2020 MITSUBISHI OUTLANDER Motor

Dual-zone automatic climate
control air conditioner
7-8 Comfort controls
7
air conditioning switch to match your per- sonal preferences.Contact your Mitsubishi
Motors dealer or a
repair facility of your choice for assistance. Refer to “Personalizi
ng the air conditioning
switch (Changing the function setting)” on page7-11. Refer to “Personalizing the air selection(Changing the function setting)” on page7-10. When the “SYNC” indicator (A) goes off by turning the passenger’s side temperature con- trol dial (B) or pressing the SYNC switch, the driver’s side and the passenger’s side temper-ature can be controlled
independently of each
other.
N00737101306
To change the amount of air flowing from thevents, press the MODE switch. Each time the MODE switch is presse
d, the mode changes
to the next one in the following sequence: “”
 “”
 “”
 “”
 “”

“ ”. The selected mode
is shown in the dis-
play (A). Refer to “C
hanging the mode selec-
tion” on page 7-3.

To control the driver’s side and the passenger’s side temperature inde-pendently
NOTE
 When the “SYNC” indi
cator (A) appears by
pressing the SYNC switch, the passenger’sside temperature will
be controlled to the
same setting temperature
as the driver’s side.
While the “SYNC” indicator (A) is dis- played, if the driver’s side temperature con-trol dial is turned
, the passenger’s side
setting temperature wi
ll be synchronized to
the driver’s side.
Mode switch
BK0278200US.book 8 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Dual-zone automatic climate
control air conditioner
7-10 Comfort controls
7
N00712300094
You can change the following functions to match your preference.  Enable automatic air selection control: When the AUTO switch is pressed, the airselection switch will also be automatically controlled.  Disable automatic ai
r selection control:
Even when the AUTO switch is pressed,the air selection switch will not be auto- matically controlled.  Changing the settings Press the air selecti
on switch for approxi-
mately 10 seconds or longer. When the setting has changed, the system will beep and the i
ndicator light (A) will
flash.
• When the setting has changed from enabled to disabled,
the system will beep
three times and the
indicator light (A)
will flash three times. • When the setting has changed from dis-abled to enabled, the system will beep two times and the indicator light (A) will flash three times. On vehicles equipped with the Smart- phone-link Display Audio (SDA), screen operations can also be used to change the setting. Refer to th
e separate owner’s
manual for details.
N00737301500
Push the switch, and the air conditioningcompressor will turn on. The indicator light (A) will come on. Push the switch again and the air condition- ing compressor will stop and the indicatorlight goes off.
 When the engine coolan
t temperature rises to
a certain level, the air selection is automati-cally switched to the
recirculation position
and the indicator light
(A) comes on. At this
time, the system will not switch to the out- side position even if
the air selection switch
is pushed.

Personalizing the air selection (Changing the function setting) NOTE
NOTE
 The factory setting is
“Enable automatic air
selection control”.  When the defogger switch is pressed, the air selection will automatically change to theoutside air position, even if the system is set to “Disable automatic air selection control”, in order to prevent windows from foggingup.
Air conditioning switch
NOTE
 If a problem is detected in the air condition- ing compressor, the indicator light blinks. Press the air conditioni
ng switch once to turn
it off, then once more to turn it back on. Ifthe indicator li
ght does not blink, there is no
problem. If it does blink,
have it checked at
an authorized Mitsubish
i Motors dealer or a
repair facility
of your choice.
BK0278200US.book 10 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Air purifier 7-14 Comfort controls
7
3. When running the air conditioner, make sure the air intake, which is located infront of the windshield, is free of obstruc- tions such as leaves. Leaves collected in the air-intake chamber may reduce airflow and plug the water drains.
If the air conditioner seem
s less effective than
usual, the cause might
be a refrigerant leak.
Have the system inspected by your authorized Mitsubishi Motors dealer
or a repair facility
of your choice.
The air conditioner should be operated for at least five minutes each week, even in cold weather. This includes the quick defrostingmode. Operating the
air condition system
weekly maintains lubrication of the compres- sor internal parts to keep the air conditionerin the best operating condition.
N00733801190
The air conditioning syst
em is equipped with
an air filter to remove pollen and dust.
The air filter’s ability to collect pollen and dirt is reduced as it be
comes dirty, so replace
it periodically. For the maintenance interval, refer to the “WARRANTY AND MAINTE- NANCE MANUAL”.
N00733901540
Your vehicle’s radio receives both AM andFM stations.The quality of your re
ception is affected by
distance, obstacles, an
d signal interference.
This radio complies wi
th Part 15 of Federal
Communications Commission (FCC) Rules(for vehicles sold in U.S.A.). Operation is subject to the following conditions:
Air conditioning system refrig- erant and lubricant recommen- dations
CAUTION The air conditioning system in your vehicle must be charged with the refrigerant HFO-1234yf and the lubricant SUN-PAG46A.Use of any other refrigerant or lubricant will cause severe damage a
nd may require replac-
ing your vehicle’s en
tire air conditioning
system. The release of refrigerant into the atmo- sphere is not recommended.The new refrigerant HFO-1234yf in your vehicle is designed not
to harm the earth’s
ozone layer. Additionall
y, it has a signifi-
cantly reduced global
warming impact on the
environment, compared to the refrigerant HFC-134a.
During a long period of disuse Air purifier
NOTE
 Operation in certain conditions such as driv- ing on a dusty road and frequent use of the air conditioner ca
n lead to reduction of ser-
vice life of the filter. When you feel that theair flow is lower than normal or when the windshield or windows st
art to fog up easily,
replace the air filter.Contact your Mitsubishi
Motors dealer or a
repair facility of your
choice for assistance.
General information about your radio
BK0278200US.book 14 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If the vehicle breaks down 8-2 For emergencies
8
N00836301230
If your vehicle breaks down on the road, move to the shoulder and turn on the hazard warning flashers. If there is no shoulder, orthe shoulder is not safe, drive in the right lane slowly with the hazard
lights flashing, until
you come to a safe stopping place. Keep theflashers flashing. If the engine stops, there will be no power assist to the steering and brakes, making these difficult to use.  The brake booster will not work, so the brakes will not grip well. The brake pedal will be harder to press than usual.  Since there is no power steering assist, the steering wheel will be hard to turn.
Get help from your passengers, bystanders, etc. to push the vehicle
and move it to a safe
area.
N00860700104
If the operation mode
cannot be changed to
OFF, perform the following procedure. 1. Move the selector lever to the “P” (PARK) position, and then change the operation mode to OFF. 2. One of the other causes could be low bat-tery voltage. If this occurs, the keyless entry system, the F.A.S.T.-key operation and the steering wheel lock (if soequipped) will also
not operate. Contact
an authorized Mitsubishi Motors dealer.
N00836401778
If the engine cannot be started because thebattery is weak or de
ad, you can start it with
the battery from anothe
r vehicle using jumper
cables.
1. Take off any metal jewelry such as watch bands or bracelets th
at might create an
accidental electrical contact. 2. Position the vehicles close enoughtogether so that the jumper cables can reach, but be sure the vehicles aren’t touching each other. 3. Set the parking brake firmly on your vehi- cle and move the selector lever into the“P” (PARK) position.
If the vehicle breaks down If the engine stops/fails When the engine fails at the intersection
If the operation mode can- not be changed to OFF (vehicles equipped with the F.A.S.T.-key) Jump-starting the engine
WA R N I N G To reduce the risk of igniting flammable gas that may be emi
tted from the battery,
carefully read this section before jump-starting the vehicle. Do not try to start you
r vehicle by pushing
or towing. This can cause an accident resulting in serious
injury or death and
can damage the vehicle.NOTE
 Do not use jumper cables if they have dam- age or corrosion.CAUTION Check the other vehicle.
It must have a 12-
volt battery. If the other system isn’t 12-volt,both systems can be damaged.
BK0278200US.book 2 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Engine overheating 8-4 For emergencies
8
9. Start the engine in the vehicle providing the boost. Let the engine idle a few min- utes, then start the engine in the vehiclewith the discharged battery.
10. After the engine is
started, disconnect the
cables in the reverse order from the wayyou connected them.
If you drive your vehicl
e with a low battery
charge after the engine has been started byusing jumper cables, th
e engine may misfire.
This can cause the anti-lock braking system warning light to blink on
and off. This is only
due to the low battery voltage. It is not a problem with the brake system. If this hap- pens, fully charge the battery and ensure thecharging system is operating properly.
N00836501447
When the engine is overheating, the follow- ing warning display will appear on the infor- mation screen in the multi-information display. Also “ ” will blink. If these warnings are displayed: 1. Stop the vehicle in a safe place. Turn on the hazard warning flashers. 2. With the engine st
ill running, carefully
raise the engine hood to vent the enginecompartment. 3. Check that the cooling fan is running. If the fan is not turn
ing, stop the engine
immediately and cont
act an authorized
Mitsubishi Motors dealer or a repair facil- ity of your choice for assistance. 4. If you see steam or spray coming from under the hood, turn off the engine.
 When connecting the jumper cable, do not connect the positive (+) cable to the nega-tive (-) terminal. Sparks can make the bat-tery explode.
Charging the battery by using an external battery charger
WA R N I N G Always remove the
battery from your
vehicle when the battery is charged by an external battery charger. Keep sparks, cigarette
s, and flames away
from the battery because the battery could explode. Keep your work area well vented when charging or using
the battery in an
enclosed space. Remove all the caps before charging the battery.WA R N I N G
 Electrolyte (battery acid) is made of corro- sive diluted sulfuric acid. If electrolytecomes in contact with your hands, eyes,clothes, or the pain
ted surface of your
vehicle, thoroughly flush with water. If electrolyte gets in your eyes, flush themimmediately and thoroughly with water, and get prompt medical attention. Always wear protecti
ve clothing and gog-
gles when working
near the battery.
Keep the battery out of
the reach of chil-
dren.
As your vehicle has anti-lock brakes
WA R N I N G
Engine overheating
WA R N I N G To avoid personal injury, keep hands, hair, jewelry and clothes aw
ay from the cooling
fan. The cooling fan ca
n start at any time.
BK0278200US.book 4 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Jack and tools
For emergencies 8-5
8
5. If you do not see stea
m or spray coming
from under the hood, leave the engine onuntil the high coolant temperature warn- ing goes off. After the high coolant tem- perature warning has gone off, you canstart driving again. If the high coolant temperature warning stays on, turn off the engine. 6. When you do not see any more steam or spray, open the hood. Look for obviousleaks, such as a split radiator hose. Be careful as components will be hot. Any leak source must be repaired.7. If there is no obvious leak source, check the coolant level in the engine coolant reserve tank. If there is
none, or if it is too
low, slowly add coolant. 8. If the engine coolant reserve tank needs coolant, you will probably also need toadd coolant to the radiator. Do not loosen or remove the radiator cap until the engine has cooled down.
9. Start the engine, a
nd slowly add coolant,
up to the bottom of the filler neck. Use plain water if you have to (and replace itwith the right coolant as soon as possible).
10. Replace the radiator cap and tighten it
fully. Check the engine coolant tempera-ture display on the mu
lti information dis-
play. You can start driving again when the high coolant temperature warning doesnot come on.
11. Have the system inspected by your autho-
rized Mitsubishi Motors
dealer or a repair
facility of your choice.
N00836601477
The jack and tools are stowed on the rightside of the luggage compartment.
WA R N I N G Before raising the en
gine hood, check to
see if there is steam or spray coming from under the hood. Steam or spray comingfrom an overheated en
gine could seriously
scald you. Do not open the hood until there is nosteam or spray.
WA R N I N G Removing the radiat
or cap could scald
you with escaping hot water or steam.When checking the radiator level, coverthe cap with a cloth before trying to remove it. Turn it slowly counterclock- wise, without pressing down, to the firstnotch. The pressure in the system will then be let out. When the pressure is COM- PLETELY LET OUT, press down andkeep turning the cap counterclockwise until it comes off.
Jack and tools Storage 1- Tools 2- Jack (if so equipped)
BK0278200US.book 5 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Tire repair kit (if so equipped) 8-6 For emergencies
8
1. Remove the lid.
2. Retract the jack to remove it from the attaching hardware (A). 1. Retract the jack, then return it to its origi- nal position. 2. Extend the jack and firmly set it in its storage area, then attach the lid.
N00800401038
The tire repair kit can be used to temporarilyrepair a minor puncture in tread area causedby a nail, screw or simi
lar object. Therefore, a
spare tire is not provided.
Tools 1- Bar2- Wheel nut wrenchRemoving and storing the jack

(if so equipped)To r e m o v e

To s t o r e

To retractTo r e t r a c t To e x t e n d
Tire repair kit
(if so equipped)
WA R N I N G The tire repair kit may not permanently seal a punctured tire. Have the tire repaired as soon as possible. Using the tire repair kit may damage the wheel and/or the tire
inflation pressure
sensor for the tire. The vehicle must promptly be inspected and repaired by an authorized Mitsubishi
Motors dealer after
using the tire repair kit. Use only the Mitsubishi Motors genuine tire repair kit. Sealant in other repair kits may not sufficiently seal the tire puncture.
BK0278200US.book 6 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Tire repair kit (if so equipped)
For emergencies 8-7
8
N00800501042
The tire repair kit is stored beneath the floor board of the cargo area.
N00800601043
Tire repair kit storage

*1: Except for vehicles equipped with the third row seats
*2: Vehicles equipped with the third row seats
Tire repair kit which
consists of 1 to 3.
1- Tire compressor 2- Tire sealant bottle 3- Speed restriction sticker
How to use the tire repair kit

WA R N I N G Never use the tire repair kit under in any of the situations listed below. The tire can-not be repaired by the tire repair kit. If any of these situations occurs, please con- tact an authorized
Mitsubishi Motors
dealer.• More than one tire is punctured.• The puncture hole has a length or widthof 1/7 inch (4 mm) or greater.• The tire is punctured in the side wall (A),not in the tread (B).• The vehicle has been driven with the tirealmost completely flat.• The tire has completely slipped over thewheel rim and come off the wheel.• The wheel is damaged.• A bump, cut or crack is on the tire.• The tire sealant’s expiration date haspassed. (The expiration date is shown on the bottle label (C).)• The ambient temperature is below -40 °F(-40 °C) or above 140 °F (60 °C).
WA R N I N G The tire sealant can
cause health damage
if swallowed. If you
accidentally swallow
it, drink as much water as possible and immediately seek medical attention. If the tire sealant gets in your eyes or on your skin, rinse it away with lots of water. If you still sense an abnormality, seekmedical attention. Consult a doctor immediately if any aller- gic reactions occur. Do not allow children to touch the tire sealant.CAUTION If the vehicle body is contaminated by the tire sealant, wipe the tire sealant off immedi- ately with a wet cloth.
BK0278200US.book 7 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
