2020 VAUXHALL VIVARO C refuelling

Keys, doors and windows31Caution
To avoid damage, do not attempt
to operate the sliding side door
when the fuel filler flap is open.
9 Danger
Do not drive with the sliding side
door open or ajar, e.g. when
transporting bulky objects, since
toxic exhaust gases, which cannot be seen or smelled, could enter
the vehicle. This can cause
unconsciousness and even death.
Refuelling 3 204.
Power sliding doors
9 Warning
Take care when operating the
power sliding doors. Risk of injury, particularly to children.
Take particular care when the
vehicle is parked on a slope: open
or close the door fully until it
latches into its locking position.
Keep a close watch on the moving doors when operating. Ensure that
nothing becomes trapped during
operation and no-one is standing
within the moving area.
The power sliding doors can be
operated by:
● pressing N or M on the radio
remote control
● pressing N or M on the electronic
key
● pressing P or O on the
instrument panel
● pressing P or O on the door
frame
● hands-free operation with motion
sensors below the rear bumper
● pulling the respective door handle.
Operation with the electronic key
Press N or M longer to open or close
the respective power sliding door.
Hands-free operation
Depending on the vehicle
configuration, the vehicle may have
one or two hands-free operated
sliding doors.

Instruments and controls113Illuminates temporarilyStart of saturation of the exhaust filter.
Start cleaning process as soon as
possible by driving at a vehicle speed of at least 40 mph.
Illuminates constantly Indication of a low additive level. Seek
the assistance of a workshop.
Exhaust filter 3 160.
AdBlue B flashes or illuminates yellow.
Illuminates yellow The remaining driving range is
between 60 miles and 1500 miles.
Flashes yellow
The remaining driving range is
between 0 miles and 60 miles.
AdBlue level is low. Refill AdBlue
soon to avoid prevention of the
engine start.
AdBlue 3 161.Deflation detection system
q illuminates or flashes yellow.
Illuminates
Tyre pressure loss in one or more
wheels. Stop immediately and check
tyre pressure.
Flashes
Fault in system. Consult a workshop.
Deflation detection system 3 238.
Engine oil pressure
T illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly after the engine starts.
Illuminates when the engine is
runningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and / or
locking of the drive wheels.
1. Select neutral gear.
2. Move out of the flow of traffic as quickly as possible without
impeding other vehicles.
3. Switch off ignition.9 Warning
When the engine is off,
considerably more force is needed
to brake and steer. During an
Autostop the brake servo unit will
still be operational.
Do not remove key until vehicle is stationary, otherwise the steeringwheel lock could engage
unexpectedly.
Keep engine turned off and let the
vehicle be towed to a workshop.
Low fuel r or 2 illuminates yellow.
Level in fuel tank is too low.
Refuelling 3 204.
Bleeding the diesel fuel system
3 218.

Instruments and controls117Trip / fuel information menu,
baselevel display
Differerent pages with combined
information can be selected.
Select the required page:
Trip pages:
Trip odometer
The recorded distance since the
reset.
To reset, press F for a few
seconds.
Average fuel consumption
Display of average consumption. The measurement can be reset at any
time and starts with a default value.
To reset, press F for a few
seconds.
Average speed
Display of average speed. The
measurement can be reset at any
time.
To reset, press F for a few
seconds.
Information pages:
Fuel range
Range is calculated from current fuel
level and current consumption. The
display shows average values.
After refuelling, the range is updated
automatically after a brief delay.
When the fuel level is low, a message
appears on the display and the
control indicator 2 in the fuel gauge
illuminates 3 113.
Instantaneous fuel consumption
Display of the instantaneous
consumption.
Digital speedDigital display of the instantaneous
speed.
Stop and Start time counter
A time counter adds up the time spent in Autostop during a journey.
It resets to zero everytime the ignition is switched on.
Compass
Displays the geographic direction of
driving.
AdBlue range
Press F repeatedly until the
AdBlue menu is shown.
Indicates an estimate of the AdBlue
level. A message indicates whether
the level is sufficient or low.
AdBlue 3 161.

118Instruments and controlsTrip / fuel information menu,
midlevel display
Differerent pages with combined
information can be selected.
Select the required page:
Trip pages:
Trip odometer
The recorded distance since the
reset.
To reset, press SET 000 for a few
seconds.
Average fuel consumption
Display of average consumption. The measurement can be reset at any
time and starts with a default value.
To reset, press SET 000 for a few
seconds.
Average speed
Display of average speed. The
measurement can be reset at any
time.
To reset, press SET 000 for a few
seconds.
Information pages:
Fuel range
Range is calculated from current fuel
level and current consumption. The
display shows average values.
After refuelling, the range is updated
automatically after a brief delay.
When the fuel level is low, a message
appears on the display and the
control indicator 2 in the fuel gauge
illuminates 3 113.
Instantaneous fuel consumption
Display of the instantaneous
consumption.
Digital speedDigital display of the instantaneous
speed.
Stop and Start time counter
A time counter adds up the time spent in Autostop during a journey.
It resets to zero everytime the ignition is switched on.
Compass
Displays the geographic direction of
driving.
AdBlue range
Press SET 000 repeatedly until the
AdBlue menu is shown.
Indicates an estimate of the AdBlue
level. A message indicates whether
the level is sufficient or low.
AdBlue 3 161.
AdBlue range
Press CHECK repeatedly until the
AdBlue menu is shown.
AdBlue range
Indicates an estimate of the AdBlue
level. A message indicates whether
the level is sufficient or low.

Instruments and controls119Trip / fuel information menu,
uplevel display
Differerent pages with combined
information can be selected.
Select the required page:
Trip pages:
Trip odometer
The recorded distance since the
reset.
To reset, press 000 for a few seconds.
Average fuel consumption
Display of average consumption. The measurement can be reset at any
time and starts with a default value.
To reset, press 000 for a few seconds.
Average speed
Display of average speed. The
measurement can be reset at any
time.
To reset, press 000 for a few seconds.
Information pages:
Fuel range
Range is calculated from current fuel
level and current consumption. The
display shows average values.
After refuelling, the range is updated
automatically after a brief delay.
When the fuel level is low, a message appears on the display and the
control indicator 2 in the fuel gauge
illuminates 3 113.
Instantaneous fuel consumption
Display of the instantaneous
consumption.
Digital speed
Digital display of the instantaneous
speed.
Stop and Start time counter
A time counter adds up the time spent
in Autostop during a journey.It resets to zero everytime the ignition is switched on.
Compass
Displays the geographic direction of
driving.
AdBlue range
Press 000 repeatedly until the AdBlue
menu is shown.
Indicates an estimate of the AdBlue
level. A message indicates whether
the level is sufficient or low.
AdBlue 3 161.
Info Display The Info Display is located in theinstrument panel near the instrument
cluster.
The Info Display can indicate: ● time 3 97
● outside temperature 3 96
● date 3 97
● Infotainment system, see description in the Infotainment
Manual
● indication of rear view camera 3 199

Driving and operating151Driving and
operatingDriving hints ............................... 152
Control of the vehicle ...............152
Steering ................................... 152
Starting and operating ...............152
New vehicle running-in ............152
Ignition switch positions ...........152
Power button ........................... 153
Starting the engine ..................154
Overrun cut-off ........................ 156
Stop-start system ....................156
Parking .................................... 159
Engine exhaust .......................... 160
Exhaust filter ............................ 160
Catalytic converter ...................160
AdBlue ..................................... 161
Automatic transmission ..............164
Transmission display ...............165
Gear selection ......................... 165
Manual mode ........................... 166
Electronic driving programmes 167
Fault ........................................ 167
Manual transmission ..................167Brakes........................................ 168
Antilock brake system .............168
Parking brake .......................... 169
Brake assist ............................. 169
Hill start assist ......................... 170
Ride control systems .................170
Electronic Stability Control and Traction Control system .........170
Selective ride control ...............171
Driver assistance systems .........173
Cruise control .......................... 173
Speed limiter ........................... 176
Adaptive cruise control ............179
Forward collision alert .............186
Active emergency braking .......188
Front pedestrian protection .....190
Parking assist .......................... 191
Side blind spot alert .................194
Panoramic view system ...........196
Rear view camera ...................199
Lane departure warning ..........200
Driver alert ............................... 201
Fuel ............................................ 203
Fuel for diesel engines ............203
Refuelling ................................ 204
Trailer hitch ................................ 205
General information .................205
Driving characteristics and towing tips .............................. 205Trailer towing........................... 206
Towing equipment ...................206
Trailer stability assist ...............209

204Driving and operatingArctic grade diesel fuel can be used
in extreme low temperatures below
-20 °C. Using this fuel grade in warm
or hot climates is not recommended
and may cause engine stalling, poor
starting or damage on the fuel
injection system.
Refuelling9 Danger
Before refuelling, switch off
ignition and any external heaters
with combustion chambers.
Follow the operating and safety
instructions of the filling station
when refuelling.
9 Danger
Fuel is flammable and explosive.
No smoking. No naked flames or
sparks.
If a smell of fuel can be noticed
inside the vehicle, have the cause of this remedied immediately by aworkshop.
A label with symbols at the fuel filler
flap is indicating the allowed fuel
types. In Europe the pump nozzles of the filling stations are marked with
these symbols. Refuel only the
allowed fuel type.Caution
In case of misfuelling, do not
switch on ignition.
Fuel filler flap is located at left rear
side of vehicle.
If the vehicle is equipped with an
electronic key system, the fuel filler
flap can only be opened if the vehicle
is unlocked. Depending on the
version, release the fuel filler flap by
pushing the flap or pulling at the right bottom corner.
Depending on the version, place the
key in the lock and unlock the cap.
To open, turn the cap slowly
anticlockwise.
The fuel filler cap can be attached to
the hook on the fuel filler flap.
Place the nozzle in straight position to the filler neck and press with slight
force to insert.
To refuel, switch on pump nozzle.

285Particulate filter........................... 160
Performing work ........................212
Peripheral lighting .......................137
Power button .............................. 153
Power outlets ............................... 97
Power seat adjustment ................49
Power sliding doors ......................30
Power windows ............................ 41
Preheating ................................. 112
Puncture ..................................... 245
R Radio Frequency Identification (RFID) ..................................... 280
Radio (Infotainment system)....... 123
Radio remote control ...................22
Rain sensor ................................ 114
REACH ....................................... 276
Reading lights ............................ 135
Rear doors .................................... 30
Rear fog light .............114, 133, 225
Rear seats ................................... 52
Rear view camera ...................... 199
Rear windows .............................. 42
Rear window wiper and washer ..96
Recommended fluids and lubricants ........................ 262, 266
Refuelling ................................... 204 Registered trademarks ...............276
Reversing lights .........................134Ride control systems ..................170
Roadside assistance ..................127
Roller blinds ................................. 44
Roof .............................................. 45
Roof bars ...................................... 89
Roof load ...................................... 90
Roof rack ..................................... 89
S Safety net .................................... 83
Seat adjustment ............................. 7
Seat belt ........................................ 8
Seat belt reminder .....................109
Seat belts ..................................... 56
Seat folding .................................. 50
Seat heating ................................. 51
Seat position ................................ 47
Selective catalytic reduction .......161
Selective ride control ..................171
Selector lever.............................. 165
Service ............................... 150, 259
Service display .......................... 108
Service information ....................259
Service vehicle soon .................. 111
Side airbag system ......................63
Side blind spot alert ............115, 194
Sidelights .................................... 129
Side turn lights ........................... 228
Sliding doors ................................ 30
Sliding side doors .........................30SOS............................................ 127
Spare wheel ............................... 245
Speed limiter....................... 115, 176
Speedometer ............................. 104
Starting and operating ................152
Starting off ................................... 18
Starting the engine ....................154
Steering ...................................... 152
Steering column controls ..............94
Steering wheel .............................. 94
Steering wheel adjustment ......9, 93
Steering wheel controls ...............93
Stop engine ................................ 111
Stop-start system........................ 156
Storage ......................................... 77
Storage compartments .................77
Sunvisor lights ........................... 136
Sun visors .................................... 44
Symbols ......................................... 4
System check ............................. 111
T
Table............................................. 86
Tachometer ............................... 106
Tailgate ......................................... 32
tailgate window ............................. 42
Tail lights ................................... 225
Three-point seat belt .................... 57
Tools .......................................... 234
torch............................................ 134
