2020 INFINITI QX50 key

8 Do-it-yourself
Maintenance precautions.........................8-2
Engine compartment check locations ..............8-3
Engine cooling system ........................... 8-4
Checking engine coolant level ..................8-5
Changing engine coolant ......................8-5
Engine oil ........................................8-6
Checking engine oil level .......................8-6
Changing engine oil and oil filter ...............8-6
Continuously Variable Transmission (CVT) fluid . . 8-10
Brake fluid ..................................... 8-10
Windshield-washer fluid ......................... 8-11
Windshield-washer fluid reservoir .............8-11
Battery ......................................... 8-11
Jump starting ............................... 8-12
Variable voltage control system .................8-13
Drive belt ...................................... 8-13
Spark plugs .................................... 8-14
Replacing spark plugs ....................... 8-14
Air cleaner ..................................... 8-15
In-cabin microfilter .......................... 8-15Windshield wiper blades
........................ 8-16
Cleaning .................................... 8-16
Replacing ................................... 8-16
Brakes ......................................... 8-18
Fuses .......................................... 8-18
Engine compartment ........................ 8-19
Passenger compartment .....................8-20
Battery replacement ............................ 8-21
INFINITI Intelligent Key ......................8-21
Lights ......................................... 8-23
Headlights .................................. 8-23
Fog lights (if so equipped) ...................8-23
Exterior and interior lights ...................8-23
Wheels and tires ............................... 8-25
Tire pressure ................................ 8-25
Tire labeling ................................. 8-28
Types of tires ............................... 8-31
Tire chains .................................. 8-34
Changing wheels

and tires ................... 8-34

CAUTION
Be careful not to allow children to swallow
the battery or removed parts.
INFINITI INTELLIGENT KEY
Replace the battery in the Intelligent Key as
follows:1. Remove the mechanical key from the In- telligent Key.
2. Insert a small flathead screwdriver
A
into the slitBof the corner and twist it
to separate the upper part from the
lower part. Place a cloth over the screw-
driver to protect the casing.
LDI3308
BATTERY REPLACEMENT
Do-it-yourself8-21

The following tables show the standard
maintenance schedule. Depending upon
weather and atmospheric conditions, varyingroad surfaces, individual driving habits and
vehicle usage, additional or more frequent
maintenance may be required.
After90,000 miles (144,000 km)/144 months,
continue maintenance at the same
mileage/time interval.
STANDARD MAINTENANCE
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace
MAINTENANCE OPERATION
Perform at number of miles, kilometers or
months, whichever comes first. Miles x 1,000
(km x 1,000) Months MAINTENANCE INTERVAL
3.75 (6)6 7.5
(12) 12 11.25
(18)18 15
(24) 24 18.75
(30)30 22.5
(36) 36 26.25
(42)42 30
(48) 48 33.75
(54)54 37.5
(60) 60 41.25
(66)66 45
(72) 72
Air cleaner filter NOTE (1) R
Brake fluid RRR
Brake lines and cables IIIIII
Brake pads and rotors I IIIII
CVT fluid NOTE (2)IIIIII
Drive belt NOTE (3) I*I*I*
Engine coolant* NOTE (4)(5)
Engine oil & oil filter NOTE (6)RRRRRR
EVAP vapor lines & Fuel lines I*I*I*
Exhaust system III
Fuel filter NOTE (7)
In-cabin microfilter RRRR
Intelligent Key battery IR RR
Intake & exhaust valve clearance* NOTE (8)
Propeller shaft & drive shaft boots
(AWD models) I IIIII
Spark plugs NOTE (9) Replace every 105,000 miles (168,000 km)
Steering gear & linkage, axle &
suspension parts  III
Tire rotation NOTE (10)
Transfer fluid & differential gear oil NOTE (11)IIIIII
STANDARD MAINTENANCE
Maintenance and schedules9-9

Abbreviations: I = Inspect and correct or replace as necessary, R = Replace
MAINTENANCE OPERATION
Perform at number of miles, kilometers or
months, whichever comes first. Miles x 1,000
(km x 1,000) Months MAINTENANCE INTERVAL
48.75 (78)78 52.5
(84) 84 56.25
(90)90 60
(96) 96 63.75
(102) 102 67.5
(108) 108 71.25
(114) 114 75
(120) 120 78.75
(126) 126 82.5
(138) 138 86.25
(138) 138 90
(144) 144
Air cleaner filter NOTE (1) R R
Brake fluid RRR
Brake lines and cables IIIIII
Brake pads and rotors IIIIII
CVT fluid NOTE (2) IIIIII
Drive belt NOTE (3) I* I* I* I* I* I*
Engine coolant* NOTE (4)(5)
Engine oil & oil filter NOTE (6) RRRRRR
EVAP vapor lines & Fuel lines I* I* I*
Exhaust system III
Fuel filter NOTE (7)
In-cabin microfilter RRRR
Intelligent Key battery RRRR
Intake & exhaust valve clearance* NOTE (8)
Propeller shaft & drive shaft boots
(AWD models) IIIIII
Spark plugs NOTE (9)Replace every 105,000 miles (168,000 km)
Steering gear & linkage, axle &
suspension parts  III
Tire rotation NOTE (10)
Transfer fluid & differential gear oil NOTE (11)IIIIII
9-10Maintenance and schedules

11 Index
2nd row bench seat adjustment.......1-4
A
Active Engine Brake ............5-185
Active noise cancellation Active sound enhancement. .5-193, 5-194
Active Trace Control ............5-184
Aiming control, headlights .........2-44
Air bag (See supplemental restraint
system).....................1-43
Air bag system Front (See supplemental front impact air
bag system) ................1-51
Air bag warning labels ............1-63
Airbagwarninglight.........1-63,2-15
Air bag warning light,
supplemental ..............1-63,2-15
Air cleaner ...................8-15
Air cleaner housing filter ...........8-15
Air conditioner Air conditioner operation ........4-36
Air conditioner specification label . .10-12
Air conditioner system refrigerant and oil
recommendations ............10-7
Heater and air conditioner (automatic)
(if so equipped) ..............4-35
Heater and air conditioner controls . .4-36
Servicing air conditioner .........4-43
Alarm system
(See vehicle security system) ........2-33
Anchor point locations ............1-27 Antenna
....................4-44
Antifreeze ..................5-191
Anti-lock brake warning light ........2-10
Anti-lock Braking System (ABS) .....5-180
Armrests.....................1-5
Around View® Monitor ...........4-11
Audible reminders ...............2-19
Autolight switch ...............2-40
Automatic Automatic drive positioner . . .3-38, 3-40
Automatic power window switch . . .2-70
Automatic anti-glare inside mirror .....3-35
Automaticbrakehold ............5-26
Automatic door locks .............3-6
Automatic drive positioner .....3-38,3-40
B
Battery.................5- 191, 8-11
Charge warning light ...........2-11
Battery replacement .............8-21
INFINITI Intelligent Key .........8-21
Keyfob...................8-21
Before starting the engine ..........5-17
Belt (See drive belt) ..............8-13
Blind Spot Intervention® (BSI) .......5-54
Blind Spot Warning (BSW) .........5-46
Boosterseats.................1-40
Brake Anti-lock Braking System (ABS) . . .5-180
Brakefluid.................8-10
Brakelight(Seestoplight) .......8-23 Brake system
.............. 5-180
Brakewarninglight ...........2-10
Brake wear indicators ......2-19,8-18
Self-adjusting brakes ..........8-18
Brake Assist .................5-181
Brakefluid...................8-10
Brakes.....................8-18
Brake system ................5-180
Break-in schedule ..............5-171
Brightness control Instrument panel .............2-45
Bulb check/instrument panel ........2-10
Bulb replacement ...............8-23
C
Camera Aiding Sonar (parking sensor) . .4-24
Capacities and recommended
fuel/lubricants ................10-2
Cargoareastoragebin ...........2-61
Cargocover.................. 2-67
Cargo
(See vehicle

loading information) .....10-14
Car phone or CB radio ............4-44
Chassis control ...............5-184
Check tire pressure .............. 2-26
Child restraints .....1-20,1-20, 1-22, 1-24
LATCH (Lower Anchors and Tethers for
CHildren) System .............1-24
Precautions on child
restraints ......1-23, 1-29, 1-35, 1-40

Front air bag system
(See supplemental restraint system)....1-51
Front and rear sonar system ........5-187
Front and rear sonar system switch ....2-50
Front-door pocket ...............2-56
Front power seat adjustment .........1-3
Frontseats....................1-2
Fuel Capacities and recommended
fuel/lubricants...............10-2
Fuel economy ...............5-173
Fuel-filler door and cap ..........3-30
Fuel gauge ..................2-7
Fueloctanerating.............10-5
Fuel recommendation ...........10-3
Loose fuel cap warning ..........2-26
Fuel efficient driving tips ..........5-172
Fuel-filler door .................3-30
Fuel gauge ....................2-7
Fuses ......................8-18
Fusiblelinks...................8-19
G
Garage door opener, HomeLink® Universal
Transceiver............2-76,2-78,2-79
Gascap.....................3-30
Gauge Engine coolant temperature gauge ....2-6
Fuel gauge ..................2-7
Odometer ...................2-5
Speedometer ..............2-4,2-5
Tachometer .................2-6
Trip odometer .............2-4,2-5
General maintenance ..............9-2 Glovebox....................2-58
Gloveboxlock.................2-58
Grocery hooks
.................2-62
H
Hazard warning flasher switch ........6-2
Headlight aiming control ...........2-44
Headlight and turn signal switch ......2-40
Headlights ...................8-23
Headlights, aiming control ..........2-44
Headlight switch ...............2-40
Head restraints ..................1-7
Head Up Display (HUD) ............2-51
Heated seats ..................2-48
Heater Heater and air conditioner (automatic)
(if so equipped) ...............4-35
Heater and air conditioner controls . . .4-36
Heater operation .............4-37
Heater and air conditioner (automatic) . . .4-35
Heater and air conditioner settings .....4-42
Hill start assist system ............5-186
HomeLink® Universal
Transceiver............2-76,2-78,2-79
Hood .......................3-23
Hook Luggage hook ...............2-61
Horn.......................2-46
I
Ignition switch Push-button ignition switch .......5-13Immobilizer system
..............5-17
Important vehicle information label . . . .10-11
In-cabin microfilter ..............8-15
Increasing fuel economy ..........5-173
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .............2-9,2-10,2-16
INFINITI Drive Mode Selector ........5-29
INFINITI Intelligent Key System .....3-2,
3-7
INFINITI
InTouch™ Owner's Manual .....4-2
INFINITI Vehicle Immobilizer
System ...............2-34,3-4,5-17
Inside automatic anti-glare mirror .....3-35
Instrument brightness control ........2-45
Instrument panel .............0-6,2-2
Instrument panel dimmer switch ......2-45
Intelligent All-Wheel Drive (AWD) .....5-173
Intelligent Cruise Control (ICC)
(for vehicles without ProPILOT Assist) . . .5-77
Intelligent Key system Key operating range ............3-8
Keyoperation ...............3-10
Mechanical key ...............3-3
Remote keyless entry operation .....3-14
Troubleshooting guide ..........3-17
Warningsignals ..............3-17
Interiorlight................... 2-74
ISOFIX child restraints ............1-24
J
Jump starting ............... 6-5, 8-12
11-3

K
Key.........................3-2
Key fob battery replacement .........8-21
Keyless entry With Intelligent Key system
(See Intelligent Key system) .......3-14
L
Label Tire and Loading Information label . .10-12
Labels Air conditioner specification label . . .10-12
C.M.V.S.S. certification label ......10-11
Emission control information label . .10-11
Engine serial number ..........10-11
F.M.V.S.S. certification label ......10-11
Tire and Loading Information label . .10-12
Vehicle identification number (VIN) . .10-10
Vehicle identification number (VIN)
plate....................10-10
Warning labels (for SRS) .........1-63
Lane Departure Prevention (LDP) .....5-40
Lane Departure Warning (LDW) ......5-35
LATCH (Lower Anchors and Tethers for
CHildren)System ...............1-24
LED Daytime Running Lights (DRL)
system......................2-44
License plate Installing the license plate ........10-12
Liftgate.....................3-23
Liftgaterelease ................3-28
Light Airbagwarninglight........1-63,2-15 Brakelight(Seestoplight)........8-23
Bulb check/instrument panel
......2-10
Bulb replacement .............8-23
Charge warning light ...........2-11
ExteriorandInteriorlights........8-23
Foglights..................8-23
Fog light switch ..............2-46
Headlight and turn signal switch ....2-40
Headlights .................8-23
Interiorlight.................2-74
Lightbulbs.................8-23
Low tire pressure warning light .....2-12
Low windshield-washer fluid warning
light .....................2-26
Passenger air bag and status light . . .1-54
Personal lights ...............2-75
Security indicator light ..........2-18
Trunklight..................2-75
Warning/indicator lights and audible
reminders ...........2-9,2-10,2-16
Lights......................8-23 Maplights..................2-75
Lock Child safety rear door lock .........3-6
Door locks ...............3-4,3-5
Gloveboxlock...............2-58
Liftgaterelease ..............3-28
Power door locks ...........3-5,3-6
Loose fuel cap warning ............2-26
Lowfuelwarninglight ........2-14,2-26
Low tire pressure warning light .......2-12
Low windshield-washer fluid warning
light .......................2-26
Luggage hook .................2-61
Luggage rack (see roof rack) .....2-62,2-63Luggage
(See vehicle loading information)
.....10-14
M
Maintenance Generalmaintenance............9-2
Inside the vehicle ..............9-3
Maintenance precautions .........8-2
Outside the vehicle .............9-2
Seat belt maintenance ..........1-19
Under the hood and vehicle ........9-4
Maintenance log ................9-13
Maintenance requirements ..........9-2
Maintenance schedules ..........9-7, 9-7
Maintenance under severe operation
conditions....................9-12
Malfunctionindicatorlight..........2-17
Maplights.................... 2-75
Memory Seat ..............3-38,3-40
Meters and gauges ...............2-4
Instrument brightness control ......2-45
Mirror Automatic anti-glare inside mirror . . .3-35
Outside mirrors ..............3-36
Rearview .................. 3-35
Vanity mirror................ 3-34
Mirrors .....................

3-35
Moonroof ................. 2-71, 7-5
Moving Object Detection (MOD) ......4-29
O
Octane rating (See fuel octane rating) . . .10-5
11-4
