2020 Lexus IS300 USB port

TABLE OF CONTENTS4
IS350 AWD/IS350/IS300 AWD/IS300_U
5-1. Basic OperationsLexus Display Audio system............................................312
Steering wheel audio switches ....................................... 318
Mobile Assistant ..........................319
USB/AUX ports ..........................321
5-2. Setup Setup menu .................................. 324
General settings......................... 325
Voice settings.............................. 328
Display settings ........................... 329
5-3. Using the audio system Selecting the audio source .......................................... 330
Optimal use of the audio system............................................331
Audio settings ............................. 332
Audio menu screen operation .................................... 335
5-4. Using the radio Radio operation.......................... 338
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ................ 344 5-6. Using an external device
Listening to an iPod ....................351
Using USB memory device .......................................... 355
Using the AUX port ................. 359
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 360
Registering a Bluetooth
®
device .......................................... 362
Selecting a Bluetooth
®
device .......................................... 363
Connecting a Bluetooth
®
audio player .............................. 364
Connecting a Bluetooth
®
phone ........................................... 365
Displaying a Bluetooth
®
device details ............................ 366
Detailed Bluetooth
®
settings ........................................ 367
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ........................................... 370
5Lexus Display Audio
system

310
IS350 AWD/IS350/IS300 AWD/IS300_U
5-1. Basic OperationsLexus Display Audio system ........................................... 312
Steering wheel audio switches........................................ 318
Mobile Assistant.......................... 319
USB/AUX ports ......................... 321
5-2. Setup Setup menu .................................. 324
General settings ......................... 325
Voice settings ..............................328
Display settings ........................... 329
5-3. Using the audio system Selecting the audio source ..........................................330
Optimal use of the audio system ........................................... 331
Audio settings ............................. 332
Audio menu screen operation ....................................335
5-4. Using the radio Radio operation..........................338
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ................ 344
Lexus Display Audio system
5

311
Lexus DisplayAudio system
5
IS350 AWD/IS350/IS300 AWD/IS300_U
5-6. Using an external device
Listening to an iPod .................... 351
Using USB memory device.......................................... 355
Using the AUX port ................ 359
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 360
Registering a Bluetooth
®
device...........................................362
Selecting a Bluetooth
®
device...........................................363
Connecting a Bluetooth
®
audio player ...............................364
Connecting a Bluetooth
®
phone ...........................................365
Displaying a Bluetooth
®
device details ............................366
Detailed Bluetooth
®
settings......................................... 367
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio............................................370 5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone .............................................371
Making a call ................................ 374
Receiving a call ........................... 377
Speaking on the phone............ 378
Using a Bluetooth
®
phone message....................... 380
Using the steering wheel switches.......................................382
Bluetooth
® phone
settings ........................................383
5-10. Phonebook Contact settings .........................385
Messaging setting..................... 388
5-11. Bluetooth
®
What to do if... (Troubleshooting)...................389
Bluetooth
®................................... 393
5-12. Other function “Information” screen................ 400
USB photo .................................... 402
Weather information................ 404
Voice command system .........405

3215-1. Basic Operations
5
Lexus Display Audio system
IS350 AWD/IS350/IS300 AWD/IS300_U
■iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if it is
not turned on.
■USB memory
Open the cover and connect the USB memory device.
Turn on the power, if applicable, of the USB memory device if it is not turned on.
■Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
USB/AUX ports
Connect an iPod, USB memory device or portable audio player to the USB/
AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “External” on
the audio source selection screen and the device can be operated via Lexus
Display Audio system.
Connecting using the USB/AUX port

3225-1. Basic Operations
IS350 AWD/IS350/IS300 AWD/IS300_U
To view a video on an iPod video or VTR, it is necessary to use a 4-pole AUX
cable to connect the portable audio device.
When connecting a portable audio devi ce to the AUX port, use a 4-pole AUX
cable with a plug that matches the ex act layout shown in the illustration.
Connected device (portable audio
device, etc.)
Left audio
Right audio
Ground
Video
When using an iPod video, a cable
that has a 4-pole AUX plug and a
USB connector is necessary. Con-
nect the plug and connector to the
AUX and USB ports.
Using a 4-pole AUX cable
1
2
3
4
5

3585-6. Using an external device
IS350 AWD/IS350/IS300 AWD/IS300_U
●MP3, WMA and AAC playback
• When a device containing MP3, WMA or AA C files is connected, all files in the
USB memory device are checked. Once the file check is finished, the first MP3,
WMA or AAC file is played. To make the file check finish more quickly, we recom-
mend that you do not include any files other than MP3, WMA or AAC files or cre-
ate any unnecessary folders.
• When a USB memory device is connected and the audio source is changed to USB memory mode, the USB memory device will st art playing the first file in the first
folder. If the same device is removed an d reconnected (and the contents have not
been changed), the USB memory device w ill resume play from the same point in
which it was last used.
●Extensions
If the file extensions .mp3, .wma and .m4a are used for files other than MP3, WMA
and AAC files, they will be skipped (not played).
●Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
• There is a wide variety of freeware an d other encoding software for MP3, WMA
and AAC files on the market, and depending on the status of the encoding and the
file format, poor sound quality or noise at the start of playback may result. In some
cases, playback may not be possible at all.
• Microsoft, Windows, and Windows Media ar e the registered trademarks of Micro-
soft Corporation in the U.S.A. and other countries.
NOTICE
■To prevent damage to the USB me mory device or its terminals
●Depending on the size and shape of the USB memory that is connected to the sys-
tem, the console box may not close fully. In th is case, do not forcibly close the console
box as this may damage the USB memory or the terminal, etc.
●Do not leave the USB memory device in the vehicle. The temperature inside the vehi-
cle may become high.
●Do not push down on or apply unnecessary pressure to the USB memory device
while it is connected.
●Do not insert foreign objects into the port.

400
IS350 AWD/IS350/IS300 AWD/IS300_U5-12. Other function
Go to “Information”: “MENU” button 
“Info”
Display the fuel consumption.
( P. 112)
Display the “USB Photo” screen.
( P. 402)
Display the Traffic Map picture.
Available when in a traffic supported
HD Radio coverage area
Display the weather information.
( P. 404)
Go to “Traffic Map”: “MENU” button  “Info” “Traffic Incidents”
Current position of your car
Traffic information line
The line color means the following:
Red: Heavy congestion
Yellow: Moderate traffic
Green: Free flowing traffic
“Information” screen
Display “Information” screen
1
2
3
4
Traffic information map
1
2

641Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
Alarm ............................................................ 78
Anchor brackets ...................................... 57
Antennas (smart access system with push-button start) ..................... 135
Anti-lock Brake System (ABS)........ 301 Warning light ...................................... 525
Approach warning (dynamic radar cruise control) ........................ 255
Armrest .................................................... 439
ASC (Active Sound Control) .......... 201
Assist grip ..................................................441
Audio input................................................321
Audio system............................................312 Audio input..............................................321
AUX port/USB port..........................321
Bluetooth
® audio...............................370
CD player ..............................................344
iPod ............................................................ 351
MP3/WMA/AAC disc .................344
Optimal use ........................................... 331
Portable music player ..................... 359
Radio ....................................................... 338
Steering wheel audio switch ......... 318
USB memory ...................................... 355 Automatic headlight leveling
system .................................................... 204
Automatic High Beam ....................... 206
Automatic light control system .................................................... 202
Automatic transmission........................ 191 If the shift lever cannot be shifted from P ..............196
M mode ....................................................194
Paddle shift switches..........................193
AUX port .................................................. 321
Average fuel economy................................. 112, 113, 115
Average vehicle speed..........................112
