2021 INFINITI QX80 glove box

17. Cup holder (P.2-60)/Tray (P.2-65)
18. Glove box (P.2-63)
Illustrated table of contents0-11

flash.
. If a forward facing child restraint is
installed in the front passenger seat,
do not position the front passenger
seat so the child restraint contacts
the instrument panel. If the child
restraint does contact the instrument
panel, the system may determine the
seat is occupied and the passenger air
bag may deploy in a collision. Also the
front passenger air bag status light
may not illuminate. See “Child re-
straints” (P.1-31) for information
about installing and using child re-
straints.
. Confirm the operating condition with
the front passenger air bag status
light.
. If you notice that the front passenger
air bag status light is not operating in
accordance with the above descrip-
tion, it is recommended you visit an
INFINITI retailer to check the pas-
senger seat advanced air bag system.
. Until you have confirmed with your
retailer that your passenger seat
advanced air bag is working properly,
position the occupants in the rear
seating positions. This vehicle is equipped with the INFINITI
Advanced Air Bag System for the driver and
front passenger seats. This system is de-
signed to meet certification requirements
under U.S. regulations. It is also permitted in
Canada.
All of the information, cautions and
warnings in this manual apply and must be
followed.
The driver supplemental front-impact air
bag is located in the center of the steering
wheel. The passenger supplemental front-
impact air bag is mounted in the instrument
panel above the glove box. The front air bags
are designed to inflate in higher severity
frontal collisions, although they may inflate
if the forces in another type of collision are
similar to those of a higher severity frontal
impact. They may not inflate in certain
frontal collisions. Vehicle damage (or lack
of it) is not always an indication of proper
front air bag operation.
The INFINITI Advanced Air Bag System
monitors information from the Air bag
Control Unit (ACU), seat belt buckle sensors
and the occupant classification sensors
(weight sensors). Inflator operation is based
on the severity of a collision and seat belt
usage for the driver. For the front passenger,
the occupant classification sensors are also
monitored. Based on information from the
sensors, only one front air bag may inflate in
a crash, depending on the crash severity and whether the front occupants are belted or
unbelted. Additionally, the front passenger
air bag may be automatically turned OFF
under some conditions, depending on the
information provided by the occupant clas-
sification sensors. If the front passenger air
bag is OFF, the front passenger air bag
status light will be illuminated (if the seat is
unoccupied, the light will not be illuminated,
but the air bag will be off). (See “Front
passenger air bag and status light” (P.1-60)
for further details.) One front air bag inflat-
ing does not indicate improper performance
of the system.
If you have any questions about your air bag
system, it is recommended you visit an
INFINITI retailer. If you are considering
modification of your vehicle due to a dis-
ability, you may also contact INFINITI.
Contact information is contained in the front
of this Owner’s Manual.
When a front air bag inflates, a fairly loud
noise may be heard, followed by release of
smoke. This smoke is not harmful and does
not indicate a fire. Care should be taken not
to inhale it, as it may cause irritation and
choking. Those with a history of a breathing
condition should get fresh air promptly.
Front air bags, along with the use of seat
belts, help to cushion the impact force on the
head and chest of the front occupants. They
can help save lives and reduce serious
Safety — seats, seat belts and supplemental restraint system1-59

How to temporarily disable the rear door
alert system ................................................................ 2-55
Power outlet .................................................................... 2-56 USB (Universal Serial Bus)
charging connector ................................................... 2-58
E-Call (SOS) Button (if so equipped) ........................ 2-59 Emergency support ................................................... 2-59
Storage ........................................................................\
..... 2-60
Cup holders ................................................................ 2-60
Sunglasses holder ...................................................... 2-62
Glove box ..................................................................... 2-63
Console box ................................................................ 2-63
Tray ........................................................................\
....... 2-65
Coat hooks .................................................................. 2-65
Luggage hooks .......................................................... 2-66
Cargo floor box .......................................................... 2-66
Roof rack ..................................................................... 2-67
Windows ........................................................................\
... 2-68
Power windows ......................................................... 2-68
Moonroof ........................................................................\
.. 2-70 Power moonroof ....................................................... 2-70
Welcome light .................................................................. 2-72 Battery saver system .............................................. 2-72
Interior lights .................................................................... 2-72
Interior light switch .................................................. 2-73
Console light ............................................................... 2-73
Map lights ................................................................... 2-74
Rear personal lights .................................................. 2-74 Vanity mirror lights ........................................................ 2-74
Cargo light ....................................................................... 2-75
HomeLink
®Universal Transceiver (Type A)
(if so equipped) ............................................................... 2-75
Programming HomeLink
®..................................... 2-76
Programming HomeLink®for Canadian
customers and gate openers ............................... 2-77
Operating the HomeLink
®
Universal Transceiver ............................................. 2-77
Programming troubleshooting ............................ 2-78
Clearing the programmed information ............. 2-78
Reprogramming a single
HomeLink
®button .................................................. 2-78
If your vehicle is stolen .......................................... 2-78
HomeLink
®Universal Transceiver (Type B) (if
so equipped) .................................................................... 2-79
Programming HomeLink
®.................................... 2-80
Using the garage door
two-way communication ...................................... 2-82
Programming HomeLink
®for Canadian
customers and gate openers ............................... 2-83
Operating the HomeLink
®
Universal Transceiver ............................................. 2-83
Programming troubleshooting ............................ 2-83
Clearing the programmed information ............ 2-84
Reprogramming a single
HomeLink
®button ................................................. 2-84
If your vehicle is stolen ......................................... 2-84

WAA0133X
1. Side ventilator
2. Meters and gauges
3. Hazard warning flasher switch
4. Center ventilator5. Upper touch screen display (upper dis-
play)
— Around View
®Monitor
— Navigation system
6. Lower touch screen display (lower dis- play) 7. Heater and air conditioner control
— Heated seats switch
— Climate controlled seats switch (if so
equipped)
— Defroster switch
8. Front passenger air bag status light
9. Audio system
10. Front passenger supplemental air bag
11. Fuse box
12. Parking brake
13. Hood release handle
14. Steering wheel — Horn
— Driver supplemental air bag
— Power steering system
15. Push-button ignition switch
16. Front console — Power outlet
— USB connection port
17. Cup holder/Tray
18. Glove box
Instruments and controls2-5
INSTRUMENT PANEL

CAUTION
.Do not use for anything other than
glasses.
. Do not leave glasses in the sunglasses
holder while parking in direct sun-
light. The heat may damage the
glasses.
SIC4393
GLOVE BOX
WARNING
Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.
To open the glove box, pull the handle
.
To close, push the lid in until the lock latches.
To lock
/unlockthe glove box, use the
mechanical key. For the mechanical key
usage, see “Keys” (P.3-2).
JVI1711X
CONSOLE BOX
Front
Type A (if so equipped):
To open the console box lid, push up the
knob
and pull up the lid.
To close, push the lid down until the lock
latches.
Instruments and controls2-63

damage the Intelligent Key. If the
Intelligent Key gets wet, immedi-
ately wipe until it is completely
dry.
— Do not bend, drop or strike it against another object.
— If the outside temperature is below 14°F (−10°C), the battery
of the Intelligent Key may not
function properly.
— Do not place the Intelligent Key for an extended period in a place
where temperatures exceed
140°F (60°C).
— Do not change or modify the Intelligent Key.
— Do not use a magnet key holder.
— Do not place the Intelligent Key near an electric appliance such as
a television set or personal com-
puter.
— Do not allow the Intelligent Key to come into contact with water
or salt water, and do not wash it
in a washing machine. This could
affect the system function.
. If an Intelligent Key is lost or stolen,
INFINITI recommends erasing the ID
code of that Intelligent Key. This will prevent the Intelligent Key from un-
authorized use to unlock the vehicle.
For information regarding the eras-
ing procedure, it is recommended you
visit an INFINITI retailer.
SPA2033
Mechanical key
To remove the mechanical key, release the
lock knob at the back of the Intelligent Key.
To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.
Use the mechanical key to lock or unlock the
doors and the glove box.
See “Doors” (P.3-4), “Storage” (P.2-60).
CAUTION
Always carry the mechanical key in-
stalled in the Intelligent Key.
Pre-driving checks and adjustments3-3

3-4Pre-driving checks and adjustments
VALET HAND-OFF
When you have to leave a key with a valet,
give them the Intelligent Key itself and keep
the mechanical key with you to protect your
belongings.
To prevent the glove box from being opened
during valet hand-off, follow the procedures
below.
1. Remove the mechanical key from theIntelligent Key.
2. Lock the glove box with the mechanical key.
3. Hand the Intelligent Key to the valet, keeping the mechanical key in your
pocket or bag for insertion into the
Intelligent Key when you retrieve your
vehicle.
See “Storage” (P.2-60).WARNING
. Always have the doors locked while
driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from unintention-
ally opening the doors, and will help
keep out intruders.
. Before opening any door, always look
for and avoid oncoming traffic.
. To help avoid risk of injury or death
through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.
SPA2457B
LOCKING WITH MECHANICAL
KEY
The power door lock system allows you to
lock or unlock all doors simultaneously using
the mechanical key.
.Turning the driver’s door key cylinder to
the front of the vehicle
will lock all
doors.
. Turning the driver’s door key cylinder
once to the rear of the vehicle
will
unlock the driver’s door. After returning
the key to the neutral position
, turning
it to the rear again within 5 seconds will
unlock all doors.
DOORS

3-12Pre-driving checks and adjustments
.When the Intelligent Key is placed
inside the glove box or a storage bin.
. When the Intelligent Key is placed
inside the door pockets.
. When the Intelligent Key is placed
inside or near metallic materials.
Unlocking doors and fuel-filler door
1. Push the door handle request switch
(driver’s or front passenger’s)or the
liftgate request switchonce while
carrying the Intelligent Key with you.
When you approach the vehicle with the
Intelligent Key, the puddle light and the
passenger cabin illumination will illumi-
nate and stay on for a short period of
time. (See “Welcome light” (P.2-72).)
2. The hazard indicator flashes once and outside chime sounds once. The corre-
sponding door will unlock.
The fuel-filler door will also unlock when
the driver’s door handle request switch is
pushed.
3. Push the door handle request switch again within 60 seconds.
4. The hazard indicator flashes once and outside chime sounds once again. All the
doors will unlock. The liftgate can be unlocked and opened by
pushing the liftgate opener switch. See
“Liftgate” (P.3-22).
All doors will be locked automatically unless
one of the following operations is performed
within 1 minute after pushing the request
switch while the doors are locked. If during
this 1-minute time period, the request switch
is pushed, all doors will be locked automa-
tically after another 1 minute.
.
Opening any door
. Pushing the ignition switch
Power liftgate open
1. Carry the Intelligent Key.
2. Push the power liftgate opener switch
.
3. The liftgate will unlock and automatically open.
4. The hazard indicator flashes 4 times and the outside chime sounds.
BATTERY SAVER SYSTEM
When all the following conditions are met
for a period of time, the battery saver
system will cut off the power supply to
prevent battery discharge.
.The ignition switch is in the ACC position,
and
. All doors are closed, and .
The shift lever is in the P (Park) position.
WARNING SIGNALS
To help prevent the vehicle from moving
unexpectedly by erroneous operation of the
Intelligent Key listed on the following chart
or to help prevent the vehicle from being
stolen, chime or beep sounds inside and
outside the vehicle and a warning displays in
the vehicle information display.
When a chime or beep sounds or the warning
displays, be sure to check the vehicle and
Intelligent Key.
See “Troubleshooting guide” (P.3-13) and
“Vehicle information display” (P.2-20).
