2020 MITSUBISHI OUTLANDER engine

8
For emergenciesIf the vehicle breaks down ...............................................................8-2 If the operation mode ca
nnot be changed to OFF
(vehicles equipped with the F.A.S.T.-key) ...................................8-2Jump-starting the engine ..................................................................8-2 Engine overheating ..........................................................................8-4 Jack and tools ...................................................................................8-5Tire repair kit (if so equipped) ..........................................................8-6 How to change a tire ...................................................................... 8-11 Towing ...........................................................................................8-18Operation under adverse driving conditions
...........
.........
.........
.....8-19
Fuel Pump Shut-off System ...........................................................8-20
BK0278200US.book 1 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If the vehicle breaks down 8-2 For emergencies
8
N00836301230
If your vehicle breaks down on the road, move to the shoulder and turn on the hazard warning flashers. If there is no shoulder, orthe shoulder is not safe, drive in the right lane slowly with the hazard
lights flashing, until
you come to a safe stopping place. Keep theflashers flashing. If the engine stops, there will be no power assist to the steering and brakes, making these difficult to use.  The brake booster will not work, so the brakes will not grip well. The brake pedal will be harder to press than usual.  Since there is no power steering assist, the steering wheel will be hard to turn.
Get help from your passengers, bystanders, etc. to push the vehicle
and move it to a safe
area.
N00860700104
If the operation mode
cannot be changed to
OFF, perform the following procedure. 1. Move the selector lever to the “P” (PARK) position, and then change the operation mode to OFF. 2. One of the other causes could be low bat-tery voltage. If this occurs, the keyless entry system, the F.A.S.T.-key operation and the steering wheel lock (if soequipped) will also
not operate. Contact
an authorized Mitsubishi Motors dealer.
N00836401778
If the engine cannot be started because thebattery is weak or de
ad, you can start it with
the battery from anothe
r vehicle using jumper
cables.
1. Take off any metal jewelry such as watch bands or bracelets th
at might create an
accidental electrical contact. 2. Position the vehicles close enoughtogether so that the jumper cables can reach, but be sure the vehicles aren’t touching each other. 3. Set the parking brake firmly on your vehi- cle and move the selector lever into the“P” (PARK) position.
If the vehicle breaks down If the engine stops/fails When the engine fails at the intersection
If the operation mode can- not be changed to OFF (vehicles equipped with the F.A.S.T.-key) Jump-starting the engine
WA R N I N G To reduce the risk of igniting flammable gas that may be emi
tted from the battery,
carefully read this section before jump-starting the vehicle. Do not try to start you
r vehicle by pushing
or towing. This can cause an accident resulting in serious
injury or death and
can damage the vehicle.NOTE
 Do not use jumper cables if they have dam- age or corrosion.CAUTION Check the other vehicle.
It must have a 12-
volt battery. If the other system isn’t 12-volt,both systems can be damaged.
BK0278200US.book 2 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Jump-starting the engine For emergencies 8-3
8
4. Set the parking brake firmly on the other vehicle. Put the automatic transaxle in “P”(PARK) or the manual transaxle in “N” (Neutral). 5. Turn the ignition switch (the engineswitch) on each vehicle to the “LOCK” or “OFF” position. 6. Make sure your batt
ery electrolyte is at
the proper level. (Refer to “Battery” onpage 9-14.) 7. Connect one end of one jumper cable to the positive (+) terminal of the dis-charged battery (A),
and then connect the
other end to the positive (+) terminal of the booster battery (B).
2.4 liter models 3.0 liter models
8. Connect one end of the other jumper cable
to the negative (-) terminal of the booster battery (B), a
nd then connect the
other end to the designated ground location of the vehicl
e with the discharged
battery (A) at the point farthest from thebattery.
NOTE
 Turn off all lights, heat
er, and other electrical
loads. This will avoid sparks and help saveboth batteries.WA R N I N G If the electrolyte flui
d is not visible, or
looks frozen, DO NOT ATTEMPT JUMP STARTING!!The battery might split open or explode if the temperature is below the freezing point or if it is not filled to the properlevel.
WA R N I N G Make sure that the jumper cables and your clothing are clear of the cooling fans and drive belts. Entanglement with the fans or belts can ca
use serious personal
injury.
NOTE
 Open the terminal co
ver before connecting
the jumper cable to the positive terminal ofthe battery.(Refer to “Battery” on page 9-14.)  Use the proper cables suitable for the battery size. Otherwise heat damage
to the cables could
result.WA R N I N G Be sure to follow the proper order when connecting the batteries, of: 
 Make sure that the connection is made to the correct designated location (as shown in the illustration) properly. If the connection is directly made to the negative(-) terminal of the battery, the flammable gases from inside the battery might catch fire and explode, caus
ing personal injury.
BK0278200US.book 3 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Engine overheating 8-4 For emergencies
8
9. Start the engine in the vehicle providing the boost. Let the engine idle a few min- utes, then start the engine in the vehiclewith the discharged battery.
10. After the engine is
started, disconnect the
cables in the reverse order from the wayyou connected them.
If you drive your vehicl
e with a low battery
charge after the engine has been started byusing jumper cables, th
e engine may misfire.
This can cause the anti-lock braking system warning light to blink on
and off. This is only
due to the low battery voltage. It is not a problem with the brake system. If this hap- pens, fully charge the battery and ensure thecharging system is operating properly.
N00836501447
When the engine is overheating, the follow- ing warning display will appear on the infor- mation screen in the multi-information display. Also “ ” will blink. If these warnings are displayed: 1. Stop the vehicle in a safe place. Turn on the hazard warning flashers. 2. With the engine st
ill running, carefully
raise the engine hood to vent the enginecompartment. 3. Check that the cooling fan is running. If the fan is not turn
ing, stop the engine
immediately and cont
act an authorized
Mitsubishi Motors dealer or a repair facil- ity of your choice for assistance. 4. If you see steam or spray coming from under the hood, turn off the engine.
 When connecting the jumper cable, do not connect the positive (+) cable to the nega-tive (-) terminal. Sparks can make the bat-tery explode.
Charging the battery by using an external battery charger
WA R N I N G Always remove the
battery from your
vehicle when the battery is charged by an external battery charger. Keep sparks, cigarette
s, and flames away
from the battery because the battery could explode. Keep your work area well vented when charging or using
the battery in an
enclosed space. Remove all the caps before charging the battery.WA R N I N G
 Electrolyte (battery acid) is made of corro- sive diluted sulfuric acid. If electrolytecomes in contact with your hands, eyes,clothes, or the pain
ted surface of your
vehicle, thoroughly flush with water. If electrolyte gets in your eyes, flush themimmediately and thoroughly with water, and get prompt medical attention. Always wear protecti
ve clothing and gog-
gles when working
near the battery.
Keep the battery out of
the reach of chil-
dren.
As your vehicle has anti-lock brakes
WA R N I N G
Engine overheating
WA R N I N G To avoid personal injury, keep hands, hair, jewelry and clothes aw
ay from the cooling
fan. The cooling fan ca
n start at any time.
BK0278200US.book 4 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Jack and tools
For emergencies 8-5
8
5. If you do not see stea
m or spray coming
from under the hood, leave the engine onuntil the high coolant temperature warn- ing goes off. After the high coolant tem- perature warning has gone off, you canstart driving again. If the high coolant temperature warning stays on, turn off the engine. 6. When you do not see any more steam or spray, open the hood. Look for obviousleaks, such as a split radiator hose. Be careful as components will be hot. Any leak source must be repaired.7. If there is no obvious leak source, check the coolant level in the engine coolant reserve tank. If there is
none, or if it is too
low, slowly add coolant. 8. If the engine coolant reserve tank needs coolant, you will probably also need toadd coolant to the radiator. Do not loosen or remove the radiator cap until the engine has cooled down.
9. Start the engine, a
nd slowly add coolant,
up to the bottom of the filler neck. Use plain water if you have to (and replace itwith the right coolant as soon as possible).
10. Replace the radiator cap and tighten it
fully. Check the engine coolant tempera-ture display on the mu
lti information dis-
play. You can start driving again when the high coolant temperature warning doesnot come on.
11. Have the system inspected by your autho-
rized Mitsubishi Motors
dealer or a repair
facility of your choice.
N00836601477
The jack and tools are stowed on the rightside of the luggage compartment.
WA R N I N G Before raising the en
gine hood, check to
see if there is steam or spray coming from under the hood. Steam or spray comingfrom an overheated en
gine could seriously
scald you. Do not open the hood until there is nosteam or spray.
WA R N I N G Removing the radiat
or cap could scald
you with escaping hot water or steam.When checking the radiator level, coverthe cap with a cloth before trying to remove it. Turn it slowly counterclock- wise, without pressing down, to the firstnotch. The pressure in the system will then be let out. When the pressure is COM- PLETELY LET OUT, press down andkeep turning the cap counterclockwise until it comes off.
Jack and tools Storage 1- Tools 2- Jack (if so equipped)
BK0278200US.book 5 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Tire repair kit (if so equipped) 8-8 For emergencies
8
1. Park the vehicle on a safe, flat and level place. 2. Set the parking brake firmly.3. Move the selector
lever to the “P”
(PARK) position, and stop the engine. 4. Turn on the hazard warning lights and setup a warning sign, such as a warning tri- angle or flashing signal lamp, at an ade- quate distance from the vehicle, and haveall your passengers leave the vehicle. 5. Take out the tire repair kit. Make sure that the compressor switch isOFF.
6. Shake the tire sealant bottle well. 7. Take the valve cap (D) off the tire valve (E).
8. Unwind the bottle hose (F) from around the sealant bottle. 9. Pull out the compressor’s hose (G) from the bottom of the compressor and securely attach it to the valve (H) of the bottle byturning it clockwise until tight.
 Immediately wash clothes contaminated with tire sealant. The tire sealant may not beremoved from the clothes.NOTE
 Do not pull out an object, such as a nail or screw, that penetrat
es the punctured tire.
 Move the vehicle so th
at the tire valve is
positioned away from the point where thetire touches the ground. If the valve is near the point where the tire touches the ground, the sealant may not enter the tire easily.  Check the tire sealant’
s expiration date regu-
larly, and be sure to
purchase a new one from
an authorized Mitsubishi Motors dealer before the expiration date.CAUTION
NOTE
 In cold conditions (w
hen the ambient tem-
perature is 32 °F {0 °C} or lower), thicken- ing of the tire sealant can make the tiresealant hard to squeeze out of the bottle. Warm the bottle betw
een your hands inside
the vehicle.
BK0278200US.book 8 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

How to change a tire
For emergencies 8-11
8
17. After driving for 10 minutes or 3 miles (5
km), park the vehicl
e in a safe place.
Remove the air compressor from the stowed position. Check the tire pressureusing the air pressure gauge on the com- pressor. If the tire pressure has not dropped, the emergency repair procedureis complete. Proceed to step 19. If the tire pressure is insufficient, inflate the tire to the specified pressure again anddrive the vehicle carefully without exceeding a speed of 50 mph (80 km/h). Before driving, make sure that the com-pressor is stowed.
18. After driving for 10 minutes or 3 miles (5
km) again, check the tire pressure usingthe air pressure gauge on the compressor. If the tire pressure has not dropped, the emergency repair procedure is complete.Before driving, make sure that the com- pressor is stowed. You must still not exceed a speed of 50 mph (80 km/h).Observe local speed limits.
19. Immediately drive with great care to an
authorized Mitsubishi
Motors dealer and
have the tire repa
ir/replacement per-
formed.
N00836901829
Before changing a tire,
first stop your vehicle
in a safe, flat location. 1. Park the vehicle on level and stable ground. 2. Set the parking brake firmly. 3. Move the selector lever to the “P”(PARK) position and turn the ignition switch (the engine switch) to the “LOCK” or “OFF” position.4. Turn on the hazard warning flashers and set up a warning sign, such as a warning triangle or flashing signal lamp, at an ade-quate distance from the vehicle, and have all your passengers
leave the vehicle.
CAUTIONIf you sense any abnormality while driving, stop the vehicle and c
ontact an authorized
Mitsubishi Motors dealer. Otherwise the tirepressure may drop before the emergency repair procedure is completed, rendering the vehicle unsafe to drive.CAUTION If the tire pressure is lower than the mini- mum permitted pressure (18 psi {130 kPa}), the tire cannot successf
ully be repaired with
the tire sealant. Do not drive the vehicle anyfurther. Contact an authorized Mitsubishi Motors dealer.
NOTE
 If the tire pressure has dropped below the specified level when you check it at the end of the repair procedure, do not drive the vehicle any further.
Contact an authorized
Mitsubishi Moto
rs dealer.
 In cold conditions (when the ambient tem- perature is 32 °F {0 °C} or lower), the time and driving distance required until comple- tion of the repair can
become longer than in
warmer conditions, and the tire pressure may drop below the specified level even after you have inflated the tire the second time andsubsequently driven the vehicle. If this hap- pens, inflate the tire to the specified pressure once more, drive for approximately 10 min-utes or 3 miles (5 km), then check the tire pressure again. If the tire pressure has again dropped below the specified level, stop driv-ing the vehicle and contact an authorized Mitsubishi Moto
rs dealer.
NOTE
Please give the empt
y sealant bottle to an
authorized Mitsubishi Motors dealer or dis-pose of the sealant bot
tle according to regu-
lations for the disposal
of chemical waste.
 To purchase a new tire
sealant bottle, contact
an authorized Mitsubishi Motors dealer.
How to change a tire
BK0278200US.book 11 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

How to change a tire
For emergencies 8-15
8
5. Remove the wheel nuts with the wheel nut wrench, then take the wheel off.
6. Clean out any mud, etc. on the hub sur- face (F), hub bolts (G)
or in the installa-
tion holes (H) in the wheel, and then mount the spare tire.
7. Turn the wheel nut clockwise by hand to initially tighten them. Temporarily tighten the wheel nuts byhand until the flange parts of the wheel nuts make light contact with the wheel and the wheel
is not loose.
WA R N I N GStop jacking up the ve
hicle as soon as the
tire is raised off the ground. It is danger-ous to raise the ve
hicle any higher.
Do not get under your vehicle while using the jack. Do not bump the raised
vehicle or leave it
sitting on the jack for a long time. Bothare very dangerous. Do not use a jack except the one that came with your vehicle. The jack should not be used for any pur- pose other than to change a tire. No one should be
in your vehicle when
using the jack. Do not start or run
the engine while your
vehicle is on the jack. Do not turn the raised wheel. The tires that are still on the ground could turn and make your vehicle fall off the jack.CAUTION Handle the wheel carefully when changing the tire, to avoid scratching the wheel sur-face.
WA R N I N G Mount the wheel with the valve stem (I) facing outward. If you cannot see the valve stem (I), you
have installed the
wheel backwards. Operating the vehicle with the spare wheel installed backwards can cause vehicledamage and result
in an ac
cident.
BK0278200US.book 15 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
