2019 YAMAHA YXZ1000R technical specifications

EBU38420
Read this manual carefully before operating this vehicle. This manual should stay with this ve-
hicle if it is sold.
ANSI ROHVA 1 - 2016General Manager
Recreational Vehicle Development Division
PF Model Development Section
PF Model Unit
YAMAHA MOTOR CO., LTD.
17 ,April, 2018
We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product
(Make, model)2014/30/EU
(Title and/or number and date of issue of the other Directives of EEC)
(If applicable)YAMAHA MOTOR EUROPE N.V.
Koolhovenlaan 101, 1119 NC Schiphol-Rijk, The Netherlands
Signature
Akihiro Tsuzuki
Date of Issue
(If applicable)and to the other relevant Directives of EEC to which this declaration applies, conforms to the essential health and
safety requirements of Directive 2006/42/EC
To effect correct application of the essential health and safety requirements
stated in the Directives of EEC, the following-standards and/or technical
specifications were consulted:
(Title and/or number and date of issue of standards and/or specifications)
Authorized Representative
EC Declaration of Conformity
conforming to Directive 2006/42/EC
Manufacturer
YAMAHA MOTOR MANUFACTURING CORPORATION OF AMERICA
1000 GA Highway 34 East, Newnan, Georgia 30265-1320, U.S.A.YXZ1000ETS (YXZ10YESK) (5Y4AN30W0J0500101–)
YXZ1000ETS (YXZ10YESK) (5Y4AN38W0J0500101–)
YXZ1000ET (YXZ10YEXK) (5Y4AN34W0J0500101–)
UB5H7AE0.book Page 1 Wednesday, July 4, 2018 1:37 PM

10-1
10
EBU32750
SPECIFICATIONS
Dimensions:Overall length:3147 mm (123.9 in)
Overall width: 1626 mm (64.0 in)
Overall height:
1751 mm (68.9 in) [YXZ10YESK (SE model),
YXZ10YEXK]
1773 mm (69.8 in) [YXZ10YESK (LE model)]
Wheelbase: 2300 mm (90.6 in)
Ground clearance:
342 mm (13.5 in)
Minimum turning radius: 6.0 m (19.69 ft)
Maximum water depth: 40 cm (16 in)Weight:Technical permissible mass (Maximum load + curb weight):1065.0 kg (2348 lb)
Curb weight: 691.0 kg (1523 lb) (YXZ10YEXK)
709.0 kg (1563 lb) [YXZ10YESK (SE model)]
729.0 kg (1607 lb) [YXZ10YESK (LE model)]
Loading:Maximum loading limit:336.0 kg (741 lb)
(Total weight of operator, passenger, cargo, and
accessories)Noise and vibration level:Noise level (77/311/EEC): 83.0 dB(A) at 4250 r/min [YXZ10YESK (SE model),
YXZ10YEXK]
87.0 dB(A) at 4250 r/min [YXZ10YESK (LE model)]
Uncertainty of measurement:
3.0 dB(A)
A-weighted sound power level: 100.0 dB(A) at 4250 r/min
Uncertainty of measurement: 3.0 dB(A)
Vibration on seat (EN1032, ISO5008):
Will not exceed 0.5 m/s²
Uncertainty of measurement: 0.1 m/s²
Vibration on handle (EN1032, ISO5008): Will not exceed 2.5 m/s²
Uncertainty of measurement:
0.5 m/s²Engine:Combustion cycle:4-stroke
