2020 JEEP PATRIOT bluetooth

UCONNECT PHONE — IF
EQUIPPED
Uconnect Phone is a voice-activated, hands-
free, in-vehicle communications system.
Uconnect Phone allows you to dial a phone
number with your mobile phone using simple
voice commands (e.g., “Call”…“Mike”…
“Work” or “Dial”…“151-1234-5555”). Your mo-
bile phone’s audio is transmitted through your
vehicle’s audio system; the system will auto-
matically mute your radio when using the
Uconnect Phone.
NOTE:
The Uconnect Phone requires a mobile
phone equipped with the Bluetooth “Hands-
Free Profile”, Version 0.96 or higher. See the
Uconnect website for supported phones.
For Uconnect Customer Support visit
UconnectPhone.com.
Uconnect Phone allows you to transfer calls
between the system and your mobile phone as
you enter or exit your vehicle and enables you
to mute the system’s microphone for private
conversation.The Uconnect Phone is driven through your
Bluetooth “Hands-Free Profile” mobile phone.
Uconnect features Bluetooth technology - the
global standard that enables different electronic
devices to connect to each other without wires
or a docking station, so Uconnect Phone works
no matter where you stow your mobile phone
(be it your purse, pocket, or briefcase), as long
as your phone is turned on and has been paired
to the vehicle’s Uconnect Phone. The Uconnect
Phone allows up to seven mobile phones to be
linked to the system. Only one linked (or paired)
mobile phone can be used with the system at a
time. The system is available in many lan-
guages.
WARNING!
Any voice commanded system should be
used only in safe driving conditions following
all applicable laws, including laws regarding
phone use. Your attention should be focused
on safely operating the vehicle. Failure to do
so may result in a collision causing serious
injury or death.Uconnect Phone Button
The radio or steering wheel con-
trols (if equipped) will contain the
two control buttons (Uconnect
Phone
button and Voice Com-
mandbutton) that will enable
you to access the system. When you push the
button you will hear the word Uconnect followed
by a BEEP. The beep is your signal to give a
command.
Voice Command Button
Actual button location may vary
with the radio. The individual but-
tons are described in the “Opera-
tion” section.
The Uconnect Phone can be used with any
Hands-Free Profile certified Bluetooth mobile
phone. See the Uconnect website for supported
phones. Refer to your mobile service provider
or the phone manufacturer for details.
The Uconnect Phone is fully integrated with the
vehicle’s audio system. The volume of the
Uconnect Phone can be adjusted either from
67

the radio volume control knob or from the
steering wheel radio control (right switch), if so
equipped.
The radio display will be used for visual prompts
from the Uconnect Phone such as “CELL” or
caller ID on certain radios.
OperationVoice commands can be used to operate the
Uconnect Phone and to navigate through the
Uconnect Phone menu structure. Voice com-
mands are required after most Uconnect Phone
prompts. You will be prompted for a specific
command and then guided through the avail-
able options.
•Prior to giving a voice command, one must
wait for the beep, which follows the “Ready”
prompt or another prompt.
•For certain operations, compound com-
mands can be used. For example, instead of
saying “Setup” and then “Pair a Device,” the
following compound command can be said:
“Pair a Bluetooth Device.”
•For each feature explanation in this section,
only the compound form of the voice com-mand is given. You can also break the com-
mands into parts and say each part of the
command when you are asked for it. For
example, you can use the compound form
voice command “Phonebook New Entry,” or
you can break the compound form command
into two voice commands: “Phonebook” and
“New Entry.” Please remember, the
Uconnect Phone works best when you talk in
a normal conversational tone, as if speaking
to someone sitting a few feet/meters away
from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
Help Command
If you need assistance at any prompt, or if you
want to know your options at any prompt, say
“Help” following the beep. The Uconnect Phone
will play some of the options at any prompt if
you ask for help.
To activate the Uconnect Phone, simply push
the Phone
button and follow the audible
prompts for directions. Uconnect Phone ses-
sions begin with a push of the Phone
button
on the radio control head.Cancel Command
At any prompt, after the beep, you can say
“Cancel” and you will be returned to the main
menu. However, in a few instances the system
will take you back to the previous menu.
Pair (Link) Uconnect Phone To A Mobile
Phone
To begin using your Uconnect Phone, you must
pair your compatible Bluetooth enabled mobile
phone.
To complete the pairing process, you will need
to reference your mobile phone Owner’s
Manual. The Uconnect website may also pro-
vide detailed instructions for pairing.
The following are general phone to Uconnect
Phone pairing instructions:
1. Activate the Bluetooth on your mobile
phone.
2. Push the Phone
button to begin.
3. After the “Ready” prompt and the following
beep, say “Device Pairing.”
4. When prompted, after the beep, say “Pair a
Device” and follow the audible prompts.
68

You will be asked to say a four-digit Personal
Identification Number (PIN), which you will later
need to enter into your mobile phone. You can
enter any four-digit PIN. You will not need to
remember this PIN after the initial pairing pro-
cess.
For identification purposes, you will be
prompted to give the Uconnect Phone a name
for your mobile phone. Each mobile phone that
is paired should be given a unique phone name.
You will then be asked to give your mobile
phone a priority level between one and seven,
with one being the highest priority. You can pair
up to seven mobile phones to your Uconnect
Phone. However, at any given time, only one
mobile phone can be in use, connected to your
Uconnect System. The priority allows the
Uconnect Phone to know which mobile phone
to use if multiple mobile phones are in the
vehicle at the same time. For example, if priority
three and priority five phones are present in the
vehicle, the Uconnect Phone will use the priority
three mobile phone when you make a call. You
can select to use a lower priority mobile phone
at any time (refer to “Advanced Phone Connec-
tivity” in this section).Dial By Saying A Number
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Dial.”
•The system will prompt you to say the num-
ber you want to call.
•For example, you can say “151-1234-5555.”
•The Uconnect Phone will confirm the phone
number and then dial. The number will ap-
pear in the display of certain radios.
Call By Saying A Name
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Call.”
•The system will prompt you to say the name
of the person you want to call.
•After the “Ready” prompt and the following
beep, say the name of the person you want
to call. For example, you can say “John Doe,”
where John Doe is a previously stored name
entry in the Uconnect phonebook or down-
loaded phonebook. To learn how to store aname in the phonebook, refer to “Add Names
to Your Uconnect Phonebook.”
•The Uconnect system will confirm the name
and then dial the corresponding phone num-
ber, which may appear in the display of
certain radios.
Phonebook Download — Automatic
Phonebook Transfer From Mobile Phone
If equipped and specifically supported by your
phone, Uconnect Phone automatically down-
loads names (text names) and number entries
from your mobile phone’s phonebook. Specific
Bluetooth Phones with Phone Book Access
Profile may support this feature. See Uconnect
website for supported phones.
•To call a name from the Uconnect Phone-
book or downloaded Phonebook, follow the
procedure in “Call by Saying a Name” sec-
tion.
•Automatic download and update, if sup-
ported, begins as soon as the Bluetooth
wireless phone connection is made to the
Uconnect Phone, for example, after you start
the vehicle.
69

Dialing Using The Mobile Phone Keypad
You can dial a phone number with your mobile
phone keypad and still use the Uconnect Phone
(while dialing via the mobile phone keypad, the
user must exercise caution and take precau-
tionary safety measures). By dialing a number
with your paired Bluetooth mobile phone, the
audio will be played through your vehicle’s
audio system. The Uconnect Phone will work
the same as if you dial the number using Voice
Command.
NOTE:
Certain brands of mobile phones do not
send the dial ring to the Uconnect Phone to
play it on the vehicle audio system, so you
will not hear it. Under this situation, after
successfully dialing a number the user may
feel that the call did not go through even
though the call is in progress. Once your call
is answered, you will hear the audio.
Mute/Un-Mute (Mute ON/OFF)
When you mute the Uconnect Phone, you will
still be able to hear the conversation comingfrom the other party, but the other party will not
be able to hear you. To mute the Uconnect
Phone:
•Push the Voice Command
button.
•Following the beep, say “Mute.”
To un-mute the Uconnect Phone:
•Push the Voice Command
button.
•Following the beep, say “Mute off.”
Advanced Phone Connectivity
Transfer Call To And From Mobile Phone
The Uconnect Phone allows ongoing calls to be
transferred from your mobile phone to the
Uconnect Phone without terminating the call.
To transfer an ongoing call from your Uconnect
Phone paired mobile phone to the Uconnect
Phone or vice versa using Voice Command:
1. Push the Voice Command
button and
say “Transfer Call.”Connect Or Disconnect Link Between The
Uconnect Phone And Mobile Phone
Your mobile phone can be paired with many
different electronic devices, but can only be
actively “connected” with one electronic device
at a time.
If you would like to connect or disconnect the
Bluetooth connection between your mobile
phone and the Uconnect Phone System, follow
the instructions described in your mobile phone
User’s Manual.
List Paired Mobile Phone Names
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Setup Phone Pairing.”
•When prompted, say “List Phones.”
•The Uconnect Phone will play the phone
names of all paired mobile phones in order
from the highest to the lowest priority. To
“Select” or “Delete” a paired phone being
announced, push the Voice Command
button and say “Select” or “Delete.” Also,
see the next two sections for an alternate
way to “Select” or “Delete” a paired phone.
76

Turn Voice Text Reply Incoming Announce-
ment ON/OFF
Turning the Voice Text Reply Incoming An-
nouncement OFF will stop the system from
announcing the new incoming messages.
To turn Voice Text Reply incoming announce-
ment on or off using Voice Command:
1. Push the Phone
button.2. After the “Ready” prompt and the following
beep, say “Setup Incoming Message An-
nouncement,” you will then be given a
choice to change it.
Bluetooth Communication Link
Mobile phones have been found to lose connec-
tion to the Uconnect Phone. When this hap-
pens, the connection can generally be reestab-lished by switching the phone off/on. Your
mobile phone is recommended to remain in
Bluetooth ON mode.
Power-Up
After switching the ignition key from OFF to
either the ON or ACC position, or after a lan-
guage change, you must wait at least 15 sec-
onds prior to using the system.
80

Primary Alternate (s)
send
set up phone settings or
phone set up
transfer call
Uconnect Tutorial
voice training
work
yes
VOICE COMMAND — IF
EQUIPPED
Voice Command System Operation
The Uconnect Voice Command
system allows you to control your
AM, FM radio, disc player, USB
Mass Storage Class device, iPod
family of devices, Bluetooth
Streaming Audio device, and a
memo recorder.NOTE:
Take care to speak into the Voice Interface
System as calmly and normally as possible.
The ability of the Voice Interface System to
recognize user voice commands may be
negatively affected by rapid speaking or a
raised voice level.
WARNING!
Any voice commanded system should be
used only in safe driving conditions following
all applicable laws, including laws regarding
phone use. Your attention should be focused
on safely operating the vehicle. Failure to do
so may result in a collision causing serious
injury or death.
When you push the Voice Command
button,
you will hear a beep. The beep is your signal to
give a command.NOTE:
If you do not say a command within a few
seconds, the system will present you with a
list of options.
If you ever wish to interrupt the system while it
lists options, push the Voice Command
but-
ton, listen for the beep, and say your command.
Pushing the Voice Command
button while
the system is speaking is known as “barging in.”
The system will be interrupted, and after the
beep, you can add or change commands. This
will become helpful once you start to learn the
options.
NOTE:
At any time, you can say the words “Can-
cel,” “Help” or “Main Menu.”
These commands are universal and can be
used from any menu. All other commands can
be used depending upon the active application.
When using this system, you should speak
clearly and at a normal speaking volume.
85

The system will best recognize your speech if
the windows are closed, and the heater/air
conditioning blower control is set to low.
At any point, if the system does not recognize
one of your commands, you will be prompted to
repeat it.
To hear the first available Menu, push the Voice
Command
button and say “Help” or “Main
Menu.”
CommandsThe Voice Command system understands two
types of commands, Universal commands and
Local commands. Universal commands are
available at all times. Local commands are
available if the supported radio mode is active.
Changing The Volume
To change the Voice Command volume:
1. Start a dialogue by pushing the Voice Com-
mand
button.
2. Say a command (e.g., “Help”).3.
Use the ON/OFF VOLUME rotary knob to
adjust the volume to a comfortable level while
the Voice Command system is speaking.
•Please note the volume setting for Voice
Command is different than the volume
setting for the audio system.
Main Menu
Start a dialogue by pushing the Voice Com-
mand
button. You may say “Main Menu” to
switch to the main menu.
In this mode, you can say the following com-
mands:
•“Radio AM” (to switch to the radio AM mode)
•“Radio FM” (to switch to radio FM mode)
•“Disc” (to switch to the disc mode)
•“USB” (to switch to USB mode)
•“Bluetooth Streaming” (to switch to Bluetooth
Streaming mode)
•“Memo” (to switch to the memo recorder)
•“System Setup” (to switch to system setup)Radio AM (Or Radio Long Wave Or Radio
Medium Wave — If Equipped)
To switch to the AM band, say “AM” or “Radio
AM.” In this mode, you may say the following
commands:
•“Frequency #” (to change the frequency)
•“Next Station” (to select the next station)
•“Previous Station” (to select the previous
station)
•“Menu Radio” (to switch to the radio menu)
•“Main Menu” (to switch to the main menu)
Radio FM
To switch to the FM band, say “FM” or “Radio
FM.” In this mode, you may say the following
commands:
•“Frequency #” (to change the frequency)
•“Next Station” (to select the next station)
•“Previous Station” (to select the previous
station)
•“Menu Radio” (to switch to the radio menu)
•“Main Menu” (to switch to the main menu)
86

Disc Mode
To switch to the disc mode, say “Disc.” In this
mode, you may say the following commands:
•“Track” (#) (to change the track)
•“Next Track” (to play the next track)
•“Previous Track” (to play the previous track)
•“Main Menu” (to switch to the main menu)
USB Mode
To switch to USB mode, say “USB.” In this
mode, you may say the following commands:
•“Next Track” (to play the next track)
•“Previous Track” (to play the previous track)
•“Play” (to play an Artist Name, Playlist Name,
Album Name, Track Name, etc.)
Bluetooth Streaming (BT) Mode
To switch to Bluetooth Streaming (BT) mode,
say “Bluetooth Streaming.” In this mode, you
may say the following commands:
•“Play” (to play the current track)
•“Pause” (to pause the current track)
•“Next Track” (to play the next track)•“Previous Track” (to play the previous track)
Memo Mode
To switch to the voice recorder mode, say
“Memo.” In this mode, you may say the follow-
ing commands:
•“New Memo” (to record a new memo) —
During the recording, you may push the
Voice Command
button to stop recording.
You proceed by saying one of the following
commands:
– “Save” (to save the memo)
– “Continue” (to continue recording)
– “Delete” (to delete the recording)
•“Play Memos” (to play previously recorded
memos) — During the playback you may
push the Voice Command
button to stop
playing memos. You proceed by saying one
of the following commands:
– “Repeat” (to repeat a memo)
– “Next” (to play the next memo)
– “Previous” (to play the previous memo)
– “Delete” (to delete a memo)
– “Delete All” (to delete all memos)System Setup
To switch to system setup, you may say one of
the following:
•“Change to system setup”
•“Main menu system setup”
•“Switch to system setup”
•“Change to setup”
•“Main menu setup” or
•“Switch to setup”
In this mode, you may say the following com-
mands:
•“Language English”
•“Language French”
•“Language Spanish”
•“Language Dutch”
•“Language Deutsch”
•“Language Italian”
•“Tutorial”
•“Voice Training”
87
