2020 NISSAN NV200 headlights

∙ Do not use double adapters or morethan one electrical accessory.
∙ Use power outlets with the engine running to avoid discharging the ve-
hicle battery.
∙ Avoid using power outlets when the air conditioner, headlights or rear win-
dow defroster (if so equipped) is on.
∙ Before inserting or disconnecting a plug, be sure the electrical accessory
being used is turned off.
∙ Push the plug in as far as it will go. If good contact is not made, the plug
may overheat or the internal tem-
perature fuse may open.
∙ When not in use, be sure to close the cap. Do not allow water or any other
liquid to contact the outlet.
FRONT-DOOR POCKETS UNDER-SEAT STORAGE BIN
To open the drawer, lif t up slightly and pull
to open. To remove the drawer, pull to the
point of resistance and lif t up and pull.

MANUAL ANTI-GLARE REARVIEW
MIRROR (if so equipped)
Use the night position1to reduce glare
from the headlights of vehicles behind you
at night.
Use the day position
2when driving in
daylight hours.

∙ Only touch the base when handlingthe bulb. Never touch the glass enve-
lope. Touching the glass could signifi-
cantly affect bulb life and/or head-
light performance.
∙ High pressure halogen gas is sealed inside the halogen bulb. The bulb may
break if the glass envelope is
scratched or the bulb is dropped.
∙ Use the same number and wattage as shown in the chart.
Fog may temporarily form inside the lens
of the exterior lights in the rain or in a car
wash. A temperature difference between
the inside and the outside of the lens
causes the fog. This is not a malfunction. If
large drops of water collect inside the lens,
it is recommended that you visit a NISSAN
dealer for this service.
Aiming the headlights
The headlights on your vehicle are properly
aimed at the assembly plant. If your vehicle
has been in a collision, the alignment of
your headlights should be checked. It is
recommended that you visit a NISSAN
dealer for this service. Vertical aim adjustment
NOTE:
Due to a maximum load condition of the
vehicle, headlight aiming adjustment
may be necessary. Please perform the
following procedure:
1. Park the vehicle directly in front of a wallor screen on a level surface, approxi-
mately 25 feet (7.6 meters) away.
∙
18 feet (2.4 meters)
∙
2Center height of headlight to ground
∙
325 feet (7.6 meters)
∙
4Horizontal reference line
2. Measure the height from the center of the headlight to the ground and mark
an 8 foot (2.4 meter) horizontal refer-
ence line on the vertical wall or screen
at this height (a piece of masking tape
works well).

H
Hazard warning flasher switch ........6-2
Headlight and turn signal switch ......2-23
Headlightcontrolswitch...........2-23
Headlights ...................8-23
Headrestraints................. .1-7
Heater Heater and air conditioner controls . .4-11
Heater operation ..............4-13
Hill start assist system ............5-29
Hood .......................3-13
Horn.......................2-25
I
Ignition switch ..................5-8
Immobilizer system .........2-19,3-2,5-9
Important vehicle information label . . . .10-11
Increasing fuel economy ...........5-21
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .................2-9,2-15
Instrument brightness control .......2-24
Instrument panel .............0-6,2-2
Instrument panel dimmer switch .....2-24
Interiorlight ...............2-33,2-35
J
Jumpstarting ..............6-10,8-13 K
Key........................ .3-2
Key fob battery replacement .....8-21,8-22
Keyless entry Without Intelligent Key system
(See remote keyless entry
system) .................3-10,3-11
Keys NISSAN Vehicle Immobilizer System
keys......................3-2
L
Label Tirewarning................10-12
Labels Air conditioner specification label . . .10-12
C.M.V.S.S. certification label .......10-11
Emission control information label . .10-11
Engine serial number ..........10-10
F.M.V.S.S. certification label ........10-11
Tire and Loading Information label . .10-11
Vehicle identification number (VIN) . .10-10
Vehicle identification number (VIN)
plate.....................10-10
Warning labels (for SRS) .........1-49
License plate Installing the license plate .......10-12
Light Airbagwarninglight........1-50, 2-14
Brakelight(Seestoplight)........8-28
Bulb check/instrument panel ......2-10
Bulb replacement .............8-28
Charge warning light ...........2-11 Headlight and turn signal switch
. . . .2-23
Headlightcontrolswitch.........2-23
Headlights .................8-23
Interiorlight .............2-33,2-35
Lightbulbs.................8-23
Lowtirepressurewarninglight.....2-12
Low windshield-washer fluid warning
light......................2-14
Passenger air bag and status light . . .1-41
Security indicator light ..........2-17
Warning/indicator lights and audible
reminders ...............2-9, 2-15
Lights ......................8-23 Maplights................. .2-34
Lock Door locks ..................3-4
Fuel-filler door lock opener lever ....3-14
Power door locks ..............3-6
Loose fuel cap warning ............2-5
Lowfuelwarninglight.............2-12
Low tire pressure warning light .......2-12
Low windshield-washer fluid warning
light........................2-14
Luggage
(See vehicle loading information) .....10-13
M
Maintenance General maintenance ...........9-2
Insidethevehicle..............9-3
Maintenanc
e precautions .........8-2
Outsidethevehicle.............9-2
Seat belt maintenance ..........1-18
Under the hood and vehicle .......9-4
11-3
