Page 69 of 114
69
LC500_LC500h_QG_OM11556U_(U)
Search by category ( )
5Select “Category”.
6Select the desired search point.
Select to set the search point from near
the current position
Select to search for POIs along the set
route
Select to set the search point from near
a city center
Select to set the search point from near
a destination
When more than 1 destination has
been set, a list will be displayed on the
screen.
Select the item to be set.
7Select the desired POI category.
8Select the desired POI.
Search by phone number ( )
6Select “Phone #”.
7Enter a phone number and select “OK”.
B
A
B
C
D
C
Page 70 of 114
70
LC500_LC500h_QG_OM11556U_(U)
To use the hands-free system, it is necessary to register a Bluetooth® phone with the system.
Refer to www.lexus.com/MobileLink
to find approved Bluetooth® phones for this system.
1Turn the Bluetooth® connection setting of your cellular phone on.
2Press the “MENU” button on the Remote Touch.
3Select “Phone”.
4Select “Yes” to register a phone.
5Select the desired Bluetooth® device.
6Register the Bluetooth® device using your Bluetooth® device.
7Check that the following screen is dis-
played, indicating pairing was success-
ful.
● The system is connecting to the regis-
tered device.
● At this stage, the Bluetooth
® functions
are not yet available.
8Check that “Connect ed” is displayed
and registration is complete.
Hands-free System For Cellular Phone
Registering/Connecting a Bluetooth® device
Page 71 of 114
71
LC500_LC500h_QG_OM11556U_(U)
1Press the “MENU” button on the Remote Touch.
2Select “Setup”.
3Select “Phone” on the sub menu.
4Select “Contacts/Call History”.
5Select “Transfer Contacts from
Device”.
6Select “From Phone (Bluetooth)”.
7Transfer the contact data to the system
using a Bluetooth
® phone.
8Check that a confirmation screen is
displayed when the operation is com-
plete.
Contacts transfer
Depending on the type of Bluetooth® phone, certain functions may not be available.
Page 72 of 114
72
LC500_LC500h_QG_OM11556U_(U)
1Press the “MENU” button on the Remote Touch.
2Select “Setup”.
3Select “Phone” on the sub menu.
4Select “Contacts/Call History”.
5Select “Add Favorite”.
6Select the desired contact to add to the
favorites list.
7Check that a confirmation screen is
displayed when the operation is com-
plete.
1Press the “MENU” button on the Remote Touch.
2Select “Phone”.
3Select “Favorites” on the sub menu and select the desired contact.
4Select the desired number.
5Check that the dialing screen is displayed.
1Press the “MENU” button on the Remote Touch.
2Select “Phone”.
3Select “Message” on the sub menu.
4Select a desired account name that is displayed on the left side of screen.
5Select the desired message from the list.
6Select , or press the switch on the steering wheel.
7Check that the dialing screen is displayed.
Registering the contacts in the favorites list
Calling by favorites list
Calling the message sender
Page 73 of 114
73
LC500_LC500h_QG_OM11556U_(U)
Select “Answer” or press the switch on the steering wheel to talk on the phone.
“Decline”: Select to refuse to receive the call.
Volume control switch
• Press the “+” side to increase the vol-ume.
• Press the “-” side to decrease the vol- ume.
Talk switch
• Press the talk switch to start the voice command system.
• To cancel voice recognition, press and hold the talk switch.
TEL switch
• Start talking
• End talking
•End dialing
Receiving a call
Main display Side display
Steering switches
A
B
C
Page 74 of 114
74
LC500_LC500h_QG_OM11556U_(U)
The audio control screen can be reached by the following methods:
Using the audio control switch
Press the “RADIO” or “MEDIA” button.
Using the Remote Touch
Press the “MENU” button on the Re mote Touch, then select “Audio”.
Using the audio control switch
1Display the audio control screen.
2Each time the “RADIO” or “MEDIA”
button is pressed, the audio source
changes.
“RADIO” button: To change radio
modes.
“MEDIA” button: To change media
modes.
From the audio source selection screen
1Display the audio control screen.
2Select “Source” on the sub menu.
3Select the desired source.
Audio System
Audio control screen
Selecting an audio source
Page 77 of 114
77
LC500_LC500h_QG_OM11556U_(U)
■Audio control switch
Turn to seek up/down
Turn to step up/down frequencies/
channels
Turn to move up/down the list.
■Control screen
Displays cover art
Select to display HD) multicast chan-
nels available
Displays the artist info and song title or
album and genre. Press to change the
displayed information.
Displays messages when available
from RBDS
Select to tune to preset stations/chan-
nels
Display items on the channels regis-
tered to smart favorites
■Presetting a station
Radio mode has a mix preset function, which can store up to 36 stations (6 stations per
page x 6 pages) from any of the AM, FM or SXM bands.
1Tune in the desired station.
2Select “(Add New)”.
● To change the preset station to a differ-
ent one, select and hold the preset sta-
tion.
3Select “Yes” on the confirmation
screen.
4Select “OK” after setting the new pre-
set station.
Radio
A
B
A
B
C
D
E
Page 78 of 114
78
LC500_LC500h_QG_OM11556U_(U)
■Audio control switch
Turn to select a track/file
Turn and hold to fast forward/rewind.
Turn to select a track/file
Turn to move up/down the list.
■Control screen
Audio CD
Displays cover art
Select to set repeat playback
Select to change the track/file
Select and hold to fast rewind.
Select to play/pause
Select to change the track/file
Select and hold to fast forward.
Select to set random playback
MP3/WMA/AAC disc
Displays cover art
Select to change the folder
Select to set repeat playback
Select to change the track/file
Select and hold to fast rewind.
Select to play/pause
Select to change the track/file
Select and hold to fast forward.
Select to set random playback
CD
A
B
A
B
C
D
E
F
A
B
C
D
E
F
G
