Body conversions325Body conversionsTipper and dropside...................325
Loading information .................325
Tailboard ................................. 326
Sideboards .............................. 327
Lashing eyes ........................... 328
Tipper operation ......................328
Safety prop .............................. 330
Hydraulic oil level ....................331
Toolbox .................................... 332
Exterior lighting ........................332
Cleaning .................................. 332
Vehicle checks ........................ 332
Technical data ......................... 333
Declaration of conformity .........333
Box body .................................... 334
Keys ........................................ 334
Doors ....................................... 334
Roller shutter ........................... 335
Step ......................................... 335
Ladder ..................................... 336
Overcab storage ......................336
Load rails ................................. 336
Interior lighting ......................... 337Crew van.................................... 337
Child restraint systems ............337
Storage .................................... 337Tipper and dropside
Loading information The tipper and dropside are not
designed for carrying people or
unsuitable / unsafe materials.
● Load the vehicle evenly, distributing the load across the
body.
● Ensure the vehicle tailboard and sideboards are securely closed
before loading.
● Secure any solid loads with additional lashing equipment.
Body conversions333components appear loose,
defective or leaking, seek the
assistance of a workshop to
rectify the cause of the fault.
● The tipper has an operating angle of 45° - 50°. If this limit is
exceeded, seek the assistance of a workshop to rectify the cause of the fault.
● Do not operate the tipper if the acoustic signal doesn't sound.Seek the assistance of a
workshop.
● Lubricate every six months the tipper body pivots with high-
pressure grease.
● Check every 50 work hours or 6 months, whichever occurs first,
the hydraulic oil level in the
reservoir.
Technical data The technical data is determined in
accordance with European
Community standards.We reserve the right to make
modifications. Specifications in the
vehicle documents always have
priority over those stated here.
Additional information can be found
on the body data plate.
Declaration of conformity The declaration of conformity which
meets directive 2006/42/CE is
provided with the vehicle.
