Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
246 Driving and Operating
Conversions and
Add-Ons Add-On Electrical
Equipment
{ WarningThe Data Link Connector (DLC) is
used for vehicle service
and Emission Inspection/
Maintenance testing. See
Malfunction Indicator Lamp
(Check Engine Light) 0 122 .
A device connected to the DLC —
such as an aftermarket fleet or
driver-behavior tracking device —
may interfere with vehicle
systems. This could affect vehicle
operation and cause a crash.
Such devices may also access
information stored in the vehicle ’ s
systems. CautionSome electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 0 72 and
Adding Equipment to the
Airbag-Equipped Vehicle 0 72 .

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
262 Vehicle Care 3. Fill the coolant surge tank with
the proper mixture to the
indicated level mark.
4. With the coolant surge tank
pressure cap off, start the
engine and let it run until you
can feel the upper radiator
hose getting hot. Watch out for
the engine cooling fan.
By this time, the coolant level
inside the coolant surge tank
may be lower. If the level is
lower, add more of the proper
mixture to the coolant surge
tank until the level reaches the
indicated level mark.
5. Replace the pressure cap
tightly.
6. Verify coolant level after the
engine is shut off and the
coolant is cold. If necessary,
repeat coolant fill procedure
Steps 1 – 6.
If the coolant still is not at the
proper level when the system
cools down again, see your
dealer. CautionIf the pressure cap is not tightly
installed, coolant loss and engine
damage may occur. Be sure the
cap is properly and tightly
secured.
Engine Overheating The vehicle has several indicators
to warn of the engine overheating.
There is an engine coolant
temperature gauge on the
instrument cluster. See Engine
Coolant Temperature Gauge 0 118 .
The vehicle may also display a
message on the Driver Information
Center (DIC).
If the decision is made not to lift the
hood when this warning appears,
get service help right away. See
Roadside Assistance Program
0 348 .
If the decision is made to lift the
hood, make sure the vehicle is
parked on a level surface. Then
check to see if the engine cooling fan is running. If the engine is
overheating, the fan should be
running. If it is not, do not continue
to run the engine. Have the vehicle
serviced.
CautionDo not run the engine if there is a
leak in the engine cooling system.
This can cause a loss of all
coolant and can damage the
system and vehicle. Have any
leaks fixed right away.
If Steam Is Coming from the
Engine Compartment
{ Warning
Steam and scalding liquids from a
hot cooling system are under
pressure. Turning the pressure
cap, even a little, can cause them
to come out at high speed and
you could be burned. Never turn
the cap when the cooling system,
(Continued)

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
264 Vehicle Care Caution.
Do not use washer fluid that
contains any type of water
repellent coating. This can
cause the wiper blades to
chatter or skip.
.
Do not use engine coolant
(antifreeze) in the
windshield washer. It can
damage the windshield
washer system and paint.
.
Do not mix water with
ready-to-use washer fluid.
Water can cause the
solution to freeze and
damage the washer fluid
tank and other parts of the
washer system.
.
When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
.
Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
(Continued) Caution (Continued) for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or can
be heard all the time when the
vehicle is moving, except when
applying the brake pedal firmly.
{ Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced. CautionContinuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the
proper sequence to torque
specifications. See Capacities and
Specifications 0 341 .
Brake pads should be replaced as
complete sets.
Brake Pedal Travel
See your dealer if the brake pedal
does not return to normal height,
or if there is a rapid increase in
pedal travel. This could be a sign
that brake service may be required.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
Service and Maintenance 335Hoses
Hoses transport fluids and should
be regularly inspected to ensure
that there are no cracks or leaks.
With a multi-point inspection, your
dealer can inspect the hoses and
advise if replacement is needed.
Lamps
Properly working headlamps,
taillamps, and brake lamps are
important to see and be seen on
the road.
.
Signs that the headlamps need
attention include dimming, failure
to light, cracking, or damage.
The brake lamps need to be
checked periodically to ensure
that they light when braking.
.
With a multi-point inspection,
your dealer can check the lamps
and note any concerns. Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
.
Signs of wear may include
steering wheel vibration, bounce/
sway while braking, longer
stopping distance, or uneven
tire wear.
.
As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
.
Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
.
Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For
information on how to clean and
protect the vehicle ’ s interior and
exterior, see Interior Care 0 321 and
Exterior Care 0 317 .

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
Index 373Fuses
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 273
Fuses and Circuit Breakers . . . 273
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 277
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 278
G Garage Door Opener . . . . . . . . . . . 142
Programming . . . . . . . . . . . . . . . . . 142
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 269
Gauges
Engine Coolant
Temperature . . . . . . . . . . . . . . . . .118
Engine Oil Temperature . . . . . . . .118
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Odometer . . . . . . . . . . . . . . . . . . . . . .116
Speedometer . . . . . . . . . . . . . . . . . .116
Tachometer . . . . . . . . . . . . . . . . . . . .116
Trip Odometer . . . . . . . . . . . . . . . . .116
Voltmeter . . . . . . . . . . . . . . . . . . . . . .119
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . .110
General Information
Service and Maintenance . . . . . 326
Towing . . . . . . . . . . . . . . . . . . . . . . . . 234 General Information (cont'd)
Vehicle Care . . . . . . . . . . . . . . . . . . 248
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 96
GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . 347
H Hazard Warning Flashers . . . . . . . 150
Head Restraints . . . . . . . . . . . . . . . . . 40
Headlamps
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 271
Automatic . . . . . . . . . . . . . . . . . . . . . 149
Bulb Replacement . . . . . . . . . . . . 271
Daytime Running
Lamps (DRL) . . . . . . . . . . . . . . . . 149
Flash-to-Pass . . . . . . . . . . . . . . . . . 148
High-Beam On Light . . . . . . . . . . 129
High/Low Beam Changer . . . . . 148
Lamps On Reminder . . . . . . . . . 129
Heated
Rear Seats . . . . . . . . . . . . . . . . . . . . . 51
Steering Wheel . . . . . . . . . . . . . . . 102
Heated and Ventilated Front
Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Heated Mirrors . . . . . . . . . . . . . . . . . . . 31
Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . 185
Heating . . . . . . . . . . . . . . . . . . . . 156, 160 High Voltage Devices and
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 272
High-Beam On Light . . . . . . . . . . . . 129
High-Speed Operation . . . . . . . . . . 289
Hill and Mountain Roads . . . . . . . . 174
Hill Start Assist (HSA) . . . . . . . . . . 200
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
How to Wear Seat Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . . 55
HVAC . . . . . . . . . . . . . . . . . . . . . . 156, 160
I Ignition Positions . . . . . . . . . . . . . . . 181
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 29
Indicator
Pedestrian Ahead . . . . . . . . . . . . 126
Vehicle Ahead . . . . . . . . . . . . . . . . 126
Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . 76
Information
Publication Ordering . . . . . . . . . . 353
Infotainment . . . . . . . . . . . . . . . . . . . . 155
Infotainment System . . . . . . . . . . . . 357
Instrument Cluster . . . . . . . . . 111, 114
Instrument Panel Overview . . . . . . . 5
Interior Rearview Mirrors . . . . . . . . . 32
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
374 Index J Jump Starting - North
America . . . . . . . . . . . . . . . . . . . . . . . 311
K Keyless Entry
Remote (RKE) System . . . . . . . . . . 8
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
L Labeling, Tire Sidewall . . . . . . . . . . 283
Lamps
Courtesy . . . . . . . . . . . . . . . . . . . . . . 151
Daytime Running (DRL) . . . . . . 149
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 151
Exterior Controls . . . . . . . . . . . . . . 146
Exterior Lamps Off
Reminder . . . . . . . . . . . . . . . . . . . 148
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . 154
License Plate . . . . . . . . . . . . . . . . . 271
Malfunction Indicator
(Check Engine) . . . . . . . . . . . . . 122
On Reminder . . . . . . . . . . . . . . . . . 129
Reading . . . . . . . . . . . . . . . . . . . . . . 151
Lane Change Alert (LCA) . . . . . . . 227
Lane Keep Assist (LKA) . . . . . . . . 229
Lane Keep Assist Light . . . . . . . . . 126
Lap-Shoulder Belt . . . . . . . . . . . . . . . 57 LATCH System
Replacing Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . 90
LATCH, Lower Anchors and
Tethers for Children . . . . . . . . . . . . 81
LED Lighting . . . . . . . . . . . . . . . . . . . . 271
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Lighting
Entry . . . . . . . . . . . . . . . . . . . . . . . . . 152
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Illumination Control . . . . . . . . . . . 151
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 271
Lights
Airbag Readiness . . . . . . . . . . . . . 120
Antilock Brake System
(ABS) Warning . . . . . . . . . . . . . . 125
Brake System Warning . . . . . . . 124
Charging System . . . . . . . . . . . . . 122
Check Engine (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . 122
Cruise Control . . . . . . . . . . . . . . . . 130
Door Ajar . . . . . . . . . . . . . . . . . . . . . 130
Electric Parking Brake . . . . . . . . 124
Engine Oil Pressure . . . . . . . . . . 128
Flash-to-Pass . . . . . . . . . . . . . . . . . 148
High-Beam On . . . . . . . . . . . . . . . . 129
High/Low Beam Changer . . . . . 148
Lane Keep Assist . . . . . . . . . . . . . 126 Lights (cont'd)
Low Fuel Warning . . . . . . . . . . . . 129
Seat Belt Reminders . . . . . . . . . . 120
Security . . . . . . . . . . . . . . . . . . . . . . 129
Service Electric Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . 125
Sport Mode . . . . . . . . . . . . . . . . . . . 125
StabiliTrak OFF . . . . . . . . . . . . . . . 127
Tire Pressure . . . . . . . . . . . . . . . . . 128
Tow/Haul Mode . . . . . . . . . . . . . . . 125
Traction Control System
(TCS)/StabiliTrak . . . . . . . . . . . . 127
Traction Off . . . . . . . . . . . . . . . . . . . 127
Locks
Automatic Door . . . . . . . . . . . . . . . . . 19
Delayed Locking . . . . . . . . . . . . . . . . 19
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Lockout Protection . . . . . . . . . . . . . . 20
Power Door . . . . . . . . . . . . . . . . . . . . . 19
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Loss of Control . . . . . . . . . . . . . . . . . 168
Low Fuel Warning Light . . . . . . . . . 129
Lower Anchors and Tethers
for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 81
Lumbar Adjustment . . . . . . . . . . . . . . 42
Front Seats . . . . . . . . . . . . . . . . . . . . . 42

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13527524) - 2020 - CRC - 4/10/19
Index 375M Maintenance
Records . . . . . . . . . . . . . . . . . . . . . . 339
Maintenance and Care
Additional . . . . . . . . . . . . . . . . . . . . . 334
Maintenance Schedule . . . . . . . . . 328
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . 337
Malfunction Indicator Lamp . . . . . 122
Manual Mode . . . . . . . . . . . . . . . . . . . 196
Massage . . . . . . . . . . . . . . . . . . . . . . . . 48
Memory Seats . . . . . . . . . . . . . . . . . . . 43
Messages
Engine Power . . . . . . . . . . . . . . . . 136
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 136
Vehicle Speed . . . . . . . . . . . . . . . . 137
Mirror
Rear Camera . . . . . . . . . . . . . . . . . . . 32
Mirrors
Automatic Dimming . . . . . . . . . . . . . 31
Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 32
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 30
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 30
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 31
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Tilt in Reverse . . . . . . . . . . . . . . . . . . 31
Mirrors, Interior Rearview . . . . . . . . 32 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Driver Control . . . . . . . . . . . . . . . . . 202
Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 290
N Navigation
Connected Services . . . . . . . . . . 366
New Vehicle Break-In . . . . . . . . . . . 181
O Odometer . . . . . . . . . . . . . . . . . . . . . . . 116
Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Off-Road . . . . . . . . . . . . . . . . . . . . . . . 169
Driving . . . . . . . . . . . . . . . . . . . . . . . . 169
Recovery . . . . . . . . . . . . . . . . . . . . . 168
Oil
Engine . . . . . . . . . . . . . . . . . . . . . . . . 253
Engine Oil Life System . . . . . . . 255
Pressure Light . . . . . . . . . . . . . . . . 128
Older Children, Restraints . . . . . . . 74
Online Owner Center . . . . . . . . . . . 347
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 357
OnStar Additional
Information . . . . . . . . . . . . . . . . . . . . 360
OnStar Emergency . . . . . . . . . . . . . 359
OnStar Overview . . . . . . . . . . . . . . . 358
OnStar Security . . . . . . . . . . . . . . . . 360 Outlets
Power . . . . . . . . . . . . . . . . . . . . . . . . 106
Overheating, Engine . . . . . . . . . . . . 262
Overview
Instrument Panel . . . . . . . . . . . . . . . . 5
P Park
Shifting Out of . . . . . . . . . . . . . . . . 187
Park Assist . . . . . . . . . . . . . . . . . . . . . 216
Parking
Brake and P (Park)
Mechanism Check . . . . . . . . . . 267
Extended . . . . . . . . . . . . . . . . . . . . . 189
Over Things That Burn . . . . . . . 189
Parking or Backing
Assistance Systems . . . . . . . . . . 216
Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . 121
Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Passenger Sensing System . . . . . 68
Pedestrian Ahead Indicator . . . . . 126
Perchlorate Materials
Requirements, California . . . . . . 249
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 137
