2020 TOYOTA COROLLA odometer

772-1. Instrument cluster
COROLLA_U
2
Vehicle status information and indicators
■Locations of gauges and meters
The units of measure may differ depending on the intended destination of
the vehicle.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C)
Clock ( P. 7 9 )
Multi-information display
Presents the driver with a variety of vehicle data ( P.86)
Displays warning me ssages if a malfunction occurs ( P.490)
Odometer and trip meter display ( P.78)
Shift position indicator ( P.153)
Display change button ( P.78)
Fuel gauge
Displays the quantity of fuel remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Gauges and meters (4.2-inch display)
Meter display

782-1. Instrument cluster
COROLLA_U
■Outside temperature display
●In the following situations, the cor-
rect outside temperature may not
be displayed, or the display may
take longer than normal to
change:
• When stopped, or driving at low
speeds (less than 16 mph [25
km/h])
• When the outside temperature
has changed suddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning.
Take your vehicle to your Toyota
dealer.
■Liquid crystal display
 P. 8 7
■Changing the display
Press the display change button
until the desired item is dis-
played.
■Display items
 Odometer
Displays the total distance the vehi-
cle has been driven.
Trip meter A/Trip meter B
Displays the distance the vehicle
has been driven since the meter
was last reset. Trip meters A and B
can be used to record and display
WARNING
■The information display at
low temperatures
Allow the interior of the vehicle to
warm up before using the liquid
crystal information display. At
extremely low temperatures, the
information display monitor may
respond slowly, and display
changes may be delayed.
For example, there is a lag
between the driver’s shifting and
the new gear number appearing
on the display. This lag could
cause the driver to downshift
again, causing rapid and exces-
sive engine braking and possibly
an accident resulting in death or
injury.
NOTICE
■To prevent damage to the
engine and its components
●Do not let the indicator needle
of the tachometer enter the red
zone, which indicates the maxi-
mum engine speed.
●The engine may be overheating
if the engine coolant tempera-
ture gauge is in the red zone
(H). In this case, immediately
stop the vehicle in a safe place,
and check the engine after it
has cooled completely.
(  P.519)
Odometer and trip meter
display

812-1. Instrument cluster
COROLLA_U
2
Vehicle status information and indicators
■Locations of gauges and meters
Analog speedometer
The units of measure may differ depending on the intended destination of
the vehicle.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Sub speedometer
Clock ( P. 8 4 )
Fuel gauge
Displays the quantity of fuel remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Display change button ( P.83)
Odometer and trip meter display ( P.83)
Multi-information display
Presents the driver with a variety of vehicle data ( P.86)
Displays warning me ssages if a malfunction occurs ( P.490)
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
Gauges and meters (7-inch display)
Meter display

822-1. Instrument cluster
COROLLA_U(50°C)
Shift position indicator (
P.153)
Digital speedometer
The units of measure may differ depending on the intended destination of
the vehicle.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Clock ( P. 8 4 )
Fuel gauge
Displays the quantity of fuel remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Display change button ( P.83)
Odometer and trip meter display ( P.83)
Multi-information display
Presents the driver with a variety of vehicle data ( P.86)
Displays warning me ssages if a malfunction occurs ( P.490)
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C)
Shift position indicator ( P.153)
■Outside temperature display●In the following situations, the cor-
rect outside temperature may not

832-1. Instrument cluster
COROLLA_U
2
Vehicle status information and indicators
be displayed, or the display may
take longer than normal to
change:
• When stopped, or driving at low speeds (less than 16 mph [25
km/h])
• When the outside temperature has changed suddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning.
Take your vehicle to your Toyota
dealer.
■Liquid crystal display
 P. 8 7
■Customization
The gauges and meters can be cus-
tomized in of the multi-informa-
tion display. ( P. 9 0 )
■Changing the display
Press the display change button
until the desired item is dis-
played.
■Display items
 Odometer
Displays the total distance the vehi-
cle has been driven.
Trip meter A/Trip meter B
Displays the distance the vehicle
has been driven since the meter
was last reset. Trip meters A and B
can be used to record and display
WARNING
■The information display at
low temperatures
Allow the interior of the vehicle to
warm up before using the liquid
crystal information display. At
extremely low temperatures, the
information display monitor may
respond slowly, and display
changes may be delayed.
For example, there is a lag
between the driver’s shifting and
the new gear number appearing
on the display. This lag could
cause the driver to downshift
again, causing rapid and exces-
sive engine braking and possibly
an accident resulting in death or
injury.
NOTICE
■To prevent damage to the
engine and its components
●Do not let the indicator needle
of the tachometer enter the red
zone, which indicates the maxi-
mum engine speed.
●The engine may be overheating
if the engine coolant tempera-
ture gauge is in the red zone
(H). In this case, immediately
stop the vehicle in a safe place,
and check the engine after it
has cooled completely.
(  P.519)
Odometer and trip meter
display

578Alphabetical Index
COROLLA_U
Manual air conditioning system ............................................... 386
Manual transmission ............. 160 iMT ....................................... 161
Media button (Menu screen).. 263
Menu icons ............................... 86
Menu screen ........................... 263 Menu screen operation ........ 263
Meter Clock ................................ 77, 81
Indicators................................ 74
Instrument panel light control79, 84
Meter control switches ........... 87
Meters .............................. 77, 81
Multi-information display ........ 86
Settings .................................. 90
Warning lights....................... 481
Warning message ................ 490
Microphone ............................. 348
Mirrors Inside rear view mirror.......... 124
Outside rear view mirror defog-gers ............................ 388, 392
Outside rear view mirrors ..... 125
Vanity mirrors ....................... 412
Mobile Assistant ..................... 343 Connectable devices and avail-able functions ..................... 343
Mobile Assistant operation ... 343
Moon roof Door lock linked moon roof oper-ation ................................... 130
Jam protection function ........ 130
Operation ............................. 130
Multi-information display Audio system-linked display ... 90
Clock ................................ 79, 84
Driving information display ..... 87
Driving support system informa-tion display ........................... 89
Dynamic radar cruise control 223 Dynamic radar cruise control
with full-speed range ..........213
Eco Driving Indicator ..............88
Fuel economy .........................88
LDA (Lane Departure Alert with steering control)..................210
LTA (Lane-Tracing Assist) .....201
Menu icons .............................86
Meter control switches............87
Navigation system-linked display .............................................89
Settings ..................................90
Tire pressure ........................447
Vehicle information display .....90
Warning message.................490
N
Navigation system-linked display .................................................89
Noise from under ve hicle...........6
O
Odometer.............................78, 83
Odometer and trip meter display
Display change button ......78, 83
Display items ....................78, 83
Oil Engine oil......................526, 527
Manual transmission ............529
Open trays ...............................402
Opener Fuel filler door.......................178
Hood .....................................434
Trunk ....................................109
Outside rear view mirrors Adjustment ...........................125
BSM (Blind Sport Monitor) ....236
Folding..................................126
Outside rear view mirror defog-gers ............................388, 392
Outside temperature ..........77, 81
