-4. Adjusting the steering wheel and mirrors
3
Before driving
(angle adjusted with the shift position in
other than R). Therefore, if the normal
position is changed after adjustment, the
tilt position will also change.
When the normal position is changed,
readjust the angle in reversing.

1223-5. Opening and closing the windows
3-5.Opening and closing the windows
The side windows can be opened and
closed by one-touch operation of the
switches.
1Closing
2 One-touch closing
*1, 2
3Opening
4 One-touch opening
*1
*1: To stop the window partway, operate
the switch in the opposite direction.
*2: It does not operate when the rear quar-ter windows are stopped partway.
The side windows and rear quarter
windows can be opened and closed by
one-touch operation
*1 of the switches. 1
Opening the palm rest
2 Operating the switch
1 Closing
2 Opening
3 One-touch opening
*2
*1: Only one-touch opening
*2: To stop the window partway, operate
the switch in the opposite direction.
■The power windows can be operated
when
The engine switch is in ON.
■Operating the power windows after
turning the engine off
The power windows can be operated for
approximately 45 seconds after the engine
switch is turned to ACC or turned OFF.
They cannot, however, be operated once
either door is opened.
■Jam protection function
If an object becomes jammed between the
window and the soft top roof while the win-
dow is closing, window movement is
stopped and the window is opened slightly.
Power windows
Opening and closing the side
windows
Opening and closing the side
windows and rear quarter win-
dows

1233-5. Opening and closing the windows
3
Before driving
■Catch protection function
Window
If an object becomes caught between the
door and window while the window is open-
ing, window movement is stopped.
Rear quarter window
If an object becomes caught between the
rear quarter window an d vehicle body while
the rear quarter wind ow is opening, win-
dow movement is stopped.
■When the window cannot be opened or
closed
When the jam protection function or catch
protection function op erates unusually and
the door window cannot be opened or
closed, perform the following operations
with the power window switch of that door.
●Stop the vehicle. With the engine switch
in ON, within 4 seconds of the jam pro-
tection function or catch protection func-
tion activating, continuously operate the
power window switch in the one-touch
closing direction or one-touch opening
direction so that the door window can be
opened and closed.
●If the door window cannot be opened
and closed even when performing the
above operations, perform the following
procedure for function initialization.
1 Close both side doors.
2 Turn the engine switch to ON.
3 Close the soft top roof, and then close
the side windows an d rear quarter win-
dows.
4 Pull and hold the power window switch
in the one-touch closing direction for
approximately 6 seconds or more.
5 Press and hold the power window
switch in the one-touch opening direc-
tion. After the door window is com-
pletely opened, continue holding the
switch for an additional 1 second or
more.
6 Release the power window switch for a
moment, resume push ing the switch in
the one-touch opening direction, and
hold it there for approximately 4 sec-
onds or more. 7
Pull and hold the power window switch
in the one-touch closing direction
again. After the door window is com-
pletely closed, continue holding the
switch for a further 1 second or more.
If you release the switch while the window is
moving, start again from the beginning.
If the window reverses and cannot be fully
closed or opened, have the vehicle
inspected by your Lexus dealer.
■When the rear quarter windows cannot
be opened or closed
When the jam protection function or catch
protection function operates unusually and
the rear quarter wind ow cannot be opened
or closed, perform the following operations
with the all window control switch.
●Stop the vehicle. With the engine switch
in ON, within 4 seconds of the jam pro-
tection function or catch protection func-
tion activating, continuously operate the
all window control switch in the closing
direction or one-touc h opening direction
so that the rear quarter window can be
opened and closed.
●If the rear quarter window cannot be
opened and closed even when perform-
ing the above operations, perform the
following procedure for function initial-
ization.
1 Close both side doors.
2 Turn the engine switch to ON.
3 Close the soft top roof, and then close
the side windows.
4 Pull and hold the all window control
switch in the closing direction for
approximately 6 seconds or more.
5 Press and hold the all window control
switch in the one-touch opening direc-
tion. After the side windows and rear
quarter windows are completely
opened, continue holding the switch for
an additional 1 second or more.
6 Release the all window control switch
for a moment, resume pressing and
holding the switch in the one-touch
opening direction for approximately 4
seconds or more.

1243-5. Opening and closing the windows
7Pull and hold the power window switch
in the one-touch closing direction to
close the side windows.
8
Pull and hold the all window control
switch in the one-touch closing direc-
tion again. After the rear quarter win-
dows are completely closed, continue
holding the switch fo r a further 1 second
or more.
If you release the switch while the windows
are moving, start again from the beginning.
If the windows reverse and cannot be fully
closed or opened, have the vehicle
inspected by your Lexus dealer.
■Door lock linked window operation
●The power windows can be opened and
closed using the mechanical key.*
(  P.330)
●The power windows can be opened using
the wireless remote control.* ( P.96)
*: These settings must be customized at
your Lexus dealer.
■Power windows open warning buzzer
The buzzer sounds and “Window Open” is
shown on the multi-information display in
the instrument cluster when the engine
switch is turned off and the driver’s door is
opened with the power windows open.
■Customization
Settings (e.g. linked door lock operation)
can be changed.
(Customizable features: P.367)
WARNING
Observe the following precautions.
Failure to do so may result in death or
serious injury.
■Closing the windows
●The driver is responsible for all the
power window operations, including
the operation for the passengers. In
order to prevent accidental operation,
especially by a child, do not let a child
operate the power windows. It is possi-
ble for children and other passengers
to have body parts caught in the power
window. Also, when riding with a child,
it is recommended to use the window
lock switch. ( P.125)
●Check to make sure that all passen-
gers do not have any part of their body
in a position where it could be caught
when a window is being operated.
●When using the wireless remote con-
trol or mechanical key and operating
the power windows, operate the
power window after checking to make
sure that there is no possibility of any
passenger having any of their body
parts caught in the window. Also do
not let a child operate window by the
wireless remote control or mechanical
key. It is possible for children and other
passengers to get caught in the power
window.
●When exiting the vehicle, turn the
engine switch off, carry the key and
exit the vehicle along with the child.
There may be accidental operation,
due to mischief, etc., that may possibly
lead to an accident.
■Jam protection function
●Never use any part of your body to
intentionally activa te the jam protec-
tion function.
●The jam protection function may not
work if something gets jammed just
before the window is fully closed. Be
careful not to get any part of your body
jammed in the window.
■Catch protection function
●Never use any part of your body or
clothing to intentionally activate the
catch protection function.

1253-5. Opening and closing the windows
3
Before driving
This function can be used to prevent
children from accidentally opening or
closing a passenger window and rear
quarter window.
Press the switch.
The indicator will come on and the
passenger window and rear quarter win-
dow will be locked.
■The power windows can be operated
when
The engine switch is in ON.
■When the battery is disconnected
The window lock switch is disabled. If nec-
essary, press the window lock switch after
reconnecting the battery.
WARNING
●The catch protection function may not
work if something gets caught just
before the window is fully opened. Be
careful not to get any part of your body
or clothing caught in the window.
Preventing accidental opera-
tion (window lock switch)
A

1263-6. Opening and closing the soft top roof
3-6.Opening and closing the soft top roof
ExteriorSoft top roof
Luggage cover
Interior
Multi-information display ( P.79)
Displays opening/closing status of the soft
top roof.
Roof switch Operation display of the soft top
roof
Displays operating parts of the soft top
roof linked to operatio
n of the roof switch.
Bar display
The bar is displayed linked to the operation
display. The bar will turn to gray when the
operation of the soft top roof has com-
pleted.
1 Open the palm rest. ( P.122)
2 Operate the switch.
1 Open
2 Close
The side windows and rear quarter win-
dows operate linked to opening or closing
the soft top roof.
Soft top roof
The soft top roof can be opened or
closed by the switch operation.
System components
A
B
A
B
Multi-information display
Opening or closing the soft top
roof
A
B
