Vehicle care285Instrument panel
illumination
Have bulbs replaced by a workshop.Electrical system
Fuses Data on the replacement fuse must
match the data on the defective fuse.
There are two fuse boxes in the
vehicle:
● on the left-hand side of the instrument panel, behind the trim
panel
● in the engine compartment located below the coolant
expansion tankCombi
An additional fuse box is located
behind a trim panel on the right-hand
side of the load compartment, beside the rear door.Bus
An additional fuse box is located on
the lower right-hand side of the load
compartment, below the step trim
panel.
Before replacing a fuse, turn off the
respective switch and the ignition.
A blown fuse can be recognised by its melted wire.
Caution
Do not replace the fuse until the
cause of the fault has been
remedied.
It is advisable to carry a full set of
fuses. Consult a workshop.
Some functions are protected by
several fuses.
Fuses may also be inserted without
existence of a function.
Note
Not all fuse box descriptions in this
manual may apply to your vehicle.
When inspecting the fuse box, refer
to the fuse box label.
Fuse extractor
A fuse extractor may be located in the
instrument panel fuse box. The
extractor has two sides, each side is
designed for a different type of fuses.

286Vehicle care
Grab the fuse with the fuse extractor
and withdraw the fuse.
Engine compartment fuse
box
Located below the coolant expansion tank.
Remove the screw to move the
coolant expansion tank to the side.
Unscrew the four screws to remove
the cover.
Disengage the fuse box cover and
remove it.
Some circuits may be protected by
several fuses.
SymbolCircuitVHeated windscreennHeating and ventilation
system / Air conditioningSRight side lightsTLeft side lights

Vehicle care287SymbolCircuitWRight low beamaLeft low beam>Front fog lightsLLeft high beamNRight high beamuABSKWindscreen wiperQPneumatic suspension
Instrument panel fuse box
Located behind the trim panel. Pull
upper part of trim panel to remove.
Do not store any objects behind this
panel.
Some circuits may be protected by
several fuses.SymbolCircuitSRight-hand side lightTLeft-hand side lightxClimate control fan&TachographÍPreheatingZInfotainment system / Seat
heating / Driver Information
Centre / Audio connec‐
tions / AlarmlHands-free connectionADPAdditional adaptationsPTOPower take-offUHeated seatsMElectronic immobiliserSymbolCircuitRWindscreen washer,Power windows / Body
control modulenRight heated rear windowmLeft heated rear windowIBody control module /
Power windows / Heating
and ventilation system / Air
conditioningSTOPBrake lightZBody control moduledInterior lights / Brake lightsuABS / Electronic Stability
ControljHorn0Interior lightsOTurn lights / Rear fog light /
Body control moduleUCentral locking

288Vehicle careSymbolCircuiteInstrument panel / Diag‐
nostic connectordHeated exterior mirrors?Power outletÌCigarette lighter
Load compartment fuse box
Combi
Located behind the trim panel on the
right-hand side of the load
compartment, beside the rear door.
Using a suitable tool, e.g. a flat-blade screwdriver, unclip the trim panel at
the three locations shown in the
illustration and remove.
Do not store any objects behind this
panel.No.Circuit1Speed 3: additional evaporator2Speed 2: additional evaporator3Speed 1: additional evaporatorBus
Located below the step trim panel on
the lower right-hand side of the load
compartment.
Using a suitable tool, e.g. a flat-blade screwdriver, unclip the trim panel at
the three locations shown in the
illustration and remove.
Do not store any objects behind this
panel.

344Disconnecting a phone...............195
Display ........................................ 129
Displaying pictures .....................161
Display screen operation ....129, 193
Door locks..................................... 23
Door open .................................. 104
Doors .................................... 30, 336
DPF (diesel particle filter) ...........233
Drink holders ................................ 74
Driver assistance systems ..........249
Driver Information Centre ...........105
Driving characteristics and towing tips .............................. 265
Driving economically................... 225
Driving hints ................................ 225
Driving style indicator Fuel economy gauge ..............129
E Easy access ............................... 129
Eco-coaching .............................. 129
Eco Driving ................................. 129
ECO mode .................................. 225
Edit Itinerary ............................... 183
Electric adjustment ......................39
Electrical accessories ...................88
Electrical system......................... 285
Electronic climate control system 210
Electronic driving programmes ..243
Electronic key system ...................22Electronic Stability Control 101,
248, 266
Emergency call ........................... 200
Emergency exit .......................42, 44
Emergency number ....................200
End-of-life vehicle recovery .......270
Engine compartment fuse box ...286
Engine coolant ........................... 272
Engine coolant temperature ......101
Engine coolant temperature gauge ....................................... 93
Engine drag torque control .........248
Engine exhaust .......................... 233
Engine identification ...................316
Engine oil ................... 271, 313, 317
Engine oil additives ....................313
Engine oil pressure ....................102
Engine oil viscosity grades .........313
Enhanced traction function 247, 248, 249
Enter an address ........................177
Entering a number manually ......201
Event data recorders ..................323
Exhaust gases ............................ 233
Exit lighting ................................ 116
Exterior care .............................. 308
Exterior light ............................... 103
Exterior lighting ............14, 110, 334
Exterior mirrors ............................. 38
External device authorisation .....197F
Fader .......................................... 137
Fault ........................................... 244
Favourite destinations ................177
Favourites ................................... 129
Media ...................................... 129
Navigation ............................... 129
Phone ...................................... 129
Services .................................. 129
Fire extinguisher ........................... 81
First aid ......................................... 81
First aid kit ................................... 81
Fixed air vents ........................... 222
FM station list ............................. 147
Fog lights .................................... 113
Folding mirrors ............................. 39
Folding mirrors setting ................129
Folding seat .................................. 74
Front airbag system .....................62
Front courtesy light .....................114
Front fog lights ...........103, 113, 279
Front reading light....................... 116
Front seats.................................... 46
Front storage ................................ 74
Front turn lights .......................... 279
Fuel economy gauge Driving style indicator ..............129
Fuel for diesel engines ..............262
Fuel gauge ................................... 93 Fuel tank ..................................... 317
