2021 Lexus GX460 display

3
GX460_QG_OM60T24U_(U)
Keys............................................................................................................................................................ 12
LDA (Lane Departure Alert) ......................................................................................................... 26
Lexus Enform ................................................................................................................... .....................89
LEXUS Enform Safety Connect ...................................................................................................8 7
List of Warning/Indicator Lights ............................................................................................... .... 97
Moon Roof ...................................................................................................................... .......................94
Multi-information Display ...................................................................................................... ........... 18
Multi-terrain Monitor .......................................................................................................... .............. 29
Multi-terrain Select........................................................................................................... .................. 27
Navigation System Register home .................................................................................................................. ...............43
Destination input
 Search by address ................................................................................45
Destination input
 Search points of interest by na me ................................................. 47
Destination input
 Search points of interest by ca tegory ..........................................48
Destination input
 Search points of interest by phone number .............................. 49
Voice Command System ........................................................................................................... 78
Portable Audio Device Ports .................................................................................................... .... 83
Power Windows ..................................................................................................................................93
Rear Air Conditioning System Control panel .................................................................................................................. ................ 76
Using the automatic mode......................................................................................................... 76
Control screen (front controller) ............................................................................................ 77
Rear Seat Entertainment System................................................................................................. .70
Rear Window Wiper and Washer ...............................................................................................39

4
GX460_QG_OM60T24U_(U)
Smart Access System with Push-button Start .......................................................................... 13
Theft Deterrent System......................................................................................................... ............. 15
Touch Screen (with multimedia system)
*
Basic operation ................................................................................................................ ...............60
Screen for display settings .................................................................................................... .....60
Touch Screen (with navigation system)
*
Basic operation ................................................................................................................ ...............40
Home ................................................................................................................................................... 41
Screen scroll operation ........................................................................................................ ........ 41
Setting a route ................................................................................................................ ................. 42
Turn Signal Lever.............................................................................................................. .................... 21
Voice Command System Basic operation ................................................................................................................ ...............78
Command list ................................................................................................................... ............... 79
Windshield Wipers and Washers ................................................................................................ 37
XM Satellite Radio ............................................................................................................. .................. 91
*: These features may be operated by Voice Command (See P. 78)

15
GX460_QG_OM60T24U_(U)
Theft Deterrent System
■Engine immobilizer system
The indicator light flashes after the engine
switch has been turned off to indicate that
the system is operating.
The indicator light stop s flashing after the
engine switch has been turned to ACCES-
SORY or IGNITION ON mode to indicate
that the system has been canceled.
■ Alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
To set the alarm:
Close the doors, glass hatch and hood, and lock all the doors. The system will be set auto-
matically after 30 seconds. The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm:
● Unlock the doors.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine.
(The alarm will be deactivated or stopped after a few seconds.)
■Steering lock
“PUSH THE ENGINE SWITCH WHILE
TURNING THE STEERING WHEEL IN
EITHER DIRECTION”/“Push the engine
switch while turning the steering wheel in
either direction” will be displayed on the
multi-information display.
Check that the shift leve r is set in P. Press
the engine switch shortly and firmly while
turning the steering wheel left and right.

16
GX460_QG_OM60T24U_(U)
Engine (Ignition) Switch
■Starting the engine
Check that the par king brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
and a message will be dis-
played on the multi-information dis-
play.
If it is not displayed, the engine can-
not be started.
Press the engine switch shortly and
firmly. When operating the engine switch,
one short, firm press is enough.
It is not necessary to press and hold
the switch.
The engine will crank until it starts or
for up to 30 seconds, whichever is
less.
Continue depressing the brake pedal
until the engine is completely started.
The engine can be started from any
engine switch mode.
■ Stopping the engine
Stop the vehicle.
Set the parking brake, and shift the shift lever to P.
Press the engine switch.
Release the brake pedal an d check that “ACCESSORY” or “IGNITION ON” is not
shown on the meter.
Performing the following oper ations when carrying the electronic key on your person
starts the engine or changes engine switch modes.
1
2
3
4
1
2
3
4

17
GX460_QG_OM60T24U_(U)
■Changing engine switch modes
Modes can be changed by pressing the engine switch with brake pedal released. (The mode
changes each time the switch is pressed.)
Off
*
The emergency flashers can be used.
ACCESSORY mode
Some electrical components such as
the audio system can be used.
“ACCESSORY” will be displayed on
the multi-information display.
IGNITION ON mode
All electrical components can be used.
“IGNITION ON” will be displayed on
the multi-information display.
*: If the shift lever is in a position other than
P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to off.
1
2
3

18
GX460_QG_OM60T24U_(U)
Multi-information Display
■Display information
Drive information
Select to display various drive data.
Vehicle information display
Select to display the vehicle information.
Driving assist system information
Select to display the operational status of the following systems:
• Dynamic radar cruise control ( P. 22)
• LDA (Lane Departure Alert) ( P. 26)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display sett ings and the operation settings of some
vehicle functions.
The following information will be displa yed when a menu icon is selected.

19
GX460_QG_OM60T24U_(U)
■Operating the meter control switches
The multi-information display is operat ed using the meter control switches.
:Switch menu
:Change displayed content,scroll up/down the screen
and move the cursor up/
down
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Press: Displays th e screen registered
to
When no screen has been registered,
the drive information screen will be dis-
played.
Press and hold: Registers the currently
displayed screen to
When the confirmation screen is dis-
played, select yes to register the
screen. If the sele cted screen cannot
be registered, a registration failure
message will be shown.
1
2
3
4
If a problem is detected in any of the vehicl e’s systems, a warning message is shown on the
multi-information display.

20
GX460_QG_OM60T24U_(U)
Eco Driving Indicator Light
Eco Driving Indicator Light
During Eco-friendly acceleration oper-
ation (Eco driving), the Eco Driving
Indicator Light will turn on. When the
acceleration exceeds Zone of Eco
driving, or when the vehicle is stopped,
the light turns off.
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with
current Eco driving ratio based on
acceleration.
Eco driving ratio based on accelera-
tion
If the acceleration exceeds Zone of
Eco driving, the right side of Eco
Driving Indicator Zone Display will illu-
minate.
Zone of Eco driving
Eco Driving Indicator will not operate
under the following conditions:
● The shift lever is in any position other
than D.
● Vehicles with adaptive variable sus-
pension system: Th e driving mode is
set to sport mode.
● The vehicle speed is approximately
81 mph (130 km/h) or higher.1
2
3
4
