INSTALLING AN ISOFIX
CHILD CARSEAT
88) 89) 90)
The rear side seats of the car are
equipped with ISOFIX anchors, for
fitting child restraint systems quickly,
simply and safely. The ISOFIX system
lets you install the ISOFIX child
restraining system without using the car
seat belts but connecting them directly
to the carseat with three anchors in the
car.
Traditional child restraint systems can
be fitted alongside ISOFIX child restraint
systems on different seats in the same
vehicle.
To install an ISOFIX child restraint
system, attach it to the two metal
anchors 1 fig. 101 located behind the
cushion of the rear seat, in the point
where it meets the backrest, then fix the
upper hook of the child restraint system
to the dedicated anchor 2
fig. 102located behind the seat
backrest.
As an example, fig. 104 shows an
example of a Universal ISOFIX child
restraint system for weight group 1.The other weight groups are covered by
specific ISOFIX child restraint systems,
which can be used only if specifically
tested for this vehicle (see list of
vehicles provided with the child restraint
system).
IMPORTANT The fig. 104 is indicative
and for assembly purposes only. Fit the
child restraint system according to the
instructions, which must be included.
10106096J0008EM
102P2000179
103F1B0117C
10406096J0007EM
95

NOTE When a Universal ISOFIX child
restraint system is used, only ECE R44
"ISOFIX Universal” (R44/03 or further
upgrades) type-approved child restraint
systems can be used (see fig. 103 ).
96
SAFETY

SUITABILITY OF PASSENGER SEATS FOR ISOFIX CHILD RESTRAINT SYSTEM USE
ISOFIX POSITIONS ON THE VEHICLE
Weight categories Size category Device Front passengerRear side
passengersRear central
passenger
Group 0 (up to 10 kg) E ISO/R1XILX
Group 0+ (up to 13 kg)E ISO/R1
XILX
D ISO/R2XILX
C ISO/R3X IL (*) X
Group 1 (from 9 up to
18 kg)D ISO/R2
XILX
C ISO/R3X IL (*) X
B ISO/F2XIUF-ILX
B1 ISO/F2XXIUF-ILX
A ISO/F3XIUF-ILX
X ISOFIX position not suitable for ISOFIX child protection systems for this weight and/or size category.
IL Suitable for ISOFIX child restraint systems of the categories for "specific vehicles", "restricted", or "semiuniversal", approved for this typeof car.
IL (*) The ISOFIX child restraint system can be installed by adjusting the front seat.
IUF Suitable for forward facing ISOFIX child restraint systems in the Universal category and type-approved for the use in the weight group.
97

i-Size CHILD RESTRAINT
SYSTEMS
These child restraint systems, built and
type-approved according to the i-Size
(ECE R129) standard, ensure better
safety conditions to carry children on
board a vehicle:
the child must be transported
rearward facing until 15 months;
child restraint system protection is
increased in the event of a side
collision;
the use of the ISOFIX system is
promoted to avoid faulty installation of
the child restraint system;
efficiency in the choice of the child
restraint system, which isn't made
according to weight any more but
according to the child's height, is
increased;
compatibility between the vehicle
seats and the child restraint systems is
better: the i-Size child restraint systems
can be considered as "Super ISOFIX";
this means that they can be perfectly
fitted in type-approved i-Size seats, but
can also be fitted in ISOFIX (ECE R44)
type-approved seats.
NOTE If your car seats are i-Size
approved, the symbol shown in
fig. 105 will appear on the seats near
the ISOFIX attachments.NOTE See the table shown on the
following page to check whether your
car is approved for installing i-Size child
restraint systems.
105F1B0124C
98
SAFETY

The following table, according to European standard ECE 129, indicates the possibility of i-Size child restraint system
installation.
i-Size POSITIONS ON THE CAR
Device Front passengerRear side
passengersRear central
passenger
i-Size child restraint systemsISO/R2 X i-U X
ISO/F2 X i-U X
i-U: suitable for Universal i-Size child restraint systems, both rearward facing and forward facing.
X: seat not suitable for Universal i-Size child restraint systems.
99

CHILD RESTRAINT SYSTEMS RECOMMENDED BY FIAT FOR YOUR VEHICLE
Lineaccessori MOPAR®includes a complete range of child restraint systems to be fixed using the seat belt with three
anchorage points or the ISOFIX anchorages.
IMPORTANT FCA recommends fitting the child restraint system according to the instructions, which must be included.
Weight group Child restraint system Type of child restraint systemChild restraint system
installation
Group 0+:
from birth to 13 kg
from 40 cm to
80 cm
BeSafe iZi Go Modular
Fiat order code: 71808564
Universal/i-Size child restraint
system.
It must be installed facing
rearwards, using the car seat
belts only, or the dedicated i-Size
base (which can be purchased
separately) and the car ISOFIX
anchorages.
It must be fitted on the rear outer
seats. ++
BeSafe iZi Modular i-Size Base
Fiat order code: 71808566
100
SAFETY

Weight group Child restraint system Type of child restraint systemChild restraint system
installation
Group 0+/1:
from9upto18kg
from 67 cm to
105 cm
BeSafe iZi Modular i-Size
Fiat order code: 71808565
i-Size approved child restraint
system.
It mustbe installed on the car
together with the iZi Modular
i-Size Base (available separately).
It can be installed facing forwards
or facing backwards (refer to the
child restraint system manual). ++
BeSafe iZi Modular i-Size Base
Fiat order code: 71808566
Group 2:
from 15 to 25 kg
from 95 cm to
135 cm
Britax Römer KidFix XP
(for versions/markets, where provided)
Fiat order code: 71807984It can only be fitted facing
forwards, using the three-point
seat belt and the ISOFIX
anchorages of the vehicle, if
present.
Fiat recommends installing it
using the vehicle’s ISOFIX
anchor points.
It must be fitted on the rear outer
seats.
101

Weight group Child restraint system Type of child restraint systemChild restraint system
installation
Group 3:
from 22 to 36 kg
from 136 cm to
150 cmBritax Römer KidFix XP
(for versions/markets, where provided)
Fiat order code: 71807984It can only be fitted facing
forwards, using the three-point
seat belt and the ISOFIX
anchorages of the vehicle, if
present.
Fiat recommends installing it
using the vehicle’s ISOFIX
anchor points.
102
