Specifications
8-1
8
Dimensions:Overall length:2150 mm (84.6 in)
Overall width:
885 mm (34.8 in)
Overall height: 1425 mm (56.1 in)
Seat height: 835 mm (32.9 in)
Wheelbase:
1510 mm (59.4 in)
Ground clearance: 150 mm (5.91 in)
Minimum turning radius: 2.8 m (9.19 ft)Wei ght:Curb weight:
267 kg (589 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Liquid cooled
Valve train: DOHC
Cylinder arrangement:
Inline
Number of cylinders: 3-cylinder
Displacement: 847 cm³
Bore × stroke:
78.0 × 59.1 mm (3.07 × 2.33 in) Starting system:
Electric starter
Engine oil:Recommended brand:
SAE viscosity grades:
10W-40
Recommended engine oil grade:
API service SG type or higher, JASO
standard MA
Engine oil quantity:
Oil change: 2.40 L (2.54 US qt, 2.11 Imp.qt)
With oil filter removal:
2.70 L (2.85 US qt, 2.38 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 1.93 L (2.04 US qt, 1.70 Imp.qt)Fuel:Recommended fuel:Unleaded gasoline (E10 acceptable)
Octane number (RON): 95
Fuel tank capacity:
18 L (4.8 US gal, 4.0 Imp.gal)
Fuel reserve amount: 4.0 L (1.06 US gal, 0.88 Imp.gal)
Fuel injection:Throttle body:ID mark: BD51 00Drivetrain:Gear ratio:
1st:2.667 (40/15)
2nd:
2.000 (38/19)
3rd: 1.619 (34/21)
4th: 1.381 (29/21)
5th:
1.190 (25/21)
6th: 1.037 (28/27)Chassis:Track:
410 mm (16.1 in)Front tire:Type:Tubeless
Size:
120/70 R 15 M/C 56V
Manufacturer/model: BRIDGESTONE/A41F MRear tire:Type:
Tubeless
Size: 190/55 R 17 M/C 75V
