Locking And Unlocking RamBox
Push and release the lock or unlock button on the key fob to
lock and unlock all doors, the tailgate and the RamBox (if
equipped). Refer to “Keys” in this chapter for further details.
To unlatch the storage bin manually, insert the emergency
key into the keyhole and turn clockwise. Always return the
key to the upright (vertical) position before removing it from
the keyhole.RamBox Safety Warning
Carefully follow these warnings to help prevent personal
injury or damage to your vehicle:
CAUTION!
• Ensure cargo bin lids are closed and latched before moving or driving vehicle.
• Loads applied to the top of the bin lid should be mini -
mized to prevent damage to the lid and latching/
hinging mechanisms.
• Damage to the RamBox bin may occur due to heavy/ sharp objects placed in bin that shift due to vehicle
motion. In order to minimize potential for damage,
secure all cargo to prevent movement and protect inside
surfaces of bin from heavy/sharp objects with appro -
priate padding.
WARNING!
• Always close the storage bin covers when your vehicle is unattended.
• Do not allow children to have access to the storage bins. Once in the storage bin, young children may not be able
to escape. If trapped in the storage bin, children can die
from suffocation or heat stroke.
• In an accident, serious injury could result if the storage bin covers are not properly latched.
• Do not drive the vehicle with the storage bin covers open.
• Keep the storage bin covers closed and latched while the vehicle is in motion.
• Do not use a storage bin latch as a tie down.2
2020_DT_1500_OM_US.book Page 139
Page 143 of 674
GETTING TO KNOW YOUR VEHICLE 141
To install the bed divider into the storage position, perform
the following:
1. Make sure the center handle is unlocked using the vehiclekey and rotate the center handle vertically to release the
divider side gates.
Center Handle And Lock 2. With the side gates open, position the divider fully
forward in the bed against the front panel.
Storage Position
1 — Center Handle Lock
2 — Handle
2
2020_DT_1500_OM_US.book Page 141
Page 144 of 674
142 GETTING TO KNOW YOUR VEHICLE
3. Rotate the side gates closed allowing the outboard ends tobe positioned in front of the cargo tie down loops.
Cargo Tie Down Loop 4. Rotate the center handle horizontally to secure the side
gates in the closed position.
Side Gates Closed
5. Lock the center handle using the vehicle key to secure the panel into place.
2020_DT_1500_OM_US.book Page 142
Page 145 of 674
GETTING TO KNOW YOUR VEHICLE 143
Divider Position
The divider position is intended for managing your cargo
and assisting in keeping cargo from moving around the bed.
There are 11 divider slots along the bed inner panels which
allow for various positions to assist in managing your cargo.
To install the bed divider into a divider position, perform the
following:
1. Make sure the center handle is unlocked using the vehiclekey and rotate the center handle vertically to release the
divider side gates.
Center Handle And Lock
1 — Center Handle Lock
2 — Handle
2
2020_DT_1500_OM_US.book Page 143
Page 149 of 674
GETTING TO KNOW YOUR VEHICLE 147
NOTE:
When a cap or pickup camper is installed on a vehicle, an
alternate Center High-Mounted Stop Light (CHMSL) must
be provided.
EASY-OFF TAILGATE
To simplify mounting of a camper unit with an overhang, the
tailgate can be removed.
NOTE:
The electric connector at the bottom of the tailgate must be
disconnected prior to removing the tailgate.
Disconnecting The Rear Camera And Remote Keyless
Entry
1. Open the tailgate to access the rear camera or RemoteKeyless Entry (RKE) connector bracket located on the rear
sill.
Connector Bracket
WARNING!
To avoid inhaling carbon monoxide, which is deadly, the
exhaust system on vehicles equipped with “Cap or
Slide-In Campers” should extend beyond the
overhanging camper compartment and be free of leaks.
2
2020_DT_1500_OM_US.book Page 147
Page 150 of 674
148 GETTING TO KNOW YOUR VEHICLE
2. Remove the connector bracket from the sill by pushinginward in the locking tab.
Locking Tab
3. Disconnect the chassis wiring harness, ensuring the connector bracket does not fall into the sill. 4. Connect the chassis plug and bracket (provided in the
glove compartment) to the chassis wiring harness and
insert the bracket back into the sill.
5. Connect the tailgate plug (provided in the glove compart -
ment) to the tailgate wiring harness to ensure that the
terminals do not corrode.
6. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will prevent
damaging the connector and bracket when storing or
reinstalling the tailgate.
Removing The Tailgate
1. Disconnect the wiring harness for the rear camera and orpower locks (if equipped).
NOTE:
Refer to “Disconnecting The Rear Camera And Remote
Keyless Entry” in this section.
2020_DT_1500_OM_US.book Page 148
Page 152 of 674
150 GETTING TO KNOW YOUR VEHICLE
Locking Tailgate
The tailgate can be locked using the key fob lock button.
TRI-FOLD TONNEAU COVER — IF EQUIPPED
Your vehicle may be equipped with a Tri-Fold Tonneau
Cover which consists of different features:
• Easy Tri-Fold cover
• Tonneau fore aft locator
• Crossbar inside bed locator
• Front and rear clamps
• Stowage strap
• Locking capability
Tri-Fold Tonneau Cover Removal
To remove the Tonneau Cover follow the following steps:
1. Open the tailgate to access the rear pair of Tonneau Coverclamps located on the underside of the Cover (left and
right side).
Clamped Position
2020_DT_1500_OM_US.book Page 150
