2020 LEXUS NX300h display

4478-2. Customization
LEXUS NX300h Owners Manual_USA_M78530_en
8
Vehicle specifications
■Moon roof*1 (  P.150)
*1: If equipped
*2: This function cannot be cust omized unless power window op erations, using the wireless
remote control or mechanical key, is enabled.
■Turn signal lever ( P.182)
■PKSA (Parking Support Alert)* ( P.246)
*:If equipped
■Intuitive parking assist* ( P.247)
*:If equipped
FunctionDefault settingCustomized set-
ting
Mechanical key linked opera-
tion
*2OffOn——O—
Wireless remote control
linked open or Tilt up opera-
tions
*2OffOn——O—
FunctionDefault settingCustomized set-ting
The number of times the turn
signal lights flash automati-
cally when the turn signal
lever is moved to the first
position during a lane change
3
4
——O—
5
6
7
Off
FunctionDefault settingCustomized set-ting
Buzzer volume21—OO—3
FunctionDefault settingCustomized set-ting
Display setting (When intui-
tive parking assist is operat-
ing)
OnOff—OO—
ABCD
ABCD
ABCD
ABCD

4508-2. Customization
LEXUS NX300h Owners Manual_USA_M78530_en
*:If equipped
■Power back door*1 ( P.114)
*1: If equipped
*2: Configured by operating the sw itch of the lower back door. (P.125)
*3: While carrying the electronic key on your person, press the back door opener switch.
*4: When the towing hitch is installed, the kick sensor does not work
■Vehicle customization
●When the speed linked door locking function and shift po sition linked door locking func-
tion are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will be locked.
Excess speed notification
methodDisplay only
No notification
—OO—Display and
buzzer
Others notification methodDisplay only
No notification
—OO—Display and buzzer
Excess speed notification
level1 mph (2 km/h)3 mph (5 km/h)—OO—5 mph (10 km/h)
FunctionDefault settingCustomized set- ting
Back door automatic open
and stop position5
Stop at the
desired position
(height)
*2O——O
1 to 5
Back door opener switch
operationsWhen the back
door is locked
*3When the back
door is unlocked——O—
Power back door operationsOnOff—O——
Operation buzzer volume31—O——2
Kick Sensor*1, 4OnOff—O——
FunctionDefault settingCustomized set- tingABCD
ABCD

4518-2. Customization
LEXUS NX300h Owners Manual_USA_M78530_en
8
Vehicle specifications
• If the vehicle is started with all the doors locked, the speed linked door locking function
would not operate.
• If the vehicle is started with any door unlock ed, the speed linked door locking function will
operate.
●When the smart access system with push-button start is off, smart door unlocking cannot
be customized.
●When the doors remain closed after unlock ing the doors and the automatic door lock
function is activat ed, the signals will be generated in accordance with the Operation sig-
nal (buzzer) and the Operation sign al (emergency flashers) settings.
■In the following situations, customize mode in which the settings can be changed
through the multi-information display will automatically be turned off.
●A warning message appears after the cu stomize mode screen is displayed.
●The power switch is turned off.
●The vehicle begins to move while the customize mode screen is displayed.

LEXUS NX300h Owners Manual_USA_M78530_en
467What to do if... (Troubleshooting)
Is the power switch in ON mode?
If you cannot release the shift lever
by depressing the brake pedal with
the power switch in ON mode
( P.180)
 It is locked automatically to prevent
theft of the vehicle. ( P.175)
 Is the window lock switch pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the window lock switch
is pressed. ( P.149)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or ON mode (the
hybrid system is not operating) for a
period of time. ( P.176)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing the seat belts? (
P.391)
 The parking brake indicator is on
Is the parking brake released?
( P.183)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.386, 396)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm
sounds. ( P.77)
To stop the alarm, turn the power
switch to ON mode or start the hybrid
system.
 Is the message displayed on the
multi-information display?
Check the message on the multi-
information display. ( P.396)
 When a warning light turns on or a
warning message is displayed, refer
to P.386, 396.
The shift lever cannot be shifted
from P even if you depress the
brake pedal
The steering wheel cannot be
turned after the hybrid system is
stopped
The windows do not open or
close by operating the power
window switches
The power switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

472Alphabetical Index
LEXUS NX300h Owners Manual_USA_M78530_en
Display BSM (Blind Spot Monitor) ..................... 261
Drive information .......................................... 90
Dynamic radar cruise control with full-speed range .............................................. 236
Energy monitor.............................................. 99
Head-up display ........................................... 94
Intuitive parking assist.............................. 247
LDA (Lane Departure Alert with steering control) ........................................................ 226
LTA (Lane Tracing Assist)...................... 217
Multi-information display .......................... 89
Warning messages ..................................396
Do-it-yourself maintenance .................... 342
Door lock Back door......................................................... 115
Side doors ........................................................ 110
Smart access system with push-button start .................................................................. 126
Wireless remote control..........................107
Doors Automatic door lock ing and unlocking
system ............................................................. 113
Back door..........................................................114
Door glasses ................................................. 148
Door lock.......................................................... 110
Outside rear view mirrors ......................146
Rear door child-protectors ..................... 113
Side doors ........................................................ 110
Drive information ........................................... 90
Drive-start control .............................. 157, 179
Driver’s seat belt remi nder light ..............391
Driver’s seat position memory ................ 138 Driving
Break-in tips ...................................................157
Correct posture............................................. 25
Driving mode select switch ..................269
Hybrid vehicle driving tips .................... 275
Procedures .................................................... 156
Winter drive tips ......................................... 277
Driving position memory........................... 138 Memory recall function............................ 139
Dynamic radar cruise control with full- speed rangeFunction ..........................................................236
E
E-Four .............................................................. 270
ECB (Electronically Controlled Brake Sys-
tem) ................................................................ 270
Eco mode........................................................ 269
EDR (Event data recorder) ........................... 8
Electric motor Location ............................................................. 67
Specification ................................................. 423
Electric Power Steering (EPS) Function .......................................................... 270
Warning light .............................................. 388
Electronic key Battery-saving function............................. 127
If the electronic key does not operate properly ........................................................ 410
Replacing the battery .............................. 368
Electronically Controlled Brake System (ECB) ............................................................ 270

LEXUS NX300h Owners Manual_USA_M78530_en
Alphabetical Index473
Emergency flashers .................................... 378
Emergency, in case ofIf a warning buzzer sounds ..................386
If a warning light turns on ......................386
If a warning message is displayed.....396
If the 12-volt battery is discharged ...... 412
If the electronic key does not operate properly........................................................ 410
If the fuel filler door cannot be opened .........................................................................409
If the hybrid system will not start ........ 407
If the vehicle is trapped in rising water ......................................................................... 379
If you have a flat tire ................................. 400
If you lose your keys.................................409
If you think something is wrong .........384
If your vehicle becomes stuck...............419
If your vehicle has to be stopped in an
emergency ................................................ 378
If your vehicle needs to be towed ...... 381
If your vehicle overheats ..........................416
Energy monitor ............................................... 99
Engine Accessory mode ......................................... 176
Compartment ............................................. 346
Engine switch................................................. 174
Hood................................................................ 344
How to start the hybrid system ............ 174
Identification number ............................... 423
If your vehicle has to be stopped in an
emergency ................................................ 378
Ignition switch (power switch) .............. 174
Overheating...................................................416
Power switch ................................................. 174 Engine compartment cover .................... 347
Engine coolant
Capacity .........................................................425
Checking .......................................................349
Preparing and checking before winter.......................................................................... 277
Warning light ...............................................387
Engine coolant temperature gauge ....... 84
Engine oil Capacity ......................................................... 424
Checking ....................................................... 347
Warning light ...............................................387
Engine switch .................................................. 174
EPS (Electronic Power Steering) Function .......................................................... 270
Warning light .............................................. 388
EV drive mode................................................ 177
EV indicator ...................................................... 68
Event data recorder (E DR) ........................... 8
F
Flat tire .............................................................400
Tire pressure warning system .............357
Floor mats .......................................................... 24
Fluid Brake ................................................................ 427
Transmission................................................. 426
Washer ............................................................ 351
Fog lights Replacing light bulbs ................................ 374
Switch................................................................ 195
Front passenger occupant classification system ................................................................ 41

474Alphabetical Index
LEXUS NX300h Owners Manual_USA_M78530_en
Front passenger’s seat belt reminder light
............................................................................391
Front seat heaters........................................ 297
Front seats ........................................................132 Adjustment...................................................... 132
Cleaning......................................................... 333
Correct driving posture ............................ 25
Driving position memory........................ 138
Head restraints ...............................................141
Power easy access system .................... 138
Seat heaters .................................................. 297
Seat position memory .............................. 138
Front side marker lights Light switch .................................................... 189
Replacing light bulbs................................ 375
Wattage.......................................................... 429
Front turn signal lights Replacing light bulbs.................... 374, 375
Turn signal lever ...........................................182
Wattage.......................................................... 429
Fuel Capacity ......................................................... 423
Fuel gauge ....................................................... 84
Gas station information..........................484
Information ....................................................430
Refueling ........................................................ 202
Type.................................................................. 423
Warning light .................................................391
Fuel filler door ............................................... 202 Refueling ........................................................ 202
When the fuel filler door cannot be opened ........................................................409
Fuses ................................................................. 370G
Garage door opener ................................. 320
Gas station information ............................ 484
Gauges ............................................................... 84
Glove box ....................................................... 304
Glove box light ............................................. 304
Grocery bag hooks .................................... 307
H
Head restraints ................................................ 141
Head-up display.............................................. 94
Headlights ....................................................... 189 Automatic headlight leveling ................ 190
Automatic High Beam ..............................192
Light switch .................................................... 189
Replacing light bulbs ................................ 374
Heated steering wheel .............................. 297
Heaters Automatic air conditioning system .. 289
Heated steering wheel ............................ 297
Outside rear view mirrors.................... 290
Seat heaters .................................................. 297
High mounted stoplight Replacing light bulb .................................. 374
Hill-start assist control ............................... 270
Hood ................................................................. 344 Open................................................................ 344
Hooks Cargo hooks............................................... 306
Retaining hooks (floor mat) ..................... 24
Horn ....................................................................144

476Alphabetical Index
LEXUS NX300h Owners Manual_USA_M78530_en
L
Lane Departure Alert wi th steering control
(LDA) ............................................................ 226
Lane Tracing Assist (LTA) ......................... 217
Language (multi-information display) 444
LATCH anchors ............................................. 55
LDA (Lane Departure Alert with steering control) ......................................................... 226
Lever Auxiliary catch lever ................................. 344
Hood lock release lever......................... 344
Shift lever.......................................................... 179
Turn signal lever ...........................................182
Wiper lever.................................................... 195
Lexus Enform Remote.................................. 65
Lexus Enform Safety Connect.................. 60
Lexus Enform Service Connect ............... 66
Lexus Safety System+ 2.0 Automatic High Beam .............................. 192
Dynamic radar cruise control with full-speed range .............................................. 236
LDA (Lane Departure Alert with steering control) ........................................................ 226
LTA (Lane Tracing Assist)...................... 217
PCS (Pre-Collision System)..................210
RSA (Road Sign Assist) ......................... 234
License plate lights Light switch .................................................... 189
Replacing light bulbs................................ 374
Light Automatic High Beam system.............. 192
Cornering lights ............................................ 191
Fog light switch ............................................ 195
Headlight switch ......................................... 189 Illuminated entry system ........................ 300
Interior light list ........................................... 300
Interior lights .................................................. 301
Luggage compartment light ................... 116
Personal lights .............................................. 301
Replacing light bulbs ................................ 374
Turn signal lever .......................................... 182
Vanity lights ................................................... 310
Wattage .......................................................... 429
Welcome light illumination control ....... 111
Light bulbs Replacing ........................................... 374, 375
Wattage .......................................................... 429
LTA (Lane Tracing Assist) ......................... 217
Luggage cover .............................................308
M
Maintenance Do-it-yourself maintenance ................. 342
General maintenance ............................. 337
Maintenance data ...................................... 422
Maintenance requirements .................. 337
Malfunction indicator la mp ..................... 387
Meter Head-up display............................................ 94
Indicators.......................................................... 80
Instrument panel light control................ 88
Meters.................................................................84
Multi-information display ..........................89
Warning lights ............................................ 386
Warning messages.................................. 396
Micro dust and pollen filter ..................... 294
