Page 29 of 108

YAMAHA MT-10 2020 Owners Manual Instrument and control functions
4-8
1
2
345
6
7
8
9
10
11
12
EAU79183
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function me

Page 35 of 108

YAMAHA MT-10 2020 Owners Manual Instrument and control functions
4-14
1
2
345
6
7
8
9
10
11
12

“AVE – –.– km/L”: The average
distance that can be traveled on
1.0 L of fuel is shown.

“AVE – –.– L/100 km”:

Instrument and control functions
4-14
1
2
345
6
7
8
9
10
11
12

“AVE – –.– km/L”: The average
distance that can be traveled on
1.0 L of fuel is shown.

“AVE – –.– L/100 km”: The aver-
age amount of fuel necessary to
travel 100 km is shown.

“AVE – –.– MPG”: The average
distance that can be traveled on
1.0 Imp.gal of fuel is shown.
To switch between the “km/L” and
“L/100 km”, push the “CLOCK” and
“RESET” buttons at the same time.
To reset the average fuel consumption,
push the “RESET” button for two sec-
onds.
TIPAfter resetting the average fuel con-
sumption, “– –.–” will be shown until the
vehicle has traveled a sufficient dis-tance. Brightness and shift indicator light
control mode
This mode cycles through five control
functions, allowing you to make the fol-
lowing settings in the order listed be-
low.

Screen brightness:
This function allows you to adjust
the brightness of the screen.

Shift indicator light style:
This function allows you to set the
indicator light to on, flash, or off.

Shift indicator light on r/min:
This function allows you to select
the engine speed at which the indi-
cator light will be activated.

Shift indicator light off r/min:This function allows you to select
the engine speed at which the indi-
cator light will be deactivated.

Shift indicator light brightness:
This function allows you to adjust
the brightness of the shift indicator
light.
TIPThe brightness level display shows thebrightness level setting.
To adjust the brightness of the screen1. Turn the key to “OFF”.
2. Push and hold the “CLOCK” but-
ton.
3. Turn the key to “ON”, and then re- lease the “CLOCK” button after
five seconds.
4. Push the “RESET” button to select the desired brightness level.
5. Push the “CLOCK” button to con- firm the selected brightness level.
The control mode changes to the
shift indicator light style function.
To set the shift indicator light style1. Push the “RESET” button to select one of the following style settings:
1. Brightness level display
1
B67-9-E4.book 14 ページ２０１９年７月１９日　金曜日　午後４時２３分

Page 36 of 108

YAMAHA MT-10 2020 Owners Manual Instrument and control functions
4-15
1
2
34
5
6
7
8
9
10
11
12

On - the indicator light will come
on when activated. (This setting
is selected when the indicator
light stays on.)

Flash - the

Instrument and control functions
4-15
1
2
34
5
6
7
8
9
10
11
12

On - the indicator light will come
on when activated. (This setting
is selected when the indicator
light stays on.)

Flash - the indicator light will
flash when activated. (This set-
ting is selected when the indica-
tor light flashes four times per
second.)

Off - the indicator light is deacti-
vated; in other words, it will not
come on or flash. (This setting
is selected when the indicator
light flashes once every two
seconds.)
2. Push the “CLOCK” button to con- firm the selected indicator light ac-
tivity. The control mode changes to
the shift indicator light on r/min
function.
To set the shift indicator light on r/min
TIPThe shift indicator light can be set be-
tween 7000 r/min and 13000 r/min in in-crements of 200 r/min. 1. Push the “RESET” button to select the desired engine speed for acti- vating the indicator light.
2. Push the “CLOCK” button to con- firm the selected engine speed.
The control mode changes to the
shift indicator light off r/min func-
tion.
To set the shift indicator light off r/min
TIP
The shift indicator light can be
set between 7000 r/min and
13000 r/min in increments of 200
r/min.

Be sure to set the off r/min to a
higher engine speed than the on
r/min setting, otherwise the shiftindicator light will not come on.
1. Push the “RESET” button to select the desired engine speed for deac-
tivating the indicator light.
2. Push the “CLOCK” button to con- firm the selected engine speed.
The control mode changes to the
shift indicator light brightness func-
tion. To adjust the brightness of the shift in-
dicator light1. Push the “RESET” button to select
the desired indicator light bright-
ness level.
2. Push the “CLOCK” button to con- firm the selected indicator light
brightness level and exit the bright-
ness and shift indicator light con-
trol mode.
B67-9-E4.book 15 ページ２０１９年７月１９日　金曜日　午後４時２３分

Page 43 of 108

YAMAHA MT-10 2020 Owners Manual Instrument and control functions
4-22
1
2
345
6
7
8
9
10
11
12
EAU57992
SeatTo remove the seat 1. Open the seat lock cover, insert the key into the seat lock, and then
turn the key counterclockwise.
