LEXUS NX300 Owners Manual_USA_M78389_en
TABLE OF CONTENTS
For your information ......................................
6
Reading this manual .................................... 10
How to search ................................................. 11
Pictorial index ................................................. 12
1-1. For safe use Before driving .................................... 24
For safe driving.................................. 25
Seat belts ............................................. 26
SRS airbags ........................................ 32
Front passenger occupant classifi- cation system ................................... 41
Exhaust gas precautions .............. 46
1-2. Child safety Riding with children........................ 48
Child restraint systems ................. 48
1-3. Lexus Enform Lexus Enform Safety Connect .... 61
Lexus Enform Remote .................. 66
Lexus Enform Service Connect 67
1-4. Theft deterrent system Engine immobilizer system ......... 68
Alarm.................................................... 70
2-1. Instrument cluster Warning lights and indicators ..... 74
Gauges and meters ....................... 79
Multi-information display............. 82
Head-up display .............................. 88
Fuel consumption information .... 923-1. Key information
Keys ....................................................... 96
3-2. Opening, closing and locking the doors
Side doors ........................................ 100
Back door......................................... 104
Smart access system with push-but- ton start ............................................ 116
3-3. Adjusting the seats Front seats......................................... 122
Rear seats.......................................... 123
Driving position memory ........... 128
Head restraints ................................ 131
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................... 133
Inside rear view mirror ................ 134
Outside rear view mirrors......... 136
3-5. Opening, closing the windows and moon roof
Power windows ............................. 138
Moon roof ........................................ 140
1For safety and security
2Vehicle status information and
indicators
3Before driving

12Pictorial index
Pictorial index
■Exterior
The shape of the headlights may differ depending on the grade, etc.
Side doors..................................................................................................................P.1 00
Locking/unlocking ............................................................................................................ P. 100
Opening/closing the side windows ........................................................................... P.138
Locking/unlocking by using th e mechanical key ................................................ P.397
Warning messages ..........................................................................................................P.384
Back door ..................................................................................................................P.10 4
Opening from inside the cabin
*................................................................................... P.107
Opening from outside ........................................................................................... P.105, 107
Warning messages ..........................................................................................................P.384
Outside rear view mirrors.................................................................................... P.136
Adjusting the mirror angle ............................................................................................. P.136
Folding the mirrors ............................................................................................................ .P.137
Driving position memory
*.............................................................................................. P.128
Defogging the mirrors ....................................................................................................P.280
A
B
C

18Pictorial index
LEXUS NX300 Owners Manual_USA_M78389_en
Power window switches ........................................................................................P.138
Window lock switch ............................................................................................... P.139
Outside rear view mirror switches .................................................................... P.136
Door lock switch......................................................................................................P.102
Driving position memory switches
*...................................................................P.128
HUD (Head-up display) switches
*...................................................................... P.88
ASC (Active Sound Control) dial
*..................................................................... P.177
*:If equipped
Audio remote control switches
*1
A
B
C
D
E
F
G
A

22Pictorial index
LEXUS NX300 Owners Manual_USA_M78389_en
■Ceiling
Inside rear view mirror .......................................................................................... P.134
Sun visors ..................................................................................................................P.2 99
Vanity mirrors .........................................................................................................P.299
Interior light
*2........................................................................................................ P.290
Personal lights........................................................................................................ P.290
Moon roof switches
*1.............................................................................................P.140
“SOS” button
*1............................................................................................................ P.61
Garage door opener switches
*1....................................................................... P.309
*1: If equipped
*2: The illustration shows the front, but they are also equipped in the rear.
A
B
C
D
E
F
G

251-1. For safe use
LEXUS NX300 Owners Manual_USA_M78389_en
1
For safety and security
Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (P.122)
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. ( P.122, 133)
Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
( P.131)
Wear the seat belt correctly.
( P.27) Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (
P.27)
Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. ( P.48)
Make sure that you can see the rear of
the vehicle clearly, by adjusting the
inside and outside rear view mirrors
properly. ( P.134, 136)
For safe driving
For safe driving, adjust the seat and
mirror to an appropriate position
before driving.
Correct driving posture
WARNING
Observe the following precautions.
Failure to do so may result in death or
serious injury.
A
B
C
D
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver to lose
control of the vehicle.
●Do not place a cushion between the
driver or passenger and the seatback.
A cushion may prevent correct pos-
ture from being achieved, and reduce
the effectiveness of the seat belt and
head restraint.
●Do not place anything under the front
seats.
Objects placed under the front seats
may become jammed in the seat
tracks and stop the seat from locking in
place. This may lead to an accident
and the adjustment mechanism may
also be damaged.
●Always observe the legal speed limit
when driving on public roads.
●When driving over long distances, take
regular breaks before you start to feel
tired. Also, if you feel tired or sleepy
while driving, do not force yourself to
continue driving and take a break
immediately.
Correct use of the seat belts
Adjusting the mirrors

772-1. Instrument cluster
LEXUS NX300 Owners Manual_USA_M78389_en
2
Vehicle status information and indicators*1: These lights turn on when the engine
switch is turned to the IGNITION ON
mode to indicate that a system check is
being performed. They will turn off after
the engine is started, or after a few sec-
onds. There may be a malfunction in a
system if the lights do not turn on, or
turn off. Have the vehicle inspected by
your Lexus dealer.
*2: This light illuminates on the multi-infor-mation display.
*3: The light flashes to indicate that the sys-tem is operating.
*4: The light comes on when the system is turned off.
*5: When the outside temperature is approximately 37°F (3°C) or lower, the
indicator will flash for approximately 10
seconds, then stay on.
*6: In order to confirm operation, the BSM outside rear view mirror indicators illu-
minate in the following situations:
When the engine switch is turned to
IGNITION ON mode while the BSM
main switch is set to ON.
When the BSM main switch is set to
ON while the engine switch is in IGNI-
TION ON mode.
If the system is func tioning correctly, the
BSM outside rear view mirror indica-
tors will turn off after a few seconds.
(White)
LTA indicator*2 (if equipped)
(  P.211)
LDA indicator
*2 (if equipped)
(  P.220)
(Green)
LTA indicator*2 (if equipped)
(  P.211)
LDA indicator
*2 (if equipped)
(  P.220)
(Orange)
LTA indicator*2, 3 (if equipped)
(  P.211)
LDA indicator
*2, 3 (if
equipped) ( P.220)
Intuitive parking assist indica-
tor (if equipped) ( P.236)
PKSB OFF indicator
*1, 4 (if
equipped) ( P.242)
Slip indicator light
*1, 3
(  P.261)
VSC off indicator
*1, 4 (  P.261)
PCS warning light
*1, 4
(  P.201)
(AWD mod-
els only)
All-wheel drive lock indicator*1
(  P.264)
(U.S.A.)
Parking brake indicator
( P.172)
(Canada)
Parking brake indicator
( P.172)
Brake hold standby indicator
*1
(  P.175)
Brake hold operated indica-
tor
*1 (  P.175)
Low outside temperature indi-
cator
*2, 5 (  P.79)
BSM outside rear view mirror
indicators
*6, 7 (if equipped)
(  P.250)
Security indicator
*8 (  P.68,
70)
(U.S.A.)
“AIR BAG ON/OFF” indi-
cator
*8 (  P.41)
(Canada)
“AIR BAG ON/OFF” indi-
cator
*8 ( P.41)

782-1. Instrument cluster
LEXUS NX300 Owners Manual_USA_M78389_en
If the BSM outside rear view mirror indi-
cators do not illuminate or do not turn
off, there may be a malfunction in the
system.
If this occurs, have
the vehicle inspected
by your Lexus dealer.
*7: This light illuminates on the outside rear view mirrors.
*8: This light illuminates on the center panel.
■Eco Driving Indicator
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), the Eco Driving Indicator Light
will turn on. When the acceleration
exceeds the Zone of Eco driving, or
when the vehicle is stopped, the light
turns off.
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with
current Eco driving ratio based on
acceleration.
Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of
Eco driving, the right side of the Eco
Driving Indicator Zone Display will illu- minate.
When this happens, the Eco Driving
Indicator Light will turn off.
Zone of Eco driving
Eco Driving Indicator will not operate
under the following conditions:
●The shift lever is in an y position other than
D.
●A paddle shift swit ch is operated.
●Neither Normal mode nor Eco mode is
selected. (P.258)
●The vehicle speed is approximately 80
mph (130 km/h) or higher.
Settings of the display and non-display of
the Eco Driving Indicator Light can be
changed. ( P.87)
A
B
C
D

95
LEXUS NX300 Owners Manual_USA_M78389_en
3
3
Before driving
Before driving
3-1. Key information
Keys ................................................... 96
3-2. Opening, closing and locking the doors
Side doors ..................................... 100
Back door ...................................... 104
Smart access system with push- button start .................................. 116
3-3. Adjusting the seats Front seats ..................................... 122
Rear seats ...................................... 123
Driving position memory ........ 128
Head restraints............................. 131
3-4. Adjusting the steering wheel and mirrors
Steering wheel............................. 133
Inside rear view mirror............. 134
Outside rear view mirrors ...... 136
3-5. Opening, closing the windows and moon roof
Power windows........................... 138
Moon roof ..................................... 140
