2020 CHEVROLET LOW CAB FORWARD automatic transmission fluid

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
4 Introduction
No. Description1 Cab tilt instruction
2 Automatic transmission fluid
level
3 VIN, weight rating, and
Greenhouse Gas (GHG)
emissions
4 NO STEP instruction
5 Certified clean idle label
6 Towing
7 Vehicle noise emission
control information
8 ID plate
9 Engine cooling
10 Fan blade Crew cab model

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
Introduction 5
No. Description1 Vehicle noise emission
control information
2 VIN, weight rating, and
Greenhouse Gas (GHG)
emissions
3 NO STEP instruction
4 Engine oil level
5 Engine oil level notice
6 Certified clean idle label
7 Towing
8 Engine cooling
9 Fan blade
10 Automatic transmission fluid
level
11 ID plate
12 Power steering fluid
13 Power steering fluid
14 Engine coolant level
15 Starting aids All models

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
52 Instruments and Controls
Instruments and
Controls
Controls
Steering Wheel Adjustment . . . . 53
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Windshield Wiper/Washer . . . . . . 54
Power Outlets . . . . . . . . . . . . . . . . . 55
Warning Lights, Gauges, and
Indicators
Warning Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . . 56
Instrument Cluster . . . . . . . . . . . . . 57
Speedometer . . . . . . . . . . . . . . . . . . 58
Odometer . . . . . . . . . . . . . . . . . . . . . . 58
Trip Odometer . . . . . . . . . . . . . . . . . 58
Tachometer . . . . . . . . . . . . . . . . . . . . 59
Fuel Gauge . . . . . . . . . . . . . . . . . . . . 59
Engine Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . . . 60
Diesel Exhaust Fluid (DEF) Gauge . . . . . . . . . . . . . . . . . . . . . . . . 60
Seat Belt Reminders . . . . . . . . . . . 60
Battery Warning Light . . . . . . . . . . 61
Malfunction Indicator Lamp (Check Engine Light) . . . . . . . . . 61
Service Vehicle Soon Light . . . . 62 Brake System Warning Light
(Parking Brake Light) . . . . . . . . . 62
Antilock Brake System (ABS) Warning Light . . . . . . . . . . . . . . . . 64
Exhaust Brake Light . . . . . . . . . . . 65
Service Transmission Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . 65
Automatic Transmission Fluid Temperature Warning Light . . . 66
Overdrive Off Light . . . . . . . . . . . . . 66
Wait-to-Start Light . . . . . . . . . . . . . 67
Engine Oil Pressure Light . . . . . . 67
Engine Oil Level Indicator Light . . . . . . . . . . . . . . . . . . . . . . . . . 67
Diesel Exhaust Fluid (DEF) Warning Light . . . . . . . . . . . . . . . . 68
Engine Shutdown Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . 68
Idle Shutdown Light . . . . . . . . . . . . 68
Reduced Engine Power Light . . . . . . . . . . . . . . . . . . . . . . . . . 69
High-Beam On Light . . . . . . . . . . . 69
Daytime Running Lamps (DRL) Indicator Light . . . . . . . . . . . . . . . . 69
Cruise Control Light . . . . . . . . . . . 70
Information Displays
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 70
Vehicle Messages
Vehicle Messages . . . . . . . . . . . . . 74
Warning Buzzers . . . . . . . . . . . . . . 79

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
66 Instruments and Controls
If this light comes on while driving, it
indicates that there is a malfunction
in the automatic transmission’s
electronic control system. If the
warning light is on, see your dealer
for service.
Automatic Transmission
Fluid Temperature
Warning Light
This light comes on briefly when the
engine control switch is in the ON
position as a check to show the light
is working. It should go out when
the engine is started.
The Automatic Transmission Fluid
(ATF) Temperature warning light
comes on if the ATF temperature is
high. This usually occurs when the
transmission is overfilled and maybe accompanied by leakage of fluid
from the transmission
breather hose.
If the light stays on, or comes on
while driving, slow down and pull off
the road. Stop the vehicle at a safe
place and put the vehicle in
P (Park). With the engine idling, wait
until the light goes off. If the light
goes off, you can drive the vehicle
again. Continuing to drive while this
light is on may damage the
transmission. While this light is on,
the transmission cannot operate in
all gears. If you attempt to shift
gears, the vehicle may not continue
to move. If you cannot drive to a
dealer immediately, have the vehicle
towed.
Caution
Driving with the ATF warning light
constantly on can cause serious
mechanical damage to the
automatic transmission.
See Automatic Transmission 0196.
Overdrive Off Light
This light should come on briefly
when the engine control switch is
turned on as a check to make sure
the light is working. It should go out
automatically.
This light comes on when the
overdrive off switch on the selector
lever is turned on. Overdrive will not
operate even when the automatic
transmission is in D, unless engine
speed is excessive.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
Instruments and Controls 71
2. Automatic transmission shiftindicator
3. Diesel Exhaust Fluid (DEF) gauge
{Warning
Warning or indicator lights
indicated on the DIC can be
temporarily cleared (for
60 seconds) by pressing the DIC
selector once. However, if the
warning light you have cleared is
an engine overheat warning or
other critical circumstance, never
continue driving without taking the
necessary actions. Otherwise,
you will be in danger of vehicle
breakdown or accident. Should
any of the critical warning lights
come on, immediately contact the
nearest dealer.
DIC Menu Items
Use the DIC selector to access the
following menu items.
Language
Select English, French, or Spanish
by turning the DIC selector
clockwise or counterclockwise.
Fuel Economy
The system calculates and stores
the distance traveled and fuel
consumption while driving to
encourage the operator to drive the
vehicle economically. Press the DIC
selector once or more to select fuel economy. Turn the selector
clockwise or counterclockwise to
toggle through the items: average
fuel economy, per trip fuel economy,
and instantaneous fuel economy.
.
Average Fuel Economy:
Indicates the average fuel
economy over the total distance
traveled.
. Per Trip Fuel Economy:
Indicates the per trip fuel
economy based on the mileage
in the TRIP B.
. Instantaneous Fuel Economy:
Indicates the fuel economy at a
given moment while driving.
How to Reset the Per Trip Fuel
Economy
Per trip fuel economy is also cleared
when you reset the TRIP B to zero.
Voltmeter
The voltmeter shows the current
status of the charge of the battery.
Green indicates the current status of
the charge of the battery.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
128 Driving and Operating
Driving and
Operating
Driving Information
Driver Behavior . . . . . . . . . . . . . . . 129
Driving for Better FuelEconomy . . . . . . . . . . . . . . . . . . . . 129
Distracted Driving . . . . . . . . . . . . 130
Control of a Vehicle . . . . . . . . . . . 130
Braking . . . . . . . . . . . . . . . . . . . . . . . 134
Steering . . . . . . . . . . . . . . . . . . . . . . 140
Driving on Wet Roads . . . . . . . . 140
Hill and Mountain Roads . . . . . 141
Winter Driving . . . . . . . . . . . . . . . . 142
If the Vehicle Is Stuck . . . . . . . . 144
Emergencies (Troubleshooting) . . . . . . . . . . . 145
Emergencies (Disabled Vehicle) . . . . . . . . . . . . . . . . . . . . . 155
Starting and Operating
New Vehicle Break-In . . . . . . . . . 156
Pedals . . . . . . . . . . . . . . . . . . . . . . . . 157
Ignition Positions . . . . . . . . . . . . . 157
Starting and Stopping theVehicle . . . . . . . . . . . . . . . . . . . . . . 159
Operating Temperature . . . . . . . 162
Winter Cover . . . . . . . . . . . . . . . . . 163 Engine Heater . . . . . . . . . . . . . . . . 163
Engine Alarm and Automatic
Shutdown . . . . . . . . . . . . . . . . . . . 164
Idle Shutdown . . . . . . . . . . . . . . . . 164
High Idle System . . . . . . . . . . . . . 165
Engine Checks Before Operating . . . . . . . . . . . . . . . . . . . 166
Parking over Things That Burn . . . . . . . . . . . . . . . . . . . 167
Engine Exhaust
Engine Exhaust . . . . . . . . . . . . . . 168
Running the Vehicle WhileParked . . . . . . . . . . . . . . . . . . . . . . 170
Diesel Particulate Filter
Diesel Particulate Filter . . . . . . . 171
Diesel Exhaust Fluid
Diesel Exhaust Fluid . . . . . . . . . . 180
Automatic Transmission
Automatic Transmission . . . . . . 196
Selector Lever . . . . . . . . . . . . . . . . 205
Overdrive Off . . . . . . . . . . . . . . . . . 206
Brakes
Antilock BrakeSystem (ABS) . . . . . . . . . . . . . . . 207
Parking Brake . . . . . . . . . . . . . . . . 211
Exhaust Brake . . . . . . . . . . . . . . . . 213
Cruise Control
Cruise Control . . . . . . . . . . . . . . . . 214
Fuel
Fuel for Diesel Engines . . . . . . . 218
Biodiesel . . . . . . . . . . . . . . . . . . . . . 219
Cold Weather Operation . . . . . . 221
Water in Fuel . . . . . . . . . . . . . . . . . 221
Running Out of Fuel . . . . . . . . . . 224
Filling the Tank . . . . . . . . . . . . . . . 225
Conversions and Add-Ons
Add-On Electrical Equipment . . . . . . . . . . . . . . . . . . 227
Power Take-Off (PTO) . . . . . . . . 227

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
154 Driving and Operating
SymptomCauseCorrective Action Reference
Loud or abnormal
noises From the
transmission
Insufficient
transmission oil
Add oilSee
Automatic
Transmission Fluid
0 241
Transmission inner
components faulty
4-
From differential Insufficient differential
gear oil
Add oilSee
Rear Axle
(Gear Oil Viscosity
Chart) 0261 or
Rear Axle (Oil
Level Check) 0262
Differential inner
components faulty
4-
From the
suspension Spring pins, shackles,
or stoppers worn
4-
From the driveshaft Poor lubrication in each
component
Lubricate themSee
Owner Checks
and Services 0330
Splines or bearings worn
4-

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500 HD/XD/5500 HD/XD
Owner Manual (GMNA-Localizing-U.S.-13337621) - 2020 - crc - 12/5/18
196 Driving and Operating
When the exhaust system warning
light comes on, promptly have the
vehicle inspected and serviced at a
dealer.
When a malfunction is detected in
the SCR system, the warning and
the indicator lights shown in the
table come on. SeeVehicle
Messages 074, Malfunction
Indicator Lamp (Check Engine
Light) 061, and Diesel Exhaust
Fluid (DEF) Warning Light 068.
When the Diesel Exhaust Fluid
(DEF) Tank is Empty
If the DEF tank is empty and
warning and indicator lights are on,
you must follow below procedure to
cancel the vehicle restriction: 1. Turn the engine control switch to the LOCK or ACC position,
and add DEF.
2. After adding DEF, turn the engine control switch to ON
position.
3. Wait until buzzer stops, warnings and indicators are
turned off. 4. If the buzzer does not stop,
return the engine control switch
back to the LOCK position and
add more DEF, and then start
over from step 2 above.
5. Restart the engine.
It may take a while until the warning
lights and indicators turn off and the
buzzer stops after turning the
engine control switch to the ON
position.
It is desirable to fill up the tank with
DEF to avoid DEF remaining level
warning indication from reappearing.
When the outside temperature is
low, refer to Adding DEF in Cold
Weather. See Driver Information
Center (DIC) 070, Brake System
Warning Light (Parking Brake Light)
0 62, Warning Buzzers 079, and
Winter Driving 0142.Automatic
Transmission
On an automatic transmission
vehicle, the driver does not use a
clutch pedal when pulling away,
changing gears, or stopping. Only
the selector lever, accelerator pedal,
and brake pedal are used.
Practice learning the characteristics
of the automatic transmission
vehicle and how to correctly operate
it. When the vehicle is stationary,
remember to keep the brake pedal
firmly pressed, and if necessary,
move the selector lever in the P or
N position and apply the parking
brake.
Creep : With the engine running
and a gear position other than P or
N selected with the selector lever,
power reaches the wheels even
when the accelerator pedal is not
pressed, causing the vehicle to tend
to move.
